Motrona touchMATRIX Series User manual

Operating Manual
motrona GmbH, Zeppelinstraße 16, DE - 78244 Gottmadingen, Tel. [phone], Fax [phone], [email protected], www.motrona.com
touchMATRIX Indicator DX350
HTL-frequency counter, -tachometer and -speed indicator with touchscreen and graphic display
Product features:
Multifunctional unit with several operating modes, e. g. speed or position indicator,
process meter, counter, timer or stopwatch
Universal HTL inputs for encoders / sensors with NPN / PNP / NAMUR characteristic
Bright and high-contrast display with event controlled color variations
Emulation of a 7-segment display inclusively icons and units
Intuitive and easy parameterization by plain text and touchscreen
24 V auxiliary output for encoder supply
Input frequencies up to 250 kHz
Linearization with 24 interpolation points
Numerous features, e. g. scaling, filtering, start-up suppression
96 x 48 mm (3.78 x 1.89 inch) norm panel housing and IP65 protection
Available options:
DX350: Basic unit with HTL inputs (A, B), 3 control inputs
Option AC350: Power supply 115 … 230 VAC
Option AO350: 16 bit analog output, 4 control outputs, serial RS232 interface
Option CO350: 4 control outputs, serial RS232 interface
Option RL350: 2relay outputs
All options can be combined

Dx350_02c_oi_e.doc / Feb-17 Seite 2 / 44
Version:
Description
DX350_01a_oi/sn- tg /Feb-17
First Version
DX350_01d_oi/cn/Okt-16
Revised first Version
DX350_02a_oi/cn/Nov-16
Second Version
DX350_02c_oi/cn/Jan-17
revised Version
Legal notices:
All contents included in this manual are protected by the terms of use and copyrights of motrona
GmbH. Any reproduction, modification, usage or publication in other electronic and printed media
as well as in the internet requires prior written authorization by motrona GmbH.

Dx350_02c_oi_e.doc / Feb-17 Seite 3 / 44
Table of Contents
1. Safety Instructions and Responsibility........................................................................... 4
1.1. General Safety Instructions..........................................................................................................4
1.2. Use according to the intended purpose.......................................................................................4
1.3. Installation....................................................................................................................................5
1.4. Cleaning, Maintenance and Service Notes .................................................................................5
2. Introduction................................................................................................................... 6
2.1. Operation mode............................................................................................................................6
2.2. Function diagram..........................................................................................................................6
3. Electrical Connections.................................................................................................. 7
3.1. DC Power Supply..........................................................................................................................7
3.2. Auxiliary Voltage Output ..............................................................................................................7
3.3. Incremental Input A, B..................................................................................................................8
3.4. Control Inputs ...............................................................................................................................9
3.5. Analog Output (Option AO350)...................................................................................................10
3.6. Serial interface (Option AO350 / CO350)...................................................................................11
3.7. Control-Output (Option AO350 / CO350)....................................................................................11
3.8. AC Power supply (Option AC350)...............................................................................................12
3.9. Relay-Output (Option RL350)......................................................................................................12
4. Display and touch screen ............................................................................................ 13
4.1. Screen structure for parametrization.........................................................................................13
4.2. Screen structure in operation.....................................................................................................14
5. Parameter / Overview-Menu Structure........................................................................ 15
5.1. General Menu.............................................................................................................................17
5.2. Mode Speed ...............................................................................................................................19
5.3. Mode Process Time....................................................................................................................21
5.4. Mode Timer ................................................................................................................................23
5.5. Mode Counter.............................................................................................................................24
5.6. Mode Velocity.............................................................................................................................25
5.7. Preselection Values....................................................................................................................27
5.8. Preselection 1 Menu ..................................................................................................................28
5.9. Preselection 2 Menu ..................................................................................................................31
5.10. Preselection 3 Menu ..................................................................................................................32
5.11. Preselection 4 Menu ..................................................................................................................33
5.12. Serial Menu ................................................................................................................................34
5.13. Analog Menu..............................................................................................................................36
5.14. Command Menu .........................................................................................................................37
5.15. Display Menu..............................................................................................................................38
5.16. Linearization Menu.....................................................................................................................39
6. Appendix..................................................................................................................... 40
6.1. Data readout via serial interface ...............................................................................................40
6.2. Linearization ...............................................................................................................................41
6.3. Dimensions .................................................................................................................................43
6.4. Technical specifications.............................................................................................................44

