AB UT THIS MANUAL
Purpose
This man al describes the assembly, installation, operation and tro bleshooting of this nit. Please read
this man al caref lly before installations and operations. Keep this man al for f t re reference.
Scope
This man al provides safety and installation g idelines as well as information on tools and wiring.
SAFETY INSTRUCTI NS
WARNING: This chapter contains important safety and operating instructions. Read and
keep this manual for future reference.
1. Before sing the nit, read all instr ctions and ca tionary markings on the nit, the batteries and all
appropriate sections of this man al.
2. CAUTI N --To red ce risk of inj ry, charge only deep-cycle lead acid type rechargeable batteries.
Other types of batteries may b rst, ca sing personal inj ry and damage.
3. Do not disassemble the nit. Take it to a q alified service center when service or repair is req ired.
Incorrect re-assembly may res lt in a risk of electric shock or fire.
4. To red ce risk of electric shock, disconnect all wirings before attempting any maintenance or cleaning.
T rning off the nit will not red ce this risk.
5. CAUTI N – Only q alified personnel can install this device with battery.
6. NEVER charge a frozen battery.
7. For optim m operation of this inverter/charger, please follow req ired spec to select appropriate cable
size. It’s very important to correctly operate this inverter/charger.
8. Be very ca tio s when working with metal tools on or aro nd batteries. A potential risk exists to drop
a tool to spark or short circ it batteries or other electrical parts and co ld ca se an explosion.
9. Please strictly follow installation proced re when yo want to disconnect AC or DC terminals. Please
refer to INSTALLATION section of this man al for the details.
10. F ses (3 pieces of 40A, 32VDC for 1KVA, 4 pieces of 40A, 32VDC for 2KVA and 6 pieces for 3KVA, 1
piece of 200A, 58VDC for 4KVA and 5KVA) are provided as over-c rrent protection for the battery
s pply.
11. GROUNDING INSTRUCTIONS -This inverter/charger sho ld be connected to a permanent gro nded
wiring system. Be s re to comply with local req irements and reg lation to install this inverter.
12. NEVER ca se AC o tp t and DC inp t short circ ited. Do NOT connect to the mains when DC inp t
short circ its.
13. Warning!! Only q alified service persons are able to service this device. If errors still persist after
following tro bleshooting table, please send this inverter/charger back to local dealer or service center
for maintenance.

2
INTR DUCTI N
This is a m lti-f nction inverter/charger, combining f nctions of inverter, MPPT solar charger and battery
charger to offer ninterr ptible power s pport with portable size. Its comprehensive LCD display offers
ser-config rable and easy-accessible b tton operation s ch as battery charging c rrent, AC/solar charger
priority, and acceptable inp t voltage based on different applications.
Features
P re sine wave inverter
B ilt-in MPPT solar charge controller
Config rable inp t voltage range for home appliances and personal comp ters via LCD setting
Config rable battery charging c rrent based on applications via LCD setting
Config rable AC/Solar Charger priority via LCD setting
Compatible to mains voltage or generator power
A to restart while AC is recovering
Overload/ Over temperat re/ short circ it protection
Smart battery charger design for optimized battery performance
Cold start f nction
Basic System Architecture
The following ill stration shows basic application for this inverter/charger. It also incl des following devices to
have a complete r nning system:
Generator or Utility.
PV mod les (option)
Cons lt with yo r system integrator for other possible system architect res depending on yo r req irements.
This inverter can power all kinds of appliances in home or office environment, incl ding motor-type appliances
s ch as t be light, fan, refrigerator and air conditioner.
Fig re 1 Hybrid Power System

3
Product verview
1-3KVA model
N TE: For parallel model installation and operation,
please check separate parallel installation g ide for
the details.
1. LCD display
2. Stat s indicator
3. Charging indicator
4. Fa lt indicator
5. F nction b ttons
6. Power on/off switch
7. AC inp t
8. AC o tp t
9. PV inp t
10. Battery inp t
11. Circ it breaker
12. RS232 comm nication port
13. Parallel comm nication cable (only for parallel model)
14. C rrent sharing cable (only for parallel model)
15. Dry contact
4KVA/5KVA single model
4KVA/5KVA parallel model

