MrPEX SALUS ST880ZB Optima Zigbee User guide

SMC-GM-WCSG-M4-2019.10v1_2019-11-10
CONNECTED WIRELESS
SYSTEM GUIDE
MODULE 3 – Wireless HVAC Thermostats

SECTION PAGE
1 Introduction
Using this Manual.........................................................................................1-1
System Overview .........................................................................................1-2
2 Salus ST880ZB Optima Zigbee Thermostat
Included Parts / Installation Tools.........................................................................2-1
Installation – Mounting & Wiring .........................................................................2-2
Controls & Display .......................................................................................2-5
Home Screen ............................................................................................2-6
Pairing Instructions ...................................................................................... 2-7
Time & Date.............................................................................................2-10
Settings .................................................................................................2-11
Firmware Update .......................................................................................2-12
Factory Reset........................................................................................... 2-13
3 Salus ST898ZB Optima S Thermostat
Included Parts / Installation Tools.........................................................................3-1
Installation – Mounting & Wiring .........................................................................3-2
Display Boot Sequence ..................................................................................3-4
Pairing Instructions ......................................................................................3-4
Initial Configuration ......................................................................................3-6
Home Screen & Controls.................................................................................3-8
Operation ................................................................................................3-9
Configuration ...........................................................................................3-10
4 Remote Thermostat Operation & Parameters
Optima & Optima S Parameters ...........................................................................4-1
Schedules & Status Options .............................................................................4-2
Setting Up Thermostat Schedules .......................................................................4-3
Using Status to Control Thermostats ....................................................................4-5
5 Troubleshooting
Troubleshooting Information ..............................................................................5-1
MRPEX®CONNECTED WIRELESS SYSTEM GUIDE
CONTENTS: WIRELESS HVAC THERMOSTATS
MODULE 3
i

1-1
USING THIS MANUAL
For the latest Instructions go to: WWW.MRPEXSYSTEMS.COM
To cover all MrPEX®Wireless Products without requiring customers to download unnecessary
documentation, the Wireless System Guide has been divided into 5 volumes. Volume 1 is required for all
wireless systems since it covers installation of the Gateway and the MrPEX®Smart Home application.
The remaining volumes are specific to a particular group of controls.
Below is a description of several icons used to direct the reader’s attention.
Special Attention Boxes
This manual uses special attention icons to alert the reader of important safety concerns, information
important to reliable operation of the controls or helpful installation/setup information.
Safety:
Indicates a condition which may cause severe
personal injury, death or major property damage
Important Information:
Indicates information which requires special
attention for correct operation of the control
Your Benefit:
Indicates helpful installation or setup information
MODULE 3 – WIRELESS HVAC THERMOSTATS
INTRODUCTION
SECTION 1

1-2
SYSTEM OVERVIEW
MrPEX®connected HVAC control systems use Zigbee-based communications protocol to provide a
universal language for smart components to work together seamlessly and securely with an internet
connection. If the internet connection is interrupted or dis connected, the HVAC component will continue
to operate together.
MODULE 3 – WIRELESS HVAC THERMOSTATS
INTRODUCTION
SECTION 1
By connecting the Gateway to your home network, the system is connected to the worldwide web.
Monitor or adjust your HVAC system from anywhere via the MrPEX®Smart Home application. If the
connection to the internet is lost, the system continues to function with the settings selected.

2-1
INCLUDED PARTS
#1 Phillips
Screwdriver
1/16” Drill Bit
(Optional)
Power Drill
(Optional
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Thermostat with
Mounting Plate
Trim Plate Screws & Anchors
Wire Labels AA Alkaline
Batteries
Optima Thermostat
User Manual Optima Thermostat
Quick Start Guide
Tools Required

2-2
Step 1. Determine the desired wiring configuration for the Salus ST880ZB Thermostat. The following
chart shows the terminal designations for gas, electric or oil (Non-HP) and heat pump (HP) installations.
Appendix A provides reference wiring diagrams for typical thermostat installations.
Step 4. Install the Mounting Plate.
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
INSTALLATION – MOUNTING & WIRING
TABLE 2.1: SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT WIRING REFERENCE
GAS, ELECTRIC OR OIL (NON-HP) HEAT PUMP (HP)
RC 24 VAC for Cooling System R 24 VAC for Heat Pump
RH 24 VAC for Heating System -- Jumper to R
C 24 VAC Common Return C 24 VAC Common Return
-- Reserved L System Monitor
Y1 Single / 1st Stage Cooling Y1 Single / 1st Stage Compressor
Y2 2nd Stage Cooling Y2 2nd Stage Compressor
W1 Single / 1st Stage Heating W1 Emergency Heat
W2 2nd Stage Heating O/B Changeover Valve
G Fan Signal G Fan Signal
-- Reserved -- Reserved
Step 2. If replacing an existing thermostat, review and record the existing wiring configuration:
• Remove thermostat from the wall to expose the wiring terminals
• Take a photograph or note the wire colors and designations (see wiring reference above)
• Attach wire labels provided to each of the existing thermostat wires
Step 3. Remove existing thermostat.
BEFORE BEGINNING the installation procedure, turn o power to the
heating system.
Label wires to correspond to
thermostat terminals.
Wrap wires around a pencil or similar
object to prevent them from falling into
the wall void.

