MRC DRS4000 User manual

User and Technical Manual
DRS4000 Receiver
Manual Part No. 400545-1 Rev. A March 2009
RF & Low Latency HD Diversity Receiver

Notices-iDRS4000 Receiver User and Technical Manual
Notices
About This Manual
Part number 400545-1
Revision A March 2009
DRS4000 Receiver
Copyright
The information in this manual may remains the property of
Microwave Radio Communications (MRC) and may not be used,
disclosed, or reproduced in any form whatsoever, without the
prior written consent of MRC.
MRC reserves the right to make changes to equipment and
specifications of the product described in this manual at any time
without notice and without obligation to notify any person of such
changes.
© 2009 Microwave Radio Communications
Microwave Radio Communications
101 Billerica Avenue - Bldg. 6
North Billerica, MA 01862-1256 USA
TEL: [phone]
+1.978.671.5700
Printed in U.S.A.
The Microwave Radio Communications and Vislink trademarks
and other trademarks are registered trademarks in the United
States and/or other countries.
Microsoft®, Windows®, and Internet Explorer® are registered
trademarks of Microsoft Corporation in the United States and/or
other countries.
Proprietary Material
The information and design contained within this manual was
originated by and is the property of MRC. MRC reserves all
patent proprietary design, manufacturing, reproduction use, and
sales rights thereto, and to any articles disclosed therein, except
to the extent rights are expressly granted to others. The
foregoing does not apply to vendor proprietary parts.
MRC has made every effort to ensure the accuracy of the
material contained in this manual at the time of printing. As
specifications, equipment, and this manual are subject to change
without notice, MRC assumes no responsibility or liability
whatsoever for any errors or inaccuracies that may appear in this
manual or for any decisions based on its use. This manual is
supplied for information purposes only and should not be
construed as a commitment by MRC.
Quality Certification
Microwave Radio Communications is certified to ISO 9001:2000.
Conventions
Pay special attention to information marked in one of the
following ways:

Notices-iiDRS4000 Receiver User and Technical Manual
WARNING Follow WARNINGS closely to prevent personal
injury or death.
CAUTION Follow CAUTIONS to prevent damage to the
equipment.
Note Read Notes for additional information to assist
you in using and maintaining the equipment.
Symbols Used
The following symbols may be used on the equipment or may be
contained in this manual:
Symbol Meaning
WARNING: General Warning. Risk of Danger.
WARNING: Risk of Electric Shock.
CAUTION: Electrostatic Discharge. Possible
Damage to Equipment.
-OR-
Fuse - Identifies fuses or their location.
Frame or Chassis Ground - Identifies the frame or
chassis terminal.
Earth Ground - Identifies the earth ground terminal.
Protective Earth Ground - Identifies any terminal
which is intended for connection to an external
conductor for protection against electric shock in
case of a fault, or the terminal on a protective earth
electrode.
Waste Electrical and Electronic Equipment
(WEEE) - The product must not be disposed of
with other waste at the end of its lifecycle. It is
the user's responsibility to dispose of the waste
equipment by handing it over to a designated
collection point for the recycling.

