MQ BA-SERIES Guide

© COPYRIGHT 2002, MULTIQUIP INC.
OPERATION AND PARTS MANUAL
BA-SERIES
WALK-BEHIND TROWEL
Revision #3 (11/30/04)
MULTIQUIP INC..
..
. PARTS DEPARTMENT:
18910 WILMINGTON AVE. 800-427-1244
CARSON, CALIFORNIA 90746 FAX: [phone]
310-537-3700
SERVICE DEPARTMENT/TECHNICAL ASSISTANCE:
800-421-1244 800-478-1244
FAX:[phone] FAX:[phone]
E-mail:[email protected] •www:multiquip.com
Atlanta • Boise • Dallas • Houston • Newark
Montreal, Canada • Manchester, UK
Rio De Janiero, Brazil • Guadalajara, Mexico
MODEL #
SERIAL #
P/N 20905

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 3
HERE'S HOW TO GET HELP
PLEASE HAVE THE MODEL AND SERIAL NUMBER
ON-HAND WHEN CALLING
PARTS DEPARTMENT
800-427-1244 or 310-537-3700
FAX: [phone] or 310-637-3284
SERVICE DEPARTMENT/TECHNICAL ASSISTANCE
800-478-1244 or 310-537-3700
FAX: [phone]
WARRANTY DEPARTMENT
888-661-4279, or 310-661-4279
FAX: [phone]
MAIN
800-421-1244 or 310-537-3700
FAX: [phone]

PAGE 4 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
BA-SERIES TROWEL— TABLE OF CONTENTS
Here's How To Get Help ............................................ 3
Table Of Contents ..................................................... 4
Parts Ordering Procedures ....................................... 5
Training Checklist ...................................................... 6
Daily Pre-Operation Checklist ................................... 7
Safety Message Alert Symbols .............................. 8-9
Rules For Safe Operation .................................. 10-11
Operation And Safety Decals .................................. 12
Specifications (Trowel) ............................................ 13
Specifications (Engines).......................................... 14
Specifications (Trowel Weights) .............................. 14
General Information ................................................ 15
MQ WHITEMAN — BA-SERIES TROWEL
Controls and Components ................................. 16-17
Basic Engine ........................................................... 18
Assembly and Installation .................................. 19-21
Pre-Inspection .................................................... 22-23
Initial Start-Up (Gasoline Engine) ...................... 24-25
Operation ........................................................... 26-27
Options ............................................................... 28-29
Maintenance ...................................................... 30-34
Troubleshooting (Trowel) ................................... 35-36
Troubleshooting (Engine) ........................................ 37
Explanation of Codes in Remarks Column ............. 38
Suggested Spare Parts ........................................... 39
Nameplate and Decals....................................... 40-41
Standard Handle Assy. ....................................... 42-43
Quick Pitch™ Handle Assy................................ 44-46
Thrust Bearing Kit Assy. ..................................... 48-49
4 Blade Spider Assy. .......................................... 50-51
Gearbox and Engine Mounts Assy. ................... 52-54
Engines, Honda, Robin, & Briggs & Stratton ..... 56-57
Hand Clutch Assy. .............................................. 58-59
Guard Ring Assy. ............................................... 60-61
Stabilizer Ring Assy............................................ 62-63
Blades and Adjustment Fixture Assy. ................ 64-65
Lifting Bale Assy. (Option) .................................. 66-67
HONDA GX240K1QA2 ENGINE
Air Cleaner Assy. ................................................ 68-69
Camshaft Assy. .................................................. 70-71
Carburetor Assy. ................................................ 72-73
Control Assy. ...................................................... 74-75
Crankcase Cover Assy. ...................................... 76-77
Crankshaft Assy. ................................................ 78-79
Cylinder Barrel Assy. .......................................... 80-81
Cylinder Head Assy. ........................................... 82-83
Fan Cover Assy. ................................................. 84-85
Flywheel Assy..................................................... 86-87
Fuel Tank Assy. .................................................. 88-89
Ignition Coil Assy. ............................................... 90-91
Muffler Assy........................................................ 92-93
Piston Assy. ........................................................ 94-95
Recoil Starter Assy. ............................................ 96-97
Labels ................................................................ 98-99
ROBIN EH25-2 ENGINE
Crankcase Assy. ............................................ 100-101
Crankshaft Assy. ............................................ 102-103
Intake and Exhaust Assy. ...............................104-105
Governor Assy. .............................................. 106-107
Cooling and Starting Assy. ............................. 108-109
Fuel Tank Assy. .............................................. 110-111
Carburetor Assy. ............................................ 112-113
Recoil Start Assy. ...........................................114-115
Oil Sensor Assy. ............................................. 116-117
Terms and Conditions of Sale — Parts ................. 118
NOTE
Specification and part number
are subject to change without
notice.

