MP-Man DVL 7 User manual

Portable DVD Player
User’sManual
DVL 7
PORTABLE DVD PLAYER

When using this DVD player, basic instructions should always be followed, including the following:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation opening, Install in accordance with the manufacture's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defect the safety purpose of the polarized plug. A polarized plug has two blades with one
wider than other. The wide blade is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments / accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart / apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged liquid has been
spilled or objects have fallen into apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15) T
he apparatus shall not be exposed to dripping or splashing and no objects filled with liquids ,
such as vases, shall be placed on the apparatus.
SAVE THESE INSTRUCTIONS
Important Safety Instructions
1

2
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR ANNOYING
INTERFERENCE, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE AND ONLY USE THE RECOMMENDED ACCESSORIES.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL FOR SERVICING.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of not isolated dangerous voltage within the
inside of the product that may be sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
KEEP AWAY FROM WATER AND MAGNETS:
POWER CORD PROTECTION:
Keep the unit away from flower vases, tubs, sinks, etc.
To avoid any malfunctions of the unit and to protect
If liquids are spilled into the unit, serious damage
against electric Shock, fire or personal injury, please
could occur.
observe the following:
The apparatus shall not be exposed to dripping or
Hold the plug firmly when connecting or
splashing and no objects filled with liquids ,such as
disconnecting the AC power cord to this unit.
vases, shall be placed on the apparatus.
Do not connect or disconnect the AC power cord with
To reduce the risk of fire or electric shock, do not
wet hands.
expose this apparatus to rain or moisture
Keep the AC power cord away from heating
Keep magnetic objects, such as speakers, distant
appliances.
from the player.
Never put any heavy object on the AC power cord.
Do not attempt to repair or reconstruct the AC power STACKING:
cord in any way. Place the unit in a horizontal position and do not place
Remove dust, dirt, etc. on the plug at regular anything heavy on it.
intervals. Do not place the unit on amplifiers or other equipment,
If the unit has been dropped or otherwise damaged, which may become hot.
turn off the power and disconnect the AC power cord. CONDENSATION:
If smoke, odors or noises are emitted from the unit, Moisture may form on the lens in the following cases:
turn off the power and disconnect the AC power cord. immediately after a heater has been turned on.
PLACEMENT: in a steamy or very humid room.
Avoid placing the unit in areas of: the unit is moved from a cold environment to a warm
direct sunlight, heating radiators or closed one.
automobiles.If moisture forms inside this unit, it may not operate
high temperature [over 35°C (95°F)] or high humidity properly. In this case, turn off the power and wait about
(over 90%).one hour for the moisture to evaporate.
excessive dust.NOISE INTERFERENCE WHILE A BROADCAST IS
vibration, impact or where the surface is tilted, as the BEING RECEIVED:
internal parts may be seriously damaged.Depending on the reception condition of the TV,
NON-USE PERIODS: interference may appear on the TV screen while you are
When the unit is not used, turn the power off. watching a TV broadcast, if the unit is switched on. This
When the unit is unused for a long period of time, the is not a malfunction of the unit or the TV. To watch a TV
unit should be unplugged from the household AC broadcast, turn off this unit.
outlet.
NO FINGERS OR OTHER OBJECTS INSIDE:
Touching internal parts of this unit is dangerous and
may cause serious damage to the unit. Do not
attempt to disassemble the unit.
Do not put any foreign object on the disc tray.
Important Safety Instructions (Cont’d)
SAVE THESE INSTRUCTIONS
The DVD-Player is a class 1 laser product. However, this DVD-Player uses a visible laser beam, which could
cause hazardous radiation exposure, if directed. Be sure to operate the DVD-Player correctly as instructed.
When this DVD-Player is plugged into the plug socket, do not place your eyes close to the opening of the disc
tray and other openings to look into the inside of this player. Do not open covers and do not repair yourself.
CLASS 1 LASER
PRODUCT
Use of the controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.