Contents
Contents-1DRS4000 Receiver User and Technical Manual
Notices - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
About This Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
Copyright - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
Proprietary Material - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
Quality Certification - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
Conventions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i
Symbols Used - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii
Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
For Whom It’s Written - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Related Documents - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Ordering Documentation - - - - - - - - - - - - - - - - - - - - - - 1-1
Calling for Service - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Tell Us What You Think - - - - - - - - - - - - - - - - - - - - - - - 1-2
System Description - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-3
Hardware Components - - - - - - - - - - - - - - - - - - - - - - - 1-5
Receiver - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-5
Antennas - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-5
Low Noise Block Downconverters - - - - - - - - - - - - - 1-5
Firmware Components - - - - - - - - - - - - - - - - - - - - - - - 1-5
Frequency Bands - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-5
Standard/High Definition MPEG Decoding - - - - - - - - - 1-6
COFDM Demodulation - - - - - - - - - - - - - - - - - - - - - - - 1-6
Applications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-6
Compatibility - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-6
Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-6
Block Downconverter Options - - - - - - - - - - - - - - - - 1-6
HD Decoding Upgrade - - - - - - - - - - - - - - - - - - - - - 1-7
Antenna Options - - - - - - - - - - - - - - - - - - - - - - - - - 1-7
RF Filter Options - - - - - - - - - - - - - - - - - - - - - - - - - 1-7
Mounting Options - - - - - - - - - - - - - - - - - - - - - - - - 1-7
Power Options - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-8
Decryption Options - - - - - - - - - - - - - - - - - - - - - - - - 1-8
Packet Switching Option - - - - - - - - - - - - - - - - - - - - 1-8
Routine Operation - - - - - - - - - - - - - - - - - - - - - - 2-1
Chapter Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Controls, Indicators, and Connectors - - - - - - - - - - - - - - 2-2
Front Panel Controls, Indicators, and Connectors- - - 2-4
Rear Panel Connectors - - - - - - - - - - - - - - - - - - - - - 2-4
PACKET Connectors - - - - - - - - - - - - - - - - - - - - - - 2-5
Preparing for Operation - - - - - - - - - - - - - - - - - - - - - - - 2-5
Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-5
Powering the Receiver- - - - - - - - - - - - - - - - - - - - - - 2-5
Control Menu Operations - - - - - - - - - - - - - - - - - - - - - - 2-6
Using the Video Monitor - - - - - - - - - - - - - - - - - - - - - - - 2-8
Keypad Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8
Routine Operations - - - - - - - - - - - - - - - - - - - - - - - - - - 2-9
Control Menu Operations - - - - - - - - - - - - - - - - - - - - - 2-9
Change Channel - - - - - - - - - - - - - - - - - - - - - - - - - 2-10
Change Frequency - - - - - - - - - - - - - - - - - - - - - - - 2-10
Monitor RF Band - - - - - - - - - - - - - - - - - - - - - - - - - 2-11
Change Modulation Mode - - - - - - - - - - - - - - - - - - 2-11
Change Video Decoder - - - - - - - - - - - - - - - - - - - - 2-12
Select Audio Output- - - - - - - - - - - - - - - - - - - - - - - 2-12
Select Polarity- - - - - - - - - - - - - - - - - - - - - - - - - - - 2-13
Select a New Preset - - - - - - - - - - - - - - - - - - - - - - 2-13
Setup Menu Operations - - - - - - - - - - - - - - - - - - - - - - 2-13
Review Hardware Configurations - - - - - - - - - - - - - 2-14
Select RF Switch Matrix - - - - - - - - - - - - - - - - - - - - 2-14
Select IP and MAC Addresses - - - - - - - - - - - - - - - 2-15
Change Use Service Information Mode - - - - - - - - - 2-16
Review or Change PIDs- - - - - - - - - - - - - - - - - - - - 2-16
Set Frame Sync - - - - - - - - - - - - - - - - - - - - - - - - - 2-18
Set Frame Sync Offset- - - - - - - - - - - - - - - - - - - - - 2-18
Set Video Color Bar Output - - - - - - - - - - - - - - - - - 2-19

