Motorola VERVE CAM User manual

en
VERVE
CAM/CAM+
Action
Accessories
Pack
User Guide

Your Action Pack 1
en
Yo u r A c t i o n P a c k
Box Contents
• VerveCam Tag with pre-installed CR2032
battery and VerveCam Tag opener
•BikeMount
•HeadMount
•HelmetMount
Additional accessories can be purchased separately
from www.verve.life
VerveCam Tag Bike Mount
Head Mount Helmet Mount

2 VerveCam Tag en
VerveCam Tag
VerveCam Tag works as a remote control for your
camera. You can pair VerveCam Tag with
multiple cameras.
Remove Plastic Strip to Power On
The device uses a replaceable battery (CR2032).
The average battery life is up to 6 months. Replace
the battery if VerveCam Tag does not respond
Replace VerveCam Tag Battery
1. Remove the battery cover using the supplied
opener.
2. Slip the opener into the slot on the back of
VerveCam Tag.
3. Gently twist the opener to pop open the
cover. Once the cover starts to open, work
your way carefully around the cover until it
pops off.

VerveCam Tag 3
en
4. Insert the battery (model: CR2032) with
positive pole (+) facing upwards into the
battery compartment.
5. Position the back cover over the battery
compartment and press down around the
edges until you hear it click into its place.
6. VerveCam Tag powers on automatically when
the battery is installed correctly.
Pair VerveCam Tag with your Camera
1. Keep the camera in power down mode.
To power down the camera, hold down the
POWER / MODE button 0 for 3 seconds.
You will hear a voice prompt indicating that
the camera is powering off before the LED
indicator goes off.
2. Hold down the camera’s SHUTTER/
SELECT button for 3 seconds to enter
pairing mode.
The LED indicator flashes in RED and BLUE.
3. Hold down the PAIR/SHUTTER button on
VerveCam Tag for 3 seconds to start pairing.
4. Once paired, VerveCam Tag will emit 2
beep tones and the LED indicator on the
camera stops flashing.
back cover
PAIR/SHUTTER button
VerveCam Tag

4 VerveCam Tag en
Un-Pair VerveCam Tag with your
Camera
When VerveCam Tag is paired with the camera:
1. Press the SHUTTER/SELECT button on the
camera to stop pairing.
2. Hold down the SHUTTER/SELECT button
on the camera for 2 seconds to unpair it with
VerveCam Tag.
Using VerveCam Tag as a Remote
Control
The PAIR/SHUTTER button on VerveCam Tag
works like the SHUTTER/SELECT button on
your camera.
You can press the PAIR/SHUTTER button on
VerveCam Tag to:
Make sure that the camera is powered On or in
Standby mode. VerveCam Tag cannot wake up
the camera when it is powered off.
With VerveCam Tag, you can shoot remotely up
to approximately 20 meters (65 feet) away from
the camera.
If you have paired VerveCam Tag with multiple
cameras, pressing the PAIR/SHUTTER button on
VerveCam Tag can trigger all the paired cameras
to take photo or video at once.
•Takephoto
• Start and Stop video recording
• Wake up the camera from standby mode

Bike Mount 5
en
Bike Mount
The Bike Mount fits most bicycle handlebars
measuring up to 30 - 31.8 mm in diameter.
1. Release the 2 screws on each end of
mounting bracket (A) with the supplied allen
key (C).
2. Fix the mounting bracket (A) onto the
handlebar of your bike and secure the other
part of the mounting bracket by tightening
the 2 screws back in place. Make sure to
align the swivel side to the front of your bike.
3. With the waterproof casing or universal
tripod mount fixed onto the camera, fasten
the camera mount (B) to the waterproof
casing or universal tripod mount.
4. Release the screw from the swivel end of
mounting bracket (A) with the allen key (C)
and slot in the camera mount (B).
5. Tighten the screw back into the swivel end of
the mounting bracket (A).
6. You can now turn on the camera and adjust
the viewing angle accordingly.
ABC

