ASTRO®APX™ 4000 Series
Digital Portable Radios
Quick Reference Card
Product Safety and RF Exposure Compliance
ATTENTION!
This radio is restricted to occupational use only to satisfy FCC RF
energy exposure requirements. Before using this product, read
the RF energy awareness information and operating instructions
in the Product Safety and RF Exposure booklet enclosed with
your radio (Motorola Publication part number 68012004065) to
ensure compliance with RF energy exposure limits.
Radio Controls
Radio On/Off
Zones and Channels
Receiving and Transmitting
Sending an Emergency Alarm
* Default emergency button press timer is set
to 1 second. This timer is programmable, see
page 66 in the user guide for details.
To exit emergency at any time, press and hold
the Emergency button.
Before using this product, read the operating instructions
for safe usage contained in the Product Safety and RF
Exposure booklet enclosed with your radio.
!
C
a u t i o
n
Battery
Multi Function Knob
(MFK)*:
Primary Feature:
_________________
Secondary Feature:
_________________
Accessory
Connector Microphone
Antenna
•On – Press and hold the MFK until the display
lights up.
•Off – Press and hold the MFK until you see
Power off?, then press Menu Select button
below Yes.
•Zone – Zone scroll to desired zone.
•Channel – Channel scroll to desired channel.
Data Feature
Button
Side Button 1
__________
Side Button 2
__________
PTT Button
Microphone
Top Lightbar
Indicator
Top Side (Select)
Button
__________
Main
Speaker
Main Display
Top (Orange)
Button
___________
Bluetooth
Pairing
Indicator
LED
Keypad
Menu Select
Buttons
4-Way
Navigation
Button
Home Button
1Select zone/channel.
2Listen for a transmission.
OR
Press and hold Volume Set button.
OR
Press Monitor button and listen for activity.
3Adjust volume, if necessary.
4Press the PTT button to transmit; release to
receive.
1Press and hold the Emergency button.
2The display shows Emergency and the
current zone/channel. You hear a short,
medium-pitched tone, and the LED blinks
momentary red.
3When acknowledgment is received, you hear
four beeps; alarm ends; and radio exits
emergency.
*PMLN6070A*
PMLN6070A
©2011 by Motorola Solutions, Inc. All Rights Reserved. 10/11
1303 East Algonquin Road, Schaumburg,
Illinois 60196, U.S.A.

English
Sending an Emergency Call
To exit emergency at any time, press and hold
the Emergency button.
Sending a Silent Emergency Call
To exit emergency at any time, press and hold
the Emergency button.
Display Status Icons
1Press the Emergency button.
2Press and hold the PTT button. Speak clearly
into the microphone.
3Release the PTT button to end call.
4Press and hold Emergency button to exit
emergency.
1Press the Emergency button.
2The display does not change; the LED does
not light up, and there is no tone.
3Silent emergency continues until you:
Press and hold the Emergency button to exit
emergency state.
OR
Press and release the PTT button to exit the
Silent Emergency Alarm mode and enter
regular dispatch or Emergency Call mode.
Receiving a call or data.
Transmitting a call or data.
u
t
Blinks when the battery is low.
The more stripes, the stronger the
signal strength for the current site
(trunking only).
Direct radio to radio communication or
connected through a repeater.
On = Direct
Off = Repeater
This channel is being monitored.
L= Radio is set at Low power.
H= Radio is set at High power.
Scanning a scan list.
Blinking dot = Detects activity on the
Priority-One Channel
during scan.
Steady dot = Detects activity on the
Priority-Two Channel
during scan.
8
v
O
M
HOR .
i
j
The vote scan feature is enabled.
On = Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted
voice call.
On = AES Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted
voice call.
On = Location feature enabled, and
location signal available.
Off = Location feature disabled.
Blinking = Location feature enabled,
but location signal unavailable.
On = User is currently associated with
the radio.
Off = User is currently not associated
with the radio.
Blinking = Device registration or user
registration with the server failed due
to an invalid username or pin.
Data activity is present.
Bluetooth is ready.
Bluetooth is connected to the device.
k
m
l
G
n
o
b
a
Menu Navigation
<or >to Menu Entry.
{, |, or }directly below
Menu Entry to select.
Hto exit.
Uor Dto scroll through sub-list.
{, |, or }directly below
Menu Entry to select.