Dx350_02c_oi_e.doc / Feb-17 Seite 4 / 44
1. Safety Instructions and Responsibility
1.1. General Safety Instructions
This operation manual is a significant component of the unit and includes important rules and hints
about the installation, function and usage. Non-observance can result in damage and/or impairment
of the functions to the unit or the machine or even in injury to persons using the equipment!
Please read the following instructions carefully before operating the device and observe all safety
and warning instructions! Keep the manual for later use.
A pertinent qualification of the respective staff is a fundamental requirement in order to use these
manual. The unit must be installed, connected and put into operation by a qualified electrician.
Liability exclusion: The manufacturer is not liable for personal injury and/or damage to property and
for consequential damage, due to incorrect handling, installation and operation. Further claims, due
to errors in the operation manual as well as misinterpretations are excluded from liability.
In addition the manufacturer reserves the right to modify the hardware, software or operation
manual at any time and without prior notice. Therefore, there might be minor differences between
the unit and the descriptions in operation manual.
The raiser respectively positioner is exclusively responsible for the safety of the system and
equipment where the unit will be integrated.
During installation or maintenance all general and also all country- and application-specific safety
rules and standards must be observed.
If the device is used in processes, where a failure or faulty operation could damage the system or
injure persons, appropriate precautions to avoid such consequences must be taken.
1.2. Use according to the intended purpose
The unit is intended exclusively for use in industrial machines, constructions and systems. Non-
conforming usage does not correspond to the provisions and lies within the sole responsibility of
the user. The manufacturer is not liable for damages which have arisen through unsuitable and
improper use.
Please note that device may only be installed in proper form and used in a technically perfect
condition (in accordance to the Technical Specifications). The device is not suitable for operation in
explosion-proof areas or areas which are excluded by the EN 61010-1 standard.

Dx350_02c_oi_e.doc / Feb-17 Seite 5 / 44
1.3. Installation
The device is only allowed to be installed and operated within the permissible temperature range.
Please ensure an adequate ventilation and avoid all direct contact between the device and hot or
aggressive gases and liquids.
Before installation or maintenance, the unit must be disconnected from all voltage-sources. Further
it must be ensured that no danger can arise by touching the disconnected voltage-sources.
Devices which are supplied by AC-voltages must be connected exclusively by switches, respectively
circuit-breakers with the low voltage network. The switch or circuit-breaker must be placed as near
as possible to the device and further indicated as separator.
Incoming as well as outgoing wires and wires for extra low voltages (ELV) must be separated from
dangerous electrical cables (SELV circuits) by using a double resp. increased isolation.
All selected wires and isolations must be conform to the provided voltage- and temperature-ranges.
Further all country- and application-specific standards, which are relevant for structure, form and
quality of the wires, must be ensured. Indications about the permissible wire cross-sections for
wiring are described in the Technical Specifications.
Before first start-up it must be ensured that all connections and wires are firmly seated and secured
in the screw terminals. All (inclusively unused) terminals must be fastened by turning the relevant
screws clockwise up to the stop.
Overvoltages at the connections must be limited to values in accordance to the overvoltage
category II.
For placement, wiring, environmental conditions as well as shielding and earthing/grounding of the
supply lines the general standards of industrial automation industry and the specific shielding
instructions of the manufacturer are valid. Please find all respective hints and rules on
www.motrona.com/download.html --> “[General EMC Rules for Wiring, Screening and Earthing]”.
1.4. Cleaning, Maintenance and Service Notes
To clean the front of the unit please use only a slightly damp (not wet!), soft cloth. For the rear no
cleaning is necessary. For an unscheduled, individual cleaning of the rear the maintenance staff or
assembler is self-responsible.
During normal operation no maintenance is necessary. In case of unexpected problems, failures or
malfunctions the device must be shipped for back to the manufacturer for checking, adjustment and
reparation (if necessary). Unauthorized opening and repairing can have negative effects or failures
to the protection-measures of the unit.

