MCONNECT
MCONNECT DUAL SWITCH
EN
USER’S AND INSTALLER’S MANUAL

1A 1B
1B
4A
4B
4B
5A
5B
6A
6A
6A
6B
6B
ENEN
00. CONTENT 01. SAFETY INSTRUCTIONS
INDEX ATTENTION:
This product is certified in accordance with European
Community (EC) safety standards.
This product complies with Directive 2011/65/EU of the
European Parliament and of the Council, of 8 June 2011, on
the restriction of the use of certain hazardous substances
in electrical and electronic equipment and with Delegated
Directive (EU) 2015/863 from Commission.
(Applicable in countries with recycling systems).
This marking on the product or literature indicates that the
product and electronic accessories (eg. Charger, USB cable,
electronic material, controls, etc.) should not be disposed
of as other household waste at the end of its useful life. To
avoid possible harm to the environment or human health
resulting from the uncontrolled disposal of waste, separate
these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material
resources. Home users should contact the dealer where
they purchased this product or the National Environment
Agency for details on where and how they can take these
items for environmentally safe recycling. Business users
should contact their vendor and check the terms and
conditions of the purchase agreement. This product and
its electronic accessories should not be mixed with other
commercial waste.
This marking indicates that the product and electronic
accessories (eg. charger, USB cable, electronic material,
controls, etc.) are susceptible to electric shock by direct or
indirect contact with electricity. Be cautious when handling
theproductandobserveallsafetyproceduresinthismanual.
CONNECTION TO WALL SWITCH OF 2 KEYS
MCONNECT DUAL SWITCH
GRAPHIC DESCRIPTION
TECHNICAL SPECIFICATIONS
PRODUCT INSTALLATION
ADD MODULE IN IN THE APP
OPERATION SETTINGS
INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS
01. SAFETY INSTRUCTIONS
02. CONNECTIONS SCHEME
03. CONTROL BOARD
04. INSTALLATION
05. CONFIGURATION
06. TROUBLESHOOTING
REMOVE MODULE FROM THE APP
RESET

2EN
01. SAFETY INSTRUCTIONS
GENERAL WARNINGS
•This manual contains very important safety and usage information.
very important. Read all instructions carefully before beginning the
installation/usage procedures and keep this manual in a safe place
that it can be consulted whenever necessary.
•This product is intended for use only as described in this manual. Any
other enforcement or operation that is not mentioned is expressly
prohibited, as it may damage the product and put people at risk
causing serious injuries.
•This manual is intended firstly for specialized technicians, and does
not invalidate the user’s responsibility to read the “User Norms”
section in order to ensure the correct functioning of the product.
•The installation and repair of this product may be done by qualified
and specialized technicians, to assure every procedure are carried
out in accordance with applicable rules and norms. Nonprofessional
and inexperienced users are expressly prohibited of taking any action,
unless explicitly requested by specialized technicians to do so.
•Installations must be frequently inspected for unbalance and the
wear signals of the cables, springs, hinges, wheels, supports and other
mechanical assembly parts.
•Do not use the product if it is necessary repair or adjustment is
required.
•When performing maintenance, cleaning and replacement of parts,
the product must be disconnected from power supply. Also including
any operation that requires opening the product cover.
•The use, cleaning and maintenance of this product may be carried
out by any persons aged eight years old and over and persons whose
physical, sensorial or mental capacities are lower, or by persons
without any knowledge of the product, provided that these are
supervision and instructions given by persons with experienced in
terms of usage of the product in a safe manner and who understands
the risks and dangers involved.
•Children shouldn’t play with the product or opening devices to avoid
the motorized door or gate from being triggered involuntarily.
WARNINGS FOR TECHNICIANS
•Before beginning the installation procedures, make sure that you have
all the devices and materials necessary to complete the installation
of the product.
•You should note your Protection Index (IP) and operating temperature
to ensure that is suitable for the installation site.
•Provide the manual of the product to the user and let them know how
to handle it in an emergency.
•If the automatism is installed on a gate with a pedestrian door, a door
locking mechanism must be installed while the gate is in motion.
•Do not install the product “upside down” or supported by elements do
not support its weight. If necessary, add brackets at strategic points to
ensure the safety of the automatism.
•Do not install the product in explosive site.
•Safety devices must protect the possible crushing, cutting, transport
and danger areas of the motorized door or gate.
•Verify that the elements to be automated (gates, door, windows,
blinds, etc.) are in perfect function, aligned and level. Also verify if the
necessary mechanical stops are in the appropriate places.
•Thecentralmustbeinstalledonasafeplaceofanyfluid(rain,moisture,
etc.), dust and pests.
•You must route the various electrical cables through protective tubes,
to protect them against mechanical exertions, essentially on the
power supply cable. Please note that all the cables must enter the
central from the bottom.
•If the automatism is to be installed at a height of more than 2,5m from
the ground or other level of access, the minimum safety and health
requirements for the use of work equipment workers at the work of
Directive 2009/104/CE of European Parliament and of the Council of

