Motorola V3 RAZR 05 User manual

Level 1 and 2 Service Manual
6809500A08-O
V3 RAZR 05
Digital Wireless Telephone
GSM 850/900/1800/1900 MHz GPRS

6809500A08-O November 09, 2005 3
Level 1 and 2 Service Manual Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Regulatory Agency Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Computer Program Copyrights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About This Service Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warranty Service Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Parts Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Controls, Indicators, and Input / Output (I/O) Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
User Interface Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Alert Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Battery Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Tools and Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Removing and Replacing the Battery Cover and Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Removing and Replacing the Subscriber Identity Module (SIM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing and Replacing the Rear Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Removing and Replacing the Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Removing and Replacing the Transceiver Board Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Removing and Replacing the Flip Assembly Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Removing and Replacing the Camera Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Removing and Replacing the Display Module Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Removing and Replacing the CLI Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Subscriber Identity Module (SIM) and Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Personality Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Manual Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Manual Test Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Programming: Software Upgrade and Flexing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Exploded View Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Exploded View Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1 and 2
Contents
V3 RAZR 05
6809500A08-O

4 November 09, 2005 6809500A08-O
Contents V3 RAZR 05

6809500A08-O November 09, 2005 5
Level 1 and 2 Service Manual Introduction
Introduction
Motorola®Inc. maintains a worldwide organization that is dedicated to provide
responsive, full-service customer support. Motorola products are serviced by an
international network of company-operated product-care centers as well as
authorized independent service firms.
Available on a contract basis, Motorola Inc. offers comprehensive maintenance and
installation programs that allow customers to meet requirements for reliable,
continuous communications.
To learn more about the wide range of Motorola service programs, contact your local
Motorola products representative or the nearest Customer Service Manager.
Product Identification
Motorola products are identified by the model number on a label usually located
under the battery. Use the entire model number when inquiring about the product.
Numbers are also assigned to chassis and kits. Use these numbers when requesting
information or ordering replacement parts.
Product Names
Product names are listed on the front cover. Product names are subject to change
without notice. Some product names, as well as some frequency bands, are available
only in certain markets.
Product Changes
When electrical, mechanical or production changes are incorporated into Motorola
products, a revision letter is assigned to the chassis or kit affected, for example;
-A, -B, or -C, and so on.
The chassis or kit number, complete with revision number, is imprinted during
production. The revision letter is an integral part of the chassis or kit number and
is also listed on schematic diagrams and printed-circuit board layouts.
Regulatory Agency Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions:
• This device may not cause any harmful interference
• This device must accept interference received, including interference that may
cause undesired operation
This class B device also complies with all requirements of the Canadian
Interference-Causing Equipment Regulations (ICES-003).
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement
sur le matériel brouilleur du Canada.
1 and 2
V3 RAZR 05
6809500A08-O

6November 09, 2005 6809500A08-O
Introduction V3 RAZR 05
Computer Program Copyrights
The Motorola products described in this manual may include Motorola computer
programs stored in semiconductor memories or other media that are copyrighted
with all rights reserved worldwide to Motorola. Laws in the United States and other
countries preserve for Motorola, Inc. certain exclusive rights to the copyrighted
computer programs, including the exclusive right to copy, reproduce, modify,
decompile, disassemble, and reverse-engineer the Motorola computer programs in
any manner or form without Motorola's prior written consent. Furthermore, the
purchase of Motorola products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license or rights under the copyrights,
patents, or patent applications of Motorola, except for a nonexclusive license to use
the Motorola product and the Motorola computer programs with the Motorola
product.
About This Service Manual
Use of this manual assures proper installation, operation, and maintenance of
Motorola products and equipment. It contains all service information required for
the equipment described and is current as of the printing date. Refer questions
about this manual to the nearest Customer Service Manager.
Audience
This manual aids service personnel in testing and repairing V3 telephones. Service
personnel should be familiar with electronic assembly, testing, and troubleshooting
methods, and with the operation and use of associated test equipment.
Scope
This manual provides basic information relating to V3 telephones, and also provides
procedures and processes for repairing the phones at Level 1 and 2 service centers
including:
•Unitswapout
• Repairing of mechanical faults
• Basic modular troubleshooting
• Testing and verification of unit functionality
• Initiate warranty claims and send faulty modules to Level 3 or 4 repair
centers