Dx350_02c_oi_e.doc / Feb-17 Seite 6 / 44
2. Introduction
This series of display unit is suitable for HTL impulse signals and panel mounting. It is very versatile
in use, due to the intuitive handling and the extensive range of functions and options.
2.1. Operation mode
All functions are can be configured in the parameter menu.
The device can be set to one of the following operation modes:
•Speed:
Speed indicator (RPM), operation as tachometer or frequency meter.
Only input A is used.
•Process Time:
Operation as baking time or processing time indicator (reciprocal speed)
Only input A is used.
•Timer:
Operation as stopwatch. Start- / Stop function can be freely parameterized.
Depending on the parameter setting, only Input A or Input B are used.
•Counter:
Operation as position indicator, event-, sum-, differential- or up-down counter.
Input A and B are used.
•Velocity:
Runtime measurement as speed indicator.
Input A operates as a start input and input B operates as a stop input.
2.2. Function diagram

Dx350_02c_oi_e.doc / Feb-17 Seite 7 / 44
3. Electrical Connections
The terminal screws should be tightened with a slotted screwdriver (blade width 2mm).
3.1. DC Power Supply
The unit accepts DC supply from 18 to 30 V at the terminals 1 and 2. The power consumption
depends on the level of the supply voltage with aprox. 100 mA and the additional current required
at the Auxiliary Voltage Output.
All GND terminals are internally interconnected.
3.2. Auxiliary Voltage Output
Terminal 3 and 4 provide an auxiliary output for supply of sensors and encoders.
The output voltage depends on the power supply.
DC version
AC version
The encoder voltage is approx. 1 V lower than
the power supply voltage at terminal 1 and 2
and should be loaded with max. 250 mA.
The encoder voltage is 24 VDC (± 15%) and
should be loaded with max. 150 mA up to 45
degrees Celsius. At higher temperature the
maximum output current is reduced to 80 mA.

Dx350_02c_oi_e.doc / Feb-17 Seite 8 / 44
3.3. Incremental Input A, B
The unit provides two inputs at terminal 5 and 7 for HTL signals.
The characteristics of the incremental input (PNP, NPN, Namur or Tri-State) can be set in the
GENERAL MENU.
Wiring of the incremental inputs:
PNP
NPN
Namur
Tri-State
Unconnected PNP inputs are always “LOW” and unconnected NPN inputs are always “HIGH”.
All inputs are designed to receive impulses from electrical impulse sources.
Notice for mechanical switching contacts:
When exceptionally mechanical contacts are used, please connect an external capacitor between
GND (-) and the corresponding input (+). A capacity of 10 µF will reduce the input frequency to
20 Hz and miscounting due to contact bouncing will be eliminated.

Dx350_02c_oi_e.doc / Feb-17 Seite 9 / 44
3.4. Control Inputs
The three control inputs at terminal 10, 11 and 12 have HTL PNP characteristics.
In the COMMAND MENU the programmable functions for the control inputs can be assigned.
Available functions are: reset the display value, display switching, locking the touch screen or
release the lock function of the control or relay outputs.
Wiring of the control inputs:
Unconnected control inputs are always “LOW”.
All inputs are designed to receive impulses from an electronic impulse source.
Notice for mechanical switching contacts:
When exceptionally mechanical contacts are used, please connect an external capacitor between
GND (-) and the corresponding input (+). A capacity of 10 µF will reduce the input frequency to
20 Hz and miscounting due to contact bouncing will be eliminated.

Dx350_02c_oi_e.doc / Feb-17 Seite 10 / 44
3.5. Analog Output (Option AO350)
A 16 bit analog output is available at terminal 13 and 14 / 15
This output can be configured and scaled in the ANALOG MENU.
The following configuration is possible:
•Voltage output: -10 … +10 V
•Current output: 0 … 20 mA
•Current output: 4 … 20 mA
The analog output is proportional to the display value and is referenced to potential AGND.
AGND and GND are internally interconnected.
Important:
A parallel operation with voltage and current output at the analog output is not allowed.