Contents-2DRS4000 Receiver User and Technical Manual
Adjust Analog Audio Level- - - - - - - - - - - - - - - - - - 2-19
Adjust Digital Audio Level - - - - - - - - - - - - - - - - - - 2-20
Adjust SDI Embedded Audio Level- - - - - - - - - - - - 2-20
Set RS-232 Data Output - - - - - - - - - - - - - - - - - - - 2-21
Set Spectrum Overlay - - - - - - - - - - - - - - - - - - - - - 2-21
Select Audio Output - - - - - - - - - - - - - - - - - - - - - - 2-22
Select Demodulator Switch - - - - - - - - - - - - - - - - - 2-22
Enter Service Name - - - - - - - - - - - - - - - - - - - - - - 2-23
Set Video Fail Mode - - - - - - - - - - - - - - - - - - - - - - 2-23
Set NTSC Pedestal - - - - - - - - - - - - - - - - - - - - - - 2-24
Select Encryption Mode - - - - - - - - - - - - - - - - - - - 2-24
Select/Edit Site Management Name - - - - - - - - - - - 2-26
Activate Site Management- - - - - - - - - - - - - - - - - - 2-26
Select Packet Switch Configuration Unit Mode - - - 2-27
Select Packet Switch Configuration ASI Mode- - - - 2-27
Select Packet Switch Configuration Default Service
Name - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-28
Select Packet Switch Configuration ASI Bitrate - - - 2-28
Select BDC Type and Band Control - - - - - - - - - - - 2-29
Complete RCL Calibration- - - - - - - - - - - - - - - - - - 2-30
Firmware Upgrade - - - - - - - - - - - - - - - - - - - - - - - 2-30
EEPROM Initialization- - - - - - - - - - - - - - - - - - - - - 2-31
Edit/Create Custom Frequency Band - - - - - - - - - - 2-31
Upgrade Tuner- - - - - - - - - - - - - - - - - - - - - - - - - - 2-32
Change Channel Spacing Password - - - - - - - - - - 2-32
Preset Menu Operations - - - - - - - - - - - - - - - - - - - - - 2-32
Add a New Licensed Option - - - - - - - - - - - - - - - - - - - 2-33
Camera Control Operations - - - - - - - - - - - - - - - - - - - 2-34
Remote Operation - - - - - - - - - - - - - - - - - - - - - - - - - 2-34
Common Features - - - - - - - - - - - - - - - - - - - - - - - 2-34
Connect to the Web Browser - - - - - - - - - - - - - - - 2-34
Perform Status Monitor - - - - - - - - - - - - - - - - - - - - 2-35
Change RF, Demodulator, and Packet Switch
Configuration Settings- - - - - - - - - - - - - - - - - - - - - 2-36
Change Decoder General Settings- - - - - - - - - - - - 2-36
Change Decoder Audio/Video Settings - - - - - - - - - 2-37
Change Encryption Settings - - - - - - - - - - - - - - - - - 2-37
Review Hardware/Software Configurations - - - - - - 2-38
Rename/Select Site Management- - - - - - - - - - - - - 2-38
Change BDC/RF Switch Matrix- - - - - - - - - - - - - - - 2-39
Change/Monitor Camera Settings - - - - - - - - - - - - - 2-39
Select New Preset- - - - - - - - - - - - - - - - - - - - - - - - 2-39
Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - 3-1
Chapter Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Video Problems - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
Audio Problems - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-4
General System Problems - - - - - - - - - - - - - - - - - - - - - 3-5
Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Chapter Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Unpacking - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Initial Inspection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Reporting Any Damage- - - - - - - - - - - - - - - - - - - - - - - - 4-2
Installing the DRS4000 - - - - - - - - - - - - - - - - - - - - - - - - 4-2
Site Preparation - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
Mounting the DRS4000 - - - - - - - - - - - - - - - - - - - - 4-2
Power Connections - - - - - - - - - - - - - - - - - - - - - - - - - - 4-4
Power Requirements - - - - - - - - - - - - - - - - - - - - - - - 4-4
Power Supply and Distribution - - - - - - - - - - - - - - - - 4-4
Grounding - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-5
Testing the Antennas - - - - - - - - - - - - - - - - - - - - - - - - - 4-5
Installing Antennas and Downconverters - - - - - - - - - - - 4-6
Cabling Practices - - - - - - - - - - - - - - - - - - - - - - - - - 4-6
Selecting Coaxial Cables - - - - - - - - - - - - - - - - - - - - 4-6
Aligning Omnidirectional Antennas- - - - - - - - - - - - - 4-7
Installing Block Downconverters and Antennas - - - - 4-8
Audio Connections - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-9
Video Connections - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-9
Monitor and Control Connectors - - - - - - - - - - - - - - - - 4-10
Data Connections- - - - - - - - - - - - - - - - - - - - - - - - - - - 4-10

Contents-3DRS4000 Receiver User and Technical Manual
Power Connections - - - - - - - - - - - - - - - - - - - - - - - - - 4-12
Optional Packet Connectors - - - - - - - - - - - - - - - - - - 4-12
Initial Power Up - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-13
Checks Before Power Up - - - - - - - - - - - - - - - - - - 4-13
Initial Power Up - - - - - - - - - - - - - - - - - - - - - - - - - 4-13
Product Modifications - - - - - - - - - - - - - - - - - - - - - - - 4-13
Replacement Parts- - - - - - - - - - - - - - - - - - - - - - 5-1
Chapter Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Replacement Parts - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Supported Repairs - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Theory of Operation- - - - - - - - - - - - - - - - - - - - - 6-1
System Architecture - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
Block Downconverters - - - - - - - - - - - - - - - - - - - - - 6-1
RF Switching Module - - - - - - - - - - - - - - - - - - - - - - 6-3
Four-Channel Input Tuner Module - - - - - - - - - - - - - 6-3
COFDM Diversity Module - - - - - - - - - - - - - - - - - - - 6-3
MPEG Decoder Module - - - - - - - - - - - - - - - - - - - - 6-4
Processor Module - - - - - - - - - - - - - - - - - - - - - - - - 6-4
Interface Module - - - - - - - - - - - - - - - - - - - - - - - - - 6-5
Power Supply - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-5
Packet-Based Switch Module - - - - - - - - - - - - - - - - 6-5
Index - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Index-1

