MoxPower power-resq User manual

1
© 2014 Maka Technologies Group. All Rights Reserved.
Trademarks
All brand and product names are trademarks or registered trademarks of Maka GPS Technologies Group. In association
with Maka GPS Technologies Private Limited (Singapore), Maka GPS Technologies Sdn. Bhd. (Malaysia), Maka
Technologies Group (H.K.) Limited & Maka Corporation (USA) Inc.
The information in this manual is subject to change without notice.
www . makagps . c o m 1 / 2015 . R 1.1
USER MANUAL
Ensure battery is fully discharge prior to the first charging to maximise your battery life.
MULTI-FUNCTION JUMP STARTER

2
© 2014 Maka Technologies Group. All Rights Reserved.
Safety information
To prevent injury to yourself and others or damage to your device, read the safety information about your device before
using the device.
Warning
Failure to comply with safety warnings and regulations can cause serious injury or death.
Do not use damaged power cords or plugs, or loose electrical sockets
Unsecured connections can cause electric shock or fire.
Do not touch the car charger with wet hands or disconnect the charger by pulling the cord
Doing so may result in electrocution.
Do not bend or damage the car charger
Doing so may cause electric shock or fire.
Do not use your device while it is charging or touch your device with wet hands
Doing so may cause electric shock.
Do not short-circuit the charger or the device
Doing so may cause electric shock or fire, or the battery may malfunction or explode.
Use manufacturer-approved batteries, chargers, accessories, and supplies
Using generic batteries or chargers may shorten the life of your device or cause the device to malfunction. They may
also cause a fire or cause the battery to explode.
Use only Maka GPS Technologies Group-approved battery and charger specifically designed for your device.
Incompatible battery and charger can cause serious injuries or damage to your device.
Maka GPS Technologies Group cannot be responsible for the user’s safety when using accessories or supplies that are
not approved by Maka GPS Technologies Group.
Do not drop or cause an impact to the charger or the device.
Handle and dispose of the device and charger with care
Never dispose of the battery or device in a fire. Never place the battery or device on or in heating devices, such as
microwave ovens, stoves, or radiators. The device may explode when overheated. Follow all local regulations when
disposing of used battery or device.
Never crush or puncture the device.
Avoid exposing the device to high external pressure, which can lead to an internal short circuit and overheating.
Protect the device, battery and charger from damage
Avoid exposing your device and battery to very cold or very hot temperatures.
Extreme temperatures can damage the device and reduce the charging capacity and life of your device and battery.
Prevent the battery from coming into contact with metal objects, as this can create a connection between the + and –
terminals of your battery and lead to temporary or permanent battery damage.
Never use a damaged charger or battery.

3
© 2014 Maka Technologies Group. All Rights Reserved.
Do not bite or suck the device or the battery
Doing so may damage the device or result in an explosion or fire. • Children or animals can choke on small parts.
If children use the device, make sure that they use the device properly.
Do not handle a damaged or leaking Lithium Ion (Li-Ion) battery
For safe disposal of your Li-Ion battery, contact your nearest authorised service centre