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 5
BA-SERIES TROWEL— PARTS ORDERING PROCEDURES
Get special freight allowances
when you order 10 or more
line items via FAX!**
■■
■■
■ UPS Ground Service at no charge for freight
■■
■■
■ UPS Third Day Service at one-half of actual freight
cost
No other allowances on freight shipped by any other carrier.
**Common nuts, bolts and washers (all items under $1.00 list price)
do not count towards the 10+ line items.
*DISCOUNTS ARE SUBJECT TO CHANGE*
Fax order discount and UPS special programs revised June 1, 1995
Earn Extra Discounts when
you order by FAX!
All parts orders which include complete part numbers
and are received by fax qualify for the following extra
discounts:
Number of
line items ordered Additional Discount
1-9 items 3%
10+ items** 5%
Now! Direct TOLL-FREE access
to our Parts Department!
Toll-free nationwide:
800-421-1244
Toll-free FAX:
800/6-PARTS-7 • 800-672-7877
■■
■■
■Dealer account number
■■
■■
■Dealer name and address
■■
■■
■Shipping address (if different than billing address)
■■
■■
■Return fax number
■■
■■
■Applicable model number
■■
■■
■Quantity, part number and description of each part
■■
■■
■Specify preferred method of shipment:
•UPS Ground
•UPS Second Day or Third Day*
•UPS Next Day*
•Federal Express Priority One (please provide us with your Federal
Express account number)*
•Airborne Express*
•Truck or parcel post
*Normally shipped the same day the order is received, if prior to 2PM west coast time.
Extra Fax DiscountExtra Fax Discount
Extra Fax DiscountExtra Fax Discount
Extra Fax Discount
for Domestic USAfor Domestic USA
for Domestic USAfor Domestic USA
for Domestic USA
Dealers OnlyDealers Only
Dealers OnlyDealers Only
Dealers Only

PAGE 6 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
TRAINING CHECKLIST
This checklist will lists some of the minimum requirements for
machine maintenance and operation. Please feel free to detach
it and make copies. Use this checklist whenever a new operator
is to be trained or it can be used as a review for more experienced
operator’s.
Operator _________________________________________ Trainee __________________________________________
COMMENTS:
BA-SERIES TROWEL— TRAINING CHECKLIST
TSILKCEHCGNINIART
.ON NOITPIRCSED ?KO ETAD
1 .yletelpmoclaunaMs’rotarepOdaeR
2dnaenignefognikcehc,stnenopmocfonoitacol,tuoyalenihcaM
.leveldiulfxobraeg
3 erudecorpgnileufer,metsysleuF
4 .)gninnurtonenihcam(slortnocfonoitarepO
5 .noitarepohctiwsllik,slortnocytefaS
6 .serudecorppotsycnegremE
7 .enihcamfoputratS
8 gnirevuenaM
9 gnihctiP
01 .seuqinhcetgnihsinifetercnoC
11 .enihcamfonwodtuhS
21 .)tnempiuqelanoitpo(enihcamfognitfiL
31 .egarotsdnatropsnartenihcaM

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 7
DAILY PRE-OPERATION CHECKLIST
COMMENTS:
BA-SERIES TROWEL— DAILY PRE-OPERATION CHECKLIST
TSILKCEHCNOITAREPO-ERPYLIAD
1 .leveLliOenignE
2 .leveLdiulFxobraeG
3 .sedalBfonoitidnoC
4 .noitarepOhctiPedalB
5 .noitarepOhctiwSlliKytefaS
6 noitarepOhctulC

