Morris WDW-91480 User manual

A NOTE TO YOU
Thank you for buying a MORRIS appliance.
MORRIS washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
INSTRUCTION MANUAL
WDW-91480
Washing Machine Instruction Manual
␊Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by
selecting optimal water level and washing time.
␊Low noise system
The washer minimizes the washing and spinning noises by sensing the
amount of laundry.
␊Child-Lock
The Child-Lock system has been used to prevent children from pressing any
button to change the program during operation.
␊Nano-silver sterilization washing(Option)
By applying very fine silver particles on essential parts inside, the washer
sterilizes up to 99.9% as is done by boiling wash.
␊Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles inside the drum on washing sequence, and
the bubbles dissolve the detergent particles completely and cleanse all the soil in clothes gently and neatly.
CONTENTS Page
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS ....................................................................................................4
INLET HOSE CONNECTION ...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER ........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................23
HOW TO CLEAN THE FILTER ......................................................................................................24
REMOVING STAINS ......................................................................................................................25
TROUBLE SHOOTING ..................................................................................................................26
SPECIFICATION ............................................................................................................................27
2013.01.02
사양 확인 및 배포
세)생산기술팀

2
PARTS AND FEATURES
The parts and features of your washer are illustrated on the page.
Become familiar with all parts and features before using your washer.
Accessories
NOTE
The drawings in the book may vary from your washer model.
They are designed to show the different features of all models coverd by this book,
Your model may not include all features.
Inlet hose Manual Cap holder(3EA)
DETERGENT CASE
INLET HOSE
COLD
DOOR
LOWER COVER ADJUSTABLE LEG
HOSE DRAIN
CONTROL PANEL
POWER CORD

3
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the
following basic precautions.
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same
wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your washer.
• Do not wash fiberglass material.
Small particles can stick to fabrics washed in following loads and cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, if you connect only cold water inlet valve, while water
temperature is selected as hot or warm, there can be water leakage from unconnected water
inlet valve.
• This appliance must be grounded.
To avoide electrical shock, use a metal pipe for the ground connection.
WASHER SAFETY
• Flammable fluids (dry-cleaning solvents,
kerosene, gasoline, etc.) should not be
used or stored in or near your washer.
Do not add flammable fluids to your wash
water.These substances give off vapors
that can create a fire hazard or explosion.
• After starting a cycle, do not reach into the
washer until all motions stop.
• Do not tamper with the controls.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• If the supply cord is damaged, it must be
replaced by the manufacturer, or its service
agent or a similarly qualified person in
order to avoid a hazard.
• If the appliance is supplied from a cord
extension set or electrical portable outlet
device it should be positioned so that it is
not subjected to splashing or ingress of
moisture.
Please ...
• Have only a qualified person install, repair,
or replace parts on washer.
• Maintain washer properly.
• Protect washer from the weather and keep
it where the temperature will not fall below
freezing.
• Do not install the washer at a place of
extremely high humidity. It could cause an
electric shock or a short circuit.
• Connect washer to the correct outlet,
electrical supply, water supply, and drain
supply.
Read all instructions before using your washer

4
Removing transit bolts
1. Before operating the washer, remove the
transit bolts(3ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 3 bolts with the 10mm hex
wrench or spanner or cross-tip screwdriver.
Keep the 3 bolts for a later time.
• When the appliance is transported, transit
bolts will be re-used.
3. Close the holes with the cap holders supplied.
Location of washer
• Check location where the washer will be installed. Make sure you have everything necessary for
correct installation.
• Do not place or store your washer below 0˚C (32˚F) to avoid any damage from freezing.
• Do not place or store laundry products on top of washer at any times.
• Install the washer on the horizontal solid floor.
If the washer is installed on an unsuitable floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
washer is not level, adjust leg up or down for horizontal installation.
• Ventilation openings must not be obstructed by carpeting when the
washer is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer
and bottom of upper plate should be at least 3mm.
INSTALLATION INSTRUCTIONS
Drain Hose
Washer
Laundry
Tub
approx.
2cm