4
© 2014 Maka Technologies Group. All Rights Reserved.
Caution
Failure to comply with safety cautions and regulations can cause injury or property damage
Do not expose the device to heavy smoke or fumes
Doing so may damage the outside of the device or cause it to malfunction.
If you notice strange smells or sounds coming from your device or the battery, or if you see smoke or liquids
leaking from the device or battery, stop using the device immediately and take it to a Maka Service Centre
Failure to do so may result in fire or explosion.
Do not store your device in very hot or very cold areas. It is recommended to use your device at temperatures from
0 °C to60 °C and humidity from 10% to 80%
Doing so may cause the screen to malfunction, result in damage to the device, or cause the battery to explode.
Do not use your device or applications for a while if the device is overheated
Prolonged exposure of your skin to an overheated device may cause low temperature burn symptoms, such as red spots
and pigmentation.
Do not drop your device or cause impacts to your device
Your device may be damaged or may malfunction.
If bent or deformed, your device may be damaged or parts may malfunction.
Ensure maximum battery and charger life
Avoid charging your device for more than a week, as overcharging may shorten battery life.
Over time, unused device will discharge and must be recharged before use.
Disconnect the charger from power sources when not in use.
Leaving batteries unused over time may reduce their lifespan and performance. It may also cause the batteries to
malfunction or explode, or cause a fire.
Your device may wear out over time. Some parts and repairs are covered by the warranty within the validity period, but
damages or deterioration caused by using unapproved accessories are not.
Do not disassemble, modify, or repair your device
Any changes or modifications to your device can void your manufacturer’s warranty. If your device needs servicing, take
your device to a Maka Service Centre.
Do not disassemble or puncture the battery, as this can cause explosion or fire.
Turn off the device before removing the battery. If you remove the battery with the device turned on, it may cause the
device to malfunction.
When cleaning your device, mind the following
Wipe your device or charger with a towel or an eraser.
Do not use chemicals or detergents. Doing so may discolour or corrode the outside the device or may result in electric
shock or fire.
Do not distribute copyright-protected material
Do not distribute copyright-protected material without the permission of the content owners. Doing this may violate copyright
laws. The manufacturer is not liable for any legal issues caused by the user’s illegal use of copyrighted material.

5
© 2014 Maka Technologies Group. All Rights Reserved.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other household waste.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these
items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for
details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and
its electronic accessories should not be mixed with other commercial wastes for disposal.

6
© 2014 Maka Technologies Group. All Rights Reserved.
Disclaimer
Some content and services accessible through this device belong to third parties and are protected by copyright, patent
trademark and/or other intellectual property laws. Such content and services are provided solely for your personal non-
commercial use.
You may not use any content or services in a manner that has not been authorised by the content owner or service provider.
Without limiting the foregoing, unless expressly authorised by the applicable content owner or service provider, you may not
modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or
medium any content or services displayed through this device.
“THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS.” MAKA GPS TECHNOLOGIES GROUP DOES NOT WARRANT
CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. MAKA EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. MAKA GPS TECHNOLOGIES GROUP DOES NOT GUARANTEE THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND
UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL MAKA GPS TECHNOLOGIES GROUP BE LIABLE, WHETHER IN
CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES,
EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR
AS A RESULT OF THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.”
Third party services may be terminated or interrupted at any time, and Maka GPS Technologies Group makes no
representation or warranty that any content or service will remain available for any period of time. Content and services are
transmitted by third parties by means of networks and transmission facilities over which Maka GPS Technologies Group has
no control. Without limiting the generality of this disclaimer, Maka GPS Technologies Group expressly disclaims any
responsibility or liability for any interruption or suspension of any content or service made available through
this device.
Maka GPS Technologies Group is neither responsible nor liable for customer service related to the content and services.
Any question or request for service relating to the content or services should be made directly to the respective
content and service providers.

7
© 2014 Maka Technologies Group. All Rights Reserved.
About this manual
This device provides high quality digital recording device using Maka’s high standards and technological expertise. This
user manual is specially designed to detail the device’s functions and features.
Please read this manual before using the device to ensure safe and proper use. Descriptions are based on the
device’s default settings.
Images and screenshots may differ in appearance from the actual product.
Content may differ from the final product, or from software provided by service providers and is subject to change
without prior notice.
For the latest version of the manual, refer to the Maka website at www.makagps.com.
Available features and additional services may vary by device, software.
Applications and their functions may vary by country, region, or hardware specifications.
Maka is not liable for performance issues caused by applications from any provider other than Maka.
Maka is not liable for performance issues or incompatibilities caused by not installing the device as stated in this
manual. Attempting to customise the installation may cause the device or applications to work improperly. This may
result in device malfunctions and data corruption or loss. These actions are violations of your Maka agreement and will
void your warranty.
Default applications that come with the device are subject to updates and may no longer be supported without prior
notice. If you have questions about an application provided with the device, contact Maka Service Centre.