PAGE 8 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
BA-SERIES TROWEL— SAFETY MESSAGE ALERT SYMBOLS
Safety precautions should be followed at all times when operating
this equipment. Failure to read and understand the Safety
Messages and Operating Instructions could result in injury to
yourself and others.
FOR YOUR SAFETY AND THE SAFETY OF OTHERS!
This Owner's Manual has been developed to provide
complete instructions for the safe and efficient operation
of the MultiQuip BA-SERIES WALK-BEHIND TROWEL.
For engine maintenance information, please refer to the
engine manufacturers instructions for data relative to its
safe operation.
Before using this WALK-BEHIND TROWEL, ensure
that the operating individual has read and
understands all instructions in this manual.
NOTE
SAFETY MESSAGE ALERT SYMBOLS
The three (3) Safety Messages shown below will inform you
about potential hazards that could injure you or others. The
Safety Messages specifically address the level of exposure to
the operator, and are preceded by one of three words: DANGER,
WARNING, or CAUTION.
DANGER: You WILL be KILLED or
SERIOUSLY injured if you DO NOT follow
directions.
WARNING: You CAN be KILLED or
SERIOUSLY injured if you DO NOT follow
directions.
CAUTION: You CAN be injured if you
DO NOT follow directions.
HAZARD SYMBOLS
Engine exhaust gases contain poisonous
carbon monoxide. This gas is colorless and
odorless, and can cause death if inhaled.
NEVER operate this equipment in a confined
area or enclosed structure that does not
provide ample free flow air.
Potential hazards associated with B-Series trowel operation will
be referenced with "
Hazard Symbols " which appear throughout
this manual, and will be referenced in conjunction with Safety
"
Message Alert Symbols ".
Gasoline is extremely flammable, and its
vapors can cause an explosion if ignited. DO
NOT start the engine near spilled fuel or
combustible fluids. DO NOT fill the fuel tank
while the engine is running or hot. DO NOT
overfill tank, since spilled fuel could ignite if it
comes into contact with hot engine parts or
sparks from the ignition system. Store fuel in
approved containers, in well-ventilated areas
and away from sparks and flames. NEVER
use fuel as a cleaning agent.
Burn Hazards
Engine components can generate extreme heat.
To prevent burns, DO NOT touch these areas
while the engine is running or immediately after
operations. NEVER operate the engine with
heat shields or heat guards removed.
Rotating Parts
NEVER operate equipment with covers, or
guards removed. Keep fingers,
hands , hair and
clothing away from all moving parts to prevent
injury.
Explosive Fuel
Lethal Exhaust Gases

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 9
Accidental Starting
ALWAYS place the engine ON/OFF
switch in the OFF position, when the
trowel is not in use.
Over Speed Conditions
NEVER tamper with the factory settings of the
engine governor or settings. Personal injury
and damage to the engine or equipment can
result if operating in speed ranges above
maximum allowable.
Respiratory Hazard
ALWAYS wear approved respiratory
protection.
ALWAYS wear approved eye and hearing
protection.
Sight and Hearing hazard
Equipment Damage Messages
Other important messages are provided throughout this manual
to help prevent damage to your trowel, other property, or the
surrounding environment.
This walk-behind trowel , other property, or
the surrounding environment could be
damaged if you do not follow instructions.
NOTE
BA-SERIES TROWEL— SAFETY MESSAGE ALERT SYMBOLS

PAGE 10 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
CAUTION:
Failure to follow instructions in this manual may
lead to serious injury or even death! This
equipment is to be operated by trained and
qualified personnel only! This equipment is
for industrial use only.
The following safety guidelines should always be used when
operating the BA-Series walk-behind trowel.
SAFETY
■ DO NOT operate or service this equipment
before reading this entire manual.
■ This equipment should not be operated by
persons under 18 years of age.
■ NEVER operate the trowel without proper protective clothing,
shatterproof glasses, steel-toed boots and other protective
devices required by the job.
■ NEVER operate this equipment when not
feeling well due to fatigue, illness or taking
medicine.
■ NEVER operate the trowel under the
influence or drugs or alcohol.
■ NEVER use accessories or attachments, which are not
recommended by Multiquip for this equipment. Damage to
the equipment and/or injury to user may result.
■ Manufacture does not assume responsibility for any accident
due to equipment modifications.
■ Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
■ ALWAYS check the trowel for loosened threads or bolts
before starting.
■ ALWAYS use extreme caution when
working with flammable liquids. When
refueling, stop the engine and allow it
to cool.
■ NEVER smoke around or near the
machine. Fire or explosion could result from
fuel vapors , or if fuel is spilled on a hot!
engine.
■ NEVER operate the trowel in an explosive atmosphere or
near combustible materials. An explosion or fire could result
causing severe
bodily harm or even death.
■ Topping-off to filler port is dangerous, as it tends to spill fuel.
■ NEVER touch the hot exhaust
manifold, muffler or cylinder. Allow
these parts to cool before servicing
the trowel.
■ The engine of this trowel requires an adequate free flow of
cooling air. NEVER operate the trowel (except electric models)
in any enclosed or narrow
area where free flow of the
air is restricted. If the air flow
is restricted it will cause
serious damage to the
trowel's engine and may
cause injury to people.
Remember the trowel's
engine gives off
DEADLY
carbon monoxide gas.
■ HighTemperatures – Allow the engine to cool before adding
fuel or performing service and maintenance functions. Contact
with
hot! components can cause serious burns.
■ ALWAYS refuel in a well-ventilated area, away from sparks
and open flames.
BA-SERIES TROWEL— RULES FOR SAFE OPERATION