5
INLET HOSE CONNECTION
The washer should be connected to the water mains using new hose sets and old hose sets
should not be reused.
In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the
cold water inlet valve.
Option : Be careful not to confuse hot water inlet and cold water inlet.
For Ordinary Tap
1Pull down the collar of
the inlet hose to separate
it from the water tap
adapter.
2Loosen the four screws
properly in fitting into
water tap.
3Fit the water tap adapter
into the water tap and
tighten the four screws
evenly while pushing up
the adapter so that the
rubber packing can
attach to the water tap
tightly.
1Connect the inlet hose to
the water tap by screwing
the connector tightly.
2Connect the connector-
inlet supplied if
necessary.
3Insert the inlet hose
adapter into the water
inlet of a washing
machine and turn it to be
fixed. .
4Remove the tape, and
screw connector B into
connector A tightly.
5Connect the inlet hose to
the water tap adapter by
pulling down the collar of
the hose end.
6Connect the inlet hose
adapter of the hose to the
water inlet of the washing
machine by turning it
clockwise to be fixed
tightly.
For Screw-Shaped Tap
• Please check the rubber
packing inside the inlet hose
adapter of the hose.
* Check the packing in the inlet
Connector B
Connector A
Connector
Hose Connector
Rubber
Packing
Connector
inlet
Connector
Hose Connector
Rubber
Packing
TAPE

6
ELECTRICAL REQUIREMENTS
Drain system
• Never forget to install drain hose before operating your washer.
• Open the packing box, and there is a drain hose inside the drum.
• Connect the drain hose to the drain outlet at the back side of the washer.
• Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer.
• When installing the drain hose to tub(sink), secure it tightly with a string.
• Proper securing of the drain hose will protect the floor from damage due to water leakage.
• When the drain hose is too long, do not force it back into the washer.
This will cause abnormal noise.
Level adjustment
1If the washer is installed on an
unsuitable floor, it could make
considerable noise, vibrate and
cause a malfunction.
Laundry tub
max. 100 cm
min. 60 cm
ca. 105 cm
Tie
strap
max. 100 cm
min. 60cm
max. 100 cm
min. 60cm
WARNING
• Electrical earth is required on this washer.
• If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Don’t earth to a gas pipe.
• Don’t change the power supply cord plug.
• Check with a qualified electrician if you are not
sure the washer is properly earthed.
Recommended earthing method
For your personal safety, this washer must be earthed.
This washer is equipped with a power supply cord ‘A’having a earthing plug ‘B’.
To minimize possible shock hazard, the cord must be plugged into a mating
earthing-type wall receptacle ‘C’. If a mating wall receptacle is not available, it is the
personal responsibility and obligation of the customer to have the proper earthed
wall receptacle installed by a qualified electrician.
C
B
A
Electrical shock hazard : Failure to follow these instructions could result in
death or serious injury.

7
OPERATING YOUR WASHER
2Adjust the level of washer using adjustable legs.
• Please check if there is any gap between the
four adjustable legs and the floor.
• Adjust the level of washer by turning
adjustable legs. And make it sure that there is
no swaying of washer.
• After the adjustment is finished, turn the fixing
nuts up tightly so that the washer maintains
the adjustment.
3Make it sure that the washer does not sway when you press
down the four corners of the washer's top plate.
adjustable leg
Fixing Nut
NOTE
There should be no swaying of washer and all the
adjustable legs should stick to the floor closely.
To obtain the best washing results, you must operate your washer properly.
This section gives you this important information.
• Close zippers, snaps, and hooks to avoid
snagging other items.
Remove pin, buckles, and other hard objects
to avoid scratching the washer interior.
• Empty pockets and pull them inside out.
• Turn down cuffs and turn synthetic knits
inside out to avoid pilling.
• Tie strings and sashes to avoid tangling.
• Treat spots and stains.
(See “Removing stains” on page 25)
Preparing clothes for washing