8
© 2014 Maka Technologies Group. All Rights Reserved.
Table of Contents
Product Specifications 9
Getting Started
Overview of your MaxPower 9900mAh Power ResQ
MaxPower 9900mAh Power ResQ Layout 10
Car Jump Terminal Layout 11
Standard Packaging of your MaxPower 9900mAh Power ResQ
Package Contents 12
Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ
Jump Start 12V Car Installation 13
Acting as a Backup Battery in your Car 17
Charging your MaxPower 9900mAh Power ResQ
Charging your Battery 18
Charging the your smartphones/ laptops 19
Operating the LED Touch Light
Turning on your Touch Light 20
FAQ on MaxPower 9900mAh Power ResQ 38

9
© 2014 Maka Technologies Group. All Rights Reserved.
Product Specifications
Smart-Charge Technology
Restore and Recharge MaxPower 9900mAh Power ResQ at the same time by diverting overloaded electricity back to
the device.
Intelligent Reverse Polarity Protection
Prevents damage to the jump starter if the battery is connected in reverse.
Alert user with an alarm and an error message on the car jump terminal display.
Multiple Intelligent Protections
Protect and limit damage to your car engine and battery from short-circuit, over-voltage, and over-current.
Extensively Charging Cycles
Delivering up to 3,000 times charging cycle that is 3 times more than the normal jump starter batteries
Dimension
(L)150mm x (W)73mm x (H)28mm
Weight
328grams
Capacity
9900mAh
Stating Current
>250A
Peak Current
450A<3S
Charging Cycles
Up to 3,000 times*
Input
14V/1A
Output
USB Port: 5V/2A
Laptop Port: 19V/3.5A
Jump Starter Output
12V
Full Charge Time
3 Hours
Operating Temperature
20°C ~ 60°C
Battery Type
Lithium Polymer
*One full charge and discharge of MaxPower 9900mAh Power ResQ Multi-function Jumpstarter.

10
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Overview of your MaxPower 9900mAh Power ResQ
Figure 1: MaxPower 9900mAh Power ResQ Multi-Function Jump Starter
Table 1: Keys of MaxPower 9900mAh Power ResQ
Key
Function
Power Button
Press and hold to turn the device on or off.
Output Port 1
Power supply can provide up to 5 Volts @ 1.0 Amps (maximum).
Output Port 2
Power supply can provide up to 19 Volts @ 3.5 Amps (maximum).
Jump Starter Port
Connect the Smart Terminal during a jump start operation. This power system is used
ONLY on vehicles with 12 volt DC battery systems.
Input Port
Connect the wall socket charger to the charging port.
LED Indicator Lights
LED indicator lights for battery level or charging status.
LED Torch Light
Emergency LED Torch Light. 3 modes: Torchlight, Burst Flashing, SOS
REAR VIEW
FRONT VIEW

11
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Overview of your MaxPower Car Jump Terminal
Figure 2: Car Jump Terminal Diagram
Table 2: Keys of Car Jump Terminal
Key
Function
Display
OLED display screen that display messages transmitted from the terminal.
Car Jump Terminal Port
Connect the Car Jump Terminal to the jump starter port. It also acts as a protection
against short-circuit, over-voltage, and over-current situation.
On/Off Button
Press button to start and stop charging from the device.
Negative (-) Black Clamp
Connect negative (–) black clamp to vehicle battery’s negative terminal.
Positive (+) Red Clamp
Connect positive (+) red clamp to vehicle battery’s positive terminal.

