MSI P600 MS-16D3 Installation instructions

P600 (MS-16D3) Disassembly Guide
■ 1、BATTERY PACK
■ 2、BOTTOM DOOR ASSY
■3、HDD MODULE
■4、ODD MODULE
■ 5、THERMAL-KIT AND RAM
■ 6、SEPARATE UPPER CASE AND LOWER CASE
■7、LOWER CASE ASSY
■8、UPPER CASE ASSY
■9、LCD MODULE ASSY

P600（MS-16D3）Disassembly Guide
1、BATTERY PACK
1.1：Move the “Unlock’ button base on left picture
shows;
1.2：Release the “Release” button and move the
battery pack base on left picture.
Component P/N Qty
Battery Pack S9N-3089200-SB3 1

P600（MS-16D3）Disassembly Guide
2、BOTTOM DOOR ASSY
2.1：Remove the 10 screws (M2.5*4mm), then
remove the Bottom door.
Attention: the screw driver touque is: 2.3Kgf-cm
Component P/N Qty
Bottom door 307-6D2J211-SE0 1
Screw E43-1254002-H29 10

P600（MS-16D3）Disassembly Guide
3、HDD MODULE
3.1：Remove the 3 screws (M2.5*4mm); Then
remove the HDD Module according to the
direction as pic shows.
Attention: the screw driver torque: 3.0Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 3
3.2 ：Remove the 2 screws (M3*3.5mm) that
stabilize the bracket.
Attention: the screw driver torque is 2.3Kgf-cm
Component P/N Qty
Screw E43-1303502-H29 2
3.3：Remove the HDD bracket.
Component P/N Qty
HDD Bracket 307-6910111-A89 1
HDD Module S71-2432538-W36 1

P600（MS-16D3）Disassembly Guide
4、ODD MODULE
4.1：Remove the ODD Module according to the
direction as pic shows.
4.2：Remove ODD Bezel as below.
Component P/N Qty
ODD Bezel 307-6D1F211-SE0 1
4.3：Remove 2pcs screws (M2*3mm). Then remove
ODD Bracket as below.
Attention: the screw driver torque: 2.3Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 2
ODD Bracket E2M-6D10112-A89 1
ODD Module S7D-2170004-H44 1

P600（MS-16D3）Disassembly Guide
5、THERMAL-KIT AND RAM
5.1:Remove the 3 screws(M2.5*4mm) and FAN
cable, after that remove the Fan.
Attention：the screw driver torque is 2.3Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 3
Fan E33-0800140-A32 1
5.2：Remove the 3 screws(M2.5*4mm) ，after that
remove the thermal module.
Attention：the screw driver torque is 2.3Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 3
HEATSINK E31-0801810-TA9 1
5.3：Push the two sides shielding of RAM as pic
Shows, then remove the RAM module; after that
remove the CPU.
Component P/N Qty
CPU A13-2220106-I06 1
RAM Module S7C-S458804-S02 1

P600（MS-16D3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.1：Remove 7 screws(M2*3mm)
Attention: the screw driver torque is 2.3Kgf-cm
Component P/N Qty
Screw E43-1203003-H29 7
6.2：Remove 13 screws(M2.5*4mm)
Attention: the screw driver torque is 2.3Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 13

P600（MS-16D3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.3：Before remove K/B, firstly remove the upside,
then remove the two sides, last remove the
downside.
6.4 ：Firstly push connector according to the
direction as pic shows; then remove the cable;
Component P/N Qty
Keyboard S1N-3EUS231-SA0 1
6.5: When remove the keyboard should
notice the two bosses at bottom of the
keyboard. .

P600（MS-16D3）Disassembly Guide
6、SEPARATE UPPER CASE AND LOWER CASE
6.6：Remove the 1 screw(M2.5*4mm);
Attention: the screw driver torque is: 2.0-2.5Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 1
6.7：First release the connector that stabilize the
cable, then remove Touchpad cable according to
the direction that pic shows.
6.8：When remove the Upper case, detach the
Upper case down side from Lower case;

P600（MS-16D3）Disassembly Guide
7、LOWER CASE ASSY
7.1：Remove the Power cable and the LVDS cable
as pic shows.
7.2：Remove 1 screw (M2.5*4mm); then remove
the Power board.
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
Power Board 607-16D3C-01S 1
Screw E43-1254002-H29 1
7.3：Remove the 3 screws (M2.5*4mm); then
remove the Audio board.
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
Audio board 607-16D3B-01S 1
Screw E43-1254002-H29 3

