MSI GT60 Installation instructions

GT60（MS-16F3）Disassembly Guide
■1、BATTERY PACK
■2、BOTTOM DOOR ASSY
■ 3、HDD MODULE
■ 4、THERMAL-KIT、CPU AND DRAM
■ 5、ODD MODULE
■6、SEPARATE UPPER CASE AND LOWER CASE
■7、LOWER CASE ASSY
■8、UPPER CASE ASSY
■ 9、LCD MODULE ASSY

GT60（MS-16F3）Disassembly Guide
1、BATTERY PACK
1.1：Move the “Unlock’ button base on left picture
shows.
1.2：Release the “Release” button and move the
battery pack base on left picture.
Component P/N Qty
Battery Pack S9N-3496200-M47 1

GT60（MS-16F3）Disassembly Guide
2、BOTTOM DOOR ASSY
2.1：Remove the 5 screws (M2.5*5mm).
Attention: the screw driver touque is: 2.5-3.0 gf-cm
Component P/N Qty
Screw E43-1205003-H29 2
2.2：Remove the 6 screws (M2.5*5mm). Then
remove the Bottom door.
Attention: the screw driver touque is: 2.5-3.0 gf-cm
Component P/N Qty
Bottom door 307-6F1J215-P89 1
Screw E43-1205003-H29 6

GT60（MS-16F3）Disassembly Guide
3、HDD MODULE
3.1: Remove the 2 screws (M2.5*5mm); then
remove the two HDD Module according to the
direction as pic shows.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255001-H29 2
3.2: Remove the 4 screws (M3*4mm) that stabilize
the two HDD bracket, then remove the HDD
bracket.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1304009-G68 4
HDD Bracket 307-6F10112-C22 2
HDD Module S71-2475704-H05 2

GT60（MS-16F3）Disassembly Guide
4、THERMAL-KIT、CPU AND DRAM
4.1: Remove the 1 screw(M2.5*5mm) and FAN
cable, after that remove the Fan.
Attention：the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255001-H29 1
FAN E33-0800182-MC2 1
4.2: Remove the 3 screws (M2.5*5mm) and 4
spring screws, after that remove the two Heatsink.
Attention：the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255001-H29 3
Heatsink E31-0403231-TA9 1
Heatsink E31-0900332-TA9 1
4.3：Open the CPU Slot with Screw Driver, then
remove CPU Module as below.
Component P/N Qty
CPU G51-N1CPX2V-I06 1
4
7
2
1
5
6
3

GT60（MS-16F3）Disassembly Guide
4、THERMAL-KIT、CPU AND DRAM
4.4 Push the two side shielding of RAM as pic
shows; Then remove the RAM module according
the direction as pic shows.
Component P/N Qty
RAM Module S7C-S469H03-E54 2
4.5：Remove 1 screw (M2.5*5mm); then remove
the VGA card as pic shows.
Attention: the screw driver torque is: 2.5-3.0Kgf-cm
Component P/N Qty
VGACard 607-1W071-05S 1
Screw E43-1255001-H29 1
4.6：Remove 2screws (M2*3mm); then remove the
HDD connector.
Attention: the screw driver torque is: 1.5-2.0Kgf-cm
Component P/N Qty
HDD connector 607-16F3A-01S 1
Screw E43-1203003-H29 2

GT60（MS-16F3）Disassembly Guide
5、ODD MODULE
5.1：Remove the ODD Module according to the
direction as pic shows.
5.2：Remove ODD Bezel as below.
Component P/N Qty
ODD Bezel 307-6F1F213-P89 1
5.3：Remove 2pcs (M2*3mm) Screws; Then remove
ODD Bracket as below.
Attention：the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 2
ODD Bracket E2M-6F10512-C22 1
ODD Module S7D-2270038-T87 1

GT60（MS-16F3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.1：Before remove K/B, firstly remove the Hinge
Cover. Care the Sensor board FPC below the
cover.
6.2：Remove the Sensor board.
Component P/N Qty
Sensor board 607-16F32-01S 1
Hinge Cover 307-6F3E211-Y31 1
6.3：Remove the LVDS and camera cable as pic
shows.

