Welcome...
to your new Motorola O2 Digital Cordless Telephone with
digital answering machine!
• Ultra long cordless 360° range, up to 1km.1
• Rugged design and sturdy composition makes your Motorola O2 phone
ideal for outdoor use.
• Dust and water resistant. Submersible in up to 1 meter of water for up to 30
minutes. Perfect for very wet environments (IP67 rated).
• Belt clip or lanyard options for flexibility when carrying around.
• Wall mountable location free base and handset charger.
• Zoom font when dialling for improved legibility.
• Inductive charging.
• Register up to 11 handsets to a single base and register each handset with
up to 4 dierent bases.
• Answering machine with up to 25 minutes digital recording time.
• All handsets are fully cordless for locating anywhere within range of.
• 200 Name and number phonebook.
• Copy phonebook entries between handsets.
• Caller ID shows you who’s calling and see details of the last 50 callers in a
Calls Lists.2
• Make internal calls, transfer external calls, hold a 3-way conversation
between two internal callers and an external caller.
Need help?
If you have any problems setting up or using your O2, please contact
Customer Services on:
Luxembourg: 8002-5704
The Netherlands: 0800-0226749
Belgium: 0800-79171
Alternatively, you may find the answer in the ‘Help’ section at the back of
this guide.
1When using the long antenna and when there is a clear line of sight
between the base and handset. Any obstruction between the base and
handset will reduce the range significantly.
2 You must subscribe to your network provider’s Caller ID service for this
feature to work. A subscription fee may be payable.
Please note that this equipment is not designed for making emergency
telephone calls when the power fails. Alternative arrangements should be
made for access to emergency services.

This User Guide provides you with all the information
you need to get the most from your phone.
Before you make your first call you will need to set
up your phone. Follow the simple instructions in
‘Getting Started’, on the next few pages.
Important
Only use the telephone line cord supplied.
Got everything?
• O2 handset with standard
antenna
• 750mAh Ni-MH battery pack (pre
installed)
• O2 base • Telephone line cord
• O2 charger • Long range antenna
• Power adaptor for the base • 1 x Belt clip (pre installed)
• Power adaptor for the charger • Screws and plugs for wall mounting
If you have purchased an O2 multiple pack you will also have the
following additional items:
• O2 handset with standard
antenna
• 750mAh Ni-MH battery pack (pre
installed)
• O2 charger • Long range antenna
• Power adaptor for the charger • 1 x Belt clip (pre installed)
• Screws and plugs for wall mounting
For a better tomorrow
We make every eort through our design, research, engineering and supply
chain management to make better products for everyone, focusing on both
social and environmental responsibility.
• Meets and / or exceeds EMEA environmental regulatory requirements.
• Eco friendly packaging with a minimum 20% post consumer recycled
content.
• Phone housing is built with a minimum of 15% post consumer recycled
content plastic.
• Energy ecient charger that meets EU Code of Conduct requirements.
• ECO mode function which reduces the transmitted power and energy
consumption, please refer to page 37.