P600（MS-16D3）Disassembly Guide
7、LOWER CASE ASSY
7.4 ：Remove the 5screws (M2.5*4mm), then
remove the main board from the Lower case.
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
Main Board 607-16D31-01S 1
Screw E43-1254002-H29 5
7.5：Remove the cable as pic shows.
7.6 ：Remove the 1 screw (M2.5*4mm); then
remove the FFC and VGA board.
Attention: the screw driver torque is 2.3Kgf-cm
Component P/N Qty
VGA board 607-16D3A-01S 1
Screw E43-1254002-H29 1

P600（MS-16D3）Disassembly Guide
7、LOWER CASE ASSY
7.7：Remove the 1 screw (M2.5*4mm) that stabilize
the left LCD hinge.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 1
7.8：Remove the 1 screw (M2.5*4mm) that stabilize
the right LCD hinge.
Attention: the screw driver torque is 2.5-3.0Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 1
7.9：Remove the Speaker module from lower case.
Component P/N Qty
Speaker Module S33-A000150-F33 1
Lower Case 307-6D1D211-SE0 1

P600（MS-16D3）Disassembly Guide
8、UPPER CASE ASSY
8.1：Remove the 2 screws (M2*3mm), then remove
the T/P bracket.
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
T/P bracket E2M-6D10511-A89 1
Screw E43-1203003-H29 2
8.2：Remove the 2 screws (M2*3mm), then remove
the F/P.
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
F/P OS1-16D3001 1
Screw E43-1203003-H29 2
8.3 ：Remove the Mylar and release the
connector that stabilize the T/P cable, then
remove the T/P module according to direction of
pic shows;
Component P/N Qty
T/P module S78-3700440-E47 1
UPPER CASE 307-6D1C221-SE0 1
FFC Cable (To MB) K1C-1012057-J36 1

P600（MS-16D3）Disassembly Guide
9、LCD MODULE ASSY
9.1：Remove the two sides LCD HINGE-CAP.
Component P/N Qty
Hinge cap-L E2P-6910151-H76 1
Hinge cap-R E2P-6910251-H76 1
9.2：Remove the 6 LCD rubbers.
Component P/N Qty
LCD Rubber E2Y-6911711-Y40 6
9.3：Remove the LCD bezel, should begin from
downside to left side, then the upside to right side;
Component P/N Qty
LCD Bezel 307-692B211-U22 1

P600（MS-16D3）Disassembly Guide
9、LCD MODULE ASSY
9.4：Remove the 3 magnets on LCD cover;
Component P/N Qty
LCD Cover Magnet E2M-6910511-SF7 2
LCD Cover Magnet E2M-6910411-SF7 1
9.5：Remove the 3 screws (M2.5*5mm); Remove
the left LCD hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1255002-H29 3
Hinge L E2M-6D10911-G60 1
9.6：Remove the 3 screws (M2.5*5mm); Remove
the right LCD hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
Screw E43-1255002-H29 3
Hinge R E2M-6D10811-G60 1

P600（MS-16D3）Disassembly Guide
9、LCD MODULE ASSY
9.7：Remove the 4 screws (M2.5*4mm)
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
Screw E43-1254002-H29 4
9.8：Firstly remove the Camera Cable, then
remove the display module from LCD cover.
9.9：Remove the LVDS cable from display module;
Component P/N Qty
LVDS Cable K19-3023011-V03 1

P600（MS-16D3）Disassembly Guide
9、LCD MODULE ASSY
9.10：Remove the 8 screws (M2*3mm)
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
Display Module S1J-642G004-CG1 1
LCD BRACKET-L E2M-6910211-A89 1
LCD BRACKET-R E2M-6910311-A89 1
Screw E43-1203003-H29 8
9.11：Remove the CMOS camera module
according to the sequence as pic shows;
Component P/N Qty
Camera Module S1F-0001550-AH3 1

P600（MS-16D3）Disassembly Guide
9、LCD MODULE ASSY
9.12：Remove the MIC Module as left picture show
Component P/N Qty
MIC Module S34-2101070-K03 1
9.13：Remove the WIRELESS board from LCD
Cover.
Component P/N Qty
Antenna S79-1800U40-J51 1
9.14：Remove the Bluetooth board from LCD
Cover.
Component P/N Qty
Bluetooth 605-3801-010 1
LCD Cover 307-691A713-SE0 1

P600（MS-16D3）Screws specification
Photo Screw specification Label
(M2.5*L4MM)black
(M2.5*L5MM)white
(M2*L3MM)white
(M3*L3.5MM) white

P600（MS-16D3）screws specification
■ 1、BOTTOM DOOR ASSY total 22pcs screws
■ specification：
Photo Screw specification label
(M2.5*L4MM) black