3
Read these battery instructions carefully before using the battery.
Charging
•Charging should shall be less than specified 8.4 V.
•The battery should be charged within the specified temperature of 0~45°C.
Discharging
•In order to prevent over-discharging, the battery should discharge between 7.0 to 7.4 V.
•The battery should be discharged within the temperature 0~60°C.
Storage
•The battery should be stored within proper voltage and temperature 0~60°C.
•Keep the battery terminals clean while storing.
Others
•Do not disassemble the cells and battery.
•Do not use a damaged battery.
•Do not expose the battery to fire, or throw the battery into a fire. This may cause the battery to explode.
•Use the specified charger only.
•Do not touch the battery terminals with metal objects.
•Keep out of reach of children.
•If any electrolyte contacts with your hands or clothes, wash it off thoroughly with water.
•The battery may present a risk of fire or chemical burn if misused.
REGION CODE INFORMATION
This portable DVD-Player has been constructed and produced in the way that it adheres to “ Local
Management “ information , which are recorded on a Digital Versatile Disc(DVD). If the number of
the destination area on a DVD-Video disc does not correspond with the number of the destination area
of this portable DVD-Player , this device won’t be able to play the corresponding disc.
The following list shows the various DVD regions of the world:
Important Battery Safety Precautions
Region 2 : Europe , Middle East , South Africa , Japan
Region 3 : Southeast Asia ,Taiwan
Region 4 : Central and South America , Mexico ,Australia , New Zealand
Region 5 : Russian federation , Africa(part) , India , Pakistan
Region 6 : China
Region 1 : USA , Canada

General Information
ImportantSafetyInstructions ...................................................1-2
ImportantBatterySafetyPrecautions ..............................................3
TableofContents ............................................................4-5
DVDPlayerFeatures&SupportedDiscs ...........................................6
CaringforOpticalDiscs.........................................................7
Player Layout, Controls and Functions
PreparingandUsingtheRemoteControl ...........................................8
RemoteControlFunctions ....................................................9-10
DVDPanelFunctions..........................................................11
DVDPanelFunctions-FunctionMenu............................................12
PowerSupply-ACAdapter.....................................................13
PowerSupply-BatteryPack....................................................14
DetachingBatteryPack........................................................15
UsingaCarAdapter...........................................................15
UsingHeadphones............................................................15
External Audio and Video Connections
ConnectingtheDVDPlayertoyourTV/Receiver.....................................16
Composite / S-Video & Stereo Audio Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Component Video & Progressive Scan Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
OpticalDigitalAudioConnections ................................................19
External Video / Audio Sources to DVD Player Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Basic Playback Functions
GettingStarted-PoweringOn&PlayingaDisc.....................................20
StoppingandPausingPlay .....................................................21
NavigatingDiscMenus ........................................................22
Advanced Playback Functions
FastForward/Reverse&SlowMotionScanning.....................................23
SkipForwardandSkipBack ....................................................23
Jumping to a Specific Chapter/Track or Time Position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Saving Locations for Quick Play with Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
RepeatingaTitle,Chapter/TrackorDisc...........................................26
RepeatingaSpecificTimeSegment ..............................................26
Playing Tracks in a Particular Order with Program Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
PlayingMP3FileswiththeMP3Navigator .........................................28
ViewingJPGFilesonYourTV...................................................29
UsingtheZoomFunction.......................................................30
VideoModePlaying...........................................................31
Built-inScreenDisplayingMode .................................................32
Brightness ..................................................................33
UsingtheOn-ScreenSetupMenu................................................34
Table of Contents (Cont’s)
4