Declaration of Conformity
English
i
Declaration of Conformity
This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party
Name: Motorola Solutions, Inc.
Address: 1303, East Algonquin Road, Schaumburg, Illinois 60196, U.S.A.
Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: APX 4000
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity
English
ii
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Contents
English
iii
Contents
This User Guide contains all the information you need
to use the APX™ 4000 Series Digital Portable Radios.
Declaration of Conformity . . . . . . . . . . . . . . . . . .i
Important Safety Information . . . . . . . . . . . . . .ix
Product Safety and RF Exposure Compliance . . . . .ix
Software Version . . . . . . . . . . . . . . . . . . . . . . . .ix
Notice to Users (FCC and Industry Canada) . . . . . .ix
Informations importantes sur la sécurité . . . . x
Sécurité du produit et respect des lignes directrices
concernant l'exposition à l'énergie RF . . . . . . . . . . . x
Version du logiciel . . . . . . . . . . . . . . . . . . . . . . . x
Avis aux utilisateurs (FCC et Industrie Canada) . . . . x
Computer Software Copyrights . . . . . . . . . . . .xi
Documentation Copyrights . . . . . . . . . . . . . . . .xi
Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . .1
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . 1
Notations Used in This Manual . . . . . . . . . . . . . . . . . 1
Additional Performance Enhancement . . . . . . . . . . . 2
Dynamic System Resilience (DSR) . . . . . . . . . . . . . 2
CrossTalk Prevention . . . . . . . . . . . . . . . . . . . . . . . 3
Encrypted Integrated Data (EID) . . . . . . . . . . . . . . . 3
SecureNet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
What Your Dealer/System Administrator
Can Tell You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparing Your Radio for Use . . . . . . . . . . . . . .4
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . 4
Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Attaching the Battery . . . . . . . . . . . . . . . . . . . . . . . . . 5
Attaching the Antenna . . . . . . . . . . . . . . . . . . . . . . . . 6
Attaching the Accessory Connector Cover . . . . . . . . 6
Attaching the Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . 7
Turning On the Radio . . . . . . . . . . . . . . . . . . . . . . . . 7
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . 9

Contents
English
iv
Identifying Radio Controls . . . . . . . . . . . . . . . . .9
Radio Parts and Controls . . . . . . . . . . . . . . . . . . . 10
Programmable Features . . . . . . . . . . . . . . . . . . . . . 11
Assignable Radio Functions . . . . . . . . . . . . . . . . . . 11
Assignable Settings or Utility Functions . . . . . . . . . 13
Accessing the Preprogrammed Functions . . . . . . . 14
Using the Menu Select Buttons . . . . . . . . . . . . . . . 14
Using the Navigation Buttons . . . . . . . . . . . . . . . . . 14
Home Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Data Feature Button . . . . . . . . . . . . . . . . . . . . . . . 14
4-Way Navigation Button . . . . . . . . . . . . . . . . . . . . 14
Multi Function Knob (MFK) . . . . . . . . . . . . . . . . . . 15
Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Keypad Characters – Uppercase Mode . . . . . . . . . 16
Keypad Characters – Lowercase Mode . . . . . . . . . 17
Keypad Characters – Numeric Mode . . . . . . . . . . . 18
Keypad Characters – Hexadecimal Mode . . . . . . . 19
Push-To-Talk (PTT) Button . . . . . . . . . . . . . . . . . . 20
Identifying Status Indicators . . . . . . . . . . . . . .20
Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Text Messaging Service (TMS) Icons . . . . . . . . . . 23
Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TMS Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . 25
Call Type Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Top Lightbar and LED Indicators . . . . . . . . . . . . . . 26
LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Top Lightbar Indiations . . . . . . . . . . . . . . . . . . . . . .27
Intelligent Lighting Indicators . . . . . . . . . . . . . . . . . 28
Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Phone Call Display and Alert Prompts . . . . . . . . . . 33
General Radio Operation . . . . . . . . . . . . . . . . 34
Selecting a Zone . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Selecting a Radio Channel . . . . . . . . . . . . . . . . . . . 35
Using Channel Search Button . . . . . . . . . . . . . . . . 36
Using Mode Select Feature . . . . . . . . . . . . . . . . . . 37
Saving a Zone and Channel to a Softkey . . . . . . . .38
Saving a Zone and Channel to a Keypad Button . .38
Receiving and Responding to a Radio Call . . . . . . 39
Receiving and Responding to a Talkgroup Call . . .39
Receiving and Responding to a Private Call
(Trunking Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Receiving and Responding to a Telephone Call
(Trunking Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Making a Radio Call . . . . . . . . . . . . . . . . . . . . . . . . 41
Making a Talkgroup Call . . . . . . . . . . . . . . . . . . . . .41
Making a Private Call (Trunking Only) . . . . . . . . . . .42

