INTRODUCING THE COMMERCIAL
SERIES MOBILE TWO-WAY RADIOS
A MOBILE RADIO THAT
FITS YOUR BUSINESS,
YOUR BUDGET AND
YOUR VEHICLE

Keep the lines of ommuni ation open
with the Motorola Commer ial Series
CM140 AND CM340
A simple single-digit display, p to ten channels of
comm nication and two programmable b ttons
(allowing p to fo r single-p sh f nctions) make the
radio easy to se.
CM160 AND CM360
For those with more sophisticated req irements, these
radios have an eight-character display and p to 64 or
100 channels (depending pon radio signalling proto-
col*). The CM160 feat res p to fo r programmable
b ttons (allowing p to eight single-p sh f nctions)
and the CM360 has three (for six single-p sh
f nctions).
Additional feat res like encryption for increased
sec rity or data transfer capabilities can be added to
the CM160 and CM360 via PROIS option boards
developed by approved Motorola Application Partners.
Option boards also allow for the development of
c stomer-specific applications so that organisations
can maximise the benefit gained from their radios.
*Some feat res depend pon the radio comm nications protocol that is
chosen. Commercial Series mobiles are available in 5 Tone/PL and MDC/PL
protocols. Let yo r local Motorola A thorised Dealer g ide yo thro gh the
benefits of the most s itable sol tion for yo r organisation.
As som of th
small st mobil radios
on th mark t, th
robust and rugg d
Motorola Comm rcial
S ri s mobil radios
off r communicators
voic and build quality
that will not l t th m
down.
Benefiting from a 75 year history in the
business of ommuni ation, Motorola
wel omes you to the future of two-way
radio with the Commer ial Series.
Comprising four new mobile radios for
powerful in-vehi le or fixed site
ommuni ations, the family also
in ludes portable radios for workteams
that need to keep in tou h wherever
they are working.
QUALITY AND RELIABILITY
Designed and b ilt to the gr elling American standard
MIL spec 810F and exceeding the exacting IP54
standard for environmental protection, all Commercial
Series radios have also passed the Motorola
Accelerated Life Test which replicates five years of
hard se in the field.
Motorola’s voice-compression technology, called
X-PandTM, offers sers excellent a dio q ality at the
to ch of a b tton.
CONTINUOUS COMMUNICATION
The ‘repeater talkaro nd’ f nction allows sers to stay
in to ch sho ld the radio repeater for their area stop
working or when sers work beyond its range.
Repeater talkaro nd is partic larly sef l where the
electricity s pply can be nreliable – often when
comm nication is most important.
BUDGET-CONSCIOUS
Not only does the Commercial Series offer a fantastic
range of feat res in one of the smallest packages on
the market, b t sers of other Motorola mobile radios
like the GM300, GM350 and GM900, can re se many
of their existing accessories, saving time and money.
All radios are s pplied with a microphone, mo nting
bracket and power cable.

MOTOROLA PROVIDES
YOUR ORGANISATION
WITH THE TOOLS TO
COMMUNICATE
Removable Slide
Mount
Bla k Desk
Mi rophone
Keypad Mi rophone
Mag One Mi rophone
Desktop Tray without
Speaker
Keylo k Mount
13W External Speaker
A stolen vehicle’s radio can be ‘st nned’ to prevent
sage and ‘ nst nned’ pon retrieval.
TARGETED COMMUNICATION
Selective calling lets sers talk one-to-one witho t
dist rbing the rest of the team, ideal when sensitive
iss es occ r. The CM360 also displays the caller’s
identity and when a call is missed, the caller’s identity
is stored for retrieval at a convenient time.
INSTALLATION VERSATILITY
The Commercial Series mobile radios are tr ly DIN-
mo ntable and offer a n mber of other mo nting
options.
To protect against theft, a removable slide mo nt
allows reg lar, q ick and easy removal of the radio
when not in se. For added sec rity, the keylock mo nt
g ards against na thorised removal. A desktop tray
with integrated speaker is also available for se in an
office or control room.
INTELLIGENT AND CUSTOMISABLE
The Commercial Series is s pported by a range of
accessories that personalises an individ al’s radio.