6809500A08-O November 09, 2005 7
Level 1 and 2 Service Manual Introduction
Conventions
The following special characters and typefaces, are used in this manual to
emphasize certain types of information.
Warranty Service Policy
The product is sold with the standard 12-month warranty terms and conditions.
Accidental damage, misuse, and extended warranties offered by retailers are not
supported under warranty. Non-warranty repairs are available at agreed fixed
repair prices.
Out-of-Box Failure Policy
The standard out-of-box failure criteria applies. Return customer units that fail
very early on after the date of sale to Manufacturing for root cause analysis, to guard
against epidemic criteria. Manufacturing to bear the costs of early life failure.
Product Support
Customer’s original units will be repaired but not refurbished as standard.
Appointed Motorola Service Hubs will perform warranty and non-warranty field
service for level 2 (assemblies) and level 3 (limited PCB component). Motorola High
Tech Centers will perform level-4 (full component) repairs.
Customer Support
Customer support is available through dedicated Call Centers and in-country help
desks. Product Service training is available through the local Motorola Support
Center.
➧Note: Emphasizes additional information pertinent to the subject
matter.
GCaution: Emphasizes information about actions which may result in
equipment damage.
EWarning: Emphasizes information about actions which may result
in personal injury.
MKeys to be pressed are represented graphically. For example, instead of “Press
the Menu Key”, you will see “Press M”.
Information from a screen is shown in text as similar as possible to what
displays on the screen. For example, PHONEBOOK.
Information that you need to type is printed in boldface type.

8November 09, 2005 6809500A08-O
Introduction V3 RAZR 05
Parts Replacement
When ordering replacement parts or equipment, include the Motorola part number
and description used in the service manual.
When the Motorola part number of a component is not known, use the product model
number or other related major assembly along with a description of the related
major assembly and of the component in question.
In the U.S.A., to contact Motorola, Inc. on your TTY, call: 800-793-7834.
Accessories and Aftermarket Division (AAD)
Order replacement parts, test equipment, and manuals from AAD.
U.S.A. Outside U.S.A.
Phone: [phone] Phone: [phone]
FAX: [phone] FAX: [phone]
Website: http://businessonline.motorola.com
EMEA
Phone: [phone]
Website: http://emeaonline.motorola.com
Asia
Phone: [phone]
Website: http://asiaonline.motorola.com

6809500A08-O November 09, 2005 9
Level 1 and 2 Service Manual Specifications
Specifications
General Function Specification
Frequency Range GSM 850 824-848 MHz Tx
869-893 MHz Rx
Frequency Range GSM 900 880-915 MHz Tx (with EGSM)
925-960 MHZ Rx
Frequency Range DCS 1800 1710-1785 MHz Tx
1805-1880 MHz Rx
Frequency Range PCS 1900 1850-1910 MHz Tx
1930-1990 MHz Rx
Channel Spacing 200 kHz
Channels 174 EGSM, 374 DCS, 374 PCS, 124 GSM 850 carriers with
8 channels per carrier
Modulation GMSK at BT = 0.3
Transmitter Phase Accuracy 5 Degrees RMS, 20 Degrees peak
Duplex Spacing 45 MHz
Frequency Stability ± 0.10 ppm of the downlink frequency (Rx)
Operating Voltage +3.2V dc to +5.5V dc (battery)
+4.8V dc to +6.5V dc (external connector)
Transmit Current Drain 101-260 mA average talk current drain
Stand-by Current drain 5 mA (DRX2), 2 mA (DXR9) typical
Temperature Range -10° C to +55° C (+15° F to +130° F)
Dimensions, with 500 mAh Li Ion
battery
53 mm x 98 mm x 13.9 mm
(2.08 inches x 3.85 inches x 0.54 inches)
Size (Volume) 65 cc (3.96 in3), with battery
Weight 90 grams (3.17 oz), with battery
Battery Life, with standard 700 mAh
Li-Ion Battery
Talk Time 6-8 hours
Standby time 6.5 -10.4 days
All talk and standby times are approximate and depend on
network configuration, signal strength, and features selected.
Standby times are quoted as a range from DRX=2 to DRX=9.
Talk times are quoted as a range from DTX off to DTX on.
Battery Charge Time 4 hours to 90% of 700 mAh capacity
Alert volume Max 95 dB @5cm, 0.5 Watts input
Transmitter Function Specification
RF Power Output 32 dBm nominal GSM 850/900,
29 dBm nominal GSM 1800/1900
Output Impedance 50 ohms nominal
Spurious Emissions -36 dBm from 0.1 to 1 GHz, -30 dBm from 1 to 4 GHz
Receiver Function Specification
Receive Sensitivity Better than -103 dBm
RX Bit Error Rate (100k bits) Type II < 2%
Speech Coding Function Specification
Speech Coding Type Regular pulse excitation/linear predictive coding with long term
prediction (RPE LPC with LTP)
Bit Rate 13.0 kbps