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 11
BA-SERIES TROWEL— RULES FOR SAFE OPERATION
■ DO NOT operate this trowel unless all guards and safety
devices are attached and in place. See Pages 16 and 17.
■ ALWAYS use proper lifting techniques when moving the
trowel.
■ ALWAYS check to make sure that the operating area is clear
before starting the engine.
■ ALWAYS test the safety kill switch devices before operating
the trowel.
■ NEVER place your feet or hands inside the guard rings
while starting or operating this equipment.
■ AVOID wearing jewelry or loose fitting clothing that may snag
on the controls or moving parts, this can cause a serious
injury.
■ ALWAYS keep clear of rotating or moving parts while
operating the trowel.
■ NEVER leave the machine unattended while running.
■ Moving Parts – Shut down the engine before performing
service or maintenance functions. Contact with moving parts
can cause serious injury.
Maintenance Safety
■ Disconnect the spark plug wires before attempting any type
of service.
■ Securely support any machine components that must be
raised.
■ NEVER lubricate components or attempt service on a running
machine.
■ DO NOT use food or plastic containers to dispose of
hazardous waste.
■ DO NOT pour waste , oil or fuel directly onto the ground,
down a drain or into any water source.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Emergencies
■ ALWAYS know the location of the nearest
fire extinguisher and first aid kit . Know the
location of the nearest telephone. Also know
the phone numbers of the nearest
ambulance , doctor and fire department .
This information will be invaluable in the case
of an
emergency .
■ Keep the trowel in proper running condition.
■ Make sure that there is no buildup of concrete, grease, oil or
debris on the trowel.
■ Fix damage to the trowel immediately and always replace
broken parts.
■ Dispose of hazardous waste properly. Examples of potentially
hazardous waste are used
motor oil , fuel and fuel filters .
■ High Temperatures – Allow the machine and engine to
cool before adding fuel or performing service and
maintenance functions. Contact with hot! components can
cause serious burns.

PAGE 12 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
BA-SERIES TROWEL— OPERATION AND SAFETY DECALS
Machine Safety Decals
The BA-Series walk-behind trowel is equipped with a number of safety decals. These decals are provided for operator safety and
maintenance information. Figure 1 below illustrates these decals as they appear on the machine. Should any of these decals
become unreadable, replacements can be obtained from your dealer.
Figure 1. BA-Series Trowel Decals
P/N 20526
BOISE, IDAHO USA
U. S. PATENT
XXXXXXX
Q
U
I
C
K
-
P
I
T
C
H
™
H
A
N
DL
E
C
O
N
C
R
E
TE
F
IN
I
S
H
E
R
C
O
N
C
R
E
T
E
F
L
O
O
R
FINISHER
B
O
I
S
E
,
I
D
A
H
O
U
S
A
Q
U
I
C
K
P
I
T
C
H
P/N 12405 P/N 1492
P/N1499
FINISH
J
COMBO
PRELOAD TRIM INDICATOR
FINISH
B
COMBO
P/N 1735
P/N 1758
Symbol indicates that it is mandatory to wear
safety glasses, safety helmet and ear protection.
Symbol indicates that it is mandatory to
wear safety shoes, with extra protection
(steel toed).
This is the symbol for belt drive.
This is the symbol for gear drive.
Radiating heat symbol. Symbol indicates equipment
is hot.
Symbol for examining or checking of the machine.
Mostly used for maintenance. Check lubrication
oil in gearbox.
Symbol indicates that it is mandatory to wear
gloves.
P/N 11247 (Part of decal kit 12620)
P/N 11247 (Part of decal kit 12620)
P/N 11247 (Part of decal kit 12620)
P/N 11246 (Part of decal kit 12620)
P/N 11246 (Part of decal kit 12620)
P/N 11246 (Part of decal kit 12620)
P/N 11246 (Part of decal kit 12620)
CONTACT MULTIQUIP
SERVICE DEPT.
NAMEPLATE
DO NOT OPERATE HANDLE UNTIL IT IS
SECURELY FASTENED TO POWER TROWEL
& INSTRUCTIONS HAVE BEEN READ
INJURY COULD RESULT IF FINISHER IS LIFTED
WITHOUT PITCH HANDLE FIRMLY ENGAGE
WARNING!
WARNING!
DO NOT LIFT MACHINERY BY GUARD
RING. MAY CAUSE DAMAGE TO
GUARD RING SHOCK MOUNTS
USE LIFT HANDLES ONLY
CAUTION
P/N 1261
P/N 20527
P/N 1940
GENUINE
TROWEL
MADE IN USA
METRIC
P
O
W
E
R
T
R
O
W
E
L
P/N 1736
P/N 1848
P/N 2938

