Morris W58243BIFF User manual

ΨΥΓΕΙΟ ENTOIΧΙΖΟΜΕΝΟ / BUILT-IN REFRIGERATOR
ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ / USER MANUAL
W58243BIFF

EN - 2
Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materia
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly

EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS ............................................................................... 4
1.1 General Safety Warnings ...............................................................................................4
11.1 During Usage ................................................................................................................8
1.2 Installation warning .......................................................................................................9
1.3 During Usage..................................................................................................................9
2 DESCRIPTION OF THE APPLIANCE.......................................................... 11
2.1 Dimensions ...................................................................................................................12
3 USING THE APPLIANCE .............................................................................. 13
3.1 Information on the Frost Free Technology ....................................................................13
3.2 Thermostat Settin .......................................................................................................13
3.3 Temperature Settings Warnings ...................................................................................13
3.4 Accessories ..................................................................................................................14
3.4.1 Ice Tray (In some models) .......................................................................................14
3.4.2 The Bottle Holder (In some models)........................................................................14
3.4.3 The Fresh Dial (In some models) ............................................................................14
3.4.4 Adjustable Door Shelf (In some models) .................................................................15
3.4.5 Maxi-fresh preserver (If available) .............................................................................15
4 FOOD STORAGE........................................................................................... 15
4.1 Refrigerator Compartment ............................................................................................15
4.2 Freezer Compartment ..................................................................................................16
5 CLEANING AND MAINTENANCE................................................................ 20
5.1 Defrostin .....................................................................................................................20
6 SHIPMENT AND REPOSITIONING.............................................................. 20
6.1 Transportation and Changing Positioning ....................................................................20
7 BEFORE CALLING AFTER-SALES SERVICE ........................................... 20
8 TIPS FOR SAVING ENERGY........................................................................ 22
9 TECHNICAL DATA......................................................................................... 22
10 INFORMATION FOR TEST INSTITUTES .................................................. 22
11 CUSTOMER CARE AND SERVICE............................................................ 23

EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be fixed in
accordance with the instructions.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and

EN - 5
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open flames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance
• This appliance is intended to be used in household
and domestic applications such as:
–staff kitchen areas in shops, offices and ot
working environments.
–farm houses and by clients in hotels, motels and
other residential type environments.
–bed and breakfast type environments;
–catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualified persons in order to avoi
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 13 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.

EN - 6
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are
not expected to use appliances safely unless
continuous supervision is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualified persons, in order to avoid a hazard
• This appliance is not intended for use at altitudes
exceeding 2000 m.

EN - 7
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a significant increase of the temperature in th
compartments of the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems
• Store raw meat and fish in suitable containers in th
refrigerator, so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dr , and leave the
door open to prevent mould developing within the
appliance.

EN - 8
Electrical information (For UK type plug)
Warning! This appliance must be earthed.
The mains lead of this appliance has been fitted with a specially earthed plug
Important: Do not use the appliance without the fuse cover in position. Should
the fuse need to be replaced, it must be replaced with a 13A fuse, ASTA approved to
BS1362.
The plug must be used with a specially earthed socket of 13 amperes. If there is no such
socket in your house, please have one installed by an authorised electrician.
The mains lead of this appliance has been fitted with a BS 1363 13A fused plug. To
change a fuse in this type of plug, follow the steps below:
1. Remove the fuse cover and fuse.
2. Fit replacement 13A fuse, ASTA approved to BS 1362 type, into the fuse cover.
3. Replace fuse cover.
11.1 During Usage
• Do not connect your fridge freezer to the mains electricity supply using an extension
lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to play with the
appliance or hang off the doo .
• Never touch the power cord/plug with wet hands. This may cause a short circuit or
electric shock.
• Do not place glass bottles or cans in the ice-making compartment as they will burst when
the contents freeze.
• Do not place explosive or flammable material in your fridge. Place drinks with hig
alcohol content vertically in the fridge compartment and make sure their tops are tightly
closed.
• When removing ice from the ice-making compartment, do not touch it. Ice may cause
frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes
immediately after they are removed from the ice-making compartment.
• Do not re-freeze thawed frozen food. This may cause health issues such as food
poisoning.

