Motion Labs PM Series User manual

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 1
PM-XXX Series Power Meter
User Manual
© 2016 Moon Laboratories, Inc.

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 2
© 2016 Moon Laboratories, Inc.

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 3
User Manual PM-XXX Series Power Meter
Table Of Contents
1. Warranty
2. Introducon
3. Overview
4. Modes
5. Setup
6. Ethernet
7. Internal Web Server
8. Local Data Logging
9. Specicaons
10. Supplemental Documentaon

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 4
User Manual PM-XXX Series Power Meter
1. Warranty
Limited One-Year Warranty; Limitaons of Liability. MLI warrants that for a period of one year
from delivery, MLI Products will be free from defects in material and workmanship under normal
use. In the event that a defect in any MLI Product is discovered within the one-year warranty
period, then the customer must nofy MLI in wring within thirty (30) days of discovering the defect
or before expiraon of the one-year warranty period, whichever shall occur rst. No claim may be
made against MLI without strict compliance wit this noce requirement. MLI shall have the opon
to repair or replace the MLI Product or any of its components solely to the extent that MLI deems it
necessary to remedy the defect. Any incidental costs, including without limitaon, the cost to ship
the defecve MLI Product or aected components to MLI, or to such other repair facility as Moon
Laboratories, in its discreon, may designate, shall be the responsibility of the buyer.
THIS WARRANTY SHALL NOT APPLY, AND MLI SHALL HAVE NO OBLIGATIONS HEREUNDER UPON
THE OCCURRENCE OF ANY OF THE FOLLOWING: (A) IF THE MLI PRODUCT IS SUBJECT TO ANY USE
FOR WHICH IT WAS NOT INTENDED; (B) IF THE MLI PRODUCT IS MODIFIED IN ANY WAY BY ANY
PARTY OTHER THAN MLI; OR (C) IF ANY PARTY OTHER THAN MLI ATTEMPTS TO REPAIR OR
REPLACE ANY DEFECT IN THE MLI PRODUCT OR IN ANY COMPONENT THEREOF.
To the fullest extent permied by applicable law, this Warranty shall be for the exclusive benet of
the buyer with which or with whom MLI is in privity of contract, and shall not inure to the benet of
any third party whatever.
UNDER NO CIRCUMSTANCES SHALL MLI BE LIABLE TO ANY PERSON OR BUSINESS ENTITY,
INCLUDING THE BUYER, UNDER ANY CAUSE OF ACTION INCLUDING, BUT NOT LIMITED TO, THOSE
BASED UPON CONTRACT, NEGLIGENCE, BREACH OF WARRANTY OR TORTIOUS CONDUCT, FOR
DIRECT, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, INCLUDING ANY CLAIMS FOR
LOST PROFITS.
THE ABOVE IS THE ONLY WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, BY STATUTE OR
OTHERWISE, REGARDING ALL MLI PRODUCTS , INCLUDING WITHOUT LIMITATION ANY IMPLIED
WARRANTIES OF MERCHANTABILTY AND/OR OF FITNESS FOR A PARTICULAR PURPOSE. ANY
WARRANTIES IMPLIED BY LAW ARE HEREBY EXPRESSLY DISCLAIMED.