2-3
Use the wall anchors and screws supplied with the
Optima Thermostat to attach the Mounting Plate
to the wall, making sure the wires go through the
center opening.
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Match each wire to the intended terminal.
• Open the terminal by lifting the latch
• Insert the wire into the terminal
• Push the latch down to secure the wire
Refer to the wire tags, wiring schematic and/or
photograph taken earlier if necessary.
If the batteries are not installed, install them in the
Thermostat, observing the CORRECT POLARITY.
• Use alkaline batteries (low battery sensor is tuned
to alkaline batteries.
• DO NOT Mix old and new batteries
• DO NOT Mix Alkaline, Ni-Cad, Lithium batteries
To cover screw holes or paint disturbance from the
old thermostat, install the Trim Plate between the
wall and the Mounting Plate. The Trim Plate can be
mounted vertically or horizontally.
Step 5. Attach wiring to the Mounting Plate.
Step 6. Install batteries in the Thermostat or remove the battery tab.

2-4
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Step 7. Configure the initial parameters
Country Selection
HVAC Type
Heat Pump Options
Non-Heat Pump Options
Step 8. Attach the Thermostat to the Mounting Plate
• After the batteries are inserted, all segments will be briefly displayed
on the LCD screen.
• Next, the firmware version number will be displayed
• When the screen is displayed, use the +/- buttons to toggle
the blinking characters to the desired country
= USA = Canada
• Then press MODE to move to HVAC Type
• When prompted , use +/- to toggle the blinking
characters to the desired HVAC Type
= Heat Pump = Electric, Gas or Oil
Heat
• Then press MODE to move on
• If is selected, options will be displayed. Use +/- to toggle
the reverse valve terminal
= O reverse valve
(energized in cooling)
= B reverse valve
(energized in heating)
• Press MODE to complete setup
• If is selected, options are displayed
- Fan for
Electric or Oil
heating
- Fan
for
Gas heating
• Press MODE to complete setup
• After the initial configuration is complete the Thermostat will
display the Home Screen
• The Thermostat is now ready to be attached to the Mounting Plate

2-5
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
• Align connector pins and retention posts
• Push the Thermostat onto the Mounting Plate
• BE SURE that the connector pins are not bent
• BE SURE that the Thermostat is FULLY SEATED on
the Mounting Plate
Turn on the power to the HVAC System.
CONTROL REGULAR MODE INSTALLATION MODE
Slider Ring Clockwise – Increment Value
Counter-clockwise – Decrement Value
Clockwise – Next OptionCounter-clockwise –
Previous Option
– / Previous Decrement Value Previous Option
+ / Next Increment Value Next Option
Fan / Hold / Back Select Fan Mode
Hold when adjusting temperature Back to Previous Menu
Mode / Enter Select Operating Mode Select Displayed Option
Reset Reset to default state (requires pin or paperclip)
CONTROLS & DISPLAY

2-6
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
DISPLAY INDICATOR DESCRIPTION
Room Temperature Room temperature at the thermostat sensor
Heat/Cool Icons
Indicates the state of the appliance
Cooling demand is active
Heating demand is active
If neither icon is shown, there is no appliance activity
Radio Icon Indicates that the thermostat is connected to a Smart Home system
Low Battery Indicates that the batteries require replacement
Fan Mode
Manual Fan Override
Auto – Fan based on Heat/Cool activity
On – Fan is always On
Day of the Week Displays the day of the week (M Tu W Th F Sa Su)
Time Displays the current time in 12 or 24 hour format
Fan Indicator
Indicates Fan State
Fan On
No fan indicator is shown when the fan is o
Temperature Set Point Displays the target temperature
Message Display Displays the thermostat state, menu or options
System Mode
Operating mode for the appliance
O – Appliance is o
Cool – Appliance is set to cooling mode
Heat – Appliance is set to heating mode
EmHeat – Emergency Heat Mode (heat pump only)
HOME SCREEN
The display returns to the default Home Screen afer 3 seconds of inactivity.