Contents-4DRS4000 Receiver User and Technical Manual

1
Introduction 1-1DRS4000 Receiver User and Technical Manual
Introduction
1.1 For Whom It’s Written
This manual is intended for use by qualified operators, installers,
and service personnel. Users of this manual should already be
familiar with basic concepts of radio, video, and audio.
1.2 Related Documents
• Glossary of Terms and Abbreviations (Part No. 400576-1)
• Channels and Frequencies (Part No. 400580-1)
• Maximal Ratio Combining (MaxRC) (Part No. 400586-1)
1.3 Ordering Documentation
Any of the manuals may be ordered by contacting MRC
Customer Service:
Business Hours: Monday - Friday
8:00 AM - 7:00 PM Eastern Time (US)
(0800 - 1900 hrs US ET)
Telephone: [phone] (Press 3)
+1.978.671.5700 (Press 3)
E-mail [e-mail]
When contacting Customer Service, please have the following
information available:
• Model number and serial number of the unit. This is
located on a label on the bottom of each unit.
• Approximate purchase date.
• Firmware revisions (depending upon the options in your
receiver), which appear on the control panel. To access
this information:
- Go to the Hardware Configuration screen as follows:
From the control panel, select SETUP and then select
Hardware Configuration.
- Press OK to display the next screen which lists all
installed hardware and software components and
revision levels.
1.4 Calling for Service
MRC Technical Support is available 24 hours a day, 7 days a
week. During regular business hours you can reach our expert
staff directly.
Business Hours: Monday - Friday
8:00 AM - 7:00PM Eastern Time (US)
(0800 - 1900 hrs US ET)
Telephone: [phone] (Press 4)
+1.978.671.5700 (Press 4)
E-mail: [e-mail]
After regular business hours and on weekends and holidays, you
can also reach our expert staff as follows:
Telephone: [phone]
Your call will be automatically forwarded to the on-call Technical
Support specialist.
When contacting Technical Support, please have the following
information available:

Introduction 1-2DRS4000 Receiver User and Technical Manual
• Model number and serial number of the unit. This is
located on a label on the bottom of each unit.
• Approximate purchase date.
• Firmware revisions (depending upon the options
contained in your receiver), which appear on the control
panel. To access this information, go to:
- Go to the Hardware Configuration screen as follows:
From the control panel, select SETUP and then select
Hardware Configuration.
- Press OK to display the next screen, which lists all
installed hardware and software components and
revision levels.
1.5 Tell Us What You Think
We’d appreciate any comments or suggestions you have about
this manual or the product. Your feedback helps us provide you
with better manuals.
If you’re viewing this manual electronically, it’s easy – just click
on the link below to send us an e-mail.
Or, you can e-mail our Technical Support team at:
[e-mail]
Be sure to tell us what product you are writing about, and the title
of the manual.
Feedback
1.6 System Description
The DRS4000 Receiver system (DRS4000) is a high
performance, cost-effective COFDM receiver suitable for sports,
news, and outside broadcasts from ground-based or aircraft-
based transmitters.
The DRS4000 Receiver (Figure 1-1) is ideal for Electronic News
Gathering (ENG), Digital Video Broadcast (DVB), mobile
communication, wireless airborne networks, and Outside
Broadcast (OB) systems, as well as for applications that require
hands off antenna diversity or deploy multiple units for up to a
four site cellular system
Figure 1-1: DRS4000 Receiver.
The receiver consists of a 2RU rack-mountable, digital, micro-
wave receiver that supports four antenna inputs. All functions
can be operated from the front control panel.
The DRS4000 Receiver uses the latest Maximal Ratio
Combining (MaxRC) technology to optimize the quality of the
transmitted signal. The DRS4000 supports Coded Orthogonal
Frequency Division Multiplexing (COFDM) demodulation, Link
Modulation System (LMS-T) demodulation, MPEG decoding in
[photo of DRS4000 (similar to cover photo)]