4
INSTALLATI N
Unpacking and Inspection
Before installation, please inspect the nit. Be s re that nothing inside the package is damaged. Yo sho ld
have received the following items inside of package:
The nit x 1
User man al x 1
Comm nication cable x 1
Software CD x 1
Preparation
Before connecting all wirings, please take off bottom cover by removing two screws as shown below.
Mounting the Unit
Consider the following points before selecting where to install:
Do not mo nt the inverter on flammable constr ction
materials.
Mo nt on a solid s rface
Install this inverter at eye level in order to allow the LCD
display to be read at all times.
The ambient temperat re sho ld be between 0°C and 55°C
to ens re optimal operation.
The recommended installation position is to be adhered to
the wall vertically.
Be s re to keep other objects and s rfaces as shown in the
right diagram to g arantee s fficient heat dissipation and
to have eno gh space for removing wires.
SUITABLE F R M UNTING N C NCRETE R
THER N N-C MBUSTIBLE SURFACE NLY.

5
Install the nit by screwing three screws.
1-3KVA 24V, 1KVA/3KVA 48V model 2-3KVA 24V/48V Plus, 4-5KVA 48V model
Battery Connection
CAUTI N: For safety operation and reg lation compliance, it’s req ested to install a separate DC over-c rrent
protector or disconnect device between battery and inverter. It may not be req ested to have a disconnect
device in some applications, however, it’s still req ested to have over-c rrent protection installed. Please refer
to typical amperage in below table as req ired f se or breaker size.
WARNING! All wiring m st be performed by a q alified personnel.
WARNING! It's very important for system safety and efficient operation to se
appropriate cable for battery connection. To red ce risk of inj ry, please se the
proper recommended cable and terminal size as below.
Recommended battery cable and terminal size:
Model Typical
Amperage
Battery
Capacity
Wire Size
Ring Terminal Torque
Value
Cable
mm
2
Dimensions
D (mm)
L (mm)
1KVA 48V 20A 100AH 1*14AWG 2 6.4 21.8 2~ 3 Nm
1KVA 24V, 2KVA 48V 33A 100AH 1*10AWG 5 6.4 22.5 2~ 3 Nm
3KVA 48V 50A 100AH 1*8AWG 8 6.4 23.8 2~ 3 Nm
2KVA 24V 66A 100AH 1*6AWG 14 6.4 29.2 2~ 3 Nm
200AH 2*10AWG 8 6.4 23.8
3KVA 24V 100A 100AH 1*4AWG 22 6.4 33.2 2~ 3 Nm
200AH 2*8AWG 14 6.4 29.2
4KVA 66A 200AH 1*4AWG 22 6.4 33.2 2~ 3 Nm
2*8AWG 14 6.4 29.2
5KVA 87A 200AH 1*4AWG 22 6.4 33.2 2~ 3 Nm
2*8AWG 14 6.4 29.2
Ring terminal:

6
Please follow below steps to implement battery connection:
1. Assemble battery ring terminal based on recommended battery cable and terminal size.
2. Connect all battery packs as nits req ires. It’s s ggested to connect at least 100Ah capacity battery for
1-3KVA model and at least 200Ah capacity battery for 4KVA/5KVA model.
N TE: Please only se sealed lead acid battery or sealed GEL/AGM lead-acid battery.
3. Insert the ring terminal of battery cable flatly into battery connector of inverter and make s re the bolts are
tightened with torq e of 2-3 Nm. Make s re polarity at both the battery and the inverter/charge is correctly
connected and ring terminals are tightly screwed to the battery terminals.
WARNING: Shock Hazard
Installation m st be performed with care d e to high battery voltage in series.
CAUTI N!! Do not place anything between the flat part of the inverter terminal and the ring
terminal. Otherwise, overheating may occ r.
CAUTI N!! Do not apply anti-oxidant s bstance on the terminals before terminals are
connected tightly.
CAUTI N!! Before making the final DC connection or closing DC breaker/disconnector, be s re
positive (+) m st be connected to positive (+) and negative (-) m st be connected to negative
(-).