Dx350_02c_oi_e.doc / Feb-17 Seite 11 / 44
3.6. Serial interface (Option AO350 / CO350)
A serial interface (RS232) is available at terminal 16, 17 und 18.
This interface can be configured in the SERIAL MENU.
The serial interface RS232 can be used:
for easy setup and commissioning of the units
to modify settings and parameters during operation
to read out internal states and actual measuring values by PC or PLC
The following drawing shows the connection to a PC by using a standard Sub-D-9 connector:
3.7. Control-Output (Option AO350 / CO350)
Four control outputs are available at terminal 20, 21, 22 and 23.
Switching conditions can be set in the PRESELECTION MENU. The output Ctrl. Out1 –4 are fast
PNP outputs with a switching capability of 5 –30 Volt / 200 mA per channel. The switching states
is displayed (display with unit and status bar) as C1 … C4.
The switching voltage of the outputs must be applied to input terminal 19 (COM+).
In case of switching inductive loads it is advisable to use external filtering of the coils.
Wiring of the control-outputs:

Dx350_02c_oi_e.doc / Feb-17 Seite 12 / 44
3.8. AC Power supply (Option AC350)
The unit accepts AC supply from 115 to 230 V at the terminals 24 and 25. The power consumption
depends on the level of the supply voltage with aprox. 3VA and the additional current required at
the Auxiliary Voltage Output.
3.9. Relay-Output (Option RL350)
Two relay outputs with potential-free changeover contacts are available at terminal 27, 28, 28, 30,
31, 32. Switching conditions can be set in the PRESELECTION MENU. The switching states is
displayed (display with unit and status bar) as K1 and K4.
AC-switching capacity max 250 VAC/ max 3 A / 750 VA
DC-switching capacity max 150 VAC/ max 2 A / 50 W
Wiring of the relay outputs

Dx350_02c_oi_e.doc / Feb-17 Seite 13 / 44
4. Display and touch screen
4.1. Screen structure for parametrization
The parameter menus and the parameters are described in chapter 5.
Start setup procedure:
To edit the parameters,
press the touchscreen for 3 seconds.
Menu selection:
Select the parameter menu via arrow
buttons and confirm with “OK”.
The menu selection can be terminated
with „C“.
Parameter selection:
Select the parameter via arrow buttons
and confirm with „OK“.
The parameter selection can be terminated
with „C“.
Parameter editing:
Edit the parameter via arrow button up and
down, shift cursor via left and right and
save with „OK“.
The parameter editing can be terminated
with „C“.
Parameter changes becomes active only after closing the menu selection

Dx350_02c_oi_e.doc / Feb-17 Seite 14 / 44
4.2. Screen structure in operation
The following screens are available during operation. Depending on the device version and the
selected operation mode, not all displays will be shown.
Display with unit and status bar
To switch to the next display,
press the touch screen.
Control - or Relay status are only shown
with Option AO350, CO350, RL350.
Display with command keys
To switch to the next display, press the
top of the screen.
This is only possible in operation mode
TIMER or COUNTER.
Display for quick start for enter
preselection values (PRESELECT VALUES)
To switch to the next display, press the
top of the screen or the “skip” button.
This is only possible with Option AO350,
CO350, RL350
Display with minimum and maximum value
To switch to the next display, press the
top of the screen or the “skip” button.

Dx350_02c_oi_e.doc / Feb-17 Seite 15 / 44
5. Parameter / Overview-Menu Structure
This section provides an overview of the menus and their parameters. The menu names are printed
bold and the associated parameters are listed under the menu name. Depending on the device
version and the selected operation mode, only the necessary menus / parameters are shown.
Menu / Parameter
GENERAL MENU
OPERATIONAL MODE
ENCODER PROPERTIES
COUNTING DIRECTION
SCALE UNITS
LINEARIZATION MODE
PIN PRESELECTION
PIN PARAMETER
BACK UP MEMORY
FACTORY SETTINGS
Menu / Parameter
MODE SPEED
DISPLAY VALUE
BASE FREQUENCY
DECIMAL POINT
SAMPLING TIME
WAIT TIME
STANDSTILL TIME
AVERAGE FILTER
MODE PROCESS TIME
DISPLAY FORMAT
DISPLAY VALUE
BASE FREQUENCY
SAMPLING TIME
WAIT TIME
STANDSTILL TIME
AVERAGE FILTER
MODE TIMER
TIME BASE
START / STOP
AUTO RESET
LATCH FUNCTION
MODE COUNTER
COUNT MODE
FACTOR
SET VALUE
DECIMALPOINT
MODE VELOCITY
DISPLAY VALUE
BASE TIME
DECIMALPOINT
WAIT TIME
STANDSTILL TIME

