Motorola USB08 User manual

DRM002/D
M
6
8H
C
08M
6
0
8M68HC08
M
8
HC08M68H
C
USB08 Universal Serial Bus
Evaluation Board
Using the MC68HC908JB8
Designer Reference Manual

blank

USB08 Evaluation Board Designer Reference Manual
MOTOROLA 3
USB08 Universal Serial Bus
Evaluation Board
Using the MC68HC908JB8
By: Dipl.-Ing. Oliver Thamm
MCT Elektronikladen GbR
Hohe Str. 9-13
04107 Leipzig
Germany
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Web:http://www.elektronikladen.de/mct
Motorola and are registered trademarks of Motorola, Inc.
DigitalDNA is a trademark of Motorola, Inc. © Motorola, Inc., 2001

Designer Reference Manual USB08 Evaluation Board
4MOTOROLA
Designer Reference Manual
Motorola reserves the right to make changes without further notice to any products
herein. Motorola makes no warranty, representation or guarantee regarding the
suitability of its products for any particular purpose, nor does Motorola assume any
liability arising out of the application or use of any product or circuit, and specifically
disclaims any and all liability, including without limitation consequential or incidental
damages. "Typical" parameters which may be provided in Motorola data sheets and/or
specifications can and do vary in different applications and actual performance may
vary over time. All operating parameters, including "Typicals" must be validated for
each customer application by customer’s technical experts. Motorola does not convey
any license under its patent rights nor the rights of others. Motorola products are not
designed, intended, or authorized for use as components in systems intended for
surgical implant into the body, or other applications intended to support or sustain life,
or for any other application in which the failure of the Motorola product could create a
situation where personal injury or death may occur. Should Buyer purchase or use
Motorola products for any such unintended or unauthorized application, Buyer shall
indemnify and hold Motorola and its officers, employees, subsidiaries, affiliates, and
distributors harmless against all claims, costs, damages, and expenses, and
reasonable attorney fees arising out of, directly or indirectly, any claim of personal
injury or death associated with such unintended or unauthorized use, even if such claim
alleges that Motorola was negligent regarding the design or manufacture of the part.
Motorola, Inc. is an Equal Opportunity/Affirmative Action Employer.

USB08 Evaluation Board Designer Reference Manual
MOTOROLA List of Sections 5
Designer Reference Manual — USB08 Evaluation Board
List of Sections
Section 1. USB08 Quick Start . . . . . . . . . . . . . . . . . . . . .17
Section 2. Hardware Description. . . . . . . . . . . . . . . . . . .27
Section 3. Software Module Descriptions. . . . . . . . . . . .43
Section 4. Universal Serial Bus (USB) Interface . . . . . .59
Appendix A. Supported Standard
Device Requests . . . . . . . . . . . . . . . . . . . . .81
Appendix B. USB08 Descriptors . . . . . . . . . . . . . . . . . . .83
Appendix C. Source Code Files. . . . . . . . . . . . . . . . . . . .89
Appendix D. Bill of Materials and Schematic . . . . . . . .127
Appendix E. Universal USB Device
Driver (USBIO). . . . . . . . . . . . . . . . . . . . . .131

Designer Reference Manual USB08 Evaluation Board
6 List of Sections MOTOROLA
List of Sections