7
AC Input/ utput Connection
CAUTI N!! Before connecting to AC inp t power so rce, please install a separate AC breaker between
inverter and AC inp t power so rce. This will ens re the inverter can be sec rely disconnected d ring
maintenance and f lly protected from over c rrent of AC inp t. The recommended spec of AC breaker is 10A
for 1KVA, 20A for 2KVA, 32A for 3KVA, 40A for 4KVA and 50A for 5KVA.
CAUTI N!! There are two terminal blocks with “IN” and “OUT” markings. Please do NOT mis-connect inp t
and o tp t connectors.
WARNING! All wiring m st be performed by a q alified personnel.
WARNING! It's very important for system safety and efficient operation to se appropriate cable for AC inp t
connection. To red ce risk of inj ry, please se the proper recommended cable size as below.
Suggested cable requirement for AC wires
Model Gauge Torque Value
1KVA 16 AWG 0.5~ 0.6 Nm
2KVA 230VAC 14 AWG 0.8~ 1.0 Nm
2KVA 120VAC
3KVA 12 AWG 1.2~ 1.6 Nm
4KVA 10 AWG 1.4~ 1.6Nm
5KVA 8 AWG 1.4~ 1.6Nm
Please follow below steps to implement AC inp t/o tp t connection:
1. Before making AC inp t/o tp t connection, be s re to open DC protector or disconnector first.
2. Remove ins lation sleeve 10mm for six cond ctors. And shorten phase L and ne tral cond ctor N 3 mm.
3. Insert AC inp t wires according to polarities indicated on terminal block and tighten the terminal screws. Be
s re to connect PE protective cond ctor ( ) first.
→Ground (yellow-green)
L→LINE (brown or black)
N→Neutral (blue)
WARNING:
Be s re that AC power so rce is disconnected before attempting to hardwire it to the nit.
4. Then, insert AC o tp t wires according to polarities indicated on terminal block and tighten terminal screws.
Be s re to connect PE protective cond ctor ( ) first.
→Ground (yellow-green)
L→LINE (brown or black)
N→Neutral (blue)

8
5. Make s re the wires are sec rely connected.
PV Connection
CAUTI N: Before connecting to PV mod les, please install separately a DC circ it breaker between inverter
and PV mod les.
WARNING! All wiring m st be performed by a q alified personnel.
WARNING! It's very important for system safety and efficient operation to se appropriate cable for PV
mod le connection. To red ce risk of inj ry, please se the proper recommended cable size as below.
Model Typical Amperage Cable Size Torque
1KVA 24V / 2KVA 24V/
3KVA 24V 25A 12 AWG 1.2~1.6 Nm
1KVA 48V / 3KVA 48V
18A 14 AWG 1.2~1.6 Nm
2KVA 24V Pl s
3KVA 24V Pl s
2KVA 48V Pl s
3KVA 48V Pl s
4KVA / 5KVA
60A 8 AWG 1.4~1.6 Nm
CAUTI N: Important
Be s re to connect AC wires with correct polarity. If L and N wires are connected reversely, it may ca se
tility short-circ ited when these inverters are worked in parallel operation.
CAUTI N: Appliances s ch as air conditioner are req ired at least 2~3 min tes to restart beca se it’s req ired
to have eno gh time to balance refrigerant gas inside of circ its. If a power shortage occ rs and recovers in a
short time, it will ca se damage to yo r connected appliances. To prevent this kind of damage, please check
man fact rer of air conditioner if it’s eq ipped with time-delay f nction before installation. Otherwise, this
inverter/charger will trig overload fa lt and c t off o tp t to protect yo r appliance b t sometimes it still ca ses
internal damage to the air conditioner.

9
PV Module Selection:
When selecting proper PV mod les, please be s re to consider below parameters:
1. Open circ it Voltage (Voc) of PV mod les not exceeds max. PV array open circ it voltage of inverter.
2. Open circ it Voltage (Voc) of PV mod les sho ld be higher than min. battery voltage.
Solar Charging Mode
INVERTER M DEL
1KVA 24V
2KVA 24V
3KVA 24V
1KVA 48V
3KVA 48V
2KVA 24V
Plus/ 3KVA
24V Plus
2KVA 48V
Plus/3KVA 48V
Plus/ 4KVA/5KVA
Max. PV Array pen Circuit Voltage
75Vdc max 102Vdc max
145Vdc
PV Array MPPT Voltage Range 30~66Vdc 60~88Vdc
30~115Vdc 60~115Vdc
Min. battery voltage for PV charge
17Vdc 34Vdc 17Vdc 34Vdc
Please follow below steps to implement PV mod le connection:
1. Remove ins lation sleeve 10 mm for positive and negative cond ctors.
2. Check correct polarity of connection cable from PV mod les and PV inp t
connectors. Then, connect positive pole (+) of connection cable to positive
pole (+) of PV inp t connector. Connect negative pole (-) of connection
cable to negative pole (-) of PV inp t connector.
3. Make s re the wires are sec rely connected.
Final Assembly
After connecting all wirings, please p t bottom cover back by screwing two screws as shown below.
1KVA/2KVA/3KVA 2KVA Pl s/3KVA Pl s/4KVA/5KVA