2-7
Step 4. Press MODE to enter
choose the Pairing option.
is displayed
with the Channel and the Radio
Icon.
Step 5. Press MODE to begin the
pairing process. A 10-minute
countdown timer will begin
while is displayed
on the screen.
Step 1. Press the MODE button
to illuminate the screen and
prepare the ST880ZB for input.
Step 2. Press and hold the
MODE button on the ST880ZB
Thermostat for 3 seconds to enter
the configuration menu.
will appear on the screen.
Step 3. Press the + button twice
until is displayed.
PAIRING INSTRUCTIONS
MODULE 3 – WIRELESS HVAC THERMOSTATS
ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
While the Optima Zigbee Thermostat doesn’t need to be installed to be paired with a Universal
Gateway, it should be at or near the intended installation location to account for potential signal
interference.

2-8
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Step 5. Open the MrPEX®Smart Home application, select the drop-down menu from the upper right of the
screen and select: All Devices Add New Device
Step 6. Press Scan Devices. After pressing “Scan Devices”,
the MrPEX®Smart Home
application scans for devices.
Step 7. Choose the check box
that corresponds to the device to
pair.

2-9
Step 8. Enter a unique descriptive
name to identify each device.
Press “Next”.
Step 9. Press “Please click here to
setup”.
Step 10. Choose from setup
options specific to the device.
Press “Complete set up”.
Step 11. Press “Finish” to
complete pairing.
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2

2-10
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Step 3. Use the +/- buttons to
change between 12- and 24-
hour display format. Press
MODE to accept.
Step 4. The display shows the
time with the hours flashing.
Use the +/- buttons to change
the hour value noting the
correct am/pm designation.
Press MODE to accept.
Step 5. When the minutes are
flashing, use +/- to update the
minutes display. Press MODE to
accept the value and proceed to
setting the date.
Step 1. After pressing MODE to
illuminate the screen and prepare
the ST880ZB for input. Press and
hold the MODE button for 3 seconds
to enter the configuration menu.
will appear on the screen.
Step 2. Release and press the MODE button again to adjust the time
zone. The default is can be changed by pressing + or -. See the
time zone chart above for the time zone settings available. Press
Mode to accept the value and the screen will advance to 12- or 24-
hour display format selection.
TIME & DATE
* Default 1-Canada Only
TABLE 2.1: TIME ZONES
NST1Newfoundland Standard
Time
AST1Atlantic Standard Time
EST Eastern Standard Time
CST Central Standard Time
MST Mountain Standard Time
PST* Pacific Standard Time
AKST Alaska Standard Time
HST Hawaii Standard Time
The ST880ZB Optima Thermostat should be configured by an experienced or authorized installer.

2-11
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Step 6. When DATE is
displayed, the Month value (M)
begins flashing. Use the +/-
buttons to adjust the month.
Press MODE to confirm.
Step 7. Set the Day (D) and Year
(Y) similarly, pressing MODE to
advance. After Day and Year are
set, the DST (Daylight Savings
Time) option is displayed.
Step 8. Use the +/- buttons to
toggle between DST ON and DST
OFF. Press MODE to confirm.
Step 1. Press and hold the MODE button
on the ST880ZB Thermostat for 3 seconds
to enter the configuration menu.
will appear on the screen. Press + once to
advance to .
Step 2. Press MODE to enter the SETTINGS
Menu, using +/- to cycle through COUNTRY,
HVAC TYPE, TEMP UNIT, OFFSET, SPAN. See
the chart below for available options.
SETTINGS

2-12
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
TABLE 2.2: SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT – SETTINGS
Country
US United States of America
CA Canada
HVAC Type
HP
O – Rev Valve Energized in Cooling (default)
B – Rev Valve Energized in Heating
NON-HP
FAN HG Fan operation for gas heating (default)
FAN HE Fan operation for electric/oil heating
Temp Unit °F or °C Fahrenheit or Celsius
Oset -7°F to +7°F
(-4°C to +4°C) Calibration oset: Value is added to the sensed temperature
Span 0.5°F to 2.0°F
(0.25°C to1.00°C)
Thermostat dead band – ex. Setpoint of 70°F with Span of 1°F – Temperature will fall
to 69°F without activating heat. Temperature will rise to 71°F without activating
cooling.
FIRMWARE UPDATE
After pressing the MODE button to illuminate the screen, preparing the
ST880ZB for input, press & hold MODE for 3 seconds. When
appears on the screen, press the - button 2 times (or the + button 3 times)
to advance to . Press MODE, is displayed
indicating an update is in progress. Once the Thermostat returns to the
home screen, the update has been loaded.