These incl de microphones and steering wheel
mo ntable and foot-operated PTT b ttons for safe
sage of driver-operated radios.
OTHER FEATURES
N isance channel delete
Monitor
System Scan
A MOBILE RADIO THAT FITS YOUR BUSINESS
The versatile Commercial Series mobile radios are
partic larly s itable for the cost-conscio s and fast-
moving taxi and co rier/distrib tion markets where
data capabilities allow q ick transmission of
passenger and delivery information. Mo nting options
allow for q ick and easy removal of the radio when
the vehicle is not in se.
For agric lt ral and environmental organisations, lone
workers are protected by b ilt-in safety feat res so
that help and advice from colleag es is only a b tton-
press away.
Within local government operations, one-to-one
calling is ideal for contact between s pervisor and
team member witho t dist rbing b sy colleag es.
EASY-TO-USE
Users benefit from an
int itive men system
and large, clearly-labelled
b ttons. Radios have
either a simple single-
character display or a
clear eight-character
starb rst display with
ten simple-to- nderstand
icons.
PROTECTING USERS
AND EQUIPMENT
Looking after employees
and reso rces is
paramo nt to stay ahead.
With this in mind, the
radios feat re ‘emergency
mode’. A single b tton
press is all it takes to
alert colleag es or base
that assistance is
req ired.
With ‘lone worker’
f nction, the radio can be
set p to req est a
response from a ser at
reg lar intervals. If the
ser is nable to give the
‘okay’ message then a
defined emergency
proced re is activated.

MOTOROLA and the Stylized M Logo are registered in the U.S. Patent & Trademark Office.
All other prod ct or service names are the property of their respective owners.
© Motorola, Inc. 2003.
For more information contact yo r local Motorola
a thorised two-way radio dealer:
CM.FB-RE (05/03)
TECHNICAL SPECIFICATIONS
MODEL NUMBERS
ACCESSORIES
General Specifications Mid Band VHF UHF
Channel Capacity CM340 10, CM360 100 CM140 8, CM160 64, CM340 10, CM360 100
UHF1 403-440MHz
Freq ency 66-88MHz VHF2 146-174MHz UHF2 438-470MHz
Power 1-25W 1-25W, 25-45W 1-25W, 25-40W
Channel Spacing 12.5/20/25KHz
Dimensions (HxWxL) 44x169x118mm
Weight 1.02Kg
Antenna Connector BNC
C rrent Drain – Standby 0.3A
– Rx@ rated, external 8ohm speaker 1.5A
– Transmit (25W, max) 7A 8A 8A
Receiver Mid Band VHF UHF
Freq ency Stability
(-30 deg C +60 deg C, +25 deg C) ± 5 ppm ± 2.5 ppm
Sensitivity (12db Sinad) 0.35µV (12.5KHz) 0.3µV (25KHz) typical
Intermod lation 65dB
Adjacent Channel Selectivity 60dB (12.5KHz) 70dB (25KHz) 65dB (12.5KHz) 75dB (25KHz) 60dB (12.5KHz) 70dB (25KHz)
Sp rio s Rejection 70dB 75dB 70dB
Rated A dio (external a dio
with 4 ohm speaker) 4W internal 13W external
A dio Distortion 3% typical
H m and Noise -40dB (12.5KHz) -45dB (25KHz) -40dB (12.5KHz) -45dB (25KHz) -35dB (12.5KHz) -40dB (25KHz)
A dio Response TIA603
Cond cted Sp rio s Emission -57dBm < 1GHz -47dBm > 1GHz
Transmitter Mid Band VHF UHF