10
Communication Connection
Please se s pplied comm nication cable to connect to inverter and PC. Insert b ndled CD into a comp ter and
follow on-screen instr ction to install the monitoring software. For the detailed software operation, please
check ser man al of software inside of CD.
Dry Contact Signal
There is one dry contact (3A/250VAC) available on the rear panel. It co ld be sed to deliver signal to external
device when battery voltage reaches warning level.
Unit Stat s
Condition Dry contact port:
NC & C NO & C
Power Off Unit is off and no o tp t is powered. Close Open
Power On
O tp t is powered from Utility. Close Open
O tp t is
powered
from
Battery or
Solar.
Program 01
set as Utility
Battery voltage < Low DC warning
voltage Open Close
Battery voltage > Setting val e in
Program 13 or battery charging
reaches floating stage
Close Open
Program 01
is set as
SBU or
Solar first
Battery voltage < Setting val e in
Program 12 Open
Close
Battery voltage > Setting val e in
Program 13 or battery charging
reaches floating stage
Close Open

11
PERATI N
Power N/ FF
Once the nit has been properly installed and the batteries are connected well, simply press On/Off switch
(located on the b tton of the case) to t rn on the nit.
peration and Display Panel
The operation and display panel, shown in below chart, is on the front panel of the inverter. It incl des
three indicators, fo r f nction keys and a LCD display, indicating the operating stat s and inp t/o tp t
power information.
LED Indicator
LED Indicator Messages
Green Solid On O tp t is powered by tility in Line mode.
Flashing O tp t is powered by battery or PV in battery mode.
Green Solid On Battery is f lly charged.
Flashing Battery is charging.
Red Solid On Fa lt occ rs in the inverter.
Flashing Warning condition occ rs in the inverter.
Function Keys
Function Key Description
ESC To exit setting mode
UP To go to previo s selection
DOWN To go to next selection
ENTER To confirm the selection in setting mode or enter setting mode
LCD display
LED indicators
F nction keys

12
LCD Display Icons
Icon Function description
Input Source Information
Indicates the AC inp t.
Indicates the PV inp t
Indicate inp t voltage, inp t freq ency, PV voltage, battery voltage and
charger c rrent.
Configuration Program and Fault Information
Indicates the setting programs.
Indicates the warning and fa lt codes.
Warning: flashing with warning code.
Fa lt: lighting with fa lt code
utput Information
Indicate o tp t voltage, o tp t freq ency, load percent, load in VA, load in
Watt and discharging c rrent.
Battery Information
Indicates battery level by 0-24%, 25-49%, 50-74% and 75-100% in battery
mode and charging stat s in line mode.
In AC mode, it will present battery charging stat s.
Stat s Battery voltage LCD Display
Constant
C rrent mode /
Constant
Voltage mode
<2V/cell 4 bars will flash in t rns.
2 ~ 2.083V/cell Bottom bar will be on and the other three
bars will flash in t rns.
2.083 ~ 2.167V/cell Bottom two bars will be on and the other
two bars will flash in t rns.
> 2.167 V/cell Bottom three bars will be on and the top
bar will flash.
Floating mode. Batteries are f lly charged. 4 bars will be on.

13
In battery mode, it will present battery capacity.
Load Percentage Battery Voltage LCD Display
Load >50%
< 1.717V/cell
1.717V/cell ~ 1.8V/cell
1.8 ~ 1.883V/cell
> 1.883 V/cell
50%> Load > 20%
< 1.817V/cell
1.817V/cell ~ 1.9V/cell
1.9 ~ 1.983V/cell
> 1.983
Load < 20%
< 1.867V/cell
1.867V/cell ~ 1.95V/cell
1.95 ~ 2.033V/cell
> 2.033
Load Information
Indicates overload.
Indicates the load level by 0-24%, 25-50%, 50-74% and 75-100%.
0%~25% 25%~50% 50%~75% 75%~100%
Mode peration Information
Indicates nit connects to the mains.
Indicates nit connects to the PV panel.
Indicates load is s pplied by tility power.
Indicates the tility charger circ it is working.
Indicates the DC/AC inverter circ it is working.
Mute peration
Indicates nit alarm is disabled.