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 13
BA-SERIES TROWEL— SPECIFICATIONS (TROWEL)
NOTE:
1. Sound pressure is a weighted measure. Measured at the
operators ear position while the walk-behind trowel is
operating at full throttle on concrete in a manner most often
experienced in “
normal ” circumstances. Sound pressure
may vary depending upon the condition of the concrete.
Hearing protection is always recommended.
Figure 2. BA-Series Trowel Dimensions
2. The vibration level indicated is the maximum RMS (Root
Mean Square) value obtained at the handle grip while
operating the walk-behind trowel on curing concrete in a
manner most often experienced in “
normal ” circumstances.
Values were obtained from all three axes of motion. The
values shown represent the maximum RMS value from
these measurements.
Side View
snoitacificepSleworTseireS-AB.1elbaT
)kooHgnitfiL(thgieH–A )mm2.678(ni5.43
)reveLtnemegagnEthgieH–B )mm2.440,1(ni1.14
htdiW–C )mm4.861,1(0.64
htgneL–D )mm1.019,1(2.57
gnitarepO–thgieW 3elbaTeeS
erusserPdnuoS bd79
noitarbiV s/m5.42(g5.2
2
)
retemaiDgniR )mc711(ni64
sedalBforebmuN 4ro3
)s/m(MPF–deepSpiTedalB )s/m5.7(mpf874,1
)enilosaG(MPR–rotoR 521ot06
)mc(.ni–htdiWhtaP )332(84

PAGE 14 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
BA-SERIES TROWEL— SPECIFICATIONS (ENGINES)
)sthgieWleworT(snoitacificepS.3elbaT
LEDOMECRUOSREWOPTHGIEWGNITAREPOTHGIEWGNIPPIHS
H8-3-BadnoHPH8).gk701(.sbl732).gk031(.sbl682
SB8-4-BnottartSdnas
ggirBPH8).gk301(.sbl822).gk621(.sbl872
R7-4-BniboRPH5.7).gk701(.sbl732).gk031(.sbl782
MR7-4-BhctulClaunaM,nib
oRPH5.7).gk701(.sbl732).gk031(.sbl782
H8-4-BadnoHPH0.8).gk011(.sbl242).gk231(.sbl292
MH8-4-BhctulClaunaM,adno
HPH0.8).gk011(.sbl242).gk231(.sbl292
)rotoMcirtcelE&senignE(snoitacificepS.2elbaT
rotoMcirtcelE/enignE
ledoM2AQ1K042XGADNOH2-52-HENIBORrotoMcirtcelE
epyT
elgniS,ekorts4delooc-riA
latnoziroH,
VHO,rednilyC
enignEenilosaGtfahS
elgniS,ekorts4delooc-riA
latnoziroH,VHO,rednilyC
enignEenilosaGtfahS
A/N
ekortSXeroB .ni03.2X.ni09.2
)mm85xmm37(
.ni42.2X.ni59.2
)mm75xmm57( A/N
tnemecalpsiDcc18.41cc13.51A/N
tuptuOxaM.M.P.R0063/.P.H0.8.M.P.R0004/.P.H5.8PH0.2
yticapaCknaTleuF snollaG.S.U95.1.xorppA
)sretiL6(
snollaG.S.U95.1.x
orppA
)sretiL6( A/N
leuFenilosaGdedaelnUenilosaGdedaelnUA/N
yticapaCliOebuLstnip3/1-2stnip2A/N
dohteMlortnoCdeep
Sthgiew-ylFlagufirtneC
epyT epyTthgiew-ylFlagufirtneCA/N
dohteMgnitratStratSlioceRtratSlioceRA/N
egatloVtupnIA
/NA/N elgniSCAV032/511
esahP
)HxWxL(noisnemiD .ni1.61X9.61x0.41
)mm014X034X553(
.ni23.71X02.61x04.41
)mm044X214X663( DBT
thgieWteNyrD ).gK52(sbl1.55).gK32(sbl7.05DBT