12
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Standard Packaging of your MaxPower 9900mAh Power ResQ
Package contents
Check the product box for the following items:
•9900mAh Power ResQ
•Operating Manual
•Wall Socket Charger
•Smartphones Connectors
•Laptop Connector Tips Kit
The items supplied with the device and any available accessories may vary depending on the region. The supplied items are
designed only for this device and may not be compatible with other devices.
Appearances and specifications are subject to change without prior notice. Malfunctions caused by using unapproved
accessories are not covered by the warranty service. Availability of all accessories is subject to change depending entirely
on manufacturing companies. For more information about available accessories, refer to the Maka GPS Technologies Group
website

13
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ
Jump Start 12V Car Installation
Warning
•This power system is to be used ONLY on vehicles with 12 volt DC battery systems.
•Read your vehicle owner’s manual first as the manufacturer may have specific steps and precautions that
pertain to your vehicle.
•If available, you should wear safety glasses and gloves while jumping your vehicle.
•If you are not in a well-ventilated area, please do not attempt to jump start your vehicle.
•Make sure that your MaxPower 9900mAh PowerResQ has at least 50% charged or has 2 indicator lights
illuminated.
•Remove any and all USB and/or charging devices connected to the MaxPower 9900mAh PowerResQ.
•Put your vehicle in PARK and engage the emergency brake.
•Make sure the vehicle battery terminals, jumper cables and MaxPower 9900mAh PowerResQ are free of any
moisture.
•Turn off ALL electronics in your vehicle (air conditioner, heater, radio, lights, chargers, etc.) to ensure optimal
performance of your MaxPower 9900mAh PowerResQ.
•Ensure key is in the “OFF” position in the ignition. For smart-key fobs (push-to-start vehicles), make sure the
vehicle is completely “OFF” before jump starting.
•Check battery terminals for build-up. If build-up is present try to clean off terminals with a wire brush or a dry
cloth. A clean terminal will provide the best conductivity between your clamps, vehicle battery, and vehicle.
•Never touch red and black clamps together —this can cause dangerous sparks, power arcing, and/or explosion.
•Excessive engine cranking can damage the vehicle‘s starter motor. If the engine fails to start after the
recommended number of attempts, discontinue jump-start procedure and look for other problems that need to
be corrected.
•The product should NOT be submerged in water, exposed to rain or moisture.
•Do NOT allow the product or accessories to get wet when in use or storage.
•Replace worn or defective parts immediately —contact the Customer Service Department at www.makagps.com

14
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ
STEP 3
Check that you have a secure connection between the
vehicle battery’s terminal and clamps. And both clamps
are connected correctly.
STEP 3
STEP 2
STEP 2
Connect positive (+) red clamp to vehicle battery’s
positive terminal.
Connect negative (–) black clamp to vehicle battery’s
negative terminal.
STEP 1
STEP 1
Make sure the battery capacity of the MaxPower
9900mAh Power ResQ is at 50% or more to jump start a
vehicle. (At least 2 indicator lights stay ON)
Note:
Do not use the jump start cable for any other purpose
other than jump starting the vehicle.

15
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ
STEP 4
Plug in the Car Jump Terminal to the Jump Starter
Port.
STEP 5
Press start button to turn on Car Jump Terminal.
Smart-Charge Technology will begin charging your
vehicle’s battery terminal and recharging MaxPower
9900mAh Power ResQ at the same time by diverting
overloaded electricity from the vehicle back to the
device.
Note:
The Car Jump Terminal will automatically switch off if
you have exceeded the time limit of 30 seconds. Press
start button again and proceed to STEP 6 immediately.
STEP 4
STEP 5
PRESS HERE
ERROR CODE ON THE CAR JUMP TERMINAL
Intelligent Reverse Polarity Protection
Jumper clamps are connected in a reverse manner, car jump terminal will cease operation.
1) The car jump terminal will alert user with an alarm.
2) An error code Err1 will appear on the display screen.
Solution: Reattach the jumper clamps correctly and press on the start button again.

