Motorola APX 2000 MODEL 2 Reference guide

English
Radio Controls
Single Knob Radio
Two Knobs Radio
Radio On/Off
Radio On/Off
Select Zone and Channel
Select Zone and Channel
Receiving and Transmitting
Data Feature
Button
Side Button 1
__________
Side Button 2
__________
PTT Button
Microphone
Top Lightbar
Indicator
Top Side (Select)
Button
__________ Main
Speaker
Main Display
Top (Orange) Button
___________
LED
Menu Select
Buttons
4-Way Navigation
Button
Home Button
Bluetooth Pair
Location Indicator
Battery
Multi Function Knob
(MFK):
Primary Feature:
_________________
Secondary Feature:
_________________
Accessory
Connector
Microphone
Antenna
Data Feature
Button
Side Button 1
__________
Side Button 2
__________
PTT Button
Microphone
Top Lightbar
Indicator
Top Side (Select)
Button
__________ Main
Speaker
Main Display
Top (Orange) Button
___________
LED
Menu Select
Buttons
4-Way
Navigation
Button
Home Button
Bluetooth Pair
Location Indicator
Battery
Accessory
Connector
Microphone
Antenna On/Off/Volume
Control Knob
16-Position Select
Knob
•On – Press and hold the MFK until the display
lights up.
•Off – Press and hold the MFK until you see Power
off?, then press Menu Select button below Yes.
•On – Rotate the On/Off/Volume Control Knob
clockwise until you hear a click.
•Off – Rotate the On/Off/ Volume Control Knob
counterclockwise until you hear a click.
1Press the MFK to see on the screen.
2Turn the MFK to scroll to desired zone or channel.
3Press MFK to select the desired zone or channel
and exit Mode Change.
1Rotate the preprogrammed 16-Position Select
Knob to the desired channel.
1Select zone/channel.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the
Stylized M logo are trademarks or registered trademarks of
Motorola Trademark Holdings, LLC and are used under
license. All other trademarks are the property of their
respective owners.
© 2011 and 2015 by Motorola Solutions, Inc. All Rights
Reserved.
1303 East Algonquin Road, Schaumburg, Illinois 60196,
U.S.A.
06/15
m ASTRO®APX™ 2000 Model 2 Digital Portable Radios Quick Reference Card
RF Energy Exposure and Product Safety Guide for Portable Two-Way Radios
ATTENTION!
This radio is restricted to Occupational use only. Before using the radio, read the RF Energy Exposure and Product Safety Guide for Portable
Two-Way Radios which contains important operating instructions for safe usage and RF energy awareness and control for Compliance with
applicable standards and Regulations.
*PMLN6071F*
PMLN6071F

English
Menu Navigation
<or >to Menu Entry.
{, |, or }directly below
Menu Entry to select.
Hto exit.
Uor Dto scroll through sub-list.
{, |, or }directly below
Menu Entry to select.
Sending an Emergency Alarm
* Default timer of Emergency button press to
activate Emergency is 50 milliseconds. This timer
is programmable, see Emergency Operation in the
user guide for details.
To exit emergency at any time, press and hold the
Emergency button.
Sending an Emergency Call
Sending a Silent Emergency Call
Display Status Icons
2Listen for a transmission.
OR
Press and hold Volume Set button.
OR
Press Monitor button and listen for activity.
3Adjust volume, if necessary.
4Press the PTT button to transmit; release to
receive.
1Press and hold the Emergency button*.
2The display shows Emergency and the current
zone/channel. Radio sounds a short, medium-
pitched tone, and the LED blinks red momentarily.
3When acknowledgment is received, you hear four
beeps; alarm ends; and radio exits emergency.
4Press and hold the Emergency button to exit
emergency.
1Press the Emergency button.
2Press and hold the PTT button. Speak clearly into
the microphone.
3Release the PTT button to end call.
4Press and hold Emergency button to exit
emergency.
1Press the Emergency button.
2The display does not change; the LED does not
light up, and there is no tone.
3Silent emergency continues until you:
Press and hold the Emergency button to exit
emergency state.
OR
Press and release the PTT button to exit the
Silent Emergency Alarm mode and enter regular
dispatch or Emergency Call mode.
MFK is in Mode Change feature.
MFK is in Volume Change feature.
Receiving a call or data.
Transmitting a call or data.
Blinks when the battery is low.
The more stripes, the stronger the signal
strength for the current site (trunking only).
Direct radio to radio communication or
connected through a repeater.
On = Direct
Off = Repeater
This channel is being monitored.
L= Radio is set at Low power.
H= Radio is set at High power.
u
t
8
v
O
M
HOR .
Scanning a scan list.
Blinking dot = Detects activity on the
Priority-One Channel during
scan.
Steady dot = Detects activity on the
Priority-Two Channel during
scan.
The vote scan feature is enabled.
On = User is currently associated with the
radio.
Off = User is currently not associated with
the radio.
Blinking = Device registration or user
registration with the server failed due to an
invalid username or pin.
Data activity is present.
Bluetooth is ready.
Bluetooth is connected to the device.
On = Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted voice
call.
On = AES Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted voice
call.
On = GPS enabled, and location signal
available.
Off = GPS disabled.
Blinking = GPS enabled, but location
signal unavailable.
i
j
k
n
o
b
a
m
l
G
