Motorola TN765T User manual

Vantage QSG
11/24/09
Quick Start Guide
MOTONAV TM
TN700 Series
Vantage.QSG.UK_final.fm Page -1 Tuesday, November 24, 2009 12:06 PM

Vantage.QSG.UK_final.fm Page 0 Tuesday, November 24, 2009 12:06 PM

1
HELLOMOTO
HELLOMOTO
welcome
Your MOTONAV™ TN700 Series Personal Navigator helps
you find the best route with Satellite Navigation accuracy
and streaming traffic information.
• Get clear directions, 3D landmarks (in major cities), and
spoken street names to eliminate second guessing.
• Make hands-free calls and send text messages while
paired with your Bluetooth® enabled phone.
• Locate your favourite restaurant, nearest bank, fuel
station, or see businesses and other locations along
your route.
• Save time and fuel, and leave getting lost in the past.
• Use MotoExtras to check the weather, fuel prices
(with purchased option), flight status, and to use
Google® local search.
We’ve crammed all the main features of your device into
this handy guide, and in a matter of minutes you’ll see just
how easy it is to use. So go on, check it out.
more information
Download the user’s guide: www.motorola.com/motonav
Check for software updates, and more:
www.motorola.com/motoextras
this guide
Caution: Before using your personal navigator for the
first time, please read the
important legal and safety
information in the back of this guide.
symbols in this guide
This means a feature is network/subscription
dependent, or that it depends on the
handsfree profile support supported by your
Bluetooth-enabled mobile phone.
Refer to your mobile phone manual for more
information.
This means a feature needs an optional
accessory.
Vantage.QSG.UK_final.fm Page 1 Tuesday, November 24, 2009 12:06 PM

2
contents
contents
welcome . . . . . . . . . . . . . . . . . . . 1
more information . . . . . . . . . . . . 1
this guide . . . . . . . . . . . . . . . . . . 1
your navigation device . . . . . . . . 3
mount it — dashboard. . . . . . . . . 4
mount it — windscreen (both
top and bottom of the screen) . . 5
charge up . . . . . . . . . . . . . . . . . . . 6
going on foot? . . . . . . . . . . . . . . . 7
set it up . . . . . . . . . . . . . . . . . . . . . 8
sync your contacts . . . . . . . . . . 10
change the volume . . . . . . . . . . 10
explore the map & Multiview . . 11
Speak & Go . . . . . . . . . . . . . . . . . 14
let’s go . . . . . . . . . . . . . . . . . . . . . 15
find an address with
Easy Search. . . . . . . . . . . . . . . . 15
set your home address . . . . . . . 16
set favourite addresses. . . . . . . 16
Traffic. . . . . . . . . . . . . . . . . . . . . 16
MotoExtras . . . . . . . . . . . . . . . . 17
safety cameras . . . . . . . . . . . . . 18
calls . . . . . . . . . . . . . . . . . . . . . . . 20
receive calls. . . . . . . . . . . . . . . . 20
make calls . . . . . . . . . . . . . . . . . 21
make calls using contacts . . . . . 21
while on a call . . . . . . . . . . . . . . 21
messages . . . . . . . . . . . . . . . . . . . 22
send text messages . . . . . . . . . 22
receiving text messages . . . . . . 22
trusted contacts. . . . . . . . . . . . . 23
tips & tricks . . . . . . . . . . . . . . . . . 24
power & charging tips . . . . . . . . 25
car charger. . . . . . . . . . . . . . . . . 25
travel charger. . . . . . . . . . . . . . . 25
troubleshooting. . . . . . . . . . . . . . 26
Support . . . . . . . . . . . . . . . . . . . 26
Bluetooth Support . . . . . . . . . . . 26
check for new maps . . . . . . . . . 26
reset your MOTONAV . . . . . . . . 26
new views, panels, & maps . . . 26
Legal & Safety . . . . . . . . . . . . . . . 27
Vantage.QSG.UK_final.fm Page 2 Tuesday, November 24, 2009 12:06 PM

3
your navigation device
your navigation device
the important buttons and connectors
Note:
You can choose which side you want for the rear button functions.
Customisable
Button
Choose the function
of this button
Power Switch
Turn it on & off
Map Button
Return to the map
Zoom In
Zoom Out
Micro USB Port
MicroSD Memory
Card Slot
Reset Button
Volume Up
Mute
Volume Down
Lock Power
Rear Buttons:
Rear Buttons:
Vantage.QSG.UK_final.fm Page 3 Tuesday, November 24, 2009 12:06 PM