2-13
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT
SECTION 2
Step 1. Choose tile icon
corresponding to the Optima
ST880ZB Thermostat and choose
the title from the upper left corner
when the tile flips.
Step 2. Choose “Remove shared
room thermostat” after scrolling
to the bottom of the screen.
Step 3. Choose “Delete” from
the dialog box.
FACTORY RESET
When resetting the Optima
Thermostat to its factory default
settings, it is necessary to delete
the device from the MrPEX®
Smart Home Application.
Step 4. Press the MODE
button to illuminate the
screen, preparing the ST880ZB for
input. Then press and hold MODE
for 3 seconds. When
appears on the screen, press the -
button 1 times (or the + button 4
times) to advance to .
Press MODE, is
displayed.
Step 5. Press + and the
Thermostat will be reset to
factory defaults.
After reset, the Optima
Thermostat will begin the
startup procedure as if it were
first powered. After entering
the required information, it
will begin the pairing process.
Note: The ST880ZB can be reset using a pin or paper clip to press the button on the bottom of the
Optima Thermostat. However, this will not clear the country, time zone, temperature units, HVAC
system type or networking information.

3-1
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST898ZB OPTIMA S THERMOSTAT
SECTION 3
INCLUDED PARTS
#1 Phillips
Screwdriver
1/16” Drill Bit
(Optional)
Power Drill
(Optional)
Thermostat with
Mounting Plate
Trim Plate Screws & Anchors
Wire Labels AA Alkaline
Batteries
Optima S Thermostat
User Manual Optima S Thermostat
Quick Start Guide
TOOLS REQUIRED

3-2
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST898ZB OPTIMA S THERMOSTAT
SECTION 3
Step 1. Determine the desired wiring configuration for the Salus ST880ZB Thermostat. The following
chart shows the terminal designations for gas, electric or oil (Non-HP) and heat pump (HP) installations.
Appendix A provides reference wiring diagrams for typical thermostat installations.
INSTALLATION – MOUNTING & WIRING
TABLE 2.1: SALUS ST880ZB OPTIMA ZIGBEE THERMOSTAT WIRING REFERENCE
Gas, Electric or Oil (Non-HP) Heat Pump (HP)
RJP POWER JUMPER (RH)
RC 24 VAC for Cooling System or Jumper to RJP
RH 24 VAC for Heating System 24 VAC for Heat Pump
C24 VAC COMMON RETURN
Y1 Single / 1st Stage Cooling Single / 1st Stage Compressor
Y2 2nd Stage Cooling 2nd Stage Compressor
W1AX Single / 1st Stage Heating Auxiliary or Emergency Heat
W2OB 2nd Stage Heating Changeover Valve
GFAN SIGNAL
L Reserved System Monitor
Step 2. If replacing an existing thermostat, review and record the existing wiring configuration:
• Remove thermostat from the wall to expose the wiring terminals
• Take a photograph or note the wire colors and designations (see wiring reference above)
• Attach wire labels provided to each of the existing thermostat wires
Step 3. Remove existing thermostat.
BEFORE BEGINNING the installation procedure, turn o power to
the heating system.
Wrap wires around a pencil or similar
object to prevent them from falling into
the wall void.
Label wires to correspond to
thermostat terminals

3-3
MODULE 3 – WIRELESS HVAC THERMOSTATS
SALUS ST898ZB OPTIMA S THERMOSTAT
SECTION 3
Use the wall anchors and screws supplied with
the Optima Thermostat to attach the Mounting
Plate to the wall, making sure the wires go
through the center opening.
Match each wire to the intended terminal.
• Push the latch to the right of the terminal to be connected
• Insert the wire into the terminal and release the button
• If properly engaged, the button will remain slightly
depressed when released
Refer to the wire tags, wiring schematic and/or
photograph taken earlier if necessary.
The Optima S Thermostat will prioritize power from the AC
connection (RC to C). If AC power is not available, the device
will switch to the internal batteries. If the batteries are
not installed, install them in the Thermostat, observing the
CORRECT POLARITY.
• Use alkaline batteries (low battery sensor is tuned to
alkaline batteries)
• DO NOT Mix old and new batteries
• DO NOT Mix Alkaline, Ni-Cad, Lithium batteries
To cover screw holes or paint disturbance from
the old thermostat, install the Trim Plate between
the wall and the Mounting Plate. The Trim Plate
can be mounted vertically or horizontally.
Step 5. Attach wiring to the Mounting Plate.
Step 6. Remove the battery tab to activate the batteries.
Step 4. Install the Mounting Plate.