Freq ency Stability
( -30deg C +60deg C, +25deg C) ± 5ppm ± 2.5ppm
Mod lation Limiting ± 2.5KHz (12.5KHz) ± 4KHz (20KHz) ± 5KHz (25KHz)
-40dB (12.5KHz) -40dB (12.5KHz) -35dB (12.5KHz)
FM H m & Noise -45dB (25KHz) -45dB (25KHz) -40dB (25KHz)
Cond cted Sp rio s Emissions -36dBm < 1GHz -30dBm > 1GHz
Adjacent Channel Power -60dB (12.5KHz) -70dB (25KHz)
A dio Response TIA603
A dio Distortion 3% typical
Name Model Number Signalling C annels Frequency Power
CM140 MDM50KNC9AA2AN PL 8 VHF2 146-174MHz 1-25W
CM140 MDM50QNC9AA2AN PL 8 UHF1 403-440MHz 1-25W
CM140 MDM50RNC9AA2AN PL 8 UHF2 438-470MHz 1-25W
CM160 MDM50KNF9AA2AN PL 64 VHF2 146-174MHz 1-25W
CM160 MDM50QNF9AA2AN PL 64 UHF1 403-440MHz 1-25W
CM160 MDM50RNF9AA2AN PL 64 UHF2 438-470MHz 1-25W
CM140 MDM50KQC9AA2AN PL 8 VHF2 146-174MHz 25-45W
CM140 MDM50RPC9AA2AN PL 8 UHF2 438-470MHz 25-40W
CM160 MDM50KQF9AA2AN PL 64 VHF2 146-174MHz 25-45W
CM160 MDM50RPF9AA2AN PL 64 UHF2 438-470MHz 25-40W
CM340 MDM50FNC9AN2AN 5 Tone 10 MB 66-88MHz 1-25W
CM340 MDM50KNC9AN2AN 5 Tone 10 VHF2 146-174MHz 1-25W
CM340 MDM50QNC9AN2AN 5 Tone 10 UHF1 403-440MHz 1-25W
CM340 MDM50RNC9AN2AN 5 Tone 10 UHF2 438-470MHz 1-25W
CM360 MDM50FNF9AN2AN 5 Tone 100 MB 66-88MHz 1-25W
CM360 MDM50KNF9AN2AN 5 Tone 100 VHF2 146-174MHz 1-25W
CM360 MDM50QNF9AN2AN 5 Tone 100 UHF1 403-440MHz 1-25W
CM360 MDM50RNF9AN2AN 5 Tone 100 UHF2 438-470MHz 1-25W
All specifications are subject to change without notice.
Microp ones
HMN3596A Compact Microphone
HMN1035C Heavy D ty Microphone
MDRMN5018A Mag One Microphone
MDRMN5029A Keypad Microphone
MDRMN5019A Mag One Keypad Microphone
MDREX4617A Telephone Style Handset
Handsfree Communication
GMMN4065A Omni-directional Visor Microphone
RLN4856A Footswitch with Remote PTT
RLN4857A P shb tton with Remote PTT
RLN4858A Gooseneck PTT
RLN4836AR External PTT with Emergency Footswitch
In-Ve icle Mounting
FTN6083A DIN Mo nt
GLN7324A Low Profile Mo nting Bracket
GLN7317A High Profile Mo nting Bracket
GLN7341A Removable Slide Mo nt
RLN4779A Keylock Mo nt
Desktop Solutions
HMN3000B Black Desk Microphone
RLN5390A Desktop Tray with Speaker
RLN5391A Desktop Tray witho t Speaker
Speakers
HSN8145B 7.5W External Speaker
RSN4001A 13W External Speaker
Public Address
RLN5288A P blic Address Kit
HSN1000B 6W Amplified External Speaker
Specialist Solutions
HLN9328C External Alarm Relay Cable
GLN7282A B zzer Kit
ENVIRONMENTAL SPECIFICATIONS & STANDARDS
Operating Temperat re - 20 to + 55 deg C
Storage Temperat re - 40 to + 85 deg C
Thermal Shock - 40 to + 80 deg C
H midity 95%RH @ 50 deg C for 8 hr
D st & Water Intr sion IP 54
Mobile Military Standards 810F
Conforms to CE Directives
RTTE Directive 1999/5/EC
A tomotive Directive 72/245/EEC (95/54/EC)
Applicable EN Standards EN300086, EN301489 01/05, EN60950, EN300113
ISO 9001 Standard – Compliance with ISO 9001, an international q ality system ass rance on
design, development, prod ction, installation and servicing of a prod ct.
