MPH Industries BEE III User manual

BEE III/Enforcer
Dash & Antenna Bracket
Assembly
Installation Materials
909090 909092
909041
908203 908340 903356
909094 909091 909085 909807G01
ABCDE
FG
HI
J
Installation Guide
Not
Included
PT#
ai.950955
&
ai.951250
Flat Head Screw #10 Nylon
Flat Washer #10 Flat Washer 1/4” Flat Washer 1/4” Nylon
Flat Washer
10-32 Knob w/ Stud 10-32 Knob w/ Insert 1/4-20 Star Knob
w/ Insert Antenna Bracket Dash Bracket
1
QUANTITY
5
QUANTITY
3
QUANTITY
1
QUANTITY
1
QUANTITY
1
QUANTITY
1
QUANTITY
1
QUANTITY
1
QUANTITY
2
QUANTITY

A
B
I
B
C
G
I
B
E
I
D
H
I
D
H
12
34
56
Insert screw (A) into hole in bracket. Slide nylon
washer (B) onto screw. Place antenna bracket (I)
onto screw. Slide nylon washer (B) onto screw.
Slide flat washer (C) onto screw. Thread knob
(G) onto screw, but do not fully tighten.
Take antenna and place large nylon (E) washer onto the stud
in the antenna. Insert stud from the antenna thru hole in
antenna bracket (I). Slide flat washer (D) onto antenna stud
and secure with star knob (H).
Place radar onto bracket.
Look on the underside of the dash where the instrument
panel is located and find two screws. Remove the screws
from the dash.
Take assembled bracket and place it above the steering
wheel, so that the slots in the dash bracket (J) line up with
screw holes. Thread screw back into the dash to secure your
bracket and radar. The bottom of the bracket is made to bend
in order to conform to your dash. Fully tighten all knobs.
Take knob with stud (F) and slide a flat washer
(C) and a nylon washer (B) onto stud. Insert stud
thru hole in antenna bracket (I), and slide nylon
washer (B) onto the stud. Thread knob into insert
in the side of the radar. Repeat for other side of
bracket.
Installation Process
F
C
B
GCB IBA
FB
CE
ID
H
IB

A
B
C D
E
F
G
H
I
J
ITEM QUANTITY PART NUMBER DESCRIPTION
1 5 3 1 1 2 1 1 1 1
909090 909092 908203 908340 903356 909094 909091 909085
909807G01
909041
10-32 x 0.50 Flat Head Screw #10 Nylon Flat Washer #10 Flat Washer 1/4” Flat Washer 1/4” Nylon Flat Washer 10-32 Knob With Stud 10-32 Knob With Insert 1/4 - 20 Star Knob With Insert Bee III/Enforcer Antenna Bracket Bee III/Enforcer Dash Bracket
GC
C
CF
F
B
BB
BB
D
H
I
E
A
