MORLEY-IAS MI-LZR User manual

M200-01-00 4 I56-2155-003R
©2005 System Sensor
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful inter-
ference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Laser Safety Information
This smoke detector does not produce any hazardous laser
radiation and is certified as a Class 1 laser product under
the U.S. Department of Health and Human Services (DHHS)
Radiation Performance Standard according to the Radiation
Control for Health and Safety Act of 1968.
Any radiation emitted inside the smoke detector is com-
pletely within the protective housings and external covers.
The laser beam cannot escape from the detector during any
phase of operation.
The Center of Devices and Radiological Health (CDRH) of
the U.S. Food and Drug Administration implemented regu-
lations for laser products on August 2, 1976. These regula-
tions apply to laser products manufactured after August 1,
1976. Compliance is mandatory for products marketed in
the United States.
CAUTION
Use of controls, adjustments, or performance of procedures
other than those specified in this manual may result in
hazardous radiation exposure.
Special Note Regarding Smoke Detector Guards
Smoke detectors are not to be used with detector guards
unless the combination has been evaluated and found suit-
able for that purpose.
Please refer to insert for the Limitations of Fire Alarm Systems
M200-01-00 1 I56-2155-003R
MI-LZR Intelligent Laser Smoke Sensor
INSTALLATION AND MAINTENANCE INSTRUCTIONS
Charles Avenue, Burgess Hill
West Sussex, RH15 9UF
Before Installing
This sensor must be installed in compliance with the con-
trol panel system installation manual. The installation must
meet the requirements of the Authority Having Jurisdiction
(AHJ). Sensors offer maximum performance when installed
in compliance with EN54 and applicable local codes.
General Description
Model MI-LZR is a plug-in type smoke sensor that uses
a laser based sensing chamber. The sensor uses analog-
addressable communications to transmit smoke density
and other information to the control panel. Rotary-decade
switches are provided for setting the sensor’s address. Two
LEDs on the sensor are controlled by the panel to indicate
sensor status. An output is provided for connection to an
optional remote LED annunciator (P/N RA400Z).
This detector requires compatible addressable commu-
nications to function properly. Connect this sensor to
listed-compatible control panels only.
Spacing
Morley recommends spacing sensors in compliance with
EN54 and applicable local codes. In low air flow applica-
tions with smooth ceilings, space sensors 30 feet apart. For
specific information regarding sensor spacing, placement,
and special applications, refer to EN54.
Specifications
Operating Voltage Range: 15 to 32 VDC
Standby Current: 330µA@ 24 VDC (one communication every 5 sec. with LED blink enabled)
Max. Alarm Current (LED on:) 6.5 mA @ 24 VDC
Operating Humidity Range: 10% to 93% Relative Humidity, noncondensing
Operating Temperature Range: –10° to 55°C
Height: 1.7 inches (43 mm)
Diameter: 4.1 inches (104 mm) installed in B501 Base
Weight: 5.0 oz. (142 g)
Wiring Instructions
All wiring must be installed in compliance with the
National Electrical Code, applicable local codes, and any
special requirements of the Authority Having Jurisdiction.
Proper wire gauges should be used. The installation wires
should be color-coded to limit wiring mistakes and ease
system troubleshooting. Improper connections will prevent
a system from responding properly in the event of a fire.
Remove power from the communication line before
installing sensors.
All wiring must conform to applicable local codes, ordi-
nances, and regulations.
1. Wire the sensor base (supplied separately) per the wir-
ing diagram, see Figure 1.
2. Set the desired address on the sensor address switches,
see Figure 2.
3. Install the sensor into the sensor base. Push the sensor
into the base while turning it clockwise to secure it in
place.
4. After all sensors have been installed, apply power to the
control unit and activate the communication line.
5. Test the sensor(s) as described in the TESTING section
of this manual.