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 15
BA-SERIES TROWEL— GENERAL INFORMATION
BA-Series Walk-Behind Trowel Familiarization
This walk-behind trowel is designed for the
floating and
finishing of concrete slabs.
Take a walk around the trowel. Take notice of all the major
components (see Figure 3, pages 16 and 17) like the engine,
blades, quick pitch control, air cleaner, centrifugal stop switch
etc. Check that there is always oil in the engine.
Read all the safety instructions carefully. Safety instructions will
be found throughout this manual and on the trowel. Keep all
safety information in good, readable condition. Operators should
be well trained on the operation and maintenance of the trowel.
Before using your trowel, test it on a flat watered down section of
finished concrete that is free of any debris and other objects.
This trial test run will increase your confidence in using the trowel
and at the same time it will familiarize you with the trowel’s
controls. In addition you will understand how the trowel handles
under actual conditions.
Engines
This trowel is available with either an 8.0 HP HONDA, 8.5 HP
ROBIN, or a 8.0 HP Briggs and Stratton gasoline engine.
Refer to the engine owner’s manual for instructions regarding
the operation and maintenance of your engine. The engine
manual is included with your trowel at the time of shipment from
Whiteman. Please contact your nearest Multiquip Dealer for a
replacement should the original manual disappear.
Drive System
Power is transferred from the engine to the gearbox input shaft
via a V-belt or pulley drive system. The pulley engages using
either a centrifugal or manual clutch. See page 23.
Gearbox
The
gearbox is located beneath the engine and transfers power
to the
rotor or spider assembly. The gearbox controls the
rotational speed of the trowel and is equipped with two shafts
(input and output).
Spider
The vertical output shaft of the gearbox connects to a cast hub
called the
spider .The spider has either 3 or 4 arms that extend
outward that are used for attachment of blades or other
accessories. Remember as the gearbox output shaft rotates so
does the spider assembly.
NEVER attempt to lift the trowel by yourself.
ALWAYS get the assistance of another
person to help lift the trowel or use a crane or
lifting device to move the trowel.
Moving the BA-Series Walk-Behind Trowel
This walk-behind trowel is designed to be moved and handled
in several ways. The easiest way to lift the trowel is to use the
auxiliary lifting tube that is attached to the main handle. See
page 24, Figure 21. When using the auxiliary tube, always use
two persons to lift the trowel.
Some models have a
lifting bale (option) installed. A strap or
chain can be attached to the lifting bale, allowing a forklift or
crane to lift the trowel up onto a slab of concrete. Use a lifting
device of adequate lifting capacity to lift the trowel.
Training
For proper training, please use the “TRAINING CHECKLIST”
located in the front of this manual (Page 6). This checklist will
provide an outline for an experienced operator to provide training
to a new operator.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Blades
The blades of the trowel finish the concrete as they are rotated
around the surface. Blades are classified as
combination (8
inches wide),
float (10 or 8 inches wide), and finish (6 inches
wide).This trowel comes equipped with either
three or four
blades per rotor equally spaced in a radial pattern and
attached to vertical rotating shaft by means of a
spider
assembly.
Centrifugal Stop Switch
In the event of a trowel runaway condition (operator releases
the handle), a centrifugal stop switch or manual clutch
depending on which trowel you have, will stop the engine
and bring the trowel to a halt.

PAGE 16 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
BA-SERIES TROWEL— CONTROLS AND COMPONENTS
Figure 3. BA-Series Walk-Behind Trowels
FINISH
FINISH
J
COMBO
COMBO
PRELOADTRIMINDICATOR
PRELOAD TRIM INDICATOR
FINISH
FINISH
B
COMBO
COMBO
W
W
13
13
15
10
STANDARD
HANDLE
12
11
7
6
7
8
8
5
3
2
5
6
4
16 17
18
14
QUICK PITCH ™
HANDLE
9
20
4
1
3
2