4
mount it — dashboard
mount it — dashboard
put your device in your vehicle...or you can carry it when you leave your wheels behind
Note:
Before you mount the device on the dashboard, clean the surface first. Put your device in a secure place. Do not
cover an airbag. DO NOT MOUNT IN A LOCATION THAT OBSTRUCTS DRIVER'S VISION OR INTERFERES WITH
OPERATION OF THE VEHICLE. To mount your device on the windscreen, see page “going on foot?” on page 7.
5
4
Tip: Align the posts on the cradle with the grooves on the
back of the device. Listen for a small click when it attaches.
Vantage.QSG.UK_final.fm Page 4 Tuesday, November 24, 2009 12:06 PM

5
mount it — windscreen (both top and bottom of the screen)
mount it — windscreen (both top and bottom of the screen)
Before installing or using, check state and local laws regarding windscreen mounting or use of equipment. DO NOT
MOUNT IN A LOCATION THAT OBSTRUCTS DRIVER'S VISION OR INTERFERES WITH OPERATION OF THE VEHICLE.
4
Tip : Align the posts on the cradle with the grooves on the
back of the device. Listen for a small click when it attaches.
Vantage.QSG.UK_final.fm Page 5 Tuesday, November 24, 2009 12:06 PM

6
charge up
charge up
plug in to power up
Note:
Your battery is designed to last the life of the product. It should be removed only by a recycling facility. ANY
ATTEMPT TO REMOVE OR REPLACE YOUR BATTERY WILL DAMAGE THE PRODUCT.
Vantage.QSG.UK_final.fm Page 6 Tuesday, November 24, 2009 12:06 PM

7
going on foot?
going on foot?
To take your MOTONAV device with you, press the Release Button to remove it from the charging dock.
Note: When you take your MOTONAV device out of the charging dock, tap Enter Pedestrian Mode to keep your device turned on
while you walk. (You have the option of continuing on battery power, switching to pedestrian mode, or turning the device
off.) If you don’t select an option, your device turns off after 30 seconds.
Press the Release
Button (on bottom)
to remove device
from charging dock.
While holding the
Release Button, lean
the device forward.
Lift the device up from
the charging dock.
Vantage.QSG.UK_final.fm Page 7 Tuesday, November 24, 2009 12:06 PM

8
set it up
set it up
let’s get you up and moving
turn it on & off
The Power Switch is located on the top of the device.
set it up
When you first turn on your device, you’ll need to do
a couple things to set it up. You know, answer a few
questions. Get to know each other.
1 Review or change the Language .
2 Review or change the Time Zone , Distance Units , and
Temperature Units .
3 Optionally customise the buttons on the rear of the
device.
4 Read and accept the Safety Warning.
5 Read and accept the End User License Agreement.
6 Connect your Bluetooth® enabled mobile phone. (Or
see “
connect it ” on page 9 to connect later.)
7 Read the Traffic feature notice, if it appears.
8 Use your connected mobile phone to try MotoExtras.
9 Tap Yes for a tutorial or tap No to continue.
10 Tap Done to start using your device.
Note: To change these settings later, see your
User’s Guide.
turn on/off slide and release left (toward )
lock slide right (toward )
(lock screen and rear buttons, but
device stays on)
Acquiring Satellites
To receive a strong signal, make sure your device has an
unobstructed view of the sky. It may take a few minutes
for your device to locate satellites the first time you turn
the power on.
Vantage.QSG.UK_final.fm Page 8 Tuesday, November 24, 2009 12:06 PM

9
set it up
connect it
Connect your MOTONAV device with your phone
using Bluetooth® wireless technology to use your
device to make hands-free calls, send text
messages (if supported by your mobile phone), or use
MotoExtras or voice prompted search features.
1 Turn on your MOTONAV device.
2 On your device, tap the map, then tap Main Menu > Settings
>
Bluetooth .
3 Tap On to turn Bluetooth on and to put your device in
discoverable mode.
4 On your mobile phone, turn on the Bluetooth feature.
5 On your mobile phone, search for nearby devices.
6 Select the name of your MOTONAV device from the
list of nearby devices found.
Tip: To change the Bluetooth name of your MOTONAV
device, go to
Main Menu > Settings > Bluetooth , then scroll to
My Device , tap the name to edit it.
7 Follow the directions on your mobile phone to
connect. If prompted for a passcode, enter
0000 .
Note: For more help connecting, visit
www.motorola.com/Bluetoothconnect .
Vantage.QSG.UK_final.fm Page 9 Tuesday, November 24, 2009 12:06 PM