GT60（MS-16F3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.4：Remove 1 screw (M2*3mm); then remove the
two side wireless card antenna as pic shows.
Attention: the screw driver torque is: 1.5-2.0Kgf-cm
Component P/N Qty
WLAN Module G51-N1WL069-X06 1
Screw E43-1203003-H29 1
6.5 ：Remove the 2 screws (M2.5*7mm) that
stabilize the left LCD hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1257002-G68 2
6.6 ：Remove the 2screws (M2.5*7mm) that
stabilize the right LCD hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1257002-G68 2

GT60（MS-16F3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.7：Remove the Keyboard.
6.8 ：Firstly push connector according to the
direction as pic shows; then remove the cable.
Component P/N Qty
Keyboard S1N-3EUS271-SA0 1
6.9：Remove the Touchpad cable.

GT60（MS-16F3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.10：Remove 2 screws (M2.5*5mm).
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255001-H29 8
6.11：Remove the 2 screws (M2.5*5mm) , then
remove the upper case.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255001-H29 2

GT60（MS-16F3）Disassembly Guide
7、LOWER CASE ASSY
7.1：Remove the FFC and Cable.
7.2：Remove the FFC.

GT60（MS-16F3）Disassembly Guide
7、LOWER CASE ASSY
7.3：Remove the 1 screws (M2*3mm).then remove
the HDD connector board.
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
screw E43-1203003-H29 3
Connector board 607-16F3C-01S 1
7.4：Remove the Audio board.
Component P/N Qty
Audio board 607-16F3B-01S 1
7.5：Remove the LED board.
Component P/N Qty
LED_Right&Forward 607-16F3F-01S 1
LED_Left&Forward 607-16F3E-01S 1

GT60（MS-16F3）Disassembly Guide
7、LOWER CASE ASSY
7.6：Remove the mainboard from Lower case.
Component P/N Qty
Main Board 607-16F31-01S 1
7.7：Remove the Speaker and woofer module from
lower case.
Component P/N Qty
Woofer S33-S030111-F33 1
Speaker Module S33-A020230-F33 1
Lower Case 307-6F2D217-P89 1

GT60（MS-16F3）Disassembly Guide
8、UPPER CASE ASSY
8.1：Remove 1 screw (M2*3mm), then remove the
T/P board.
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
screw E43-1203003-H29 1
Touchpad board .607-16F3D-01S 1
Upper Case 07-6F3C211-Y31 1
8.2：Release the connector that stabilize the T/P
Cable, then remove the T/P module.
Component P/N Qty
Touchpad Module S78-3700650-SD2 1

GT60（MS-16F3）Disassembly Guide
9、LCD MODULE ASSY
9.1：Remove the 6 cover rubber.
Component P/N Qty
Rubber E2Y-6F11611-Y40 4
9.2：When removing the LCD bezel, should begin
from the two sides, then the upside to downside.
Component P/N Qty
LCD Bezel 307-6F2B214-P89 1

GT60（MS-16F3）Disassembly Guide
9、LCD MODULE ASSY
9.3：Remove the 2 screws (M2.5*5mm).
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
screw E43-1205003-H29 2
9.4 ：Remove the 3 screws (M2.5*5mm) that
stabilize the left hinge.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
screw E43-1205003-H29 3
Hinge L E2M-6F20811-G60 1
9.5 ：Remove the 3 screws (M2.5*5mm) that
stabilize the right hinge.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1255001-H29 3
Hinge R E2M-6F20712-G60 1

GT60（MS-16F3）Disassembly Guide
9、LCD MODULE ASSY
9.6：Remove the camera cable, then remove the
display module from LCD cover.
9.7：Remove the LVDS cable from display module.
Component P/N Qty
LVDS Cable K19-3031004-V03 1

GT60（MS-16F3）Disassembly Guide
9、LCD MODULE ASSY
9.8：Remove the 8 screws (M2*3mm)
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
Display Module S1J-6E0A002-L47 1
LCD BRACKET-L E2M-6F20811-G60 1
LCD BRACKET-R E2M-6F20712-G60 1
Screw E43-1203003-H29 8
9.9：Remove the CMOS camera module according
to the sequence as pic shows.
Component P/N Qty
Camera Module S1F-0005160-B36 1

GT60（MS-16F3）Disassembly Guide
9、LCD MODULE ASSY
9.10：Remove the MIC Module as left picture show.
Component P/N Qty
MIC Module S34-2101230-N44 1
9.11：Remove the WIRELESS L-Antenna board
from LCD Cover.
Component P/N Qty
L-Antenna S79-1801790-V03 1
9.12：Remove the WIRELESS R-Antenna board
from LCD Cover.
Component P/N Qty
R-Antenna S79-1801780-V03 1
LCD Cover 307-6F3A211-Y31 1
