MORLEY ANALOG MULTI FX User manual

Model AFX-1
Authentic All Analog Multi FX with Switchless Classic Wah,
Vintage Dual Distortion with Hi Gain, Stereo Chorus and Echo.
No Programming or Complicated Menus. Plug In and Play!
Owners Manual
I. WARRANTY
A. Your Morley® AFX-1 is warranted to be free of any defects in materials and workmanship if used under normal operating
conditions for one year from date of purchase, subject to the limitations described below. This warranty is not transferable under
any circumstance.
B. PLEASE NOTE: In order to validate your warranty, save your dated purchase receipt. You will need it to get service.
C. If the AFX-1 Malfunctions in the first 12 month as a result of faulty materials or workmanship, Morley® will repair the defect(s)
or replace the pedal, at its sole discretion. If original materials are no longer available, Morley® reserves the right to use materials
regularly utilized at the time of repair. If replacement of customer’s pedal is deemed necessary by our Service Department,
Morley® will replace the pedal with one of the same.
D. This warranty covers the cost of both labor and materials on any repair deemed necessary by our Service Department for the
one year. Only Morley® Service Department may perform warranty service and any service performed by unauthorized persons
will void this warranty. Morley® shall not be held liable for any and all defects or damage caused by services performed by
unauthorized persons.
II. THIS WARRANTY IS SUBJECT TO THE FOLLOWING LIMITATIONS AND EXCLUSIONS:
The following items are not covered by this warranty:
A. Any pedal whose serial number is missing or has been altered or tampered with in any manner.
B. Any pedal that has been modified from original design.
C. Any pedal whose purchase receipt has been falsified or altered.
D. Any pedal upon which any unauthorized repair or service has been performed.
E. Normal wear and tear on cosmetic aspects of pedal: powder coating, screen printing, treadle rubber, knobs and/or packaging.
F. Subjective issues such as tonal characteristics.
G. Damage caused by negligence or improper use.
H. Damage caused by accidents deemed Acts of God: fires, floods, etc…
I. Shipping damages of any kind.
J. Freight charges to Morley® service center.
K. Any and all charges if no problem is found at time of repair/inspection.
L. Any and all charges incurred from priority service requests (Rush Service) or priority shipping for replacement parts or return
of customer’s merchandise.
III. HOW TO OBTAIN WARRANTY SERVICE
A. If you experience any malfunction that is covered under Morley® Warranty, please contact Morley® Service Department at
[email protected].
IV. RETURNING YOUR PEDAL FOR WARRANTY SERVICE
A. Owner is responsible for all freight & insurance costs to ship the pedal to Morley® Service Department. Owner must contact
Morley to receive and RA # (Return/Repair Authorization Number) to return any Morley pedal. RA # must be clearly marked on
the outside of the package being returned to Morley®. No pedal may be returned to Morley® and delivery will not be accepted
without such prior authorization.
B. After the returned pedal is inspected upon its arrival, Morley Service Department will advise the Owner of the approximate
date of completion. The repaired pedal will be returned to the Owner freight prepaid.
V. WARRANTY SERVICE:
A. Only Morley Service Department may perform warranty service and any service performed by anyone other than Morley will
void this warranty. Morley shall not be held liable for any and all defects or damage caused by services performed by unautho-
rized persons.
B. PLEASE NOTE: Morley does not offer repair service of any kind other than warranty repair service. If your pedal needs any
service or maintenance that is not covered under warranty, you should contact the Morley Dealer where the pedal was
purchased. For a list of authorized Morley Dealers and Distributors, please visit our website at www.morleyproducts.com.
VI. LIABILITY
A. THE WARRANTIES AND REMEDIES SET FORTH IN THIS SECTION ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES WHETHER STATUTORY, EXPRESS, OR IMPLIED (INCLUDING ALL WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE AND ALL WARRANTIES ARISING FROM COURSE OF DEALING OF USAGE
OR TRADE) AND WHETHER THE CLAIMS OF CUSTOMER ARE BASED IN CONTRACT, TORT (INCLUDING NEGLIGENCE
OR STRICT LIABILITY), OR UNDER ANY WARRANTY, OR OTHERWISE, NOR SHALL M-WAVE BE LIABLE TO CUSTOMER
FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL LOSS OR DAMAGE WHATSOEVER, OR FOR LOSS
OF OR DAMAGE TO THE CUSTOMER'S FACILITIES, LOSS OF USE OF EQUIPMENT LOSS OF PROFITS OR REVENUES
OR THE LOSS OR USE THEREOF, OR CLAIMS OF CUSTOMER. IN NO EVENT SHALL THE TOTAL LIABILITY OF MORLEY,
WHETHER IN CONTRACT, IN TORT (INCLUDING NEGLIGENCE AND STRICT LIABILITY), UNDER WARRANTY, OR
OTHERWISE, EXCEED, AND CUSTOMER WAIVES AND WILL REQUIRE ITS INSURERS TO WAIVE ALL RIGHTS OF
RECOVERY AGAINST MORLEY FOR ANY LIABILITIES IN EXCESS OF, THE PRICE PAID TO MORLEY UNDER
THE AGREEMENT.