10
set it up
sync your contacts
After you connect with your mobile phone, you can set
your device to automatically download your contacts, text
messages, and recent calls to your MOTONAV device.
Note: Downloading your phonebook and text messages
depends on your phone's capabilities. To determine
whether your phone supports these features, go to
www.motorola.com/Bluetoothconnect .
1 Your MOTONAV device downloads all of your contacts
from the phone. There is no limit to the number of
contacts you can download, however only the first 300
contacts are displayed in the Contact list.
1 Tap the map, then tap Phone > Sync , then tap On to turn
AutoSync on.
2 Tap Phonebook , Messages , or Recent Calls .
3 Tap Sync Now .
change the volume
Adjust the volume during a call by pressing Volume Up or
Volume Down on the back of the device (see page 3).
To mute, press Mute (see page 3).
To customise these buttons, tap the map, then tap
Main Menu > Settings > System > Customisable buttons .
Vantage.QSG.UK_final.fm Page 10 Tuesday, November 24, 2009 12:06 PM

11
set it up
explore the map & Multiview
Your MOTONAV display has expandable left and right
views. You can use these panels without ever leaving the
map.
map buttons
Tap the map to see these main features.
right panel—main menu
Tap the map, then tap Main Menu to expand the right panel.
The main menu opens:
Pair a phone
or place a call.
View the
main menu.
Enable Voice
Recognition.
Go to your
home address.
Search for an address or point of interest.
Access your
favourite locations
Vantage.QSG.UK_final.fm Page 11 Tuesday, November 24, 2009 12:06 PM

12
set it up
left panel—not in a route
Tap on the bar on the left side of the display to open the left
panel and see information about your route. Tap the trip
progress bar to close the left panel.
left panel—in a route
Tap the left panel to see information about your route. To
close the left panel, tap it.
• Aerial View —overview of your area
• Turn by Turn —steps of your route from end to end
•Waypoints —stops along a planned route
CURRENT ST
NW
Search or E
Destinatio
CU
C
C
CURRENT ST
NW
Search or E
Destinatio
CU
C
C
Vantage.QSG.UK_final.fm Page 12 Tuesday, November 24, 2009 12:06 PM

13
set it up
•TripInfo —destination, estimated time of arrival,
distance remaining, time remaining, elapsed time
• Nearby POIs —points of interest in your area
• Dashboard —trip information (current location, GPS
signal, heading, speed, altitude)
•Traffic —current traffic situation & detour suggestions
Vantage.QSG.UK_final.fm Page 13 Tuesday, November 24, 2009 12:06 PM

14
Speak & Go
Speak & Go
use your voice & keep your hands on the wheel
Tap , then say these voice commands:
Note: If the Display Language setting on your device is set
to a language different than the language of the country in
which you are using the device, voice commands for
Address Entry and Search will not be recognised. Please
use the touchscreen to enter an address or perform a
search.
voice
commands
(say these
when
looking at
the map
screen)
“Dial Number”
“Call Contact”
“Call Information”
“Cancel Trip”
“Enter Address”
“Favourites”
“Find Place”
“Go Home”
“Help”
“Main Menu”
“Messages”
“Mute”/”Unmute”
“Recent Calls”
“Recent Trips”
“Send Location”
“Voicemail”
“Volume Up”
“Volume Down”
“Where am I?”
control
commands
(say these
for moving
through
screens)
“Back”
“Cancel”
“Page Up”
“Page Down”
global
commands
(say these at
any time)
“Read Out”
“Repeat”
“Exit”
Speak & Go
Plus
While using Search, tap to use your
voice to enter an address.
Vantage.QSG.UK_final.fm Page 14 Tuesday, November 24, 2009 12:06 PM