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 17
Figures 3 shows the location of the basic controls or components,
for the BA-Series trowel. Listed below is a brief explanation of
each control or component
1. Quick Pitch™ Control Handle – To adjust the pitch of
the blades, grasp the handle then squeeze and either move
the handle forward or backward to achieve the desired
blade pitch.
2. Handlebar Adjuster – Change the angle/height of the
handle bars by loosening star wheel, adjust handlebars to
desired location, tighten starwheel firmly to hold handlebars
in that position.
3. Hand Grip/Handle Bar – When operating the trowel, place
both hands on each grip to maneuver the trowel. Replace
hand grips when they become worn or damaged.
4. Throttle Control Grip – Controls the speed of the engine.
Rotate the hand grip away from the operator to increase
engine speed (high), toward the operator to decrease
engine speed (low).
5. Throttle – Controls engine speed when throttle control
grip is rotated.
6. Hand Grip/Handle Bar – When operating the trowel, place
both hands on each grip to maneuver the trowel. Replace
hand grips when they become worn or damaged.
7. Centrifugal Kill Switch – In the event the operator loses
control of the trowel, this switch will shut-down the engine.
8. Auxiliary LiftingTube - Use this tube to lift the trowel onto
a slab.Tube is to be inserted into socket located in front of
the gearbox.
9. Weights – The trowel may be equipped with two 10 lbs.
weights. The weights may be removed to reduce the
operating weight of the trowel.
10. Trowel Lifting Point – Insert the auxiliary lifting tube here.
See Figure 21.
11. Pitch Control (standard models) - Turn this "Star Wheel"
clockwise for increase blade pitch, and counter-clockwise
for decrease blade pitch.
12. Clutch Lever - Clutch engagement lever.When this lever
is engaged, the blades will begin to rotate. May be used
with either Quick Pitch™ or Standard handle.
13. Main Tube - When disassembling components inside the
tube exercise extreme CAUTION! Tube is spring-loaded,
severe injury could result if not disassembled correctly.
14. Guard Ring- NEVER! put hands or feet inside guard ring.
15. Engine – This trowel uses Honda, Robin and Briggs and
Stratton type gasoline engines.
16. Trowel Arm – NEVER operate the trowel with a bent,
broken or out of adjustment trowel arm. If the blades show
uneven wear patterns or some blades wear out faster than
others, the trowel arm may need to be adjusted. Use the
trowel arm adjustment tool P/N 1817 to adjust the trowel
arms.
17. Blades – This trowel is equipped with combination blades.
These blades are versatile and should take care of most
troweling needs. In addition float discs can be attached to
the trowel arms that will allow the trowel to float on "wet"
concrete.
18. V-Belt Cover – Remove this cover to gain access to the V-
belt. NEVER operate the trowel with this cover removed.
20. Stabilizer Ring – Reduces trowel arm vibration. Helps
stabilize trowel arm.
BA-SERIES TROWEL— CONTROLS AND COMPONENTS

PAGE 18 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
Figure 4. Engine Controls and Components
INITIAL SERVICING
The engine (Figure 4) must be checked for proper lubrication and
filled with fuel prior to operation. Refer to the manufacturers engine
manual for instructions & details of operation and servicing. The
engine shown above is a HONDA engine, operation for other
types of engines may vary somewhat.
1. Fuel Filler Cap – Remove this cap to add unleaded
gasoline to the fuel tank. Make sure cap is tightened
securely. DO NOT over fill.
5. Fuel Valve Lever – OPEN to let fuel flow, CLOSE to stop
the flow of fuel.
6. Choke Lever – Used in the starting of a cold engine, or in
cold weather conditions. The choke enriches the fuel
mixture.
7. Air Cleaner – Prevents dirt and other debris from entering
the fuel system. Remove wing-nut on top of air filter
cannister to gain access to filter element.
8. Spark Plug – Provides spark to the ignition system. Set
spark plug gap to 0.6 - 0.7 mm (0.028 - 0.031 inch) Clean
spark plug once a week.
9. Muffler – Used to reduce noise and emissions.
Engine components can generate extreme heat.
To prevent burns, DO NOT touch these areas
while the engine is running or immediately after operating. NEVER
operate the engine with the muffler removed.
10. Fuel Tank – Holds unleaded gasoline. For additional
information refer to engine owner's manual.
DANGER
NOTE
Operating the engine without an air filter,
with a damaged air filter, or a filter in need of
replacement will allow dirt to enter the
engine, causing rapid engine wear.
WARNING
BA-SERIES TROWEL— BASIC ENGINE
HONDA engine shown.
Adding fuel to the tank should be done only when
the engine is stopped and has had an opportunity to
cool down. In the event of a fuel spill, DO NOT attempt to start the
engine until the fuel residue has been completely wiped up, and the
area surrounding the engine is dry.
2. Throttle Lever – Used to adjust engine RPM speed (lever
advanced forward
SLOW , lever back toward operator
FAST ).
3. Engine ON/OFF Switch – ON position permits engine
starting, OFF position stops engine operations.
4. Recoil Starter (pull rope) – Manual-starting method. Pull
the starter grip until resistance is felt, then pull briskly and
smoothly.