Introduction 1-3DRS4000 Receiver User and Technical Manual
either standard definition or high definition (SD/HD), and optional
spectrum viewing, making it an excellent solution for expanding
and extending your remote capabilities.
The DRS4000 Receiver exhibits more sensitivity, provides a
cleaner video image, and minimizes multipath effects when
compared to other microwave receivers.
The receiver operates on 100 to 260 VAC at 50 to 60 Hz. An
auto-sensing circuit detects actual line voltage.
You can readily change system parameters from the front panel
using a keypad and the control screen or by using a studio-
based master controller. Frequently used settings can be saved
in one of 40 presets. A video monitor offers a display of live
video as well as an optional overlay of the RF spectrum.
In a typical DRS4000 system, each antenna is connected to a
low-noise block downconverter (BDC) by a short cable or direct
N-Type connector. The converters output a UHF signal through
coaxial cable to UHF input ports at the rear of the receiver. The
receiver and downconverters may be separated by up to 600
feet (183 m), depending on frequency and cable type.
Incoming signals and downconverter power travel on the same
cable using Bias-T interfaces in both the converter and the
DRS4000 Receiver. The DRS4000 Receiver samples the
signal-to-noise ratio (SNR) from all antennas, constructing an
optimized signal from one or more of the signals. High quality
75-ohm coaxial cable (RG6 or RG11) should be used to connect
the receiver to the downconverters.
The COFDM demodulator and SD/HD MPEG decoder support
standard Digital Video Broadcast-Terrestrial (DVB-T) 2K
operation as well as the highly advanced Link Modulation
System-Terrestrial (LMS-T). LMS-T employs COFDM
technology in a proprietary format that utilizes powerful LDPC
error correction codes to achieve a 30% increase in throughput
with a corresponding increase in robustness over DVB-T. All
MRC and Link SD/HD ENG transmitters and wireless camera
systems also support LMS-T.
Figure 1-2 on page 1-4 depicts a typical configuration.
1.7 Features
The DRS4000 Receiver offers the following features:
• Two or four antenna inputs (DVB-T/LMS-T)
• Maximal ratio combining diversity technology
• ASI packet switching technology (Optional)
• Supports DVB-T and LMS-T demodulation technology
• Front panel live video monitor
• Real-time front panel monitoring for Signal-to-Noise
(SNR), Link Quality signal integrity (LQ), Receive Carrier
Level (RCL), and Bit Error Rate (BER)
• Embedded real-time operating system accessible via front
panel control screen
• Up to 40 programmable presets (saved settings) using the
DRS4000 front panel
• Rack Mountable, compact (EIA 19-inch rack, 2RU height)
• Supports 6, 7, and 8 MHz COFDM/DVB-T pedestals, and
10 and 20 MHz COFDM/LMS-T pedestals
• Internal web server for remote management via any
networked computer
• Controlling a remote camera
• Compatible with MRC and Link Research low-noise block
downconverters

Introduction 1-4DRS4000 Receiver User and Technical Manual
• Interfaces with MRC CodeRunner4 and MRX4000 Plus
products at the 70 MHz IF level
• Spectrum viewer option that overlays the video signal with
an RF spectrum (future option)
Figure 1-2: DRS4000 Receiver Typical 4-Input SD Configuration
Slave Controller
Control
Com
UltraScan II
Sector RX
Antennas
High Gain
Steerable
BDC Support :
2, 3, 5, or 7 GHz
SD Video/
Audio
Output
Dual ASI Outputs
(To Backhaul or L2014)
SD Video/Audio
Output
MRX4000
SDI
Outputs
(SD &HD)
ASI Output
to Backhaul
Network/Control
& Monitoring
Output
Independent
Receive Sites
UHF Input/
+18.5V DC
Out
Pole Mounted or
Angle Bracket
Mounted BDC
Package
Band
Control
Band Control
UHF Input/
+18.5V DC Out
Low Delay
SDI Output
(option)
DRS4000
MRC CodeRunner 4
BDC Support :
2, 3, 5, or 7 GHz
CR4 Receiver
Filter
BDC
Filter
BDC
Filter
BDC
Filter
BDC

Introduction 1-5DRS4000 Receiver User and Technical Manual
1.8 Hardware Components
A typical installation consists of a receiver, antennas, low-noise
block downconverters, and cables.
1.8.1 Receiver
The DRS4000 Receiver accepts 2 or 4 antenna inputs and
incorporates MaxRC diversity technology, COFDM
demodulation, SD/HD MPEG decoding, and DVB-T and LMS-T
demodulation modes. With a front panel video monitor and
control screen, the receiver takes up only 2 RU of space in a 19-
inch rack. The receiver can be operated locally or remotely via a
master controller.
Base models include:
• DRS4000 4-input receiver with MaxRC, SD, and LMS-T
(DRS-R4LAJ)
• DRS4000 4-input receiver with MaxRC, SD, LMS-T, and
ASI Packet Switch (DRS-R4LAJP).
1.8.2 Antennas
MRC offers several types of antennas and several models within
some antenna types. See ”Antenna Options” on page 1-7 for
more information.
1.8.3 Low Noise Block Downconverters
The DRS4000 Receiver is compatible with several MRC and
Link Research downconverters (LNBs). The downconverters
transform the incoming RF signal into UHF for input to the
receiver. See ”Block Downconverter Options” on page 1-6 for
additional information.
1.9 Firmware Components
The DRS4000 Receiver is controlled by software installed on
programmable read-only memory (PROM). You can access this
firmware via the front control screen, and use it to monitor the
incoming signal and control settings such as channel and
frequency.
The firmware also provides a web browser interface that you can
access via a web browser on any PC or laptop computer as long
as both the DRS4000 Receiver and the computer are connected
to the same Local Area Network (LAN). You can also access the
web browser interface via a direct Ethernet connection. See
”Routine Operation” on page 2-1 for additional information.
1.10 Frequency Bands
The DRS4000 Receiver can operate in one of several factory-
programmed frequency bands. You can select the band via the
front control screen or via a master controller interface at the
studio or command center.
MRC offers a range of block downconverters and antennas
designed for each frequency range. The downconverters
transform the incoming RF signal to a 110 to 860 MHz VHF/UHF
signal while the DRS4000 Receiver is capable of accepting a
signal in the range of 70 to 860 MHz.
The following frequency bands are supported:
• 2 GHz
• 3 GHz (non-U.S.)
• 5 GHz
• 7 GHz
• 1.9 to 2.5 GHz / 6.4 to 7.1 GHz (dual band support option)