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 5
2. Introducon
This Manual describes how to use the Moon Laboratories PM-XXX Series Power Meter.
The data and illustraons found in this manual are not binding. We reserve the right to modify our
products in line with our policy of connuous product development. The informaon in this
document is subject to change without noce and should not be construed as a commitment by
Moon Laboratories.
Moon Laboratories assumes no responsibility for any errors that may appear in this document. If
you have any suggesons for improvements, amendments, or have found errors in this document,
please nofy us. No part of this document may be reproduced in any form or by any means,
without the express wrien permission of Moon Laboratories. All rights reserved.
All pernent state, regional, and local safety regulaons must be observed when installing and using
this product. For reasons of safety and to assure compliance with the documented system data,
only the manufacturer should perform repairs to the components.
We value and welcome your comments about this product and product documents. You can reach
us at www.moonlabs.com.
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 6
3. Overview
The PM Series of Power Meter comes in dierent current capacies. The Part Numbers and
Descripons are as follows:
PM-25 Three phase four wire 25 amps per phase
PM-100 Three phase four wire 100 amps per phase
PM-200 Three phase four wire 200 amps per phase
PM-400 Three phase four wire 400 amps per phase
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 7
3. Overview (Connued)
Moon Laboratories PM-XXX series is a mul-funcon power meter. Using dierent current
transformers (CTs’) the meter is available in 25, 100, 200 and 400 amp models. Current
values up to 999 amps can be displayed when congured with CT’s matching the intended
range of use.
Front panel connecvity for USB and Ethernet provide data logging and remote data access.
Upon plugging in a USB memory sck data will begin data logging in CSV le format. Time
stamp comes from the internal real me clock.
Ethernet connecon has mulple funcons. With the IP address known as indicated on the
Menu screen, any device with a web browser on the same network can see data from the
meter. Simply type the web address into the browser of the device on the same network.
Subscripon based remote viewing of data and logging over me with advanced graphical
presentaon can be accomplished by web browser from anywhere in the world.
For applicaons where meter data would be used for a custom applicaon registers can be
read via MODBUS TCP.
Four LCD panels display data and a h screen controls modes of operaon and display
status which includes:
1. Standby Mode
2. Voltage Current Frequency Mode
3. Power Mode
4. Power Factor Mode
5. Total Harmonic Distoron Mode
Change between display modes by pressing the MODE buon on the control screen.
Ethernet status is also displayed.
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 8
4. Modes
Standby Mode
Dim animated graphics are displayed while meter is acve internally.
On power up or exing standby mode the display always defaults to volt amp frequency dis-
play mode.
Voltage Current Frequency Mode
Voltage – current – frequency mode displays the following:
True RMS voltage phase to neutral
True RMS voltage phase to phase
Current per phase
Neutral current
20 segment current bar graph with user seable scaling
Frequency
Graphical Ground to neutral voltage displays 1,2,3,4,10,20,30,40,50,60 volts
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 9
User Manual PM-XXX Series Power Meter
4. Modes (Connued)
Power Mode
Power mode displays the following:
Power in kilowas per phase
Total power in kilowas
Total kilowa hours
Relave kilowa hours (user reseable)
Power Factor Mode
Power factor mode displays the following:
Power factor per phase
Total power factor

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 10
4. Modes (Connued)
Total Harmonic Distoron Mode
The Total Harmonic Distoron (THD) mode displays the following:
THD per phase
THD phase to phase
THD current per phase
THD neutral current
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 11
5. Setup
Enter setup mode by pressing the blue Moon Labs logo ve seconds. A code entry screen
will be displayed. Without entering the code you will be able to see the current me and
date of the real me clock and the meter’s 24 character unique ID number and the site ID.
The unique ID number is required for setup of subscripon based remote access website.
Using up and down arrow keys adjust each digit to code 65476. Press the enter key to
change to a dierent digit. Once you have the correct code displayed press enter to get to the
main setup menu. Pressing escape while on the code entry page will bring you back to the
voltage current frequency mode.
Press & Hold Here (5 Sec)
User Manual PM-XXX Series Power Meter
Enter Key