BA-SERIES WALK-BEHIND TROWEL — PARTS & OPERATION MANUAL — REV. #3 (11/30/04) — PAGE 19
BA-SERIES TROWEL — ASSEMBLY AND INSTALLATION
Assembly and Installation
Before the trowel can be put into operation there are some
components that must be installed before the trowel can be used.
This section provided general instructions on how to install those
components. Instruction sheet P/N 20485 provides further details
for the handle assembly.
HandleTube Installation (All Models)
1. Install the
handle tube to the gearbox as shown in (Figure 5).
The mounting hardware should be contained in the shipping
container.
Figure 5. Handle Tube Installation
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
The Quick-Pitch™ handle is spring loaded,
personal injury or damage could result from
improper handling or installation. Be careful
when installing this component.
NOTE
Considerable force may be required when
moving the Quick-Pitch™T-handle
forward or backward.
2. On Quick-Pitch™ models, pivot the T-handle back
(full pitch) (Figure 6). This will relax the spring inside the
handle tube. On either model, spread the handle bar ends
just enough to engage the teeth on the handle tube. Attach
the hand wheel assembly, position handlebar to desired
location, and tighten hand wheel firmly.
Figure 6. Handlebar Installation
2. Feed the throttle cable through the cable housing. Make sure
the throttle indicator is on 1".
3. Connect the throttle cable to the engine. (Figure 8),
Honda
and (Figure 9), Robin . There should be a piece of wire
installed on the trowel to show where to route the throttle
cable. When connecting the cable housing, make sure that
no more than
1/4" (6.4mm) of the cable housing protrudes
past the housing clamp on the engine.
Figure 8. Throttle Cable Connection (HONDA)
CABLE HOUSING
ENGINE
THROTTLE
LEVER
SWIVEL STOP
SCREW
THROTTLE
CABLE END
CABLE
HOUSING
CLAMP
Figure 7. Throttle
Throttle Cable Installation (Honda and Robin Engines)
1. Set the
throttle (Figure 7) to the idle position by rotating
the grip toward the operator and away from the engine.

PAGE 20 — BA-SERIES WALK-BEHIND TROWEL— PARTS & OPERATION MANUAL — REV. #3 (11/30/04)
Handle Height Adjustment
If handle height adjustment is desired, a handle wedge kit can be
purchasedforyourtrowelby ordering P/N 2576 from your Multiquip
dealer.These wedges are placed between the handle and the
gearbox to adjust the operating height of the handle. This kit
comes complete with wedges, new bolts and installation
instructions.This will move your operating handle position up or
down approximately 3” (76mm).
BA-SERIES TROWEL — ASSEMBLY AND INSTALLATION
Safety Kill Wire
Locate the
RED wire protruding from the handle tube (Figure11)
and connect it to the
RED tail wire on the engine. Test the kill
switch to insure proper operation.
Figure 11. Engine Kill Wire Connection
Figure 12. "No Pitch" Position (Standard)
Figure 13. "No Pitch" Position (Quick-Pitch™)
1. Expose the pitch cable to maximum by adjusting the handle
pitch to the "no pitch" position. On the standard model turn
the pitch control counter-clockwise, (Figure 12). On the
Quick-Pitch™ model, pivot the pitch handle forward or no
pitch, (Figure 13).
Figure 9. Throttle Cable Connection (ROBIN)
7. These are general instructions. Installation of the throttle
cable may vary for different engine configurations. Please
look for more detailed instructions inside the box containing
the handle.These more detailed instructions should provide
adequate guidance for installing.
4. Tighten cable clamp screw and swivel stop screw.
5. After the cable has been installed on the engine, adjust
and tighten operator position of the handle to lock the
throttle cable at the proper length.
6. Adjust cable tension by rotating the barrel adjuster. (Figure
10)
Pitch Cable Installation
BARREL ADJUSTER
Figure 10. Barrel Adjuster