8
• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together.
• Separate dark colors from light colors, colorfast items from non-colorfast item.
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lignts, Darks) Separate white clothes from colored clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Color (White, Lights, Darks) Separate white clothes from colored clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Sorting
• Drop items into washer loosely. Items should move
easily through wash water for best cleaning and
wrinkle-free results.
• Load washer properly and select correct load size
setting.
Overloading and selecting a setting too small for the
wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of pilling)
• Mix large and small items in each load. Load evenly
to maintain washer balance.
An unbalanced load can make the washer vibrate
during spin.
• Reduce wash time when using a small load size
setting. Load with only a few small items needs less
wash time.
• Use a large load size setting to reduce wrinkling with
permanent press clothes and some synthetic knits.
These items should have more room to move in the
water than heavy items. (towels, jeans)
1Detergent case 2Adding fabric softener
• If desired, add measured liquid fabric
softener to the softener inlet.
• Pour liquid fabric softener into the
dispenser using the amount recommended
on the package.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the
fabric softener which could stain clothes.
• Do not open the detergent case when
water is supplied.
• Avoid pouring fabric softener directly on
the clothes.
• Please use only the powder detergent for the front loader washing machine.
• Please use the proper amount of detergent in conformity with the instruction of the detergent manufacturer.
• A use of a large amount of detergent more than the recommended amount can cause many soapsuds and
the overload to the motor. In addition to, this will deteriorate the washing and rinse performmance.
Main wash Pre wash
Fabric softener
Loading
Adding detergent

Press this switch to turn the power on or off.
Operation and temporary stop is repeated as it is pressed.
When you want to change program in operating;
Press the ‘Start/Pause’ button ᵎSelect the program that you want to change ᵎ
Press the ‘Start/Pause’ button again.
You can select the course you want, and each lamp is turned on when that course
is selected.
For the more detailed information, please refer to the page 11~22.
It can be used to adjust temperature of water according to types of the load to be
washed. As the button is pressed, temperature of water is selected by
Cold ᵎ30°C ᵎ40°C ᵎ60°C ᵎ95°C
By pressing the spin button, the spin speed can be chosen.
Rinse Hold • Is selected by pressing the spin button repeatedly. This function leaves clothes in
the machine; suspended in the water after a rinse without entering into spin.
• To proceed through to a drain or spin, after the Rinse Hold function is completed,
use spin button.
Spin Only • If you want only spin, you can operate spin only.(See page 22.)
Rinse+ • Is used to add a rinse, which may assist in removing traces of detergent residue.
• By selecting Rinse+ function, the rinse time and the rinse water are increased.
Pre-Wash • The washer operates one additional wash and spin before the main wash.
• If the laundry is heavily soiled, Pre-Wash course is effective.
• Pre-Wash is available in Cotton, Baby Care and Synthetic programs.
By pressing the ADD+ button, Rinse+Spin and Drain function can be chosen.
Rinse+Spin • The washer operates one time Rinse and Spin process without Wash process.
Drain • The washer operates drainage process only without any process.
It can be used to pre-engage time for wash.
Reservation can be made from 2 hours to 12 hours.
Use this function when you want to protect any accident occurring from handling of washer by a
child. During an operation of washer, press ‘ADD+’ and ‘Time Delay’ buttons simultaneously. In
Child Lock mode, no button functions except Power button.
In Child Lock mode, press ‘ADD+’ and ‘Time Delay’ buttons simultaneously like setting Child
Lock and Child Lock is cancelled.
To change to the desired program, while in Child Lock mode;
1. Press both the ‘ADD+’ and ‘Time Delay’ buttons together once again.
2. Press the Start/Pause button.
3. Select the desired program and press the Start/Pause button again.
• The Child Lock will be cancelled when
power is off.
9
THE FUNCTIONS OF THE CONTROL PANEL
Change the
desired
program

10
1. COTTON IS AUTOMATICALLY SELECTED UPON POWER ON
• Press the Power button to start.
• Press the Start/Pause button.
• Initial condition.
- Program : Cotton
- Wash : main wash
- Rinse : 3 times
- Spin : 800 rpm
- Water temperature : 40˚C
WASHING PROCEDURE AND PROGRAM SELECTION
2. MANUAL SELECTING
• Press the Power button to start.
• Select the conditions which you want to use by turning the program dial and pressing each button.
• Press the Start/Pause button.
3. RESERVED WASHING
• Reservation can be made from 2 hours to 12 hours.
example) To make reservation to complete washing in 8 hours.
- Procedure to press the button.
* Each pressing of the button advances time delay by one hour.
• Now the reservation is made.
• If you want to check the selected program, press the 'Start/Pause' button again.
• Preparing washing before starting 'Time Delay';
- Turn on the water tap.
- Load laundry and close the door.
- Place the detergent and fabric softener in the detergent case.
• To cancel the time delay, press the Power button.
select the
program
or manual
adjust to "8"

