MOS OPT100 User manual

INSTRUCTION MANUAL
OPT100
OxygenMonitor

2. Specifications
Housing ABSPlastic
Finishing ElectrostaticEpoxyPaint
ElectricalConnection TerminalBoard
CableInlet Racor1/2"(3x)
Installation WallMounted
IPProtection IP65
Power  3.5VA
Weight 1.2Kg
PowerSupply 90~240VACor24VDC
OperatingTemperature 5~40ºC
Humidity 20~80%
Display 7SegmentRed
MeasuringRange 0100%O2
Precision 0.1
Accuracy 0.02%fullscale
OperatingTemperature 540 ºC
AutoTemperatureCompensation 40ºC
MeasuringSystem ClarkPolarographicCell
SamplingTime 20sec.
BarometricPressureCompensation 811mPA1216mPA
SignalOutput Analog420mAprogrammable.
GalvanicIsolation 2000VAC(optokupler)
LineResistance 1K2Ohms
2
Sensorlifetimevarywiththeoperatingconditions.Itis3yearsundernormalconditions.Sensor
revealexchangetimeviareducingtheoutputto70%.Thismeansillogical O2readoutfromthe
monitor.Pleasekindlyexchangethesensorimmediatelywhenyouwillencounterthiskindofrapid
decrease.
Pleasekindlyinstallnewsensorintothe O2Monitorimmediatelyafterreceivingit.
Youshouldkeepthesensorinrefrigeratedspacearound5to10ºCuntilinstallation.
Keepthesensorinitsairtightplasticbag.PleasecheckSensorExchangepartfor
installationdetails.

3. MechanicalDimensions
198mm
191mm
1
2
3
4
5 6
7
3
Oxygenvalueas%
Leddisplay
Keypad.Foradjustmentandparameterexchange.
Sirenandflasher
OxygenSensor
CableInlets
CableInletPartCover
Sensorinletshouldbecoveredfordustand
particlepenetrationduringinstallation.
Locationshouldbeselectedcarefullyto
preventanydirectairflowtotheMonitor
fromothermachineryand/orventilation.
Donotinstalltheunitnearbyanyheatsource.
1.Electricalconnectionsshouldbestartedafterfinishingtheinstallation.
Monitorcaneasilybeconnectedtothewallwithinstallationfittingsthatareinsidethepackage.
Afterdecidingproperlocation,youcandrillthewall.Monitorwillbeinstalledandscrewedaccordingly.

4. ElectricalInstallation
1 2 3 4 5 6 7 8
9 10 11 12 13 14 F1
F2
200mA
500mA
NoConnection
+OxygenSensorInlet(Red)
OxygenSensorInlet(Black)
NoConnection
RS485A(ModBusRTU)
RS485B(ModBusRTU)
+AnalogOutput420mA
AnalogOutput420mA
N.O.ALARMHIGH
CALARMHIGHRelayOut
N.C.ALARMHIGH
N.O.ALARMLOW
CALARMLOWRelayOut
N.C.ALARMLOW
PowerSupply
90240VACor24VDCconnection.
Warning:PleaseconnecteitherACorDC
Powertotheunit
90240VAC
24VDC
4
Electricconnectionscanbecarriedoutduringinstallation.Powershouldbeturnedonafterfinishingtheinstallationcompletely.
Removetheelectricconnectionpartcover.Paycautiontothedatacableinbetweencoverandtheboxandremovethiscablefrom
itssocketonthe mainboard.
Connectyourpowersupply(220VACor24 VDC,whicheverwillbeused)
Thereare3 racorontheunitforpowerandalarmcables.Useone racorforonlyonecable.
Thereisonefuseforeachpowersupply(220VACand24 VDC)
AlarmoutputisdrycontactanditcanbeselectedasNCorNO.Afterfinishingalarmconnection,reconnectthedatacablethatis
comingfromthecover.
Installthecover.Besurethatisolationgasketisinstalledintocoverhousing.Otherwiseunitcouldntbesealedandlostitsisolation.

5. ParameterSetting
209
o2
OPT100,showsO2measurementvalueatnormal
Operationmode.HighO2alarmvaluecanbeset
With ALRHparameter.
PRG
aLrH
250
SET
SET
209
o2
SET
AdjustHIGHAlarmvaluewithupanddown
buttons.
Youcansetitinbetween5.0to30.00.
aLrL
250
LowO2alarmvaluecanbesetwith ALRL
parameter.
Pressbutton.
Pressbutton.
Pressbutton.
AfteradjustmentsOPT100returnitsnormal
operationmode.
5
AdjustLOWAlarmvaluewithupanddown
buttons.
Youcansetitinbetween5.0to30.00.