USB08 Evaluation Board Designer Reference Manual
MOTOROLA Table of Contents 7
Designer Reference Manual —USB08 Evaluation Board
Table of Contents
Section 1. USB08 Quick Start
1.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
1.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
1.3 Required System Configuration . . . . . . . . . . . . . . . . . . . . . . . .17
1.4 Connecting the Demo Board to the PC . . . . . . . . . . . . . . . . . .18
1.5 Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
1.6 Starting the Windows Demo Application. . . . . . . . . . . . . . . . . .24
Section 2. Hardware Description
2.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
2.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
2.3 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
2.3.1 MC68HC908JB8 Microcontroller . . . . . . . . . . . . . . . . . . . . .28
2.3.2 USB08 Evaluation Board . . . . . . . . . . . . . . . . . . . . . . . . . . .29
2.4 Circuit Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2.4.1 MCU Core Circuit and USB Interface. . . . . . . . . . . . . . . . . .31
2.4.2 Input/Output Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
2.4.3 Monitor Mode Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
2.4.4 User RS232 Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
2.4.5 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
2.5 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
2.6 Jumpers and Bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Designer Reference Manual USB08 Evaluation Board
8 Table of Contents MOTOROLA
Table of Contents
2.7 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
2.7.1 Expansion Connector X1 . . . . . . . . . . . . . . . . . . . . . . . . . . .40
2.7.2 Monitor Mode Connector X2 . . . . . . . . . . . . . . . . . . . . . . . .40
2.7.3 User RS232 Connector X3. . . . . . . . . . . . . . . . . . . . . . . . . .41
2.8 Memory Map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Section 3. Software Module Descriptions
3.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
3.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
3.3 General Structure of the M68HC08 Firmware . . . . . . . . . . . . .44
3.4 How to Build the Compiler Project . . . . . . . . . . . . . . . . . . . . . .45
3.5 Main Module U08MAIN.C. . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
3.6 Interrupt and Reset Vector Module VECJB8.C. . . . . . . . . . . . .49
3.7 C Startup Module CRTSJB8.S . . . . . . . . . . . . . . . . . . . . . . . . .50
3.8 Push Button Module U08KEY.C. . . . . . . . . . . . . . . . . . . . . . . .50
3.9 LED Control with U08LED.H. . . . . . . . . . . . . . . . . . . . . . . . . . .52
3.10 Software ADC Module U08ADC.C . . . . . . . . . . . . . . . . . . . . . .52
3.11 RS232 Communication Module U08232.C. . . . . . . . . . . . . . . .54
3.12 USB Communication Module U08USB.C. . . . . . . . . . . . . . . . .56
3.13 Compiler Specific Adjustments. . . . . . . . . . . . . . . . . . . . . . . . .57
Section 4. Universal Serial Bus (USB) Interface
4.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
4.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
4.3 Characteristics of the USB08 Reference Design . . . . . . . . . . .60
4.4 USB Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Table of Contents
USB08 Evaluation Board Designer ReferenceManual
MOTOROLA Table of Contents 9
4.5 USB Implementation in the Reference Design. . . . . . . . . . . . .65
4.5.1 Activation of the USB Module. . . . . . . . . . . . . . . . . . . . . . . .65
4.5.2 Endpoint Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
4.5.3 USB Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
4.6 Device Management with Endpoint 0. . . . . . . . . . . . . . . . . . . .69
4.6.1 Enumeration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
4.6.2 Assignment of the Device Address . . . . . . . . . . . . . . . . . . .69
4.6.3 Requesting Descriptors . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
4.6.4 Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
4.6.5 STALL Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
4.7 Data Communication via Endpoints EP1 and EP2. . . . . . . . . .75
4.7.1 Receiving Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
4.7.2 Transmission of Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
4.8 Host Interaction: Vendor ID and Product ID . . . . . . . . . . . . . . .78
4.9 Windows Device Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Appendix A. Supported Standard Device Requests
Supported Standard Device Requests. . . . . . . . . . . . . . . . . . .81
Appendix B. USB08 Descriptors
B.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
B.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
B.3 Device Descriptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
B.4 Configuration Descriptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
B.5 Interface Descriptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
B.6 Endpoint 1 Descriptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
B.7 Endpoint 2 Descriptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
B.8 String Descriptors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Designer Reference Manual USB08 Evaluation Board
10 Table of Contents MOTOROLA
Table of Contents
Appendix C. Source Code Files
C.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
HC908JB8.H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
U08USB.H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
U08232.H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
U08LED.H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
U08MAIN.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
U08DESC.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
U08USB.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
U08232.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
U08KEY.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
U08ADC.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
VECJB8.C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
CRTSJB8.S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
USB08.LKF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
BUILD.BAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
USB08.MAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
USB08.S19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Appendix D. Bill of Materials and Schematic
Bill of Materials and Schematic. . . . . . . . . . . . . . . . . . . . . . . .127
Appendix E. Universal USB Device Driver (USBIO)
E.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
E.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135
E.3 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135
E.3.1 Platforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136
E.3.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136
E.4 Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
E.4.1 USBIO Object Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140
E.4.1.1 USBIO Device Objects. . . . . . . . . . . . . . . . . . . . . . . . . .140
E.4.1.2 USBIO Pipe Objects . . . . . . . . . . . . . . . . . . . . . . . . . . .142
E.4.2 Establishing a Connection to the Device . . . . . . . . . . . . . .144
E.4.3 Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146