Introduction 1-6DRS4000 Receiver User and Technical Manual
1.11 Standard/High Definition MPEG
Decoding
The DRS4000 Receiver incorporates a Standard Definition (SD)
MPEG decoder. High Definition (HD) decoding is an option. The
SD decoder includes the following features:
• 4:2:2 or 4:2:0 chroma support
• NTSC or PAL color television standard compliance with
four analog audio channels
• SDI outputs
• AES/EBU Digital Audio
• Wayside Data Channel
• DVB-ASI Output.
1.12 COFDM Demodulation
The DRS4000 Receiver incorporates a COFDM demodulator
that offers the following features:
• DVB-T Compliant
• DVB-T Bandwidth is Auto sensing (6 MHz, 7 MHz, or 8
MHz)
• LMS-T support
• LMS-T Bandwidth is 10 or 20 MHz selectable
• QPSK, 16QAM, or 64QAM modulation
1.13 Applications
The DRS4000 Receiver has several applications:
• Electronic News Gathering (ENG)
• Central receive sites
• Outside Broadcasting (OB)
• Portable Broadcasting.
1.14 Compatibility
The DRS4000 Receiver is compatible with the following
transmitters:
• MRC STRATA Portable Transmitter
• PTX PRO Transmitter
• MTX5000 Transmitter
• LINK XP
• LINK XP HD (future).
1.15 Options
You can customize the DRS4000 Receiver by choosing any of
the following options.
1.15.1 Block Downconverter Options
The following block downconverters are available as options:
MRC Models The following LNBs are supported:
• MRC 908149-5 LNB, 1.7 to 1.85 GHz
• MRC 908149-2 LNB, 1.9 to 2.2 GHz
• MRC 908149-10 LNB, 1.9 to 2.2 GHz/2.2 to 2.49 GHz
Switchable
• MRC 908149-1 LNB, 1.99 to 2.5 GHz
• MRC 908149-4 LNB, 2.3 to 2.7 GHz

Introduction 1-7DRS4000 Receiver User and Technical Manual
• MRC 908149-7 LNB, 3.2 to 3.6 GHz
• MRC 908149-8 LNB, 3.4 to 3.8 GHz
• MRC 908149-9 LNB, 3.5 to 3.95 GHz
• MRC 908149-3 LNB, 4.4 to 4.7 GHz
• MRC 908149-6 LNB, 4.8 to 5.0 GHz
• MRC 908149-11 LNB, 6.4 to 7.1 GHz
• MRC 908149-12 LNB, 6.425 to 7.7 GHz/6.7 to 7.1 GHz
Switchable
• MRC 908149-13 LNB, 6.425 to 6.7 GHz
• MRC 908149-14 LNB, 6.7 to 7.1 GHz.
Link Models The following LNBs and filters are supported:
• L3070 LNB base unit
• L3030 Input filter for L3070 1.95 to 2.7 GHz
• L3033 input filter for L3070 2.2 to 2.3 GHz
• L3034 input filter for L3070 2.3 to 2.4 GHz
• L3037 input filter for L3070 2.5 to 2.7 GHz
• L3060 input filter for L3070 3.4 to 3.6 GHz
• L3080 input filter for L3070 6.425 to 7.125 GHz.
1.15.2 HD Decoding Upgrade
The DRS4000 base models includes an SD MPEG decoder.
The HD option includes the following features:
• 4:2:2 or 4:2:0 chroma support
• HD-SDI Output
• Four analog audio channels
• AES/EBU digital audio
• ASI output.
1.15.3 Antenna Options
To take advantage of diversity combining, you need to select
either 2 or 4 antennas. MRC works with you to select the proper
antennas for your receive site, including your legacy antennas
where feasible.
The following types of antennas are available:
•Omnidirectional These antennas are vertically polarized
and non-steerable. Models include the Omni-Directional
Antenna and OmniPole Antenna.
•Sector Scan These antennas include fixed-position
antennas such as sector panels. Models include
SectorScan.
•Steerable (pan only) These antennas offer full 360-
degree rotation in azimuth. Models include ProScan and
UltraScan DR.
•Steerable (pan and tilt) These antennas offer full
rotation in azimuth as well as tilt (elevation) control.
Models include MicroScan and Ellipse DR.
1.15.4 RF Filter Options
The following RF filters are available as options for mounting
inside a 908441-1 box with a LNB:
• PCS/MMDS filter
• BAS relocation filter
1.15.5 Mounting Options
The DRS4000 Receiver is designed to mount in a standard EIA