10 November 09, 2005 6809500A08-O
Specifications V3 RAZR 05
Frame Duration 20 ms
Block Length 260 bits
Classes Class 1 bits = 182 bits; Class 2 bits = 78 bits
Bit Rate with FEC Encoding 22.8 kbps
Speech Coding Function Specification

6809500A08-O November 09, 2005 11
Level 1 and 2 Service Manual Product Overview
Product Overview
Motorola V3 telephones represent the thinnest, compact and lightweight global
system for mobile communications (GSM) general packet radio service (GPRS)
wireless application protocol (WAP)-enabled mobile phones. The V3 phones
incorporate a new user interface (UI) for easier operation, allows short message
service (SMS) text messaging, and includes personal information manager (PIM)
functionality.
The V3 is a quad-band phone that allows roaming within the GSM 900 MHz, GSM
850 MHz, 1800 MHz digital cellular system (DCS), and 1900 MHz PCS bands.
V3 telephones support GPRS and SMS in addition to traditional circuit switched
transport technologies.
V3 telephones have a clam form factor. They feature an anodized aluminum housing
and have an externally viewable 96 x 80 pixel 4K CSTN display for caller
identification and date/time, an internal 176 x 220 pixel 64K TFT display, and the
speaker located in the flip. The bottom part of the clam (front housing) contains the
keypad, transceiver printed circuit board (PCB), microphone, flex connection,
external accessory connector, smart button, volume buttons, and voice button. The
standard 700 mAh Lithium Ion (Li Ion) battery fits behind a removable back cover.
The phone accepts both 3V and 1.8V mini subscriber identity module (SIM) cards
which fit into the SIM holder next to the battery. The antenna is internal.
Inexpensive direct connection to a computer or handheld device via RS232 USB or
Bluetooth® for data and fax calls, and for synchronizing phonebook entries with
Mobile Phone Tools software, can be accomplished by using the optional data cable
and soft modem.
Features
V3 telephones use advanced, self-contained, sealed, custom integrated circuits to
perform the complex functions required for GSM GPRS communication. Aside from
the space and weight advantage, microcircuits enhance basic reliability, simplify
maintenance, and provide a wide variety of operational functions.
Features available in this family of telephones include:
• GSM 850/900/1800/1900 MHz GPRS (2U/4D)
• Built in VGA Camera (640x480 pixels)
• 64K Thin Film Transistor (TFT) Active Color Display
• External color CLI Display
• Polyphonic Speaker
•SpeakerPhone
• Bluetooth™
• 5MB User Memory