Table of Contents
USB08 Evaluation Board Designer ReferenceManual
MOTOROLA Table of Contents 11
E.4.4 Device State Change Notifications. . . . . . . . . . . . . . . . . . .148
E.5 Programming Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
E.5.1 Programming Interface Overview. . . . . . . . . . . . . . . . . . . .149
E.5.2 Control Requests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
E.5.3 Data Transfer Requests. . . . . . . . . . . . . . . . . . . . . . . . . . .182
E.5.3.1 Bulk and Interrupt Transfers . . . . . . . . . . . . . . . . . . . . .182
E.5.3.2 Isochronous Transfers. . . . . . . . . . . . . . . . . . . . . . . . . .184
E.5.4 Input and Output Structures. . . . . . . . . . . . . . . . . . . . . . . .185
E.5.5 Enumeration Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
E.5.6 Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .218
E.6 USBIO Class Library. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220
E.6.1 CUsbIo Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220
E.6.2 CUsbIoPipe Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .221
E.6.3 CUsbIoThread Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . .222
E.6.4 CUsbIoReaderClass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .222
E.6.5 CUsbIoWriter Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .222
E.6.6 CUsbIoBufClass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .223
E.6.7 CUsbIoBufPool Class. . . . . . . . . . . . . . . . . . . . . . . . . . . . .223
E.7 USBIO Demo Application . . . . . . . . . . . . . . . . . . . . . . . . . . . .223
E.7.1 Dialog Pages for Device Operations . . . . . . . . . . . . . . . . .224
E.7.1.1 Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .224
E.7.1.2 Descriptors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .224
E.7.1.3 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .225
E.7.1.4 Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .225
E.7.1.5 Pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .225
E.7.1.6 Class or Vendor Request. . . . . . . . . . . . . . . . . . . . . . . .226
E.7.1.7 Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226
E.7.1.8 Other . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226
E.7.1.9 Dialog Pages for Pipe Operations . . . . . . . . . . . . . . . . .227
E.7.1.10 Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .227
E.7.1.11 Buffers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .227
E.7.1.12 Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .228
E.7.1.13 Read from Pipe to Output Window . . . . . . . . . . . . . . . .228
E.7.1.14 Read from Pipe to File. . . . . . . . . . . . . . . . . . . . . . . . . .228
E.7.1.15 Write from File to Pipe . . . . . . . . . . . . . . . . . . . . . . . . . .229

Designer Reference Manual USB08 Evaluation Board
12 Table of Contents MOTOROLA
Table of Contents
E.8 Installation Issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .229
E.8.1 Automated Installation: The USBIO Installation Wizard. . .229
E.8.2 Manual Installation: The USBIO Setup Information File. . .232
E.8.3 Uninstalling USBIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .236
E.8.4 Building a Customized Driver Setup. . . . . . . . . . . . . . . . . .237
E.9 Registry Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .239
E.10 Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241
E.11 Light Version Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . .241

USB08 Evaluation Board Designer Reference Manual
MOTOROLA List of Figures 13
Designer Reference Manual —USB08 Evaluation Board
List of Figures
Figure Title Page
1-1 Demo Board Connected to the USB Hub. . . . . . . . . . . . . . . . .18
1-2 Found New Hardware Screen . . . . . . . . . . . . . . . . . . . . . . . . .19
1-3 Found New Hardware Wizard Start Screen . . . . . . . . . . . . . . .20
1-4 Locate Driver Files Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . .21
1-5 Driver Files Search Results Screen . . . . . . . . . . . . . . . . . . . . .22
1-6 Found New Hardware Wizard Finish Screen . . . . . . . . . . . . . .23
1-7 Windows Demo Application IO08USB . . . . . . . . . . . . . . . . . . .24
1-8 Driver Entry for USB08 in the Device Manager Window . . . . .25
2-1 USB08 Evaluation Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2-2 PCB Component Side Layout Plan. . . . . . . . . . . . . . . . . . . . . .37
2-3 Detailed Layout Plan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
2-4 Solder Bridge Placement on Downside of the PCB . . . . . . . . .39
3-1 Structure and Dependencies of the Firmware Files . . . . . . . . .45
3-2 Measurement of Resistor Values Using a Digital Input . . . . . .52
4-1 USB Address Register (UADDR) . . . . . . . . . . . . . . . . . . . . . . .65
4-2 USB Control Register 3 (UCR3). . . . . . . . . . . . . . . . . . . . . . . .66
4-3 USB Interrupt Register 0 (UIR0). . . . . . . . . . . . . . . . . . . . . . . .68
4-4 USB Control Register 0 (UCR0). . . . . . . . . . . . . . . . . . . . . . . .68
4-5 USB Interrupt Register 1 (UIR1). . . . . . . . . . . . . . . . . . . . . . . .69
4-6 USB Status Register 0 (USR0). . . . . . . . . . . . . . . . . . . . . . . . .70
4-7 USB Control Register 0 (UCR0). . . . . . . . . . . . . . . . . . . . . . . .71
4-8 USB Address Register (UADDR) . . . . . . . . . . . . . . . . . . . . . . .72
4-9 USB Interrupt Register 1 (UIR1). . . . . . . . . . . . . . . . . . . . . . . .75
4-10 USB Status Register 1 (USR1). . . . . . . . . . . . . . . . . . . . . . . . .76
4-11 USB Control Register 1 (UCR1). . . . . . . . . . . . . . . . . . . . . . . .77