6. SensorCalibration
Sensorcalibrationcanbeappliedtoanewsensororanexistingonewithshiftedmeasurement.Underthis
conditionO2sensorshouldbecalibratedviaOPT100paneltoreadoutcorrectO2level.
Sensoroutputdecreasesto70%whenitslifetimeexpires.Youcaneasilyrecognizethisconditionwithvery
lowandunlogicalO2valuearound5%to10%.Calibrationdoesntcorrectthiscaseandsensorshouldbe
exchangedforcorrectmeasurement.
NormallyO2sensormeasure20,9%O2inregularambientcondition.Ifyoureaddifferentvaluefollowbelow
mentionedsteps;
1. ConnectcalibrationfittingintoN2bottle(99,9%N2)withpneumatichose.
2. ConnectcalibrationfittingintotheO2sensorviainstallingintothesensorinlet.
3. OpentheN2bottlevalveandsupplygastothesensor.
4. CheckO2valuedropfromOPT100display.O2valuedropwilltakeapproximately
30seconds.O2shouldreachto0,0.Ifthevalueisbiggerthan0,
Zerocalibrationshouldbecarriedout.
5. Afterreaching0valueclosetheN2bottlevalveandremovethecalibrationfitting.
6. O2valuewillriseslowlyandreachto20,9approximatelyin1minute.Ifthevalueis
differentthan20,9SPANcalibrationshouldbecarriedoutwithSPANparameter.
FollowupSPANcalibrationinstructions.
Calibration
Accessory
Nitrogen(N2)Tube
%99.9
6

7. SpanveZeroParameterAdjustment
Pressbuttonfor5seconds.
PRG
11
o2
Code
122
OPT100willrequestsafetycode.Write122witharrowbuttonsandpressSET.
SET
CaLb
6rvb Calibrationadjustmentparameterwillbeopened.
SET
Zero
11
ZEROparameterscreenwillbeopened.Decreasethevalueto0,0witharrow
buttonviapressingitcontinuously.BesurethatCalibrationfittingisconnectedto
thesensorandN2bottlevalveisopenedwith99,9%N2gassupplytothesensor.
Afterreachingto0valuepressSETbuttonandstopthegassupply.
SET
span
209
NormalOperationScreen
SPANparametershowsambientO2value.Applycalibrationforvaluesdifferent
than20,9(lowerorhigher)Reach20,9valuebypressingarrowbuttons.
Afterreaching20,9valuedonottouchanybutton.OPT100willreturntonormal
operationmodebyitselfin30seconds.
209
o2 NormalOperationScreen.
7

8. OxygenSensorExchange/Repair
SENSOREXCHANGE:
Sensorispackedwithitscovertokeepitselectrolyteinpassivemode.Openthesensorcoverjust
before24hoursofinstallationandkeepitatambientconditionthatwilloperate.Passiveelectrolyte
willgetactivewiththiswayandstarttomeasurecorrectlyafterinstallationintotheOPT100panel.Do
notforgettonotesensorinstallationdateontothepanel.PleasecheckSENSORCALIBRATIONpart
fornewsensorcalibration.
Sensordatecode: ②⑦①③
Week Year(2013)
SENSORREPAIR:
Do not open the sensor for any repair attempt.  There isnt any repairable part inside the
sensoranditwillbedamagedpermanently.InnerElectrolytecanalsocreatesevereirritation
onskin.
8

9TroubleShottingGuide
O2levelistoolow:
Sensorinletcanbeblocked.
Sensorlifetimecanbeexpired.Pleasecheckinstallationdateofthesensor.
O2Levelstayconstantandfreezed.
Blowairintothesensorinletslowlyfor5to10secondsandobservevaluealteration.
Checkterminalboardconnectionsofthesensor.
Removeoneoftheterminalboardconnectionofthesensorandcheckpanelscreenforalteration.
Ifscreenvalueisexchangedthansensorisdamagedorexpired.Ifvaluestayconstantconsult
supplier.
Panelscreenisntworking.
Please check the cable and its socket in between front panel and mainboard and be sure its
properlyconnected.
Openthepanelcoverandcheckaftterminalboardconnections.
Checkthepowersupply.
IfO2levelandgreenPOWERlightarenton,checkthefusesinsidethepanel.
IfgreenPOWERlightisntonbutO2levelisworking;
Please check the cable and its socket in between front panel and mainboard and be sure its
properlyconnected.
ConsultManufacturer.
Flasherwithbuzzerdoesntrunduringalarm;
ChecktheterminalboardconnectionsoftheFlasher
9