14
LCD Setting
After pressing and holding ENTER b tton for 3 seconds, the nit will enter setting mode. Press “UP” or “DOWN”
b tton to select setting programs. And then, press “ENTER” b tton to confirm the selection or ESC b tton to
exit.
Setting Programs:
Program
Description Selectable option
00 Exit setting mode
Escape
01
O tp t so rce priority:
To config re load power
so rce priority
Solar first
Solar energy provides power to the
loads as first priority.
If solar energy is not s fficient to
power all connected loads, battery
energy will s pply power the loads at
the same time.
Utility provides power to the loads only
when any one condition happens:
- Solar energy is not available
- Battery voltage drops to either
low-level warning voltage or the
setting point in program 12.
Utility first (defa lt)
Utility will provide power to the loads
as first priority.
Solar and battery energy will provide
power to the loads only when tility
power is not available.
SBU priority
Solar energy provides power to the
loads as first priority.
If solar energy is not s fficient to
power all connected loads, battery
energy will s pply power to the loads
at the same time.
Utility provides power to the loads only
when battery voltage drops to either
low-level warning voltage or the
setting point in program 12.
02
Maxim m charging c rrent:
To config re total charging
c rrent for solar and tility
chargers.
(Max. charging c rrent =
tility charging c rrent +
solar charging c rrent)
Available options in 1KVA 24V and 1KVA/3KVA 48V models:
10A
20A (defa lt)
Available options in 2-3KVA 24V models:
20A
30A (defa lt)
Available options in 2-3KVA 24V/48V Pl s and 4-5KVA 48V
models:

15
10A (Not available
for 2-3KVA 24V Pl s)
20A
30A
40A
50A
60A (defa lt)
Available options in 4K/5K model
70A
80A
90A
100A
110A 120A
03 AC inp t voltage range
Appliances (de
fa lt)
If selected, acceptable AC inp t
voltage range will be within
90-280VAC.
UPS
If selected, acceptable AC inp t
voltage range will be within
170-280VAC.
04 Power saving mode
enable/disable
Saving mode disable
(defa lt)
If disabled, no matter connected load
is low or high, the on/off stat s of
inverter o tp t will not be effected.
Saving mode enable
If enabled, the o tp t of inverter will
be off when connected load is pretty
low or not detected.
05 Battery type
AGM
(defa lt)
Flooded
User-Defined If “User-Defined” is selected, battery
charge voltage and low DC c t-off
voltage can be set p in program 26,
27 and 29.
06 A to restart when overload
occ rs
Restart disable
(defa lt)
Restart enable

16
07 A to restart when over
temperat re occ rs
Restart disable
(defa lt)
Restart enable
08
O tp t voltage (only
available for 120Vac
models)
110V
120V (defa lt)
09 O tp t freq ency
50Hz (defa lt)
60Hz
11 Maxim m tility charging
c rrent
Available options in 1KVA 24V and 2KVA 24V Pl s 120Vac
model:
10A
20A(defa lt):
Available options in 2-3KVA 24V and 2-3KVA 24V Pl s models:
20A
30A (defa lt)
Available options in 1KVA/3KVA 48V and 2-3KVA 48V Pl s
models:
10A
15A(defa lt):
Available options in 2KVA 48V Pl s 120Vac model:
5A
10A(defa lt)
Available options in 4KVA/5KVA models:
2A
10A
20A
30A (defa lt)
40A
50A
60A

17
12
Setting voltage point back
to tility so rce when
selecting “SBU priority” or
“Solar first” in program 01.
Available options in 24V models:
22.0V
22.5V
23.0V (defa lt)
23.5V
24.0V
24.5V
25.0V
25.5V
Available options in 48V models:
44V
45V
46V (defa lt)
47V
48V
49V
50V 51V
13
Setting voltage point back
to battery mode when
selecting “SBU priority” or
“Solar first” in program 01.
Available options in 24V models:
Battery f lly charged
24V
24.5V
25V
25.5V
26V

18
26.5V
27V (defa lt)
27.5V
28V
28.5V
29V
Available options in 48V models:
Battery f lly charged
48V
49V
50V
51V
52V
53V
54V (defa lt)
55V
56V
57V
58V
16
Charger so rce priority:
To config re charger so rce
priority
If this inverter/charger is working in Line, Standby or Fa lt
mode, charger so rce can be programmed as below:
Solar first Solar energy will charge battery as
first priority.
Utility will charge battery only when
solar energy is not available.
Utility first
Utility will charge battery as first
priority.
Solar energy will charge battery only
when tility power is not available.