VII. FOR MORE INFORMATION:
A. Write: Morley Service Department 256A S Washington Street Carpentersville, IL 60110
B. Email: [e-mail]
C. Online: www.morleyproducts.com
Page 3
For Online Owners Manual, Set Up Tips
and Videos, Scan QR Code

Thank you for purchasing this Morley® All Analog
Multi-FX. We hope you enjoy playing it as much as we
enjoyed making it.
POWER REQUIREMENTS
Your Morley® AFX-1 is designed to be powered by a Truetone One Spot power
supply; 9V 1700mA Center Polarity Negative. The adapter is included with the
AFX-1. Use of any other brand adapter is not recommended. The AFX-1 does NOT
have a battery option.
FEATURES
Optical & Switchless Wah
Classic Wah Tones
Analog Hi-Gain Distortion
Pre/Post Gain
High, Mid, Low Tone Controls
Standard or Hi-Gain Mode with Boost
Smooth Analog Chorus
Rate and Depth Controls
Mono or Stereo Mode
Analog Echo Slapback to Hall
Echo, Repeat and Mix Controls
OTHER COOL FEATURES:
Custom Buffer Circuit
Mono & Stereo Outputs
FX Loop
Glow-in-the-Dark Treadle Grip on Wah
Unique LED Indicators for Each Mode
Power Adapter Included
Proudly American Made
Cold Rolled Steel Housing
Custom Hand-Crafted Finish
12.5” Length x 8” Width x 2.75” Height
5 lbs
CLASSIC WAH
1. SWITCHLESS WAH: Simply step on to engage Wah and step off to go to bypass.
2. OPTICAL WAH: No more pots to get scratchy or replace.
3. CLASSIC WAH TONES: Enjoy the traditional Wah tones of our Morley Classic Wah.
4. LED INDICATION: Red LED lights when in Wah mode.
DIAMOND DISTORTION
5. DISTORTION SWITCH: Turns on/off Distortion Effect.
6. LED INDICATION: Blue LED Lights when in Distortion mode.
7. PRE KNOB: Controls the Input Gain, this determines the amount of distortion.
8. POST KNOB: Controls the Output Gain, this acts as the Distortion Level.
9. LOW EQ: Controls the lower frequencies of the Distortion.
10. MID EQ: Controls the middle frequencies of the Distortion.
11. HIGH EQ: Controls the higher frequencies of the Distortion.
12. HI GAIN SWITCH: Turns on/off Hi Gain Distortion Mode.
13. LED INDICATION: Green LED lights when in Hi Gain mode.
14. HI GAIN KNOB: Controls amount of Saturation in Hi Gain Mode.
CRYSTAL CHORUS
15. CHORUS SWITCH: Turns on/off Chorus Effect.
16. LED INDICATION: Orange LED lights when in Chorus mode. Also Orange LED
blinks in time with Chorus Rate.
17. RATE KNOB: Controls the speed of the Chorus.
18. DEPTH KNOB: Controls the amount of pitch-shifting and delay in the Chorus.
NOTE: The full Chorus signal is sent to both Left / Mono and Right / Stereo Jacks.
EMERALD ECHO
19. ECHO SWITCH: Turns on/off Echo Effect.
20. LED INDICATION: Yellow LED Lights when in Echo mode.
21. ECHO KNOB: Controls the Echo Time from Slapback to Hall.
22. REPEAT KNOB: Controls the amount of repeats.
23. MIX KNOB: Controls the mix of original “dry” signal and echoed “wet” signal.
NOTE: The full Echo Signal is sent to the Left / Mono jacks. When using Echo in
Stereo Mode, Echo will be present on Left / Mono Jack (”wet”) but Right /
Stereo Jack will be without Echo (”dry”). This creates a wide sonic spectrum
that make the sound seem Larger Than Life!
OTHER FEATURES
24. PREMIUM BUFFER: Ensures no signal loss or tone change even when using long
cables. Buffer is always engaged.
25. MONO / STEREO OUTPUTS: Use in Mono by using Left Output Jack or use in
Stereo using both Left and Right Jacks.
26. FX LOOP: Place other effects between the Distortion and the Chorus.
27. TREADLE GLOW: Patented Glow-in-the-Dark Treadle Grip allow you to always
locate your pedal, even on a dark stage.
28. MADE IN THE USA: Designed and Built in Carpentersville Illinois.
29. STEEL HOUSING: Built like a tank.
30. CUSTOM HAND-CRAFTED FINISH: Each pattern was created by hand one by one
for a unique and awesome looking design.
1
2
3
4
6 5
8 14 7
11 10 9
13 1216 15
18
17
20 19
22
21
23
24 25 26 27 28
29 30
Page 1 Page 2
See Page 2 for Feature and Control Explanations