First check if laundry is machine
washerble.(white cotton, linen
towel and sheets, ...)
Colorfast garments (shirts, night
dresses, pajamas, ...) and lightly
soiled white cottons.
(underwear, ...)
Colored laundry which is lightly
soiled fast.
Highly soiled laundry.
Laundry type is the same as
Cotton.
Baby clothes.
Use to clean the Tub and Drum.
Lightly soiled fast and thin
laundry.
Colored laundry which is lightly
soiled fast.
Machine washable woolens with
pure new wool only.
Polyamide, Acrylic, Polyester.
Highly soiled laundry.
Program
11
4. FUNCTION
• Recommended programs according to the laundry type.
• Pre-Wash : If the laundry is heavily soiled, 'Pre-Wash' program is recommended.
Pre-Wash is available in Cotton, Baby Care and Synthetic programs.
• Rinse+ : Used to introduce an additional rinse, which may assist in removing traces of detergent
residue.
• Eco White : By selecting Eco White program, the water temperature is lowered and washing time is
increased. So you can economize your comsumption of heating energy.
• Speed Wash : The 'Speed Wash' course has a very short cycle time. Recommended uses include small
amount of the laundry, a lelatively clean laundry, frequently used clothes.
• Rinse Hold : This function leaves clothes in the machine suspended in the water after a rinse without
entering into spin. Rinse Hold option is selectable with all programs except Tub Clean
program and Drain option.
Fabirc
Type
60°C (95°C)
40°C
(Cold, 30°C, 60°C)
Cold
40°C
(Cold, 30°C, 60°C)
60°C
95°C
Cold
Cold (30°C, 40°C)
30°C (Cold, 40°C)
Cold (30°C, 40°C)
40°C
(Cold, 30°C, 60°C)
40°C
(Cold, 30°C,
60°C, 95°C)
Proper
Temp. Option Maximum Load
Rating
Rating
Less than 2.0kg
Less than 2.0kg
Rating
Less than 2.0kg
Without load
Rating
Less than 2.0kg
Less than 2.0kg
Less than 2.0kg
Rating
Cotton
Color
Intensive Wash
Eco White
Baby Care
Tub Clean
Sports Wear
Speed Wash
Wool
Synthetic
Bubble Shower
Pre-Wash
Rinse+
Pre-Wash
Rinse+
Rinse+
Rinse+
Rinse+
Pre-Wash
Rinse+
Rinse+
Rinse+
Rinse+
Rinse+
Pre-Wash
Rinse+
Rinse+

12
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent
case. Softener should be below the ‘MAX’ level.
• Put detergent into the prewash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Cotton’ program using program selection dial.
• If you press Start/Pause button after Power button without selecting program, the
'Cotton' program is selected as default program.
• Washing temperature '40'°C , spin '800' rpm and rinse '3' times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash options
(Pre-Wash, Rinse+), press each button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* COTTON PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• 'Cold', '30'°C, '40'°C, '60'°C and '95'°C washing temperatures are selectable with Cotton program.
• 'Pre-Wash' and ‘Rinse+’ options are selectable with Cotton program.
Caution!
• If you select washing temperature '95'°C, some cold water is supplied before the drain of main wash. This
is to protect the user from the hazard of burn injury by lowering the temperature of hot wash water instead
of directly draining it. Therefore this is not a malfunction.
(Be careful with the draining water, since it can be still hot although the temperature is lowered.)
1
2
3
4

13
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Color’ program using program selection dial.
• Washing temperature 'Cold', spin '800' rpm and rinse '2' times are selected
automatically.
• If you want to change the spin velocity or add wash option(Rinse+), press each
button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* COLOR PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only 'Cold' washing temperature is selectable with Color program.
• Only ‘Rinse+’ wash option is selectable with Color program.
• The appropriate amount of laundry for Color program is below 2.0kg.
1
2
3
4

14
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Intensive Wash’ program using program selection dial.
• Washing temperature '40'°C , spin '800' rpm and rinse '3' times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash option
(Rinse+), press each button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* INTENSIVE WASH PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only 'Cold', '30'°C, '40'°C and '60'°C washing temperatures are selectable with Intensive Wash program.
• Only ‘Rinse+’ wash option is selectable with Intensive Wash program.
• The appropriate amount of laundry for Intensive Wash program is below 2.0kg.
1
2
3
4