12 November 09, 2005 6809500A08-O
Product Overview V3 RAZR 05
Speaker Dependant Voice Activation and Voice Note Recording
Voice tags can be used for voice dialing up to 20 phone numbers in the phone book
and for creating up to 5 voice shortcuts for menu items. The phone must be “trained”
by the voice tag being read into the phone’s memory twice before it is recognized.
You can add voice tags to the phone’s memory using the usual name addition
methods (i.e., via the phone book menu structure or with the shortcut editor).
V3 telephones also include a voice recorder that allows up to 2 minutes of personal
messages to be recorded. This feature has a complete set of record, playback, and
management tools that make it easy to store and maintain a list of personal memos.
Wireless Access Protocol (WAP) 1.1 Compliancy
In the WAP environment, access to the Internet is initiated in wireless markup
language (WML), which is derived from hypertext markup language (HTML). The
request is passed to a WAP gateway which retrieves the information from the server
in standard HTML (subsequently filtered to WML) or directly in WML if available.
The information is then passed to the mobile subscriber via the mobile network.
The V3 microbrowser can be configured for baud, idle timeout, line type, phone
number, and connection type.
SIM Application ToolkitTM - Class 2
SIM Application Toolkit is a value-added service delivery mechanism that allows
GSM operators to customize the services they offer their customers, from the
occasional user who requests sports news and traffic alerts, to a high call time
business user who receives stock alerts and checks flight times. Operators can now
create their own value-added services menu quickly and easily in the phone. The
customized menu will appear as the first menu and may be updated over-the-air
with new services when customers request them.
➧You cannot place or receive calls while adding voice tags to the phone’s memory.
➧Because the GSM standard does not provide the option to store voice tags onto the
SIM card, voice tags are added to the phone’s memory.
➧Bitmap image data will download as text. If the image is larger than the screen,
only part of the image will display.
➧When the user receives a call while in browser mode, the browser will pause and
allow the user to resume after completing the call.

6809500A08-O November 09, 2005 13
Level 1 and 2 Service Manual Product Overview
Simplified Text Entry
There are three different ways to enter text using the phone keypad:
• iTAP™ predictive text entry. Press a key to generate a character and a
dynamic dictionary uses this to build and display a set of word or name
options. The iTAP™ feature may not be available on the phone in all lan-
guages.
• Tap. Press a key to generate a character.
• Numeric. The keypad produces numeric characters only. For some text areas
this is the only method available; for example, phone numbers.
Caller Line Identification
Upon receipt of a call, the calling party’s phone number is compared to the phone
book. If the number matches a phone book entry, that name will be displayed. If
there is no phone book entry, the incoming phone number will be displayed. In the
event that no caller identification information is available, the Incoming Call
message is displayed.
Other Features
Detailed descriptions of these and other V3 features can be found in the appropriate
user’s guide listed in the “Related Publications” section toward the end of this
manual.
➧User must subscribe to a caller line identification service through their service
provider.

14 November 09, 2005 6809500A08-O
General Operation V3 RAZR 05
General Operation
Controls, Indicators, and Input / Output (I/O) Connections
The V3 series telephone’s controls are located on the sides of the flip and on the
keypad. Indicators, in the form of icons, are displayed on the LCD (see Figure 2).
V3 phones have an audible alert transducer on the top and I/O connectors,
consisting of a charger/accessory port, located on the side of the phone. See Figure 1.
“Soft keys” refer to non-labeled keys that correspond to text options displayed on
the screen. The left and right soft keys perform the function shown in the corners
031935o
Figure 1. Controls, indicators, and I/O
040128o
Left Soft Key
Perform function
in lower left
display.
Voice Key
Create voice
records & voice
dial names.
Smart Key
Volume Keys
Operator Key
4-Way
Navigation Key
with Center
Select
Menu Key
Message Key
Right Soft Key
Perform function
in lower right
display.
Power & End Key
Turn phone
on/off, end calls,
exit menu
system.
Accessory
Connector Port
Insert charger &
phone
accessories.
Send Key
Make & answer
calls.
Camera Lens Bluetooth ®
LED Indicator
Smart Key
Take self-portrait
photo with
camera when flip
is closed.
External Display
View incoming
call information,
use as camera
viewfinder when
flip is closed.

