welcome
Your MOTO NAV ™ TN20/TN30 helps you find the best
route with GPS accuracy. Features and benefits
include:
• Hear directions and street names —Spoken
street names and turn-by-turn directions in
clear, easy to understand voice, eliminate
second-guessing when making a turn. You can
feel as confident as you would in your own
neighborhood.
• Save time and gas —Get there quickly and
avoid getting lost. Your MOTO
NAV
TN20/TN30 helps you find the best route with
GPS accuracy. If you miss your turn, it will
show you how to get back on track. Select
between fastest and shortest modes, or
bypass tolls, if you prefer.
• Find what you need —Locate your favorite
restaurant, nearest bank, or see what’s
available along your route. Search over a
million businesses and other points of interest
to find destinations while in-town or away.
• Make handsfree calls (TN30 only) —Connect
with your compatible Bluetooth® enabled
phone for handsfree calls. It works as a
speakerphone, displays caller ID on the
screen, and automatically mutes turn-by-turn
voice prompts while a call is in progress.
Navigation and handsfree calling helps you
keep your hands on the wheel, and eyes on
the road.
PND_UG.fm Page 1 Thursday, August 14, 2008 1:00 PM

2
Map View Screen
Map Control Icons
Here’s a quick guide for using the map view screen icons to control operation.
2
2
3
4
5
6
7
1
8
9
PND_UG.fm Page 2 Thursday, August 14, 2008 1:00 PM

3
1 Tap to view a smaller area in more detail.
Tap to view a larger area in less detail.
2 Tap to display main menu screen.
3
/
Tap to change map view display (3D or 2D).
4
/
Tap to adjust/mute/unmute volume.
5 Heading indicator.
6 Current street indicator (if GPS connection). If not, tap to display
GPS Information screen.
7 (TN30 only) Tap to make a handsfree call.
8
///
Battery indicator:
Connected to power source / Full / Partial / Low.
9 (TN30 only) Indicates Bluetooth on
PND_UG.fm Page 3 Thursday, August 14, 2008 1:00 PM

4
Route Screen
Here’s a quick guide for using the map view screen to view and control route information.
next
turn
current
location
route status bar
route
next
street
bar
lane information
PND_UG.fm Page 4 Thursday, August 14, 2008 1:00 PM

5
Tap the route status bar to switch between viewing:
• travel distance, time remaining, and estimated time of arrival,
• current street name, or
• current speed and altitude.
Tap the
next street bar to display route menu to:
• display driving directions,
• view route map overview, or
• cancel route.
Tap the
next turn icon to repeat audio turn instructions.
The
lane information icon displays all turns at an intersection.
PND_UG.fm Page 5 Thursday, August 14, 2008 1:00 PM

6
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.motorola.com
www.motorola.com/motonav
1-877-MOTOBLU (Motorola Bluetooth support)
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
The use of wireless devices and their accessories may be
prohibited or restricted in certain areas. Always obey the laws and
regulations on the use of these products.
All features, functionality, and other product specifications, as well
as the information contained in this user’s guide are based upon
the latest available information and are believed to be accurate at
the time of printing. Motorola reserves the right to change or
modify any information or specifications without notice or
obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. The Bluetooth trademarks are owned
by their proprietor and used by Motorola, Inc. under license.All
other product or service names are the property of their respective
owners.
© 2008 Destinator is a registered trademark of Intrinsyc Software
International, Inc. Unauthorized duplication is a violation of all
applicable laws. Other names and brands mentioned herein may
be the property of their respective owners. Patents pending.
Map data: © 1993 – 2007 NAVTEQ. All rights reserved.
© 2008 Motorola, Inc. All rights reserved.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United
States and other countries preserve for Motorola and third-party
software providers certain exclusive rights for copyrighted
software, such as the exclusive rights to distribute or reproduce
the copyrighted software. Accordingly, any copyrighted software
contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to
the extent allowed by law. Furthermore, the purchase of the
Motorola products shall not be deemed to grant either directly or
by implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Motorola or any
third-party software provider, except for the normal, non-exclusive,
royalty-free license to use that arises by operation of law in the
sale of a product.
Manual Number: 68000201366-A
Bluetooth QD ID: B014454
PND_UG.fm Page 6 Thursday, August 14, 2008 1:00 PM