15
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Eco White’ program using program selection dial.
• Washing temperature '60'°C , spin '800' rpm and rinse '3' times are selected
automatically.
• If you want to change the spin velocity or add wash option(Rinse+), press each
button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* ECO WHITE PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only '60'°C washing temperature is selectable with Eco White program.
• Only ‘Rinse+’ wash option is selectable with Eco White program.
1
2
3
4

16
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash and prewash compartments in the detergent
case. Softener should be below the ‘MAX’ level.
• Put detergent into the prewash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Baby Care’ program using program selection dial.
• Washing temperature '95'°C , spin '400' rpm and rinse '3' times are selected
automatically.
• If you want to change the spin velocity or add wash options(Pre-Wash, Rinse+),
press each button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* BABY CARE PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• Only '95'°C washing temperature is selectable with Baby Care program.
• More than '1000'rpm of spin velocity is not selectable with Baby Care program.
• 'Pre-Wash' and ‘Rinse+’ options are selectable with Baby Care program.
• The appropriate amount of laundry for Baby Care program is below 2.0kg.
Caution!
• If you select 'Baby Care' program, some cold water is supplied before the drain of main wash. This is to
protect the user from the hazard of burn injury by lowering the temperature of hot wash water instead of
directly draining it. Therefore this is not a malfunction.
(Be careful with the draining water, since it can be still hot although the temperature is lowered.)
1
2
3
4

17
Put 250ml of chlorine bleach mixed with 500ml of detergnet into the detergent case.
Then close the door.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Tub Clean’ program using program selection dial.
• Washing temperature 'Cold' , spin '400' rpm and rinse '2' times are selected
automatically.
• If you want to add wash option(Rinse+), press 'Option' button.
Press Start/Pause button.
• The washer will be operated with locking Door and supplying water.
* TUB CLEAN PROGRAM
Note
• All programs are not selectable except rinse time(s).
• Time Delay is not selected.
• Only 'Cold' washing temperature is selectable with Tub Clean program.
• Only '400'rpm of spin velocity is selectable with Tub Clean program.
• Use this program WITHOUT load.
• The appropriate cleaning time is one time per a month.
1
2
3
4

18
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Sports Wear’ program using program selection dial.
• Washing temperature 'Cold' , spin '800' rpm and rinse '2' times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash option
(Rinse+), press each button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* SPORTS WEAR PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• 'Cold', '30'°C and '40'°C washing temperatures are selectable with Sprots Wear program.
• More than '1000'rpm of spin velocity is not selectable with Sports Wear program in order to protect damage
on laundry.
• Only ‘Rinse+’ wash option is selectable with Sports Wear program.
1
2
3
4

19
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Speed Wash’ program using program selection dial.
• Washing temperature '30'°C, spin '800' rpm and rinse '2' times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash option
(Rinse+), press each button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* SPEED WASH PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• 'Cold', '30'°C and '40'°C washing temperatures are selectable with Speed Wash program.
• Only ‘Rinse+’ wash option is selectable with Speed Wash program.
• The appropriate amount of laundry for Speed Wash program is below 2.0kg.
1
2
3
4

20
Put the laundry in the drum. Put detergent and softener into the detergent case.
Then close the door.
• Put detergent into the main wash compartment in the detergent case. Softener
should be below the ‘MAX’ level.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
• The LED shows only '---' and all Program Lights turn on.
Select the ‘Wool’ program using program selection dial.
• Washing temperature 'Cold', spin '400' rpm and rinse '2' times are selected
automatically.
• If you want to change washing temperature, the spin velocity or add wash option
(Rinse+), press each button.
Press Start/Pause button.
• The Door is locked. By sensing the weight of laundry and supplying wash water,
The appliance starts washing.
* WOOL PROGRAM
Note
• If you want to change the setting during operation, press the Start/Pause button to hold the operation and
press the button you want.
• 'Cold', '30'°C and '40'°C washing temperatures are selectable with Wool program.
• More than '1000'rpm of spin velocity is not selectable with Wool program in order to protect damage on
laundry.
• Only ‘Rinse+’ wash option is selectable with Wool program.
• The appropriate amount of laundry for Wool program is below 2.0kg.
• Use only special detergent for wool. (Since special neutral detergent for wool creates a lot of bubbles, use
appropriate amount.)
1
2
3
4