Introduction 1-8DRS4000 Receiver User and Technical Manual
19-inch rack, making it suitable for fixed mounting at a receive
site or for portable mounting in a vehicle. Only 2 rack units (RU)
of height are required.
1.15.6 Power Options
A voltage auto-sense feature detects input voltage, which can be
100 to 260 VAC at 50 to 60 Hz. A 3-prong power cable is
included.
The rear power connector includes a removable fuse holder with
a pair of 2-amp glass fuses.
1.15.7 Decryption Options
The receiver supports the Basic Interoperable Scrambling
System (BISS):
• BISS-1
• BISS-E.
1.15.8 Packet Switching Option
The packet switching option enables the addition of feature-rich
enhancements, including cellular diversity hubs and support for
existing central receivers through an ASI interface.

Routine Operation 2-1DRS4000 Receiver User and Technical Manual
Routine Operation
2.1 Chapter Overview
This chapter provides basic information that will enable you to
operate your DRS4000 Receiver.
Here are the topics covered:
Topic Page
Controls, Indicators, and Connectors 2-2
Front Panel Controls, Indicators, and
Connectors
2-4
Rear Panel Connectors 2-4
PACKET Connectors 2-5
Preparing for Operation 2-5
Installation 2-5
Powering the Receiver 2-5
Control Menu Operations 2-9
Using the Video Monitor 2-8
Keypad Operation 2-8
Routine Operations 2-9
Control Menu Operations 2-9
Change Channel 2-10
Change Frequency 2-10
Monitor RF Band 2-11
Change Modulation Mode 2-11
Change Video Decoder 2-12
Select Audio Output 2-12
Select Polarity 2-13
Select a New Preset 2-13
Setup Menu Operations 2-13
Review Hardware Configurations 2-14
Select RF Switch Matrix 2-14
Select IP and MAC Addresses 2-15
Change Use Service Information Mode 2-16
Review or Change PIDs 2-16
Set Frame Sync 2-18
Set Frame Sync Offset 2-18
Set Video Color Bar Output 2-19
Adjust Analog Audio Level 2-19
Adjust Digital Audio Level 2-20
Adjust SDI Embedded Audio Level 2-20
Set RS-232 Data Output 2-21
Set Spectrum Overlay 2-21
Select Audio Output 2-22
Select Demodulator Switch 2-22
Enter Service Name 2-23
Set Video Fail Mode 2-23
Set NTSC Pedestal 2-24
Select Encryption Mode 2-24
Select/Edit Site Management Name 2-26
Activate Site Management 2-26
Select Packet Switch Configuration Unit
Mode
2-27
Select Packet Switch Configuration ASI Mode 2-27
Select Packet Switch Configuration Default
Service Name
2-28

Routine Operation 2-2DRS4000 Receiver User and Technical Manual
Select Packet Switch Configuration ASI
Bitrate
2-28
Select BDC Type and Band Control 2-29
Complete RCL Calibration 2-30
Firmware Upgrade 2-30
EEPROM Initialization 2-31
Edit/Create Custom Frequency Band 2-31
Upgrade Tuner 2-32
Change Channel Spacing Password 2-32
Preset Menu Operations 2-32
Add a New Licensed Option 2-33
Camera Control Operations 2-34
Remote Operation 2-34
Common Features 2-34
Connect to the Web Browser 2-34
Perform Status Monitor 2-35
Change RF, Demodulator, and Packet Switch
Configuration Settings
2-36
Change Decoder General Settings 2-36
Change Decoder Audio/Video Settings 2-37
Change Encryption Settings 2-37
Review Hardware/Software Configurations 2-38
Rename/Select Site Management 2-38
Change BDC/RF Switch Matrix 2-39
Change/Monitor Camera Settings 2-39
Select New Preset 2-39
2.2 Controls, Indicators, and
Connectors
Controls, indicators, and connectors contained on the front and
rear panels of the DRS4000 are shown in Figure 2-1 on page 2-
3.