16
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ
STEP 6
After a successful start, detach the clamps. First,
disconnect the black clamp and then the red clamp in
that order.
Note:
You should be sure to run your vehicle for at least 15
minutes before shutting the engine off again. If you
have engaged the emergency brake, disengage before
driving your vehicle.
STEP 7
Start the vehicle and leave the engine running. If
the engine fails to start, repeat step 4 to 5 again.
Note:
If the engine fails to start after 3attempts,
discontinue jump-start procedure and look for
other problems that need to be corrected.
STEP 6
STEP 7
ERROR CODE ON THE CAR JUMP TERMINAL
Multiple Intelligent Protections
Short Circuit Protection
Car jump terminal will cut off power supply when any short circuit is detected.
1) The car jump terminal will alert user with an alarm.
2) An error code Err2will appear on the display screen.
Solution: Your fuse might have likely blown. It is advisable to have it professionally checked or replaced.
Over-voltage Protection
The car terminal jumper limits the voltage supplied to the MaxPower 9900mAh Power ResQ by blocking
any unwanted voltages above a safe threshold.
1) The car jump terminal will alert user with an alarm.
2) An error code Err3 will appear on the display screen.
Solution: It is advisable to have your car professionally checked.

17
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ
Acting as a Backup Battery in your Car
MaxPower 9900mAh Power ResQ will keep the PIN codes and settings for radios and navigation systems from getting
erased when you disconnect the battery on your car.
Warning
•Set up a secure working environment.
•Park on a flat, level surface at a safe distance from traffic, sparks or open flames.
•Put on the parking brake.
•Don't smoke, and make sure any smokers in proximity to the working area know not to smoke as well.
•Remember that electricity is not the only danger; batteries contain a sulfuric acid electrolyte solution, which is
highly corrosive (i.e. can burn your skin) and produces a flammable gas.
•Put on gloves and safety goggles.
STEP 2
HOLD FOR
3 SECONDS
STEP 1
Make sure you have SWITCH OFF your car engine.
Secure both clamps on the vehicle battery’s terminal.
STEP 1
STEP 2
Hold on to the start button on the Car Jump Terminal
for 3 seconds. The alarm will sound for 2 times.
The word “Uninterruptible Power Supply” will be
flashing on the display screen.
You may replace your old battery now with the clamps
tightly secured to your car battery terminal.

18
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Charging your MaxPower 9900mAh Power ResQ
Charging the battery
Warning
Ensure battery is fully DISCHARGE prior to the FIRST charging to maximise your battery life.
MaxPower 9900mAh Power ResQ will take approximately 3 hours to have a full charge.
Only charge the product at temperatures between 20°C ~ 60°C.
Do NOT modify or disassemble the product.
If corrosive liquid seeps from the product and comes in contact with your eyes, immediately wash your eyes with
running water and consult with a doctor.
Use only the supplied home charger to charge the MaxPower 9900mAh Power ResQ. Unapproved chargers can
cause the battery to explode or damage the device.
Plug the home charger to the wall socket and connect it to the charging port (14V/1A) of your MaxPower 9900mAh
Power ResQ.
Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not
covered by the warranty.
•The device can be used while it is charging, but it may take longer to fully charge the battery.
•If the device is not charging properly, contact the Customer Service Department at www.makagps.com

19
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Charging your MaxPower 9900mAh Power ResQ
Charging the your smartphones/ laptops
Charging Smartphones
•You may use the USB data cable that comes standard with your phones or choose from the given smartphone charger
connector to charge.
•Attach the USB connector to Output Port 1 (5V/2A) and dock connector to the bottom of the phone.
•If the battery is completely discharged, the device cannot be turned on immediately. Allow a depleted battery to charge
for a few minutes before turning on the device.
Charging Laptops
•Choose your laptop connector tip from the given package and plug into the charging cable given.
•Attach the cable to Output Port 2 (19V/3.5A) and charging tip to your laptop.

20
© 2014 Maka Technologies Group. All Rights Reserved.
Getting Started
Operating the LED Touch Light
Turning on your Touch Light
There are 3 modes of LED Touch Light to choose from:
1) Torchlight
2) Burst Flashing
3) SOS
STEP 1
Hold on to the Power Button for 3 Seconds.
STEP 2
Press on the Power Button again to toggle between
the 4 different modes –Touchlight/ Burst Flashing/
SOS/ Off