3EN
16 September 2009.
•Attach the permanent label for the manual release as close as possible
to the release mechanism.
•Disconnect means, such as a switch or circuit breaker on the electrical
panel, must be provided on the product’s fixed power supply leads in
accordance with the installation rules.
•If the product to be installed requires power supply of 230Vac or
110Vac, ensure that connection is to an electrical panel with ground
connection.
•The product is only powered by low voltage satefy with central (only
at 24V motors)
WARNINGS FOR USERS
•Keep this manual in a safe place to be consulted whenever necessary.
•If the product has contact with fluids without being prepared, it must
immediately disconnect from the power supply to avoid short circuits,
and consult a specialized technician.
•Ensure that technician has provided you the product manual and
informed you how to handle the product in an emergency.
•Ifthesystemrequiresanyrepairormodification,unlocktheautomatism,
turn off the power and do not use it until all safety conditions have
been met.
•In the event of tripping of circuits breakers of fuse failure, locate
the malfunction and solve it before resetting the circuit breaker or
replacing the fuse. If the malfunction is not repairable by consult this
manual, contact a technician.
•Keep the operation area of the motorized gate free while the gate in in
motion, and do not create strength to the gate movement.
•Do not perform any operation on mechanical elements or hinges if the
product is in motion.
RESPONSABILITY
•Supplier disclaims any liability if:
•Product failure or deformation result from improper installation
use or maintenance!
•Safety norms are not followed in the installation, use and
maintenance of the product.
•Instructions in this manual are not followed.
•Damaged is caused by unauthorized modifications
•In these cases, the warranty is voided.
01. SAFETY INSTRUCTIONS
SYMBOLS LEGEND:
• Important safety
notices
• Useful information
• Programming
information
• Potentiometer
information
• Connectors
information
• Buttons
information

4A 4B
230V
ENEN
02. CONNECTIONS SCHEME
CONNECTION TO WALL SWITCH OF 2 KEYS
LEDs
• Flash in purple Pairing mode (It is waiting to be added)
• Red No network
• Flash in red Lost connection to the cloud
• Blue Successfully connected to the local network, but not yet connected
to the cloud
• Flash in blue Upgrading Firmware
• Green Connected to the cloud
LAMP
COM Lights Output - Common
L Lamp output 1
L Lamp output 2
PULL
Wall switch connection - Common
SW Wall switch connection - Lamp 1
SW Wall switch connection - Lamp 2
-AC
F230V line input (phase)
N230V line input (neutral)
MCONNECT DUAL SWITCH
GRAPHIC DESCRIPTION
03. CONTROL BOARD
The MCONNECT DUAL SWITCH was developed to control up to two lamps remotely or by pushbutton,
using the MCONNECT App and a module previously connected to the application.
Its small size allows installation inside junction boxes, existing behind electrical switches (push buttons).
Advantages of using MCONNECT:
• Easy installation and configuration;
• Possibility to control the lights in your home from anywhere;
• Reading the status of lights;
• Possibility of creating intelligent scenarios, which allow triggering a
series of functions with a simple click or by voice control;
• Possibility of configuring routines for the devices (example: turn on the
lights at 10am and turn off at 10.30am).
Lights
Wall switch