6 Head Mount en
Head Mount
Capture photos or the videos while reeling in your
big catch or playing with your pets has never been
easier. The Head Mount can be used for any
activities where you need to be “hands free” from
your camera.
1. Put on the Head Strap (A) and adjust the
length of the strap so that it fits your head
comfortably.
2. With the waterproof casing or universal
tripod mount fixed onto the camera, fasten
the camera mount (B) to the waterproof
casing or universal tripod mount.
3. Slot the swivel end of the camera mount (B)
into the swivel end of the head strap (A).
4. Use the bolt (C) to fasten the swivel ends to
secure the whole assembly.
5. You can now turn on the camera and adjust
the viewing angle accordingly.
A
BC
(share with Helmet Mount)

Helmet Mount 7
en
Helmet Mount
Capture every moment while you are rock
climbing or even sky diving.
1. Wrap the helmet strap (A) around your
helmet and secure it tightly using the buckle
provided.
2. Fasten the clip (B) to Helmet strap (A).
3. With the waterproof casing or universal
tripod mount fixed onto the camera, fasten
the camera mount (D) to the waterproof
casing or universal tripod mount.
4. Slot the swivel end of the camera mount (D)
into the swivel end of clip (B).
5. Use the bolt (C) to fasten the swivel ends to
secure the whole assembly.
6. You can now turn on the camera and adjust
the viewing angle accordingly.
A
BCD
(share with Head Mount)

8 Help & more en
Help & more
If your product is not working properly....
1. Read this User Guide.
2. Visit our website: www.verve.life/contact
3. Contact Customer Service at
Consumer Products and Accessories Limited Warranty
Thank you for purchasing this Motorola branded product
manufactured under license by Binatone Electronics International
LTD ("BINATONE").
What Does this Warranty Cover?
Subject to the exclusions contained below, BINATONE warrants
that this Motorola branded product ("Product") or certified
accessory ("Accessory") sold for use with this product that it
manufactured to be free from defects in materials and
workmanship under normal consumer usage for the period
outlined below. This Warranty is your exclusive warranty and is not
transferable.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY HAVE OTHER RIGHTS THAT VARY BY STATE, PROVINCE OR
COUNTRY. FOR CONSUMERS WHO ARE COVERED BY CONSUMER
PROTECTION LAWS OR REGULATIONS IN THEIR COUNTRY OF
PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF RESIDENCE,
THE BENEFITS CONFERRED BY THIS LIMITED WARRANTY ARE IN
ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY SUCH
CONSUMER PROTECTION LAWS AND REGULATIONS. FOR A FULL
UNDERSTANDING OF YOUR RIGHTS YOU SHOULD CONSULT THE
LAWS OFYOUR COUNTRY, PROVINCE OR STATE.
For UK: [phone] (UK only)*
*Calls cost 7p per minute plus your telephone
company’s access charge
[phone] (ROI)
For Europe: [phone]
For South
Africa:
Safe Motion
Solutions
011 7917225
For Dubai: Life Time Trendz
General Trading
LLC
[e-mail]
[phone]
For Turkey: Müşteri Hizmetleri teknikservi[email protected]
[phone]
For Singapore: Alcom SG [phone]
For Hong
Kong:
HK Good Century +(852)3619 6499
For China: China MT Digital 400-889-9090

Help & more 9
en
Who is covered?
This Warranty extends only to the first consumer purchaser, and is not
transferable.
What will BINATONE do?
BINATONE or its authorised distributor at its option and within a
commercially reasonable time, will at no charge repair or replace
any Products or Accessories that do not conform to this Warranty.
We may use functionally equivalent reconditioned/ refurbished/
pre-owned or new Products, Accessories or parts.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR
REPLACEMENT PROVIDED UNDER THIS EXPRESS LIMITED
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND
IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED. IN NO EVENT SHALL MOTOROLA OR BINATONE BE LIABLE,
WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE)
FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS
OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE
PRODUCTS OR ACCESSORIES TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.
Some jurisdictions do not allow the limitation or exclusion of
incidental or consequential damages, or limitation on the length of
an implied warranty, so the above limitations or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you
may also have other rights that vary from one jurisdiction to
another.
Exclusions
Normal Wear and Tear. Periodic maintenance, repair and
replacement of parts due to normal wear and tear are excluded
from coverage.
Products Covered Length of Coverage
Consumer Products One (1) year from the date of the
products original purchase by the
first consumer purchaser of the
product.
Consumer Accessories Ninety (90) days from the date of the
accessories original purchase by the
first consumer purchaser of the
product.
Consumer Products and
Accessories that are
Repaired or Replaced
The balance of the original warranty
or for Ninety (90) days from the date
returned to the consumer,
whichever is longer.