Contents
English
v
Making an Enhanced Private Call (Trunking Only) .43
Making a Telephone Call (Trunking Only) . . . . . . . .44
Repeater or Direct Operation . . . . . . . . . . . . . . . . . 45
Monitoring Features . . . . . . . . . . . . . . . . . . . . . . . . 45
Monitoring a Channel . . . . . . . . . . . . . . . . . . . . . . .46
Conventional Mode Operation . . . . . . . . . . . . . . . .46
Advanced Features . . . . . . . . . . . . . . . . . . . . . 47
Advanced Call Features . . . . . . . . . . . . . . . . . . . . . 47
Receiving and Making a Selective Call (ASTRO
Conventional Only) . . . . . . . . . . . . . . . . . . . . . . . . .47
Receiving a Selective Call . . . . . . . . . . . . . . . . . . .47
Making a Selective Call . . . . . . . . . . . . . . . . . . . . . 48
Using the Talkgroup Call Feature (Conventional
Operation Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Selecting a Talkgroup . . . . . . . . . . . . . . . . . . . . . .48
Sending a Status Call . . . . . . . . . . . . . . . . . . . . . . .49
Using the Dynamic Regrouping Feature (Trunking
Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Requesting a Reprogram (Trunking Only) . . . . . . .50
Classifying Regrouped Radios . . . . . . . . . . . . . . . . 51
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Making a Private Call from Contacts . . . . . . . . . . . .52
Adding a New Contact Entry . . . . . . . . . . . . . . . . . .53
Deleting a Contact Entry . . . . . . . . . . . . . . . . . . . . .55
Adding a Contact to a Call List . . . . . . . . . . . . . . . .55
Removing a Contact from a Call List . . . . . . . . . . . 56
Editing a Contact in a Call List . . . . . . . . . . . . . . . . 56
Editing an Entry Alias . . . . . . . . . . . . . . . . . . . . . . 56
Editing as Entry ID . . . . . . . . . . . . . . . . . . . . . . . . 57
Editing a Call Type . . . . . . . . . . . . . . . . . . . . . . . . 58
Viewing Details of a Contact . . . . . . . . . . . . . . . . . 58
Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Viewing a Scan List . . . . . . . . . . . . . . . . . . . . . . . . 59
Editing the Scan List . . . . . . . . . . . . . . . . . . . . . . . 59
Changing the Scan List Status . . . . . . . . . . . . . . . 60
Viewing and Changing the Priority Status . . . . . . 61
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Turning Scan On or Off . . . . . . . . . . . . . . . . . . . . . 61
Making a Dynamic Priority Change (Conventional
Scan Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Deleting a Nuisance Channel . . . . . . . . . . . . . . . . 62
Restoring a Nuisance Channel . . . . . . . . . . . . . . . 63
Call Alert Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Receiving a Call Alert Page . . . . . . . . . . . . . . . . . . 63
Sending a Call Alert Page . . . . . . . . . . . . . . . . . . . 64
Emergency Operation . . . . . . . . . . . . . . . . . . . . . . . 65
Sending an Emergency Alarm . . . . . . . . . . . . . . . . 66
Sending an Emergency Call (Trunking Only) . . . . 66
Sending an Emergency Alarm with
Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Sending a Silent Emergency Alarm . . . . . . . . . . . . 67