Routine Operation 2-3DRS4000 Receiver User and Technical Manual
Figure 2-1: DRS4000 Front and Rear Panels
I0
POWER USB ETHERNET MONITOR
DRS4000
DRS4000
BACK OK
BDC 1
BDC 4
BDC 2
BDC 3
BDC 6BDC 5
CTRL/MON1
CTRL/MON3
CTRL/MON5
DIVERSITY
AC IN 100-120/200-240V
50-60Hz, 2A
CV 2CV 1
HD SDISD SDI HD MON
AUDIO 1
WAYSIDE DATA ALARM
ASI OUT ASI OUT
GEN LOCK
AES 2AES 1
CTRL/MON2
CTRL/MON4
CTRL/MON6 AUDIO 2 AUDIO 3 AUDIO 4
RS-232 CNTRL
70 MHz IN
ASI IN
POWER
ASI IN 2
ASI IN 4
ASI IN 1
ASI OUT
PACKET
SDI OUT
ASI IN 3
ASI OUT
(Blank Panel)
Blank panel is standard.
Packet panel is optional.

Routine Operation 2-4DRS4000 Receiver User and Technical Manual
2.2.1 Front Panel Controls, Indicators, and
Connectors
POWER Switch The POWER switch controls application of
power to the unit. When set to on ( I), power is applied to the
unit. When set to off ( O), power is removed from the unit.
USB Connector The USB 2.0 connector allows you to install
firmware updates from MRC via a flash drive.
ETHERNET Connector The RJ-45 ETHERNET connector
allows you to connect the receiver to a computer and use the
DRS4000 web browser interface to control the receiver.
MONITOR Screen The MONITOR screen provides a live view
of the incoming video signal. If the receiver loses the incoming
signal for any reason, the MONITOR screen will display either a
freeze frame or a blank screen.
With the spectrum viewer option installed, the monitor also
displays the RF spectrum as an overlay to the video display.
Control Menu The Control menu reports real-time data for the
video signal and shows current RF settings. The Control menu
also displays menus used to change system settings.
Keypad The keypad consists of easy-to-use push buttons that
provide access to all system parameters and settings. See
“Keypad Operation” on page 2-8 for details.
2.2.2 Rear Panel Connectors
The rear panel contains the connectors for power, diversity
inputs and outputs, and audio outputs. If the packet switching
subsystem is installed, the blank panel is replaced by the
PACKET connector panel.
The rear panel provides numerous inputs and outputs. These
inputs and outputs are as follows.
CNTL/MON 1 thru CTRL/MON 4 Connectors The control/
monitor connectors are 7-pin Lemo sockets that provide control
outputs and monitor inputs for the corresponding downconverter.
For example, CTRL/MON 4 controls and monitors BDC 4.
BDC 1 thru BDC 4 Connectors The block downconverter
(BDC) connectors are TNC connectors that accept the UHF
signals from the downconverters and their corresponding
antennas. To power each downconverter, +8.5/+18.5 VDC is
applied to the coaxial cable that runs from the BDC connector to
the downconverter.
CV 1 and CV 2 Connectors These Composite Video (CV)
connectors are 75 ohm, female, BNC connectors that provide
analog video signal outputs.
WAYSIDE DATA Connector This RS-232, 9-pin female
connector is the wayside channel, used for transfer of data such
as global positioning satellite (GPS) data or meta data from the
MPEG decoder. Using a standard RS-232 cable, you can
connect the receiver’s WAYSIDE DATA connector to a computer
or an auto-tracking antenna system.
ALARM Connector This DB-15 female connector connects to
single-pole single throw (SPST) switches for summary alarm
data for common faults and events and for site management
control. One SPST switch is for a minor alarm, one SPST switch
is for a major alarm, and four SPST switches are for site
management.
GEN LOCK Connector This 75 ohm, female, BNC connector
provides the Gen Lock input to the MPEG module.
The Frame Sync function must be turned on via the Set Frame
Sync Menu in order to use GEN LOCK.
SDI Connectors The SDI connectors are 75 ohm, female, BNC
connectors that provide SD/HD video data stream outputs from
the MPEG module that are compliant with SMPTE 259M.