Table of Contents (Cont’d)
5

Supported Disc Formats
The following is a list of disc types that are suitable for play in your DVD Player:
Digital Video Discs
This player is suitable for DVDs of 12cm and 8cm sizes. Single-Sided and Double-Sided DVDs of
Single-Layer or Double-Layer type are supported. Discs of NTSC and PAL color systems are
supported.
Note: This DVD Player adheres to Region Code Standards. Units sold in North America will only
play Region Code 1 discs. The region code is marked on the disc as shown:
Compact Discs - Digital Audio
Music CDs may be used in this player. Also, CD-R and CD-RW discs containing CD-Audio tracks
are supported.
MP3 Discs (Including CD-R & CD-RW)
This player features an On-Screen MP3 Player for navigating and playing MP3 files stored on
disc. Files must have the “Mp3”extension. When recording MP3 files to a CD-R or CD-RW disc,
you must “close the session”before the disc will be useable with this player. A maximum of 250
directories and tracks are allowed.
Product Features and Supported Discs Format
6
*Specifications are subject to change without notice. *All trademarks, logos, brand names and company names are the property of their respective owners.
The is a slim size portable DVD Player,with 7” 16:9 WS TFT LCD monitor. With 14 on board function Function
Key provides convenience operation, built-in Progressive Scan Video out feature present the execllent video effect
through YPbPr cable.
Product Features :
a7” LCD monitor, 26.5mm height ultra slim type.
a480p Progressive Scan Video output with 3-2 pull down.
aPlay multiple disc formats (DVD, CD, CD-R, CD-RW, DVD-R/RW).
aPlay back multiple file formats (DVD, SVCD, VCD, Mp3, Dolby Digital, DTS,C D-DA, JPEG).
a16:9 WS, 4:3 LB, 4:3 PS aspect ratios.
aMultiple Angle capability, multiple languages display and multiple subtitles selection.
aDigital forward and reverse scan.
aFull dunction remote with zoom control and menu control.
aDolby digital output and DTS digital output.
aParental control.
a14 key on board for convenience operation.
aSlim 44 key remote controller.
Compatibility of PC created discs
When recording a disc with a PC , even if it is recorded in a compatibility format as listed above , therefore
may be cases in which the disc cannot be played in this device due to the application software setting used to
create the disc. In this case , please check with the software publisher for more detailed information.
Note : Don’t load any exceptional discs in the Player , as this will cause null playback or other problems
(also with copy-saved Audio Cds)
Data transfer rates
The maximum speed for playing Cds is 4x. The corresponding data transfer rate is 600 KB/sec.
The maximum speed for playing DVDs is 2x with a data transfer rate of 2700 KB/sec.

Labels
Tapes
Labeling Side
Surface
Handling of Discs:
Please hold the disc by gripping the rim or by placing the index finger in the
central hole. Never touch the signal surface, which is shiny. This applies to
both sides of double sided discs.
Cleaning of Discs:
Finger prints or stains on the surface of the disc may cause signal loss.
Depending on the degree of the stain, the reflected luminosity from the signal
surface may be weakened, resulting in degraded picture quality. Therefore,
please use a soft cloth and wipe in a radiating manner from the center of the
disc to the outer rims when cleaning the disc surface.
If the surface of your disc is very dirty, please wipe the disc with a moist cloth,
followed by a dry soft cloth to remove all water stains.
Never use electrostatic prevention products or solutions which contain
benzene, thinner or any other vaporizing substances, as they may damage
the disc surface.
Never add labels or adhesive tapes on the discs and be careful not to
scratch or damage the disc surface.
Storage of Discs:
To prevent discs from becoming bent or deformed, they should be vertically
kept in the disc storage case. To prevent damage, avoid leaving discs in your
car, where they may be subject to direct sunlight and high temperature.
Please thoroughly read the "Instruction Points for Attention" on the discs.
Discs to avoid :
Please only use conventional , fully circular discs in this DVD-Player. It is not recommended to use
warped , cracked , chipped or otherwise damaged discs in this device.
Cleaning the DVD Player:
The control panel and the case of the player will only require occasional wiping with a soft cloth. Areas with
stubborn stains can be cleaned with a soft cloth dipped in a neutral detergent. To prevent damaging the player,
never use vaporizing solutions.
Disc Accessories:
Do not use any disc accessory to improve the audio quality, disc protective solutions or lens cleaner. These
products may cause problems.
Caring for Optical Discs
7