Contents
English
vi
Using the Emergency Keep-Alive Feature . . . . . . . 68
Man Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Pre-Alert Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Post-Alert Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Alerting User When Man Down Feature is
Triggered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Triggering Emergency . . . . . . . . . . . . . . . . . . . . . . 70
Exiting Man Down Feature . . . . . . . . . . . . . . . . . . . 71
Re-Initiating Man Down . . . . . . . . . . . . . . . . . . . . . 71
Testing the Man Down Feature . . . . . . . . . . . . . . . 72
Automatic Registration Service (ARS) . . . . . . . . . . 73
Selecting or Changing the ARS Mode . . . . . . . . . . 73
Accessing the User Login Feature . . . . . . . . . . . . . 74
Logging In as a User . . . . . . . . . . . . . . . . . . . . . . . 74
Logging Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Text Messaging Service (TMS) . . . . . . . . . . . . . . . 76
Accessing the TMS Features . . . . . . . . . . . . . . . . . 76
Composing and Sending a New Text Message . . . 77
Sending a Quick Text Message . . . . . . . . . . . . . . . 78
Using the Priority Status and Request Reply
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Appending a Priority Status to a Text Message . . . 80
Removing a Priority Status from a Text Message . 80
Appending a Request Reply to a Text Message . . 80
Removing a Request Reply from a Text Message 81
Appending a Priority Status and a Reply Request
to a Text Message . . . . . . . . . . . . . . . . . . . . . . . . .81
Removing a Priority Status and a Reply Request
from a Text Message . . . . . . . . . . . . . . . . . . . . . . .81
Managing Text Messages . . . . . . . . . . . . . . . . . . . .82
Receiving a Text Message . . . . . . . . . . . . . . . . . . .82
Viewing a Text Message from the Inbox . . . . . . . .82
Replying to a Received Text Message . . . . . . . . . .83
Accessing the Drafts Folder . . . . . . . . . . . . . . . . . .84
Managing Sent Text Messages . . . . . . . . . . . . . . . .84
Viewing a Sent Text Message . . . . . . . . . . . . . . . .84
Sending a Sent Text Message . . . . . . . . . . . . . . . .85
Deleting a Text Message . . . . . . . . . . . . . . . . . . . .86
Deleting All Text Messages . . . . . . . . . . . . . . . . . .86
Secure Operations . . . . . . . . . . . . . . . . . . . . . . . . . 87
Selecting Secure Transmissions . . . . . . . . . . . . . . .87
Selecting Clear Transmissions . . . . . . . . . . . . . . . .87
Managing Encryption . . . . . . . . . . . . . . . . . . . . . . .87
Loading an Encryption Key . . . . . . . . . . . . . . . . . .87
Using the Multikey Feature . . . . . . . . . . . . . . . . . . .88
Selecting an Encryption Key . . . . . . . . . . . . . . . . .88
Selecting a Keyset . . . . . . . . . . . . . . . . . . . . . . . . .89
Erasing the Selected Encryption Keys . . . . . . . . . .89
Requesting an Over-the-Air Rekey (ASTRO
Conventional Only) . . . . . . . . . . . . . . . . . . . . . . . . .90
MDC Over-the-Air Rekeying (OTAR) Page . . . . . .91
Hear Clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Contents
English
vii
Radio Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Unlocking Your Radio . . . . . . . . . . . . . . . . . . . . . . 92
Changing Your Password . . . . . . . . . . . . . . . . . . . 92
Enabling or Disabling the Radio Lock Feature
(Secure Radios Only) . . . . . . . . . . . . . . . . . . . . . . . 93
The Global Positioning System (GPS) . . . . . . . . . . 93
Understanding the GPS Feature . . . . . . . . . . . . . . .93
Enhancing GPS Performance . . . . . . . . . . . . . . . . .94
The Outdoor Location Feature (Using GPS) . . . . . .94
Accessing the Outdoor Location Feature . . . . . . . . 95
Saving a Waypoint . . . . . . . . . . . . . . . . . . . . . . . . .96
Viewing a Saved Waypoint . . . . . . . . . . . . . . . . . .97
Editing the Alias of a Waypoint . . . . . . . . . . . . . . . 98
Editing the Coordinates of a Waypoint . . . . . . . . . .99
Deleting a Single Saved Waypoint . . . . . . . . . . . .100
Deleting All Saved Waypoints . . . . . . . . . . . . . . . 100
Measuring the Distance and Bearing from a
Saved Waypoint . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Using the Location Feature While in Emergency
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Trunking System Controls . . . . . . . . . . . . . . . . . . . 102
Using the Failsoft System . . . . . . . . . . . . . . . . . . .102
Going Out of Range . . . . . . . . . . . . . . . . . . . . . . .102
Using the Site Trunking Feature . . . . . . . . . . . . . .102
Locking and Unlocking a Site . . . . . . . . . . . . . . . .103
Viewing and Changing a Site . . . . . . . . . . . . . . . .103
Viewing the Current Site . . . . . . . . . . . . . . . . . . . 103
Changing the Current Site . . . . . . . . . . . . . . . . . 103
Mission Critical Wireless
- Bluetooth - . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Turning the Bluetooth On . . . . . . . . . . . . . . . . . . . 104
Turning the Bluetooth Off . . . . . . . . . . . . . . . . . . . 105
Re-Pair Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Bluetooth Drop Timer . . . . . . . . . . . . . . . . . . . . . . 106
Pairing Bluetooth Device with the Radio . . . . . . . 107
Indicating Bluetooth Connection is Lost . . . . . . . . 108
Turning On the Bluetooth Audio (Routing the Audio
from the Radio to the Headset) . . . . . . . . . . . . . . 109
Turning Off the Bluetooth Audio (Routing the Audio
from the Headset to the Radio) . . . . . . . . . . . . . . 109
Adjusting the Volume of the Radio from Bluetooth
Audio Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Viewing the Bluetooth Active Devices . . . . . . . . . 110
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Viewing the Recent Calls . . . . . . . . . . . . . . . . . . . 111
Selecting the Power Level . . . . . . . . . . . . . . . . . . 112
Selecting a Radio Profile . . . . . . . . . . . . . . . . . . . 112
Enabling and Disabling the Radio Alias . . . . . . . . 113
Selecting the Audio Speaker . . . . . . . . . . . . . . . . 113
Controlling the Display Backlight . . . . . . . . . . . . . 114
Locking and Unlocking the Keypad and Control . 115
Turning Keypad Tones On or Off . . . . . . . . . . . . . 115
Turning Voice Mute On or Off . . . . . . . . . . . . . . . 116