6809500A08-O November 09, 2005 15
Level 1 and 2 Service Manual General Operation
of the display. The right key will usually select an option whereas the left key will
usually exit a function or return to a previous screen.
The menu key opens the initial menu structure, or allows access to a submenu
whenever Mappears on the display.
Color Display
The V3 wireless phones feature a 64k color Thin Film Transistor (TFT) 176x220
pixel display.
Display animation makes the phone’s menus move smoothly as the user scrolls up
and down. Turn animation off to conserve the battery.
Figure 2 shows some common icons displayed on the LCD.
•Signal Strength Indicator. Shows the strength of the phone’s connection
with the network. Calls cannot be sent or received when the “no signal” indica-
tor is displayed.
•In Use Indicator. Appears when a call is in progress.
•Roam Indicator.5Appears when the phone uses another network system out-
side the user’s home network. When leaving the home network area, the phone
040146o, 040147o
Figure 2. Icon Indicators
➧Whether a phone displays all indicators depends on the programming and services
to which the user subscribes.
Menu Indicator
Service Provider
10/15/03
STYLES CAMERA
Left Soft Key
Label
Right Soft Key
Label
Date
Recent Calls
Messages
Clock
Browser
Phonebook
Service Provider
10/15/04
STYLES CAMERA
3. Signal
Strength
8. Battery
Level
2. GPRS 9. Ring Style
1. Data
Transmission
6. Messaging
Presence
7. Message 4. Roam
5. Call
Status

16 November 09, 2005 6809500A08-O
General Operation V3 RAZR 05
roams, or seeks another network.
•Message Waiting Indicator.5Appears when the phone receives a text mes-
sage. This is a network-dependent feature.
•Voice Message Waiting Indicator.1Appears when a voicemail message is
received. This is a network-dependent feature.
•Battery Level Indicator. Shows the amount of charge left in the battery. The
more segments visible, the greater the charge. Recharge the battery as soon as
possible when the Low Battery warning message appears.
•Clock. Shows the current date and time.
•Menu Indicator. Indicates the user can press the menu soft key to open a
menu.
•Alert Setting Indicator. Shows the current selected alert. The default alert
setting is a ringer.
User Interface Menu Structure
Figure 3 shows the telephone menu structure.
1. Network, subscription and SIM card or service provider dependent feature. Not available in all areas.
Figure 3. Menu Structure
n Phonebook
s Recent Calls
• Received Calls
• Dialed Calls
• Notepad
•CallTimes
•CallCost
• Data Times
• Data Volumes
e Messages
• Create Message
•EmailMsgs
• Message Inbox
•Voicemail
• Browser Msgs
• Info Services
•QuickNotes
• Outbox
•Drafts
• MMS Templates
É Office Tools
• SIM Apps
•Calculator
• Datebook
• Shortcuts
• Voice Records
•AlarmClock
• Dialing Services
• Fixed Dial
• Service Dial
• Quick Dial
• Chat
Q Games & Apps
á Web Access
•Browser
• Web Shortcuts
• Stored Pages
•History
• Go To URL
•BrowserSetup
• Web Sessions
h Multimedia
•Themes
• Camera
•Pictures
• Sounds
• MotoMixer
• Videos
ã IM
w Settings
(see next page)
l Personalize
• Home Screen
• Main Menu
•Skin
•Greeting
• Wallpaper
• Screen Saver
• Quick Dial
t Ring Styles
•Style
•Style Detail
L Connection
• Bluetooth Link
•Sync
H Call Forward
•VoiceCalls
• Fax Calls
• Data Calls
• Cancel All
• Forward Status
U In-Call Setup
• In-Call Timer
•CallCostSetup
•MyCallerID
• Talk and Fax
•AnswerOptions
• Call Waiting
Z Initial Setup
• Time and Date
•1-TouchDial
• Display Timeout
• Backlight
• TTY Setup
•Scroll
• Language
• Brightness
•DTMF
•MasterReset
• Master Clear
m Phone Status
• My Tel. Numbers
• Credit Info/Available
• Active Line
• Battery Meter
• Other Information
S Headset
• Auto Answer
• Voice Dial
J Car Settings
• Auto Answer
• Auto Handsfree
j Network
• New Network
•NetworkSetup
• Available Networks
•MyNetworkList
• Service Tone
• Call Drop Tone
u Security
• Phone Lock
• Lock Application
•FixedDial
• Call Barring
• SIM PIN
•NewPasswords
• Certificate Mgmt
c Java Settings
• Java App Loader
• Java System
• Delete All Apps
• App Vibration
• App Volume
• App Priority
• App Backlight
• Set Standby App
• DNS IP
Settings MenuMain Menu