5A 5B
54
2
3
ENEN
TECHNICAL SPECIFICATIONS
03. CONTROL BOARD
• Power Supply 90-230 Vac 50-60Hz
• Maximum light power 230Vac; 1000W
• Output relay capacity 5A 250VAC 5A 30VDC
• Consumption 15mA @ 230AC
• Operating temperature -20C to 70C
• Module frequency 2.4 GHz
• Input 2 contact inputs without tension
• Output 2 relay outputs without tension
• Technology WIFI IEEE 802.11b/g/n , Bluetooth
• Wifi access 50m in open country
• Protection level IP44
• Construction material ABS
23mm
56mm
44mm
52mm
04. INSTALLATION
PRODUCT INSTALLATION
1 • Turn off the general lights of the house on the
electrical panel.
2 • Disassemble the switch plate and disconnect
all wires.
3 • Connect module wires to the installation
wires (see page A).
4 • Insert the MCONNECT DUAL SWITCH module
inside the junction box.
5 • Replace the switch plate and tighten it
completely.
• The existence of a Wi-Fi network is required in the space where the device will be working;
• The device must be installed behind a normal switch, inside the junction box, passing all light control to
be performed by the device.

6A 6B
ENEN
05. CONFIGURATION
RESET
05. CONFIGURATION
OPERATION SETTINGS
SWITCH MODE
• PULSE
Changes the state whenever the pulse switch is pressed.
• EDGE MODE
Changes the state (ON or OFF) whenever the switch
changes position.
Ex: If the wall switch is in the OFF position and the light
is ON, changing the switch to the ON position will turn
the light OFF.
• FOLLOWING MODE
It changes the state depending on the position of the switch, it works like a normal switch.
Ex: If the wall switch is in the OFF position and the light is ON, switching the switch to the ON position will
not change the light status. If you change it back to the OFF position then it will turn off the light.
1 • Open MCONNECT app.
2 • Login.
3 • On the home page press the "+" button at the top right.
4 • Press Add new MCONNECT.
5 • Accept all requested permissions.
6 • Turn on the power.
7 • Check that the module is in pairing mode (flashing purple).
Note • if it is not in pairing mode it is necessary to reset.
8 • Read the QR Code on the module box.
9 • If you prefer or don't have the QR Code, can change the button to Scan
nearby and select the module in the devices found.
10 • Enter the name and password of the Wifi network you are connected to.
11 • Wait for add process be complete.
ADD MODULE IN IN THE APP
1 • Press on the device you want to remove.
2 • Press on the icon with a gear symbol on the upper right
side of the screen.
3 • Press Remove MCONNECT.
4 • Confirm.
REMOVE MODULE FROM THE APP
Reset button
When resetting, the device is no longer connected to the
account it is associated with in the application.
Press the reset button until the LED changes to pairing
mode (flashing purple), which will confirm successful
operation.
06. TROUBLESHOOTING
INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS
PROBLEM SOLUTION
The LED reader does not light up Check that the power is connected correctly.
The module is not in pairing mode
(LED flashing purple) and I haven't
configured it yet
Press the Reset button located on the back of the
module, until it switches to pairing mode.
The module has the red LED
Make sure the network you configured the module on is
available.
Check if you have coverage of the network to which the
module is connected.
Check if the network you have configured the module has
Internet access.
The module has the blue LED Check if the network you configure the module has
Internet accesst.
The output does not change state Check that the connections are correct.
The switch does not change the state
output
Make sure the connections are correct.
Check the App to confirm the switch mode is in the
correct mode.