Contents
English
viii
Using the Time-Out Timer . . . . . . . . . . . . . . . . . . 116
Setting the Time and Date . . . . . . . . . . . . . . . . . . 117
Editing the Time and Date . . . . . . . . . . . . . . . . . . 117
Using the Conventional Squelch Operation
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Analog Options . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Digital Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Using the PL Defeat Feature . . . . . . . . . . . . . . . . 119
Using the Digital PTT ID Feature . . . . . . . . . . . . . 119
Using the Smart PTT Feature (Conventional
Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
IMPRES™ Battery Annunciator . . . . . . . . . . . . . . 120
Accessing the Battery Info screen . . . . . . . . . . . . 120
Procedure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Accessing the General Radio Information . . . . . . 121
Accessing the Radio Information . . . . . . . . . . . . . 121
Viewing the IP Information . . . . . . . . . . . . . . . . . . 122
Viewing the Control Assignments . . . . . . . . . . . . 123
Editing the Soft ID . . . . . . . . . . . . . . . . . . . . . . . . 123
Voice Announcement . . . . . . . . . . . . . . . . . . . . . . 124
Helpful Tips . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Acoustic Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Caring for Your Radio . . . . . . . . . . . . . . . . . . . . . . 127
Cleaning Your Radio . . . . . . . . . . . . . . . . . . . . . . 128
Handling Your Radio . . . . . . . . . . . . . . . . . . . . . . 129
Servicing Your Radio . . . . . . . . . . . . . . . . . . . . . .129
Taking Care of the Battery . . . . . . . . . . . . . . . . . . 130
Checking the Battery Charge Status . . . . . . . . . . .130
LED and Sounds . . . . . . . . . . . . . . . . . . . . . . . . .130
Fuel Gauge Icon . . . . . . . . . . . . . . . . . . . . . . . . . .130
Battery Recycling and Disposal . . . . . . . . . . . . . .131
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Highlights for the Accessories . . . . . . . . . . . . . . . 132
Appendix: Maritime Radio Use in the VHF
Frequency Range . . . . . . . . . . . . . . . . . . . . . 133
Special Channel Assignments . . . . . . . . . . . . . . . 133
Emergency Channel . . . . . . . . . . . . . . . . . . . . . . .133
Non-Commercial Call Channel . . . . . . . . . . . . . . .133
Operating Frequency Requirements . . . . . . . . . . 134
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Commercial Warranty . . . . . . . . . . . . . . . . . . 141

