Morel OCTAVE Series OCTAVE CENTER User manual

OCTAVE CENTER
OWNERS MANUAL

Congratulations on acquiring Morel’s Octave Center.
We encourage you to read this manual in order to understand the key issues
and important elements that led us to design and develop the Octave Center.
The information in this manual will help you get the best possible performance
out of your system.
If you have any questions, please contact your Morel dealer.
You can also visit our website at www.morelhifi.com
We are happy you have become a part of the Morel family and hope you will
enjoy the rich listening experience of the Octave.
The technological innovation we employed in the Octave Center helps to
optimize accuracy and control as well as get the best dispersion over a wide
listening area.
The dynamic reach and power handling of the Octave Center allows it to cope
with the most demanding sound effects and music and capture the details of
even the softest whisper.
The Octave Center consists of three 5 ¼”(130 mm) woofer units and a wide-
range tweeter. The construction is based on the integration of the Octave
system’s drive units in the center speaker. The center speaker has the same
sound characteristics as an Octave speaker with a more powerful bass impact
and higher power handling capability. The construction of the tweeter, located
above the woofer, serves to avoid horizontal dispersion problems that are
so typical to many center speakers.
The Octave Center acoustical design is made for high definition dialogue in an
audio-visual system and perfect for a non-compromise music reproduction.
The unusual drive unit configuration design is made as two separate sections,
divided into three individual cabinets. The central part is the bass midrange
unit with the tweeter on top, for full range performance. The two left and
right woofers operate in a common bass reflex loaded cabinet, enhancing the
low frequency bass notes.
The Octave Center is magnetically shielded therefore it can be placed close
to a TV screen, either above or below it, without causing any disturbances.
OCTAVE CENTER

Placement options
2
Min 50cm Min 50cm
Plasma screen
Projector
1
Option A
Option B

3-way 4 units, Full range center speaker with low magnetic stray field
MDF tricoTM polimer, coated cabinet with 3 separate acoustic
chambers one for each drive unit
Double port bass reflex for bass chamber/sealed for bass midrange & tweeter
213/4“x 93/4“ 123/4“(550 x 247 x 325mm)
Woofers- two 51/4“(130mm) rear-vented. Double magnet motor.
Bass midrange- one 51/4“(130mm) rear vented hybrid motor. Both feature one
piece intergrated dome and surround cone, made of damped polymer composite.
3“ (75mm) Aluminum Hexatech voice coil using Morel external voice coil technology(EVC)
Tweeter- MID/HIGH frequency unit, low resonance soft dome, Acuflex coated,
vented double magnet Neodymium motor. 11/8“(28mm) Aluminum Hexatech voice coil
and Morel’s EVC technology. All units are shielded with low magnetic stray field.
20 - 30,000Hz (40-18,000Hz -1.5dB)
4 Ohm
300W RMS
1500W 10m/sec
88 dB
36 lbs (16 Kgs)
Within 1.5 dB - 18,000Hz
Horizontal: over 600
Vertical: over 200
SPECIFICATIONS
www.morelhifi.com
SPECIFICATIONS OCTAVE CENTER
Type
Construction
Acoustical Loading
Dimensions (W x H x D)
Drive Units
Frequency Response
Nominal Impedance
Nominal Power Handling
Peak Power Handling
Sensitivity 1 W/1 M
Weight
Dispersion
+