15
let’s go
let’s go
hit the road, on wheels or on foot
find an address with Easy Search
Before you start driving, say or use the keyboard to enter
an address or part of one to create a route.
1 Tap the map.
2 Tap Enter Destination .
3 To optimise your search results, specify the city or
town you want to search within by tapping the box in
the upper right and entering the city or town name.
Alternatively you can enter your desired postcode in
the same box.
If you don’t enter a city or town, the search will return
results for your current location.
4 Tap the display to enter a keyword or the street
number and street name.
A list of matching addresses and points of interest
appears on the right side of the screen.
Tip: To go to an intersection, enter the two street
names separated by +.
5 Tap anywhere on the list to expand it.
6 Tap the address in the list.
An overview map appears along with options for the
address your selected.
7 Tap Go!
Vantage.QSG.UK_final.fm Page 15 Tuesday, November 24, 2009 12:06 PM

16
let’s go
set your home address
1 Tap the map.
2 Tap Main Menu .
3 Tap Favourites > Set Home .
4 Tap Current location if you are at home, or tap Enter location to
enter your home address.
Tip: The next time you want to go home, tap the map, then
tap the home icon, and you’re as good as there.
set favourite addresses
After you select an address or point of interest, tap
the name, then tap
Make Favourite (at the bottom of the
overview map).
To see your saved addresses and points of interest, tap the
map, then
Main Menu > Favourites .
Traff ic
The Traffic service provides streaming traffic updates.
When using the traffic service, your device calculates
routes that minimise or avoid traffic delays. If traffic is
detected on your route, your device offers you alternate
routes to save you time. You can preview detours before
accepting them.
Routes are updated automatically or you can preview
detours before accepting them. (Tap
Settings > Traffic > Automatic
Avoid
.) An icon appears next to progress bar showing the
new route time.Tap the icon to learn more about the
alternate route.
Traffic information is included with MOTONAV device
models numbers that end in "t" or with the purchase of
a charging dock with built-in traffic receiver . Visit
www.motorola.com/motoextras for more information or to
purchase a charging dock with built-in traffic receiver for
your device.
Note: You receive traffic information only if your device
supports this feature. Your device must be in the charging
cradle and plugged in to the car charger to receive traffic
information.
Vantage.QSG.UK_final.fm Page 16 Tuesday, November 24, 2009 12:06 PM

17
let’s go
The traffic feature is only available for England, Wales,
Scotland and Northern Ireland. The service is not available
for the Republic of Ireland or outside the UK at this stage.
MotoExtras
Stay up on weather, flight status, and fuel prices. Your
device includes 3 months free of MotoExtras, which you
can renew online after your 3 months are up. Visit
www.motorola.com/motoextras to purchase MotoExtras for your
device.
Note: These MotoExtra features are available only for
the UK.
MotoExtras gives you these updates and features:
• weather
• fuel prices
• flight status
• Google® local search
Note: Your device must be connected to a Bluetooth®
enabled mobile phone to receive information.
1 Tap the map.
2 Tap Main Menu .
3 Select Weather , Flight Status , or Fuel Prices .
Vantage.QSG.UK_final.fm Page 17 Tuesday, November 24, 2009 12:06 PM

18
let’s go
Google® local search
You can use Google to search for an address or point of
interest. Your device must be connected to your mobile
phone via Bluetooth to use this feature.
1 Tap Search or Enter Destination .
2 Enter what you want to search for.
3 Tap Google > Search .
send addresses from the Web
MotoExtras also lets you send addresses from the internet
to your device so you can navigate to them easily without
entering the address. To use this feature, make sure your
mobile phone is connected to your device via Bluetooth.
1 On your PC or mobile phone browser, navigate to
www.google.co.uk/maps .
2 Search for an address or business.
3 After you find what you’re looking for, click Send .
4 Click GPS , then click Motorola .
5 Enter your mobile phone number, then click Send .
A text message is sent to your phone. The text
message will include the options to
Call or Go to this
location.
safety cameras
Your MOTONAV can warn you when approaching a speed
camera, red light camera, or hazard area. Cameras appear
as icons on the map.
You can:
• Set your MOTONAV to give you either audio or visual
warnings, or both.
• Set the audio warning to be either a tone or a voice.
• Select warnings for speed cameras, red light cameras,
or hazard areas.
Your device includes 3 months of free Safety Camera
alerts, which you can renew online after your 3 months are
up. Visit
www.motorola.com/motoextras to purchase the safety
camera feature or to get software updates for your device.
Vantage.QSG.UK_final.fm Page 18 Tuesday, November 24, 2009 12:06 PM