7
Warning: Traffic laws and current traffic conditions must always
be observed and take precedence over the instructions issued by
the navigation system. The user should be aware of situations
where current traffic conditions and the instructions from the
navigation system may be in conflict.
The use of the navigation system does not relieve the user of
his/her responsibilities. The user is ultimately responsible for the
vehicle under his/her control and should be aware of the
surroundings at all times. For traffic safety reasons, it is
recommended that routes should be planned in a stationary
vehicle before starting a trip.
MOTOROLA IS NOT RESPONSIBLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, CONSEQUENTIAL, EXEMPLARY, SPECIAL, OR
PUNITIVE DAMAGES, OR OTHER DAMAGE ARISING OUT OF THE
USE OF, OR INABILITY TO USE, THIS PRODUCT. THIS INCLUDES
DAMAGE TO PROPERTY AND, TO THE EXTENT PERMITTED BY
LAW, DAMAGES FOR PERSONAL INJURY AND DEATH.
Laws in some areas prohibit the use of a cellular phone and other
devices when driving a motor vehicle. Please use the utmost care
in using your devices safely under all circumstances. It is the
responsibility of each user to be aware of and abide by any and all
local laws and ordinances, which may restrict the use of cellular
phones and other devices.
Your local law may prohibit attaching the Navigation Device to the
windshield. In such case, attach the mount to the enclosed plastic
disk and adhere it securely to a clean, smooth surface of your car.
Never position the device in a manner which blocks your view of
the road, interferes with the safe operation of the vehicle (e.g. do
not place on the steering wheel or in front of an air bag), or could
otherwise result in injury to the user. Always obey local laws and
restrictions concerning use of such products.
PND_UG.fm Page 7 Thursday, August 14, 2008 1:00 PM

8
welcome
contents
contents . . . . . . . . . . . . . . . . . . 8
get started . . . . . . . . . . . . . . . . 9
components . . . . . . . . . . . . . 9
initial setup . . . . . . . . . . . . . 10
turn on & off . . . . . . . . . . . . 10
power & charging . . . . . . . . 10
map view screen . . . . . . . . 11
main menu screen . . . . . . . 12
navigation . . . . . . . . . . . . . . 13
routes . . . . . . . . . . . . . . . . . . . 14
create a route . . . . . . . . . . . 14
manage a route. . . . . . . . . . 18
cancel a route . . . . . . . . . . . 21
use the keyboard . . . . . . . . 22
maps. . . . . . . . . . . . . . . . . . . . 24
map display controls . . . . . . 24
manage maps . . . . . . . . . . . 26
browse map . . . . . . . . . . . . 26
view GPS information . . . . . 28
install new maps . . . . . . . . . 29
settings. . . . . . . . . . . . . . . . . . 30
set your language . . . . . . . . 30
set your time zone . . . . . . . 30
set your units of measure . . 31
set keyboard type . . . . . . . . 31
set voice prompts . . . . . . . . 32
connect to your phone for
handsfree calls (TN30 only) . 32
manage paired phone list
(TN30 only) . . . . . . . . . . . . . 34
handsfree calls (TN30 only) . 37
answer a call . . . . . . . . . . . . 37
reject/ignore a call . . . . . . . . 37
make a call . . . . . . . . . . . . . 37
mute/unmute a call . . . . . . . 40
transfer a call . . . . . . . . . . . . 41
end a call . . . . . . . . . . . . . . . 41
display in call screen . . . . . . 41
Safety Information . . . . . . . . . 42
Driving Safety. . . . . . . . . . . . . 44
Industry Canada Notice. . . . . 46
FCC Notice . . . . . . . . . . . . . . . 46
Warranty . . . . . . . . . . . . . . . . . 47
Registration . . . . . . . . . . . . . . 51
Export Law . . . . . . . . . . . . . . . 51
Recycling Information . . . . . . 52
index . . . . . . . . . . . . . . . . . . . . 53