6809500A08-O November 09, 2005 17
Level 1 and 2 Service Manual General Operation
Alert Settings
V3 telephones include up to 32 preset alert tones and vibrations that can be applied
to all alert events at the same time.
Battery Function
Battery Gauge
The telephone displays a battery level indicator icon in the idle screen to indicate
the battery charge level. The gauge shows four levels: 100%, 66%, 33%, and Low
Battery.
Battery Removal
Removing the battery causes the device to immediately shut down and any pending
work (for example, partially entered phone book entries or outgoing messages) is
lost.
Operation
For detailed operating instructions, refer to the appropriate User’s Guide listed in
the Related Publications section toward the end of this manual.
➧Pressing either volume key will mute the alert.
➧To ensure proper memory retention, turn OFF the phone before removing the
battery. Immediately replace the old battery with a fresh battery.
GIf the battery is removed while receiving a message, the message will be lost.

18 November 09, 2005 6809500A08-O
General Operation V3 RAZR 05

6809500A08-O November 09, 2005 19
Level 1 and 2 Service Manual Tools and Test Equipment
Tools and Test Equipment
The following table lists tools and test equipment recommended for disassembly
and reassembly of V3 telephones. Use either the listed items or equivalents.
Table 1. General Test Equipment and Tools
Motorola Part Number1Description Application
RSX4043-A Torque Driver Used to remove and replace screws
—Torque Driver Bit T-5 Plus, Apex 440-6IP
Torx Plus or equivalent Used with torque driver
See Table 7 Rapid Charger Used to charge battery and to power
device
0180386A82
Antistatic Mat Kit (includes 66-80387A95
antistatic mat, 66-80334B36 ground
cord, and 42-80385A59 wrist band)
Provides protection from damage to
device caused by electrostatic discharge
(ESD)
6680388B67 Disassembly tool, plastic with flat and
pointed ends (manual opening tool)
Used during assembly/disassembly of
device
6680388B01 Tweezers, plastic Used during assembly/disassembly
— Digital Multimeter, HP34401A2Used to measure battery voltage
8102430Z04 GSM / DCS Test SIM Used to enable manual test mode
1. To order in North America, contact Motorola Aftermarket and Accessories Division (AAD) at [phone] or
FAX [phone]; Internationally, AAD can be reached by calling [phone] or faxing [phone].
2. Not available from Motorola. To order, contact Hewlett Packard at [phone].
1 and 2
V3 RAZR 05
6809500A08-O

20 November 09, 2005 6809500A08-O
Disassembly V3 RAZR 05
Disassembly
The procedures in this section provide instructions for the disassembly of V3
telephones. Tools and equipment used for the phone are listed in Table 1, preceding.
Removing and Replacing the Battery Cover and Battery
1. Ensure the phone is turned off.
2. Press in and hold the battery door latch as shown in Figure 1.
3. Rotate the battery cover upward and lift it completely off the phone.
GMany of the integrated devices used in this equipment are vulnerable to damage
from electrostatic discharge (ESD). Ensure adequate static protection is in place
when handling, shipping, and servicing the internal components of this equipment.
GAvoid stressing the plastic in any way to avoid damage to either the plastic or
internal components.
EAll batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed terminals.
The conductive material may complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any charged battery, particularly when
placing it inside a pocket, purse, or other container with metal objects.
040698o
Figure 1. Removing the Battery Cover
Battery Cover
Battery Latch