Dx350_02c_oi_e.doc / Feb-17 Seite 16 / 44
Menu / Parameter
PRESELECTION VALUES
PRESELECTION 1
PRESELECTION 2
PRESELECTION 3
PRESELECTION 4
PRESELECTION 1 MENU
MODE 1
HYSTERESIS 1
PULSE TIME 1
OUTPUT TARGET 1
OUTPUT POLARITY 1
OUTPUT LOCK 1
START UP DELAY 1
EVENT COLOR 1
PRESELECTION 2 MENU
MODE 2
HYSTERESIS 2
PULSE TIME 2
OUTPUT TARGET 2
OUTPUT POLARITY 2
OUTPUT LOCK 2
START UP DELAY 2
EVENT COLOR 2
PRESELECTION 3 MENU
MODE 3
HYSTERESIS 3
PULSE TIME 3
OUTPUT TARGET 3
OUTPUT POLARITY 3
OUTPUT LOCK 3
START UP DELAY 3
EVENT COLOR 3
PRESELECTION 4 MENU
MODE 4
HYSTERESIS 4
PULSE TIME 4
OUTPUT TARGET 4
OUTPUT POLARITY 4
OUTPUT LOCK 4
START UP DELAY 4
EVENT COLOR 4
Menu / Parameter
SERIAL MENU
UNIT NUMBER
SERIAL BAUD RATE
SERIAL FORMAT
SERIAL INIT
SERIAL PROTOCOL
SERIAL TIMER
SERIAL VALUE
ANALOG MENU
ANALOG FORMAT
ANALOG START
ANALOG END
ANALOG GAIN
ANALOG OFFSET
COMMAND MENU
INPUT 1 ACTION
INPUT 1 CONFIG
INPUT 2 ACTION
INPUT 2 CONFIG
INPUT 3 ACTION
INPUT 3 CONFIG
DISPLAY MENU
COLOR
BRIGHTNESS
CONTRAST
SCREEN SAVER
UP-DATE-TIME
FONT
LINEARISATION MENU
P1(X)
P1(Y)
P2(X)
P2(Y)
…
…
P23(X)
P23(Y)
P24(X)
P24(Y)

Dx350_02c_oi_e.doc / Feb-17 Seite 17 / 44
5.1. General Menu
OPERATIONAL MODE
This parameter specifies the selected measuring function.
0
SPEED
Speed indicator (RPM), tachometer or frequency counter
1
PROCESS TIME
Operation as baking time or processing time indicator (reciprocal speed)
2
TIMER
Operation as stopwatch
3
COUNTER
Operation as position indicator, event-, sum-, differential- or up-down counter
4
VELOCITY
Runtime measurement as speed indicator
ENCODER PROPERTIES
This parameter determines the characteristics of the pulse input.
0
PNP
PNP (switch to +)
1
NPN
NPN (switch to -)
2
NAMUR
Connect sensor (–) to GND and sensor (+) to input (A or B)
3
TRI-STATE
Tri-State
COUNTING DIRECTION
This parameter determines the direction of counting. (Only in mode COUNTER)
0
FORWARD
forward
1
REVERSE
reverse
SCALE UNITS
This parameter defines the required engineering unit. This parameter does not affect the calculation of the
display value. The number of decimal places must be defined with the parameter DECIMAL POINT.
0
HZ
Default
1
KHZ
2
M/S
3
M/MIN
4
KM/H
5
MPH
6
MIN-1
7
RPM
8
SEK-1
9
RPS
10
STK/H
11
PCS/H
12
MM
13
M
14
INCH