10 Help & more en
Batteries. Only batteries whose fully charged capacity falls below
80% of their rated capacity and batteries that leak are covered by
this Warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the
product resulting from misuse; (b) contact with liquid, water, rain,
extreme humidity or heavy perspiration, sand, dirt or the like,
extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of MOTOROLA or BINATONE, are excluded from coverage.
Use of Non-Motorola branded Products and Accessories.
Defects or damage that result from the use of Non-Motorola
branded or certified Products or Accessories or other peripheral
equipment are excluded from coverage.
Unauthorised Service or Modification. Defects or damages
resulting from service, testing, adjustment, installation,
maintenance, alteration, or modification in any way by someone
other than MOTOROLA, BINATONE or its authorised service
centres, are excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers
or date tags that have been removed, altered or obliterated; (b)
broken seals or that show evidence of tampering; (c) mismatched
board serial numbers; or (d) nonconforming or non-Motorola
branded housings, or parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of
Products or Accessories due to any communication service or
signal you may subscribe to or use with the Products or
Accessories is excluded from coverage.
How to Obtain Warranty Service or Other Information?
To obtain service or information, please call:
For UK: [phone] (UK only)*
*Calls cost 7p per minute plus your telephone
company’s access charge
[phone] (ROI)
For Europe: [phone]
For South
Africa:
Safe Motion
Solutions
011 7917225
For Dubai: Life Time Trendz
General Trading
LLC
[e-mail]
[phone]
For Turkey: Müşteri Hizmetleri teknikservi[email protected]
[phone]
For Singapore: Alcom SG [phone]
For Hong
Kong:
HK Good Century +(852)3619 6499
For China: China MT Digital 400-889-9090

Help & more 11
en
You will receive instructions on how to ship the Products or
Accessories at your expense and risk, to a BINATONE Authorised
Repair Centre.
To obtain service, you must include: (a) the Product or Accessory;
(b) the original proof of purchase (receipt) which includes the date,
place and seller of the Product; (c) if a warranty card was included
in your box, a completed warranty card showing the serial number
of the Product; (d) a written description of the problem; and, most
importantly; (e) your address and telephone number.
These terms and conditions constitute the complete warranty
agreement between you and BINATONE regarding the Products
or Accessories purchased by you, and supersede any prior
agreement or representations, including representations made in
any literature publications or promotional materials issued by
BINATONE or representations made by any agent employee or
staff of BINATONE, that may have been made in connection with
the said purchase.
CE DECLARATION
This product is in compliance with the essential requirements and
other relevant provisions of the R&TTE directive 1999/5/EC.
Download User Guide from website:
www.verve.life

www.motorolahome.com
www.verve.life
RECYCLING
This product bears the selective sorting symbol for
Waste electrical and electronic equipment (WEEE).This
means that this product must be handled pursuant to
European directive 2012/19/EU in order to be recycled
or dismantled to minimise its impact on the
environment.
User has the choice to give his product to a competent
recycling organisation or to the retailer when he buys a
new electrical or electronic equipment.
DC Voltage
Manufactured, distributed, or sold by Binatone Electronics International
LTD., official licensee for this product. MOTOROLA and the Stylised M
Logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC. and are used under license. Apple logo is a trademark of
Apple Inc., registered in the U.S. and other countries. App Store is a
service mark of Apple Inc. Google Play and Android are trademarks of
Google Inc. All other trademarks are the property of their respective
owners. © 2017 Motorola Mobility LLC. All rights reserved.
UK_EU_ROW_EN Version 1.0
Printed in China
Model number: CA001-AP
