Mooer S10 User manual

Precautions
Please Read Carefully Before Proceeding
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.
FC C certification
Connections
Always turn off the power and all other equipment before connecting
or disconnecting. This will help prevent malfunction and damage to
any of the devices. Make sure to unplug all connection cables and
power cords before moving this unit.
Interference with other electrical devices and Cleaning：
Radios and televisions placed nearby may experience reception
interference. Operate this unit at a suitable distance from radios and
televisions.
Clean only with a soft, dry cloth.
Handling：
Do not apply excessive force to the switches or controls.
Do not let paper, metal, or other objects into this unit.
Take care not to drop the unit, and do not subject it to shock or
excessive pressure.
To avoid deformation, discoloration, or other serious damage, do not
expose this unit to the following conditions：
Direct sunlight
Heat sources
Magnetic fields
Extreme temperature or humidity
Excessively dusty or dirty location
High humidity or moisture
Strong vibration or shock
Rechargeable professional Battery
pedalboard power supply
Introduction
Main Features
Mooer Power Bank S10 is a professional pedal board power supply
loaded with a high capacity, rechargeable lithium battery. Now you
can take your pedal board anywhere without the need for an
electrical outlet and have the cleanest, most pure and noise free
power possible.
10 power outputs: 7 x 9V / 1 x 12V / 1 x 15V / 1 x 18V
2A total maximum output
20000mAh capacity
High quality, long life Lipo power cells (can be recycled more than
50,000 times)
Overcurrent protection
Supplied with special adapter for charging

Specifications
Power input: 25.2V, 2A centre pin negative
Power output: 7 x 9V / 1 x 12V / 1 x 15V / 1 x 18V
Operating current: 2A total maximum output
size:135mm(D)X75mm(W)X45.6mm (H)
weight:758g
Accessories: power adapter, power cable, user manual
*Notes：Any specification’s update will not be amended in this manual.
Part No:620010619
Charging Procedure
Ensure that the S10 power bank's power switch is in the off position
Connect the included A/C charging adapter to the power input on
the S10
Connect it to the A/C outlet
The power charging light will illuminate red to indicate that the
battery is charging and the LE D display will flash and show the
current capacity state of the battery. When the battery is fully
charged the L ED display will stop flashing and show 100. You
can now disconnect the charging adapter.
MOOER AUDIO CO.,LTD
www.mooeraudio.com
