Movon MBEC3FOB2004 User manual
Copyright ⓒMovon Corporation. All rights Reserved.
User Manual
적용차종 페이지(SHT/SHTS)
작성처
Information Document (5 sheets: Include cover)
Attachment 1 - System diagram (1 sheet)
Attachment 2 - Fob block diagram (1 sheet)
Attachment 3 - Schematic of fob (Each 1 sheet)
Attachment 4 - Layout of fob (1 sheet)
Attachment 5 - Part List (1 sheet)
-2019.09.26 H S GIM
Rev.NO REV. DATE REV. BY
SORT PREPARED CHECKED APPROVED
R H HWANG
J H LEE
RELEASED
ALL
DESCRIPTION OF CHANGE
APPR
OVAL
H S GIM
2019.12.12
CHANGE PAGE
REL. DATE
Team
목차
Title : RELATING TO CE TYPE-APPROVAL
AS SEPARATE TECHNICAL UNIT
OF VEHICLE RF REMOTE KEYLESS ENTRY IN SMART KEY SYSTEM
REFERENCE
Original archive
(PLM SYSTEM)
1/5
INFORMATION DOCUMENT NO.
CN7 / FOB
Wireless Design
Title : NO.
Date
SHT/SHTS : 2/5
0. GENERAL
0.1. Make
MOBASE ELECTRONICS Co.,Ltd.
0.2.
Model No.
- Transmitter : MBEC3FOB2004
- Transmitter : MBEC4FOB2004
- Transmitter : MBEC5FOB2004
- Receiver : (IBU : Intergrated Body control Unit)
0.3. Name and address of manufacturer
MOBASE ELECTRONICS Co.,Ltd.
100, Saneop-ro 156beon-gil, Gwonseon-gu, Suwon-si, Gyeonggi-do, Republic of Korea
0.4. Address of assembly plant
MOBASE ELECTRONICS Co.,Ltd.
100, Saneop-ro 156beon-gil, Gwonseon-gu, Suwon-si, Gyeonggi-do, Republic of Korea
Information Document
Title : NO.
Date
SHT/SHTS : 3/5
2. PRODUCT SPECIFICATION
2.1 Scope of RKE, passive entry control, passive start control in SMART Key system.
2.1.1 FOB KEY : It has the functions for passive entry and passive start including
RKE functions. It also has the TP for emergency authentication for passive start
2.1.2 SMART Key system : It is an ECU to control the whole smart key system.
It has the functions such as passive entry control, passive start control, RKE functions.
2.2 SPECIFICATIONS
2.2.1 FOB KEY
2.2.2 RECEIVER
Battery life
2 Year(10Times/Day)(Lithium 3V 1EA)
Electric field strength
10mW (433.92MHz)
Code
Rolling Code(Hopping Algorithm)
Operating voltage range
DC 2.5 ~ 3.2V
ITEM
SPECIFICATION
Rated supply voltage
DC 3V
Operating temperature range
- 10 ~ + 60℃with Battery
Frequency
433.92MHz
Storage temperature range
- 30 ~ + 85℃without Battery
Modulation
FSK
Operating Temperature
- 35 ~ + 75℃
Max Humidity
95%
Standby Current
(in alarm setting condition)
Below than 6mA
Specification
Item
DC 9 ~ 16V
Operating Voltage
DC 12V
Rated Supply Voltage
Information Document
Title : NO.
Date
SHT/SHTS : 4/5
2.3 Operating summary
-RKE
①Push button of FOB
(Transmitter / Lock, Unlock, Trunk, Panic, Telecranking)
②TX modulates data to FSK and transmits RKE data using an RF frequency.
(433.92MHz)
③IBU(receiver) distinguish the RKE command data and transmit command after
check the door, trunk state
④Door lock, unlock, trunk open, panic(option),
Telecranking(option) function is activated
- Passive Start
①the SSB button of SMK is pressed to start the engine.
②The indoor ANT of the car transmits the code via the Low Frequency.
③Fob(receiver) decrypts the received code from SMK.
④Fob transmits the code via radio frequency.
⑤IBU should check the boot state.
⑥IBU controls a start-up operation and the transition of supply power.
2.3.1 LOCK & UNLOCK & TRUNK & PANIC
1) RKE Locking request
- When you push Lock button, All door locks will be locked.
2) RKE Unlocking request
- When you push Unlock button, All door locks will be unlocked.
3) RKE Trunk release request
- When you push Trunk button for 1 second, trunk locks will be opend.
4) RKE Panic request(Option)
- When you push Panic button for 1 second (KMC : 0.5s, HMC : 1s), Horn will alarm.
5) RKE Telecranking request(Option)
- When you push Telecranking button for 2 second, will be engine start.
2.4 Caution
①Danger of explosion if battery is incorrectly replaced.
②Replace only with the same or equivalent type recommended by the manufacturer.
③Dispose of used batteries according to the manufacturer's instructions.
Information Document
Title : NO.
Date
SHT/SHTS : 5/5
3. USER MANUAL
3.1 ITEM : FOB LF system
- This system is IBU and inculdes RKE.
- RKE in IBU system is intended for auto door lock or unlock or TRUNK in vehicle.
- This SMK system is to be installde on motor vehicles as *OE item.
*OE : Original Equipment.
*IBU : Intergrated Body control Unit
*RKE : Remote Keyless Entry.
3.2 SYSTEM CONSTRUCTION
3.2.1 SYSTEM IN VEHICLE
3.2.2 SYSTEM FOR TEST
①Connect the 12V power supply and turn on the switch
②Pressing the white tact switch, LF signal is transmitted and FOB LED and IBU LED is flahes
③When the tact switch is pressed repeatively, FOB LED and IBU LED is flahes, repeatively.
* It shows the status of operation through the LED used.
Information Document
Information Document
Information Document
Radio Frequency
(433.92MHz)
ANTENNA
BATTERY
LF ANT
IBU
Low Frequency
(125KHz)
SSB
Radio Frequency
(433.92MHz)
ANTENNA
BATTERY
LF ANT
IBU
Low Frequency
(125KHz)
SwitchLED
U S E R M A N U A L
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
5HRULHQWRUUHORFDWHWKHUHFHLYLQJDQWHQQD
,QFUHDVHWKHVHSDUDWLRQEHWZHHQWKHHTXLSPHQWDQGUHFHLYHU
&RQQHFW WKH HTXLSPHQW LQWR DQ RXWOHW RQ D FLUFXLW GLIIerent from that to which the receiver is con-
nected.
&RQVXOWWKHGHDOHURUDQH[SHULHQFed radio/TV technician for help.
Caution
0RGLILFDWLRQV QRW H[SUHVVO\ DSSURYHG E\ WKH SDUW\ UHsponsible for compliance could void the user’s
authority to operate the equipment.
FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired
operation
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