Important Safety Information
English
ix
Important Safety Information
Product Safety and RF Exposure
Compliance
ATTENTION!
This radio is restricted to occupational use only to
satisfy FCC RF energy exposure requirements.
Before using this product, read the RF energy awareness
information and operating instructions in the Product
Safety and RF Exposure booklet enclosed with your radio
(Motorola Publication part number 68012004065) to
ensure compliance with RF energy exposure limits.
For a list of Motorola-approved antennas, batteries, and
other accessories, visit the following website:
http://www.motorola.com/APX
Software Version
All the features described in the following sections are
supported by the radio's software version R07.00.00 or
later.
See Accessing the Radio Information on page 121 to
determine your radio's software version.
Check with your dealer or system administrator
for more details of all the features supported.
Notice to Users (FCC and Industry Canada)
This device complies with Part 15 of the FCC rules and RSS
210 of the Industry Canada rules per the conditions listed
below:
1This device may not cause harmful interference.
2This device must accept any interference received, including
interference that may cause undesired operation.
3Changes or modifications made to this device, not expressly
approved by Motorola, could void the user's authority to
operate this equipment.
Before using this product, read the operating
instructions for safe usage contained in the
Product Safety and RF Exposure booklet
enclosed with your radio.
!
C
a u t i o
n

Informations importantes sur la sécurité
x
Français Canadien
Informations importantes sur la
sécurité
Sécurité du produit et respect des lignes
directrices concernant l'exposition à
l'énergie RF
ATTENTION!
Cette radio est réservée à un usage professionnel
seulement pour satisfaire les normes d'exposition
à l'énergie RF de la FCC. Avant d'utiliser ce produit,
lisez l'information sur la sensibilisation à l'énergie RF
et les directives d'utilisation présentées dans le livret
Sécurité du produit et exposition à l'énergie RF
accompagnant votre radio (publication de Motorola,
numéro d'article 68012004065)) pour assurer le respect
des limites d'exposition à l'énergie RF.
Pour obtenir une liste d'antennes et d'autres accessoires
approuvés par Motorola, consultez le site Web :
http://www.motorola.com/APX
Version du logiciel
Toutes les fonctionnalités décrites dans les sections
suivantes sont prises en charge par la version du logiciel
R07.00.00 ou ultérieure de la radio.
Vérifiez auprès de votre détaillant ou de l'administrateur
de système pour obtenir des renseignements toutes les
fonctionnalités prises en charge.
Avis aux utilisateurs (FCC et Industrie
Canada)
Cet appareil est conforme à la Partie 15 des règlements de la
FCC et RSS 210 du règlement d'Industrie Canada selon les
conditions énumérées ci-dessous:
1Ce dispositif ne doit pas causer d'interférences nuisibles.
2Cet appareil doit accepter toute interférence reçue, y compris
les interférences qui peuvent perturber le fonctionnement.
3Les changements ou les modifications apportées à ce
dispositif, non expressément approuvées par Motorola,
peuvent annuler le droit de l'utilisateur à utiliser cet
équipement.
Avant d'utiliser ce produit, lisez les directives
d'utilisation sécuritaire présentées dans le livret
Sécurité du produit et exposition à l'énergie RF
accompagnant votre radio.
!
Mise en garde

Computer Software Copyrights
English
xi
Computer Software Copyrights
The Motorola products described in this manual may
include copyrighted Motorola computer programs stored
in semiconductor memories or other media. Laws in the
United States and other countries preserve for Motorola
certain exclusive rights for copyrighted computer
programs, including, but not limited to, the exclusive right
to copy or reproduce in any form the copyrighted
computer program. Accordingly, any copyrighted
Motorola computer programs contained in the Motorola
products described in this manual may not be copied,
reproduced, modified, reverse-engineered, or distributed
in any manner without the express written permission of
Motorola. Furthermore, the purchase of Motorola
products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the
copyrights, patents or patent applications of Motorola,
except for the normal non-exclusive license to use that
arises by operation of law in the sale of a product.
Documentation Copyrights
No duplication or distribution of this document or any
portion thereof shall take place without the express
written permission of Motorola. No part of this manual
may be reproduced, distributed, or transmitted in any
form or by any means, electronic or mechanical, for any
purpose without the express written permission of
Motorola.
Disclaimer
The information in this document is carefully examined,
and is believed to be entirely reliable. However, no
responsibility is assumed for inaccuracies. Furthermore,
Motorola reserves the right to make changes to any
products herein to improve readability, function, or
design. Motorola does not assume any liability arising out
of the applications or use of any product or circuit
described herein; nor does it cover any license under its
patent rights, nor the rights of others.