0832
0832-CPD-0195
www.acornfiresecurity.com
www.acornfiresecurity.com

M200-01-00 2 I56-2155-003R
CAUTION
Dust covers provide limited protection against airborne dust
particles during shipping. Dust covers must be removed
before the sensors can sense smoke. Remove sensors prior
to heavy remodeling or construction.
Testing
Before testing, notify the proper authorities that the system
is undergoing maintenance, and will temporarily be out of
service. Disable the system to prevent unwanted alarms.
All sensors must be tested after installation and periodi-
cally thereafter. Testing methods must satisfy the Authority
Having Jurisdiction (AHJ). Sensors offer maximum perfor-
mance when tested and maintained in compliance with
EN54 and applicable local codes.
The sensor can be tested in the following ways:
A. Functional: Magnet Test (P/N M02-04-01 or M02-09-00)
This sensor can be functionally tested with a test mag-
net. The test magnet electronically simulates smoke in
the sensing chamber, testing the sensor electronics and
connections to the control panel.
1. Hold the test magnet in the magnet test area as shown
in Figure 3.
2. The sensor should alarm the panel.
Two LEDs on the sensor are controlled by the panel
to indicate sensor status. Coded signals, transmitted
from the panel, can cause the LEDs to blink, latch
on, or latch off. Refer to the control panel technical
documentation for sensor LED status operation and
expected delay to alarm.
C0100-00
32
1
32
1
+
–
–
+
OPTIONAL RETURN LOOP
REMOTE ANNUNCIATOR
+ –
B. Smoke Entry: Aerosol Generator (Gemini 501)
The GEMINI model 501 aerosol generator can be used
for smoke entry testing. Set the generator to represent
4%/ft. to 5%/ft. obstruction as described in the GEMINI
501 manual. Using the bowl shaped applicator, apply
aerosol until the panel alarms.
A sensor that fails any of these tests should be cleaned
as described under CLEANING, and retested. If the
sensor fails after cleaning, it must be replaced and returned
for repair.
When testing is complete, restore the system to nor-
mal operation and notify the proper authorities that the
system is back in operation.
Figure 1. Wiring diagram:
M200-01-00 3 I56-2155-003R
C0169-00
C0170-00
Cleaning
It is recommended that the detector be removed from
its mounting base to facilitate cleaning. The detector is
cleaned as follows:
NOTE: Before removing the detector, notify the proper
authorities that the smoke detector system is
undergoing maintenance and will be temporarily
out of service. Disable the zone or system undergo-
ing maintenance to prevent unwanted alarms.
1. Remove the detector cover by prying away the four
side tabs with a small-bladed screwdriver, and then
pulling the cover from the base.
2. Vacuum the screen carefully without removing it. If
further cleaning is required continue with Step 3, oth-
erwise skip to Step 7.
3. Remove the screen/chamber cover assembly by pull-
ing it straight out (see Figure 4).
4. Clean the chamber by vacuuming or blowing out dust
and particles.
5. Replace the sensing chamber cover, aligning the arrow
on the top with arrow on the printed circuit board.
6. To replace the screen, place it over the chamber
assembly, turning it until it snaps into place.
7. Replace the cover using the LEDs to align the cover
and then gently pushing it until it locks into place.
8. Reinstall the detector.
9. Test the detector as described in TESTING.
10. Reconnect disabled circuits.
11. Notify the proper authorities that the system is back
on line.
C0146-00
Figure 2. Rotary decade address switches:
Figure 3. Test magnet position:
tenS oneS
9
8
7
6
5
4
3
210
9
8
7
6
5
4
3
210
D
N
T
N
I
A
P
T
O
O
LED STATUS
INDICATORS
TEST
MAGNET
PAINTED
SURFACE
PAINTED
SURFACE
TEST
MAGNET
MAGNET TEST
MARKER
Figure 4. Sensor assembly:
CAUTION
Do not loop wire under terminal 1 or 2. Break
wire run to provide supervision of connection.