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 12
5. Setup (Connued)
Setup Menu Structure
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 13
5. Setup (Connued)
Main Setup Page
Pressing escape while on the setup menu page will bring
you back to the default mode (voltage current frequency
mode). When in any setup menu if there are no buon
presses within 60 seconds the meter will change back to
default mode.
NOTE* With the excepon of the “NETWORK” screens, in all of the other sub screens, once
you adjust any value, pressing escape will write that new value and return to previous page.
Pressing escape will exit without changes IF NO ADJUSTMENTS WERE MADE.
Clock Set
From the main set up page, press “CLOCK SET” to access
this screen.
Use the up and down arrows to adjust any me/date
parameter. Pressing the enter key will advance to the next
parameter as indicated by the yellow underscore. Once all
adjustments are complete press escape to set me.
Seconds are set to 0 for any changes.
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 14
5. Setup (Connued)
Network to SET IP and SITE ID
Because the “NETWORK” screen has two addional indents and makes non-volale changes
to the program, the process of updang and returning to previous pages is slightly modied.
As before, pressing escape without changes will return you to the previous page. In the “SET
IP” window however, aer making changes, pressing escape once will update and reboot the
screen, then bring you back to the same page allowing you to verify your changes. Press the
escape again to return to the previous page.
In the “SITE ID” window aer making changes, pressing escape once will update the screen
without reboong allowing you to verify your changes. Press the escape again to return to
the previous page.
Network (SET IP)
From the main set up page press the “NETWORK” buon,
then the “SET IP” buon to access this window. The
network setup page has the choice of changing IP sengs
for a xed address or choosing DHCP for automac
addressing.
To change the IP, Use the UP and DOWN arrows to adjust
any network octet. Pressing the enter key will advance to
the next parameter as indicated by the yellow underscore.
Once all adjustments are complete press escape to set.
The screen will blank and display “UPDATING …” and then “REBOOTING …” for about 15
seconds. The network screen will RETURN displaying the new sengs.
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 15
5. Setup (Connued)
Once all adjustments are complete press escape to set.
The screen will blank and display “UPDATING …” and then “REBOOTING …” for about 15
seconds. The network screen will RETURN displaying the new sengs.
To set DHCP the following network sengs must be acve:
NETWORK IP = 0.0.0.0
GATEWAY IP ADDRESS = 0.0.0.0
SUBNET MASK = 255.255.255.0
For convenience press and hold the SET DHCP buon for 3 seconds to set all network sengs
for DHCP automacally.
Site ID
From the main set up page press the “NETWORK” buon,
then the “SITE ID” buon to access this window. To change
Site ID use the UP and DOWN arrows to select upper and
lower case leers, numbers and standard characters as
desired. Press and hold arrow keys for fast scroll through
characters. Press the enter key to advance to the next
posion indicated by the yellow underscore. Up to 22
characters may be used including spaces.
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 16
5. Setup (Connued)
Bar Graph Scaling
From the main set up page, press the “BAR GRAPH” buon
to access this window. Bar graph amp scaling allows you to
set the range of the 20 segment current bar graph for the
X, Y, Z and Neutral displays in the volt amp frequency
mode. Use the up/down buons to adjust the value from
20 to 1000 amps. The bar graph will display all 20 bars
when measured current is the same as set current value.
Press escape to return to the main setup menu.
KWh Reset
From the main set up page, press the “KWh RESET” buon
to access this window. When the display is in Power Mode,
Kilowa hours and relave kilowa hours are displayed.
While kilowa hours is not changeable, relave kilowa
hours can be reset to zero. The display will show present
relave KWh. If you escape no change will be made.
Pressing the enter key will zero the relave KWh as
indicated on the display.
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 17
User Manual PM-XXX Series Power Meter
6. Ethernet
Note: see setup Ethernet setup
States
Control screen showing Ethernet disconnected
Control Screen showing Ethernet connected in DHCP mode
with address
Control screen showing Ethernet connected in stac
mode with address

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 18
7. Internal Web Server
Through the front panel RJ-45 Ethernet connector you can see measurement values from the
meters web page.
With the meter connected to a local network, open your web browser on a device connected
to the same network and type in the IP address on the right screen of the meter.
The meter will display a web page with 4 tabs
User Manual PM-XXX Series Power Meter

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 19
User Manual PM-XXX Series Power Meter
7. Internal Web Server (Connued)
Measurements
On the measurement tab you can view basic readings like voltage phase-to-phase, voltage
phase-to-neutral, amps, frequency, average phase-to-neutral voltage, average phase-to-
phase voltage, average current, Total power, total reacve power (KVAr), total apparent
power (KVA), power factor, demand, and total harmonic distoron (THD).

Property of Moon Laboratories, Inc.
Created By: Michael Shaw Approved By: Peter Herrmann, Philip Nubile Page: 20
User Manual PM-XXX Series Power Meter
7. Internal Web Server (Connued)
Counters
For the counters tab, only counter 1 is used. Import power is the total kWh’s used (kWh1-
Im). Since the meter is a line connected device export power is not used. There are also
counters for inducve power (kVArh1-In) and capacive power (kVArh1-Cp).