Dx350_02c_oi_e.doc / Feb-17 Seite 18 / 44
Continuation „General Menu“:
15
FEET
16
STUECK
17
PCS
18
SEC
19
MIN
20
MIN:SEC
21
H:M:S
22
%
23
LPM
24
GPM
25
ML/MIN
26
GR/MIN
27
no unit
LINEARIZATION MODE
This parameter defines the linearization function. See chapter 6.1.
0
OFF
No linearization
1
1 QUADRANT
Linearization in the 1. quadrant
2
4 QUADRANT
Linearization in all 4 quadrants
PIN PRESELECTION
This parameter defines the PIN-code to lock the quick start of the menu PRESELECTION VALUE for entering
the preselection values.
(master PIN 6079).
This Lock function is only useful in conjunction with active lock function in PIN PARAMETER.
0000
No lock
…
9999
Access after entering PIN-Code 9999
PIN PARAMETER
This parameter defines the PIN-code for lock function of all parameters (master PIN 6079).
0000
No lock
…
9999
Parameterization of the unit after entering PIN-code 9999
BACK UP MEMORY
0
NO
No back memory –up by power failure
1
YES
Backup memory by power failure, actual value will be saved
FACTORY SETTINGS
0
No
No default values are loaded
1
Yes
Load default values of all parameters (grey marked default values)

Dx350_02c_oi_e.doc / Feb-17 Seite 19 / 44
5.2. Mode Speed
This menu defines the operation as speed indicator (RPM), tachometer or frequency meter.
In this operation mode only input A is used. This menu is only displayed when the appropriate
OPERATIONAL MODE in GENERAL MENU is selected.
DISPLAY VALUE
Desired value, which should be displayed at the setting of BASE FREQUENCY.
1
Smallest value
1000
Default value
99999999
Highest value
BASE FREQUENCY (HZ)
Reference frequency for the desired DISPLAY VALUE.
1
Smallest value
100
Default value
500000
Highest value
DECIMAL POINT
This value defines the position of the decimal point.
0
NO
No decimal point
1
0000000.0
Decimal point at the specified position
2
000000.00
Decimal point at the specified position
3
00000.000
Decimal point at the specified position
4
0000.0000
Decimal point at the specified position
5
000.00000
Decimal point at the specified position
6
00.000000
Decimal point at the specified position
7
0.0000000
Decimal point at the specified position
SAMPLING TIME (S)
The configured value corresponds to the minimum measurement time. The Parameter is used as a filter in
case of irregular frequencies. This parameter directly affects the response time of the unit.
0.005
Shortest Sampling time
0.1
Default value
9.999
Longest Sampling time

Dx350_02c_oi_e.doc / Feb-17 Seite 20 / 44
Continuation „Mode Speed“:
WAIT TIME (S)
This parameter defines the period time of the lowest frequency, accordingly the time between two rising
signal edges detecting frequency 0 Hz. Frequencies with a period time higher than the set “WAIT TIME” will
be detected as frequency = 0 Hz.
0.01
Frequency = 0 Hz, for frequencies below 100 Hz
1.00
Default value
99.99
Frequency = 0 Hz, for frequencies below 0,1 Hz
STANDSTILL TIME (S)
This parameter defines the time setting for standstill definition. A time of xx.xx seconds after detection "
frequency = 0 Hz " the unit signals "standstill" and reactivates the start-up-delays.
Stand still detection can be set in PRESELECT MENU.
0.00
Shortest time
…
99.99
Largest time
AVERAGE FILTER
Selectable average or filter function to avoid measuring fluctuations by unstable frequencies. At setting 1 to
4 a floating average calculation is preformed. At settings 5 to 8, the device uses an exponential filter. The
time constant T (63%) corresponds to the sampling cycles.
For example: If SAMPLING TIME = 0,1 s and AVERAGE FILTER = Exponential filter, T (63 %) = 2x SAMPLING
TIME, after 0,2 seconds, 63% of the step size are reached
0
No average value will be created
1
2 numbers of floating average cycles
2
4 numbers of floating average cycles
3
8 numbers of floating average cycles
4
16 numbers of floating average cycles
5
Exponential filter, T (63 %) = 2x SAMPLING TIME
6
Exponential filter, T (63 %) = 4x SAMPLING TIME
7
Exponential filter, T (63 %) = 8x SAMPLING TIME
8
Exponential filter, T (63 %) = 16x SAMPLING TIME