EN - 9
1.2 Installation warnings
Before using your fridge freezer for the first
time, please pay attention to the following
points:
• The operating voltage for your fridge
freezer is 220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your fridge freezer may have an odour
when it is operated for the first time. This
is normal and the odour will fade when
your fridge freezer starts to cool.
• Before connecting your fridge freezer,
ensure that the information on the data
plate (voltage and connected load)
matches that of the mains electricity
supply. If in doubt, consult a qualifie
electrician.
• Insert the plug into a socket with an
efficient ground connection. If the sock
has no ground contact or the plug does
not match, we recommend you consult a
qualified electrician for assistance
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located on
the inside left of the appliance).
• We do not accept responsibility for any
damages that occur due to ungrounded
usage.
• Place your fridge freezer where it will not
be exposed to direct sunlight.
• Your fridge freezer must never be used
outdoors or exposed to rain.
• Your appliance must be at least 50 cm
away from stoves, gas ovens and heater
cores, and at least 5 cm away from
electrical ovens.
• If your fridge freezer is placed next to a
deep freezer, there must be at least 2
cm between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of fridge
freezer with lace. This will affect th
performance of your fridge freezer.
• Clearance of at least 150 mm is required
at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your fridge freezer, wipe all
parts with a solution of warm water and
a teaspoon of sodium bicarbonate. Then,
rinse with clean water and dry. Return all
parts to the fridge freezer after cleaning.
• The installation procedure into a kitchen
unit is given in the installation manual.
This product is intended to be used in
proper kitchen units only.
1.3 During Usage
• Do not connect your fridge freezer to
the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play with
the appliance or hang off the doo .
• Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
• Do not place glass bottles or cans in the
ice-making compartment as they will
burst when the contents freeze.
• Do not place explosive or flammabl
material in your fridge. Place drinks with
high alcohol content vertically in the
fridge compartment and make sure their
tops are tightly closed.
• When removing ice from the ice-making
compartment, do not touch it. Ice may
cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or ice cubes
immediately after they are removed from
the ice-making compartment.
• Do not re-freeze thawed frozen food. This

EN - 10
may cause health issues such as food
poisoning.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause an
accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of your old appliance
The symbol on the product or on
its packaging indicates that this
product may not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling
of this product. For more detailed
information about recycling of this product,
please contact your local city office, you
household waste disposal service or the
shop where you purchased the product.
Packaging and the Environment
Packaging materials protect
your machine from damage that
may occur during transportation.
The packaging materials are
environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual
carefully before installing and using your
appliance. We are not responsible for the
damage occurred due to misuse.
• Follow all instructions on your appliance
and instruction manual, and keep this
manual in a safe place to resolve the
problems that may occur in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specified purposes. It is not suitable fo
commercial or common use. Such use
will cause the guarantee of the appliance
to be cancelled and our company will not
be responsible for any losses incurred.
• This appliance is produced to be used
in houses and it is only suitable for
cooling / storing foods. It is not suitable
for commercial or common use and/or
for storing substances except for food.
Our company is not responsible for any
losses incurred by inappropriate usage of
the appliance.

EN - 11
2 DESCRIPTION OF THE
APPLIANCE
1
2
3
4
5
6
7
8
9
10
11
B
12
13
14
15
A
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
A) Refrigerator compartment
B) Freezer compartment
1) Thermostat knob
2) Lamp cover
3) Turbo fan *
4) Wine rack *
5) Refrigerator shelves
6) Crisper cover
7) Crisper
8) Freezer upper flap / Drawe
9) Freezer drawers
10) Ice box tray
11) Freezer glass shelves*
12) Bottle shelf
13) Adjustable door shelf * / Door shelf
14) Door shelves
15) Egg holder
*In some models
General notes:
Fresh Food Compartment (Fridge): Most
efficient use of energy is ensured in th
configuration with the drawers in the bottom
part of the appliance, and shelves evenly
distributed, position of door bins does not
affect energy consumption
Freezer Compartment (Freezer): Most
Efficient use of energy is ensured in th
configuration with the drawers and bins are
on stock position.

EN - 12
2.1 Dimensions
* 1770 - 1778 for metal top cover
min 200 cm2min 40 mm
560 - 570 mm
max 2100 mm
1770 - 1790 mm
560 mm
(recommended)
min. 550 mm
545 mm
540 mm
62 mm
995,5 mm623,5 mm
660,3 mm
1770 mm