Disclaimer
English
xii
Notes

Getting Started
English
1
Getting Started
Take a moment to review the following:
How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . page 1
Notations Used in This Manual . . . . . . . . . . . . . . . . . . . page 1
Additional Performance Enhancement . . . . . . . . . . . . . page 2
What Your Dealer/System Administrator
Can Tell You. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
How to Use This Guide
This User Guide covers the basic operation of the APX™ 4000
Portables.
However, your dealer or system administrator may have
customized your radio for your specific needs. Check with your
dealer or system administrator for more information.
Notations Used in This Manual
Throughout the text in this publication, you will notice the use of
WARNING, Caution, and Note. These notations are used to
emphasize that safety hazards exist, and the care that must be
taken or observed.
An operational procedure, practice, or condition,
etc., which may result in injury or death if not
carefully observed.
An operational procedure, practice, or
condition, etc., which may result in damage
to the equipment if not carefully observed.
Note: An operational procedure, practice, or condition,
etc., which is essential to emphasize.
!
W
A R N I N
G
!
!
C
a u t i o
n

Getting Started
English
2
The following special notations identify certain items: Additional Performance Enhancement
The following are some of the latest creations designed to
enhance the security, quality and efficiency of APX radios.
Dynamic System Resilience (DSR)
DSR ensures the radio system is seamlessly switched to a
backup master site dynamically in case of system failure.
DSR also provides additional indication e.g. failure detection,
fault recovery, and redundancy within the system to address to
the user in need. Mechanisms related to the Integrated Voice
and Data (IV & D) or data centric are all supported by DSR.
Example Description
Home button
or H
Buttons and keys are shown in bold print
or as an icon.
Phone Menu entries are shown similar to the
way they appear on the radio’s display.
>This means “Press the right side of the
4-way Navigation button”.


Getting Started
English
3
CrossTalk Prevention
This feature prevents crosstalk scenario from happening,
especially when a wideband antenna is used. This feature
allows the adjustment of the Trident Transmitting SSI clock rate
in the radio to be varied from the Receiving Frequency. This
subsequently reduced the possibilities of radio frequency
interfering spurs and prevents the issues of crosstalk.
Encrypted Integrated Data (EID)
EID provides security encryption and authentication of IV & D
data bearer service communication between the radio and the
Customer Enterprise Network.
SecureNet
SecureNet allows user to perform secured communications on
an Analog or Motorola Data Communication (MDC) channel.
The MDC OTAR feature will allow users to perform OTAR
activities on an MDC channel.
What Your Dealer/System Administrator
Can Tell You
Check with your dealer or system administrator, if the radio is to
be operated in extremely temperatures (less than -30 °C or
more than +60 °C), for the correct radio settings to ensure
proper top and front display operation.
You can also consult your dealer or system administrator about
the following:
•Is your radio preprogrammed with any preset conventional
channels?
•Which buttons have been preprogrammed to access other
features?
•What optional accessories may suit your needs?




Preparing Your Radio for Use
English
4
Preparing Your Radio for Use
Assemble your radio by following these steps:
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Attaching the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
Attaching the Antenna. . . . . . . . . . . . . . . . . . . . . . . . . . page 6
Attaching the Accessory Connector Cover . . . . . . . . . . page 6
Attaching the Belt Clip. . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Turning On the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . page 9
Charging the Battery
The Motorola-approved battery shipped with your radio is
uncharged. Prior to using a new battery, charge it for a minimum
of 16 hours to ensure optimum capacity and performance.
For a list of Motorola-authorized batteries available for use
with your radio, see Accessories on page 132.
Note: When charging a battery attached to a radio, turn the
radio off to ensure a full charge.
Battery Charger
To charge the battery, place the battery, with or without the
radio, in a Motorola-approved charger. The charger’s LED
indicates the charging progress; see your charger’s user guide.
For a list of chargers, see Accessories on page 132.
To avoid a possible explosion:
•DO NOT replace the battery in any area
labeled “hazardous atmosphere”.
•DO NOT discard batteries in a fire.
!
W
A R N I N
G
!