8
Make sure no objects
are between the remote
and the player.
Similar remote controls
could interfere with the
function of the player.
Make sure not to store
the remote upside
down or with any
objects pressing on the
buttons - this could
drain the battery.
Operation of Remote Control
When using the Remote control, please aim
at the device's remote control sensor,
located on the front of DVD Player. A 30
degree angle is recommended for best
operation.
Installing the Battery
If the remote control only operates when you get closer to the DVD Player, it may indicate that the battery is
weak. Please replace the battery (Lithium battery) simultaneously with a new battery of the same type (CR 2025).
Please note the positive (+) side is facing upwards when the remote is held as shown below.
Important Notes about the Battery
If the unit will not be used for an extended length of time, it’s wise to remove the battery before storage.
The life of the battery depends on the amount of usage. With typical usage, a battery life of approximately 6
months can be expected.
1. Please become familiar with your
remote controller’s battery holder parts
below.
2. Grasp the remote with the underside facing upward. Notice the
release clip to the left and handle to the right. To remove the battery
holder, place pressure on the release clip towards the center of the
remote,while pulling the handle out towards you, as the arrows show.
3. Use you thumbnail to squeeze the release clip
inward, while at the same time,pull the Handle
out with your index fingernai.
Preparing and Using the Remote Control
Remote Control
Bottom
Remote Control
Bottom
4. Insert new battery into the holder. Make sure
that positive(+) side is facing upwards. Return
the battery holder back into the remote.
Handle
Release Clip
QuickTips
30
°°
PORTABLE DVDPLAYER

SETUP
With playback stopped, press to
enter the DVD Player’s On-Screen
Setup Menu.
DISPLAY
Shows elapsed time and other
information for the current disc.
GOTO
Press to navigate to a specific
chapter. Follow with corresponding
number key.
PROGRAM
Create a custom play list of selected
tracks and play sequence.
BRIGHTNESS
Press repeatedly to adjust the
brightness through 20 levels.
FAST FORWARD
Press to play the disc at high speed
for searching. Press again to cycle
available speeds - 2x,4x,8x,16X,32X.
PLAY/PAUSE
Press to PLAY the current disc or
selected chapter or track. During
playback, press to PAUSE audio
track play or video on a still frame.
Press again to resume normal
playback.
POWER
Press the power button to put
player into Standby mode. Press
again to power unit on.
TITLE
Used to enter the Title Menu
supported on DVD discs.
MENU
Press to enter the menu of a
DVD.
BOOKMARK
Press to store the current point on
the disc as a bookmark that can
be accessed quickly without
searching.
ANGLE
View Multi-Angles with discs that
support this feature. Press again
to cycle through available angles.
FAST REVERSE
Press to reverse-play the disc at
high speed for searching. Press
again to cycle through available
speeds - 2x,4x,8x,16X,32X.
LEFT/RIGHT/UP/DOWN
ARROWS
Use the arrow keys to select menu
items in disc menus, as well as to
navigate in the Setup Menu and
other modes.
ENTER
Use the enter key to confirm
menu choices and execute
selected instructions.
SKIP PREVIOUS
Press to skip to the previous
chapter or track.
Understanding the Buttons on the Remote
The Remote Control provides access to the DVD Player¢s advanced functions, such as searching, repeating video
segments, accessing the Setup Menu, choosing subtitle mode, muting the volume and pausing the action, just to
name a few. The remote is also used to put the unit into “standby”mode, and power it on again.
Remote Control Functions (1 of 2)
9
SUBTITLE
Use with ARROW keys to turn
subtitles On/Off and cycle through
available languages.
*See next page for remaining buttons.
LCD
Press to select Display Modes.
Press again to cycle through Modes
- Full, Wide, Normal, or Off.
STOP
Press once to stop current disc play
but hold resume location. Press
again to completely stop play.
Please note that theVIDEO MODE Button onthe Remote andthe MONITOR Button ontheplayerare the samefunction.
*
MONITOR