EN - 13
3 USING THE APPLIANCE
3.1 Information on the Frost Free
Technology
The Frost Free refrigerators have a
different operating system to static
refrigerators.
In normal (static) fridges, the humidity
entering the fridge due to opening the
door, and the humidity inherent in the
food, causes frost build-up in the freezer
compartment. To defrost the frost and
ice in the freezer compartment, you are
required to periodically switch off the fridge,
place the frozen food in a separate cooled
container, then remove the ice gathered in
the freezer compartment.
The situation is completely different in
No-frost fridges. A built-in fan blows dry
and cold air evenly throughout the cooler
and freezer compartments. The cold air
disperses uniformly between the shelves,
ensuring all your food is cooled equally,
thus preventing humidity and frost build-up.
Therefore, your No-frost fridge allows ease
of use, in addition to its huge capacity and
stylish appearance.
3.2 Thermostat Setting
The thermostat automatically regulates the
temperature inside the cooler and freezer
compartments. Refrigerator temperatures
can be obtained by rotating the knob
to higher numbers; 1 to 3, 1 to 5 or SF
(Maximum numbers on the thermostat
depends on your product.)
Lamp cover Thermostat knob
Super switch /
Low ambient Switch
(In some models)
(The images are representative)
Thermostat settings:
1 – 2 : For short-term storage of food in the
freezer compartment.
3 – 4 : For long-term storage of food in the
freezer compartment.
5 – MAX : For freezing fresh food. The
appliance will work longer. Once the food
is fully frozen, reset the thermostat to its
original position.
3.3 Temperature Settings Warnings
• Your appliance is designed to operate in
the ambient temperature ranges stated
in the standards, according to the climate
class stated in the information label. It
is not recommended that your fridge is
operated in the environments which are
outside of the stated temperature ranges.
This will reduce the cooling efficiency
the appliance.
• Temperature adjustments should be
made according to the frequency of
door openings, the quantity of food kept
inside the appliance and the ambient
temperature in the location of your
appliance.
• When the appliance is first switched on
allow it to run for 24 hours in order to
reach operating temperature. During this
time, do not open the door and do not
keep a large quantity of food inside.
• A 5 minute delay function is applied
to prevent damage to the compressor

EN - 14
of your appliance when connecting
or disconnecting to mains, or when
an energy breakdown occurs. Your
appliance will begin to operate normally
after 5 minutes.
Climate class and meaning:
T (tropical): This refrigerating appliance
is intended to be used at ambient
temperatures ranging from 16 °C to 43 °C.
ST (subtropical): This refrigerating
appliance is intended to be used at ambient
temperatures ranging from 16 °C to 38 °C.
N (temperate): This refrigerating appliance
is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C.
SN (extended temperate): This
refrigerating appliance is intended to be
used at ambient temperatures ranging from
10 °C to 32 °C.
The Turbo Fan (if available)
Do not block the air inlet and outlet
openings when storing food, otherwise air
circulation provided by the turbo fan will be
impaired.
3.4 Accessories
Visual and text descriptions in the
accessories section may vary according
to the model of your appliance.
3.4.1 Ice Tray (In some models)
• Fill the ice tray with water and place in
the freezer compartment.
• After the water has completely frozen,
you can twist the tray as shown below to
remove the ice cubes.
3.4.2 The Bottle Holder (In some models)
Use the bottle holder to prevent
bottles from slipping or falling over.
3.4.3 The Fresh Dial (In some models)
(The images are representative)
or
(The images are representative)
If the crisper is full, the fresh dial located
in front of the crisper should be opened.
This allows the air in the crisper and the
humidity rate to be controlled, to increase
the life of food within.
The dial, located behind the shelf, must be
opened if any condensation is seen on the
glass shelf.

EN - 15
3.4.4 Adjustable Door Shelf (In some
models)
Six different height adjustments can be
made to provide storage areas that you
need by adjustable door shelf.
To change the position of adjustable door
shelf ;
Hold the bottom of the shelf and pull the
buttons on the side of
the door shelf
direction of arrow.
(Fig.1)
Position door shelf
the height you need
by moving up and
down. After you get
the position that you
want the door shelf,
release the buttons on
the side of the door
shelf (Fig.2) Before
releasing the door
shelf, move up down
and make sure the
door shelf is fixed
Note: Before moving door shelf is
loaded, you must hold the shelf by
supporting the bottom. Otherwise, door
shelf could fall off the rails due to the
weight. So damage may occur on the door
shelf or rails.
3.4.5 Maxi-fresh preserver (If available)
Maxi Fresh Preserver technology helps to
remove ethylene gas (a
volatile organic compound
released naturally from fresh
foods) and unpleasant odors
from the crisper.
In this way, food stays fresh
for a longer time.
• Maxi Fresh Preserver must
be cleaned once in a year.
The filter should be waite
for 2 hours at 65°C in a
oven.
• To clean the filte , please remove the
back cover of the filter box by pulling it i
the direction of the arrow.
Fig. 1
Fig. 2
• The filter should not be washed wit
water or any detergent.
Maxi Fresh Preserver
(In some models)
(The images are representative)
Visual and text descriptions in
the accessories section may vary
according to the model of your
appliance.
4 FOOD STORAGE
4.1 Refrigerator Compartment
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers in the
refrigerator. Frost tends to concentrate in
the coldest parts of the evaporating liquid
and, in time, your appliance will require
more frequent defrosting.
• Cooked dishes must remain covered
when they are kept in the fridge.Do
not place warm foods in fridge.Place
them when they are cool, otherwise the
temperature/humidity inside the fridge will
increases, reducing the fridge’s efficien .
• Make sure no items are in direct contact
with the rear wall of the appliance as
frost will develop and packaging will stick
to it. Do not open the refrigerator door
frequently.
• We recommend that meat and clean fis
are loosely wrapped and stored on the
glass shelf just above the vegetable bin
where the air is cooler, as this provides
the best storage conditions.