Designer Reference Manual USB08 Evaluation Board
14 List of Figures MOTOROLA
List of Figures
Figure Title Page
D-1 USB08 Evaluation Board Schematic . . . . . . . . . . . . . . . . . . .129
E-1 USB Driver Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
E-2 USBIO Device and Pipe Objects Example. . . . . . . . . . . . . . .143
E-3 Layout of an Isochronous Transfer Buffer . . . . . . . . . . . . . . .183
E-4 USBIO Class Library. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220

USB08 Evaluation Board Designer Reference Manual
MOTOROLA List of Tables 15
Designer Reference Manual —USB08 Evaluation Board
List of Tables
Table Title Page
2-1 Port A Monitor Mode Entry Levels . . . . . . . . . . . . . . . . . . . . . .33
2-2 Monitor Mode Cable Pin Configuration. . . . . . . . . . . . . . . . . . .34
2-3 Jumper Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
2-4 Solder Bridges Configuration . . . . . . . . . . . . . . . . . . . . . . . . . .39
2-5 MC68HC908JB8 Memory Map. . . . . . . . . . . . . . . . . . . . . . . . .41
3-1 Memory Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
4-1 Low-Speed USB Packet Types . . . . . . . . . . . . . . . . . . . . . . . .62
4-2 MC68HC908JB8 Endpoint Configuration. . . . . . . . . . . . . . . . .66
D-1 Bill of Materials for USB08 V 1.01 . . . . . . . . . . . . . . . . . . . . .128
E-1 I/O Operations Supported by the USBIO Device Driver. . . . .149
E-2 Error Codes Defined by the USBIO Device Driver . . . . . . . . .218
E-3 Registry Parameters Supported by the USBIO Driver . . . . . .239

Designer Reference Manual USB08 Evaluation Board
16 List of Tables MOTOROLA
List of Tables

USB08 Evaluation Board Designer Reference Manual
MOTOROLA USB08 Quick Start 17
Designer Reference Manual —USB08 Evaluation Board
Section 1. USB08 Quick Start
1.1 Contents
1.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
1.3 Required System Configuration . . . . . . . . . . . . . . . . . . . . . . . .17
1.4 Connecting the Demo Board to the PC . . . . . . . . . . . . . . . . . .18
1.5 Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
1.6 Starting the Windows Demo Application. . . . . . . . . . . . . . . . . .24
1.2 Introduction
This section describes the connection and startup of the USB08
(universal serial bus) evaluation board demo application. The main
component of the USB08 is the Motorola MC68HC908JB8 8-bit
microcontroller (MCU).
1.3 Required System Configuration
To connect theUSB08, youwill needa personal computer (PC) withone
of the following Microsoft®operating systems:
•Windows®98
•Windows ME
•Windows 2000 Professional
NOTE: Ensure that the PC has the necessary hardware (universal serial bus
(USB) host controller and USB root hub) and that the necessary system
drivers are installed.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States
and/or other countries.

Designer Reference Manual USB08 Evaluation Board
18 USB08 Quick Start MOTOROLA
USB08 Quick Start
1.4 Connecting the Demo Board to the PC
Since low-speed USB devices should be equipped with a captive
connection, the USB cable is fixed on the USB08 board (downstream
direction). In the upstream direction (PC/host side), the USB
connections are alwaystypeA. Therefore, the cable oftheUSB08demo
board has a type A plug.
The connection ofthe demoboard is made directly to the USB socketof
the PC or, as shown in the Figure 1-1, to a USB hub.
Figure 1-1. Demo Board Connected to the USB Hub
The board supply current can be delivered by the USB connection.
Therefore, the jumper JP2, which is directly beside the USB cable, has
to be in the position Bus Powered. The jumper JP1-A (jumper block,
highest position) must be opened, which corresponds to the default
shipping configuration.

USB08 Quick Start
Driver Installation
USB08 Evaluation Board Designer ReferenceManual
MOTOROLA USB08 Quick Start 19
1.5 Driver Installation
Forthisexample,theinstallationofthedriversoftwareisdescribedusing
the Windows 2000 operating system. The installation using Windows 98
(second edition) looks quite similar.
After the electrical connection of the demo board, the Windows
operating system recognizes the presence of a new hardware
component and shows the message Found New Hardware.
Figure 1-2. Found New Hardware Screen

Designer Reference Manual USB08 Evaluation Board
20 USB08 Quick Start MOTOROLA
USB08 Quick Start
The hardware assistant, Figure 1-3, now tries to find the suitable driver
information for the USB08 evaluation board. Click the Next button.
NOTE: The installation using the Windows 2000 operating system requires
administrator rights.
Figure 1-3. Found New Hardware Wizard Start Screen
