MR. FLAME™Inc.
GLASS SCREEN
www.FireplaceDoorStore.com
GO Sales Inc.
3334 SE Teal Dr.
Gresham, OR 97080
1-877-663-7454
OWNERS
MANUAL
CAUTION:
Read Assembly
and Installation
Instructions
Carefully
The tempered safety glass
in your glass fireplace screen
has been developed to give
you many years of trouble
free service
A few rules for the proper
use and care of your
Glass Screen are necessary
for proper operation and
satisfactory service
Always use a grate for fires.
Place grate a minimum of 4
inches away from the glass.
When you have a large fire,
keep the doors open.
Do not allow burning coals or
logs to contact glass
Keep combustibles away from
front of screen.
Do not clean glass doors
while they are hot,
Read these instructions
completely before
proceeding.

2
IMPORTANT INFORMATION... Please read before installing your enclosure
ACID HEARTH: Hydrochloric (muriatic) acid is often used by builders to
clean excess mortar from new fireplaces. The fumes from this acid are
highly corrosive and will damage the finish on your fireplace fixtures or other
nearby metal objects. This corrosive action damages brass, steel and iron
and can last for many years if not neutralized. Consult your builder/mason for
correction.
The following suggestion, while not a guaranteed remedy, may aid in
correcting this condition.
1. To neutralize, saturate the masonry with ammonia water or a hearth
cleaner. Use care to avoid contact with adjacent carpet, floor etc.
2. Rinse thoroughly with clean, warm water;
3. Rinse several times with cool water to remove all ammonia;
4. Allow hearth to dry and seal with a hearth sealer.
Any acidic or caustic material used around your fireplace can damage the
finish of your enclosure. This includes some mortars or sealants that may be
used to install and seal enclosures and some paints used on fireplace faces.
MR. FLAMETm Inc. ASSUMES NO RESPONSIBILITY FOR DAMAGES
CAUSED TO GLASS ENCLOSURES CAUSED BY “ACID HEARTH"
CREOSOTE FORMATION AND THE NEED FOR REMOVAL: Wood
never burns completely. Wood smoke is a combination of unburned gases
and a fog of unburned tar-like liquids. When these gases come in contact
with a cool surface they will condense and form a nasty brown or black
substance which has an unpleasant, acrid odor. This is creosote. When
ignited, creosote makes an extremely hot fire. The chimney connector and
chimney should be inspected at least twice monthly during the heating
season to determine if a creosote buildup has occurred. If creosote has
accumulated, it should be removed to reduce the risk of a chimney fire.
HOW TO MINIMIZE CREOSOTE
1. Burn only seasoned hardwoods;
2. Do not allow the fire to smolder overnight;
3. Do not burn trash in your fireplace;
4. Check for buildup at least two times per month during the burning
season. (You can check for creosote by opening the damper and looking into
the smoke chamber with a flashlight. Take a screwdriver and scratch through
the buildup to the masonry. If the buildup is more than 1/4", a clean-up is
due. If the chimney is a factory built metal type, it should be cleaned
after 1/8" buildup. The smoke chamber is where the fire starts, not the top of
the chimney.)
ASH DISPOSAL: Ashes should be placed in a metal container with a tight-
fitting lid. The closed container of ashes should be placed on a
noncombustible floor or on the ground, well away from all combustible
materials, pending final disposal. If the ashes are disposed of by burial in soil

3
or otherwise locally dispersed, they should be retained in the closed
container until all cinders have thoroughly cooled.
CARE AND CLEANING:
WARNING - DO NOT CLEAN GLASS WHEN HOT OR BREAKAGE MAY
OCCUR.
1. The glass in your glass enclosure is safety tempered. It may be
broken by contact with burning wood or spilled liquids, by cleaningthe
glass with a wet cloth or by too large a fire. Broken glass or discolored trim
is usually a result of too large a fire or contact with burning wood.
Tempered glass, if broken, will crumble into small pieces less than 1/2"
square. lf glass breaks into larger pieces, it has been de-tempered by too
large a fire. Replace all glass you suspect has been de-tempered. Replace
with tempered glass only.
2. Do not use ammonia-based glass cleaner to clean the glass or the
enclosure as these types of cleaners may damage the finish of your
enclosure. Minor finish scratches can be removed by applying lemon oil.
GENERAL SAFEGUARDS
Burning trash, scraps (construction) or railroad ties is not
recommended for use with this enclosure. Intense heat can cause loss
of temper in glass and the fumes from this can create health hazards.
Intense heat such as hot ashes, coals, or logs coming in contact with
the back of the enclosure will cause tarnishing or discoloration to the
finish.

4
FIVE YEAR LIMITED WARRANTY
MR. FLAME™ Inc. warrants the construction of this product to the
original retail purchaser*against defects in construction for a period of
five years from date of the original retail purchase. The glass is
warranted for a period of 6 months or 1 year if purchased from
www.FireplaceDoorStore.com. MR. FLAME™ Inc. will replace, at no
charge to the original retail purchaser, any part that fails due to a defect
in construction.
This warranty covers only parts and applies only to products
purchased for consumer use. This warranty does not cover damage
which occurs in transit or results from alteration, accident, misuse,
abuse, or improper installation. It also makes no warranty as to
maximum temperature and stresses which may cause discoloration of
the finish. MR. FLAME™ Inc. shall not be liable for consequential or
indirect damages which are caused by defects in its product, by its
repair or replacement. Some states do no allow the exclusion, limitation,
incidental or consequential damages, so the exclusion or limitation in the
preceding sentence may not apply to you.
If you need to take advantage of this limited warranty during the five year
period, simply contact your dealer. Proof of the original purchase date
will be required in order for you to take advantage of the limited warranty.
The implied warranties of merchantability and fitness for a particular
purpose which may arise under state law are also limited in duration to
five years from the original purchase of this product. Some states do not
allow limitations on how long and implied warranty lasts, so this limitation
may not apply to you.
When ordering replacement parts, always provide height, width, and model
number.
*Must be purchased from an authorized dealer.

5
MOUNTING PARTS
REMOVE ALL PARTS FROM HARDWARE KITS AND THE CARTON.
TO ENSURE YOU HAVE ALL THE NECESSARY PARTS, MATCH UP
PIECES WITH THE PARTS LISTED ABOVE.

6
INSTALLATION INSTRUCTIONS
1. Before installing enclosure, be sure fire is out and fireplace is cool and clean. Read
"Ash Disposal" (page 2) ALWAYS lift enclosure by sides, NEVER top bar. Remove
enclosure from box and lean upright against the wall. Remove and save hardware kit
from the box. Remove packing material and any shipping support from under doors.
2. INSTALLING ENCLOSURE –FIG A., FIG B.
and Picture C
Remove parts from hardware kit.
FIG A. - Put hex screws through slot in flex
bracket. Attach flex bracket to back of enclosure,
screwing bracket into proper hole. DO NOT
TIGHTEN.
Screw thumb screws into lintel clamps.
Put machine screws through slot in flex bracket
and screw into lintel clamps. DO NOT TIGHTEN.
Push enclosure firmly against fireplace so it
overlaps evenly on both sides.
FIG B. - Attach lintel clamps to fireplace lintel bar
and tighten thumbscrews.
Tighten hex screws and machine screws. Be
sure enclosure is firmly attached to fireplace and
fiberglass is in place.
3. Picture C –Install Top and Bottom Damper
Knobs and Door Handles as seen in
Picture C.
Picture C