EN - 16
• Store loose fruit and vegetable items in
the crisper containers.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being affected by ethylene
releaser fruits (banana, peach, apricot,
fig etc.)
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products
depends on the initial quality of the food
and an uninterrupted refrigeration cycle
before refrigerator storage.
• Water leaking from meat may
contaminate other products in the
refrigerator. You should package meat
products and clean any leakages on the
shelves.
• Do not put food in front of the air flo
passage.
• Consume packaged foods before the
recommended expiry date.
Do not allow food to come into contact with
the temperature sensor, which is located
in the refrigerator compartment, in order
to keep the refrigerator compartment at
optimum temperature.
• For normal working conditions, it will
be sufficient to adjust the temperatu
setting of your refrigerator to +4 °C.
• The temperature of the fridge
compartment should be in the range
of 0-8 °C, fresh foods below 0 °C are
iced and rotted, bacterial load increases
above 8 °C, and spoils.
• Do not put hot food in the refrigerator
immediately, wait for the temperature
to pass outside. Hot foods increase the
degree of your refrigerator and cause
food poisoning and unnecessary spoiling
of the food.
• Meat, fish, etc. should be store in th
chiller compartment of the food, and the
vegetable compartment is preferred for
vegetables. (if available)
• To prevent cross contamination, meat
products and fruit vegetables are not
stored together.
•Foods should be placed in the refrigerator
in closed containers or covered to
prevent moisture and odors.
The table below is a quick guide to show
you the most efficient way to store th
major food groups in your refrigerator
compartment.
Food Maximum
storage time
How and where to
store
Vegetables
and fruits 1 week Vegetable bin
Meat and
sh 2 - 3 days
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
Fresh
cheese 3 - 4 days On the designated door shelf
Butter and
margarine 1 week On the designated door shelf
Bottled
products
e.g. milk
and
yoghurt
Until the
expiry date
recommended
by the
producer
On the designated
door shelf
Eggs 1 month On the designated
egg shelf
Cooked
food 2 days All shelves
NOTE:
Potatoes, onions and garlic should not
be stored in the refrigerator.
4.2 Freezer Compartment
• The freezer is used for storing frozen
food, freezing fresh food, and making ice
cubes.
• Food in liquid form should be frozen
in plastic cups and other food should
be frozen in plastic folios or bags.For
freezing fresh food; wrap and seal fresh
food properly, that is the packaging
should be air tight and shouldn’t leak.
Special freezer bags, aluminum foil
polythene bags and plastic containers
are ideal.
• Do not store fresh food next to frozen

EN - 17
food as it can thaw the frozen food.
• Before freezing fresh food, divide it into
portions that can be consumed in one
sitting.
• Consume thawed frozen food within a
short period of time after defrosting
• Always follow the manufacturer's
instructions on food packaging when
storing frozen food. If no information is
provided food, should not be stored for
more than 3 months from the date of
purchase.
• When purchasing frozen food, make sure
that it has been stored under appropriate
conditions and that the packaging is not
damaged.
• Frozen food should be transported in
appropriate containers and placed in the
freezer as soon as possible.
• Do not purchase frozen food if the
packaging shows signs of humidity
and abnormal swelling. It is probable
that it has been stored at an unsuitable
temperature and that the contents have
deteriorated.
• The storage life of frozen food depends
on the room temperature, the thermostat
setting, how often the door is opened,
the type of food, and the length of time
required to transport the product from
the shop to your home. Always follow the
instructions printed on the packaging and
never exceed the maximum storage life
indicated.
• If the freezer door has been left open for
a long time or not closed properly, frost
will form and can prevent efficient a
circulation. To resolve this, unplug the
freezer and wait for it to defrost. Clean
the freezer once it has fully defrosted.
• The freezer volume stated on the label is
the volume without baskets, covers, and
so on.
• Do not refreeze thawed food. It may
pose a danger to your health and cause
problems such as food poisoning.
NOTE: If you attempt to open the freezer
door immediately after closing it, you
will find that it will not open easil . This
is normal. Once equilibrium has been
reached, the door will open easily.
• Use the fast freezing shelf to freeze
home cooking (and any other food
which needs to be frozen quickly) more
quickly because of the freezing shelf’s
greater freezing power. Fast freezing
shelf is the bottom drawer of the freezer
compartment.
• To use the maximum capacity of the
freezer compartment, use the glass
shelves for the upper and middle section,
and use the lower basket for the bottom
section.
The table below is a quick guide to
show you the most efficient way t
store the major food groups in your freezer
compartment.

EN - 18
Meat and sh Preparation Maximum storage time
(months)
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if it has a membrane 1 - 3
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 2.5 kg portions or as fillet 6 - 8
Freshwater sh
(Salmon, Carp, Crane,
Catsh)
After cleaning the bowels and scales of the fish,
wash and dry it. If necessary, remove the tail and
head.
2
Lean sh (Bass, Turbot,
Flounder) 4
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
2 - 4
Shellsh Clean and in a bag 4 - 6
Caviar In its packaging, or in an aluminium or plastic
container 2 - 3
Snails In salty water, or in an aluminium or plastic container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it
must not be re-frozen.
Vegetables and Fruits Preparation Maximum storage time
(months)
String beans and beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove the core
and boil in water 8 - 10
Spinach Wash and boil in water 6 - 9
Cauliower Remove the leaves, cut the heart into pieces and
leave it in water with a little lemon juice for a while 10 - 12
Eggplant Cut into pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12

EN - 19
Vegetables and Fruits Preparation Maximum storage time
(months)
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12
Maximum storage time
(months)
Thawing time at room
temperature (hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation Maximum storage time
(months) Storage conditions
Packet (Homogenized)
Milk In its own packet 2 - 3 Pure Milk – in its own packet
Cheese - excluding
white cheese In slices 6 - 8
Original packaging may be
used for short-term storage.
Keep wrapped in foil for
longer periods.
Butter, margarine In its packaging 6

EN - 20
5 CLEANING AND
MAINTENANCE
Disconnect the unit from the power
supply before cleaning.
Do not wash your appliance by
pouring water on it.
Do not use abrasive products,
detergents or soaps for cleaning the
appliance. After washing, rinse with clean
water and dry carefully. When you have
finished cleaning, reconnect the plug to the
mains supply with dry hands.
• Make sure that no water enters the lamp
housing and other electrical components.
• The appliance should be cleaned
regularly using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately by
hand with soap and water. Do not wash
accessories in a dish washer.
• Clean the condenser with a brush at least
twice a year. This will help you to save on
energy costs and increase productivity.
The power supply must be
disconnected during cleaning.
5.1 Defrosting
water tray
• Your appliance performs automatic
defrosting. The water formed as a result
of defrosting passes through the water
collection spout, flows into the water tra
behind your appliance and evaporates
there.
• Make sure you have disconnected the
plug of your appliance before cleaning
the water tray.
• Remove the water tray from its position
by removing the screws (if it has screws).
Clean it with soapy water at specific tim
intervals. This will prevent odours from
forming.
Replacing LED Lighting
To replace any of the LEDs, please contact
the nearest Authorised Service Centre.
Note: The numbers and location of the
LED strips may change according to
the model.
6 SHIPMENT AND
REPOSITIONING
6.1 Transportation and Changing
Positioning
• The original packaging and foam may be
kept for re-transportation (optional).
• Fasten your appliance with thick
packaging, bands or strong cords and
follow the instructions for transportation
on the packaging.
• Remove all movable parts or fix the
into the appliance against shocks
using bands when re-positioning or
transporting.
Always carry your appliance in the
upright position.
7 BEFORE CALLING AFTER-
SALES SERVICE
If you are experiencing a problem with
your appliance, please check the following
before contacting the after-sales service.
Your appliance is not operating
Check if:
• There is power
• The plug is correctly placed in the socket
• The plug fuse or the mains fuse has
blown
• The socket is defective. To check this,
plug another working appliance into the
same socket.
