MTD 20 User manual

Operator’s Manual
PRINTED IN U.S.A.
FORM NO.
769-01439
(11/2004)
IMPORTANT: Read safety rules and instructions carefully before operating equipment.
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019.
20” Rotary Mower
Model Series 020
For US Customers: MTD LLC, P.O. BOX 361131, CLEVELAND, OHIO 44136-0019
For Canadian Customers: MTD Products Ltd., P. O. BOX 1386, KITCHENER, ONTARIO N2G 4J1

2
TABLE OF CONTENTS
FINDING MODEL NUMBER
This Operator’s Manual is an important part of your new equipment. It will help you assemble, prepare and maintain the unit for
best performance. Please read and understand what it says.
Before you start assembling your new equipment, please locate the model plate on the equipment and copy the
information from it in the space provided below. A sample model plate is also given below. You can locate the model
plate by standing at the operating position and looking down at the rear of the deck . This information will be
necessary to use the manufacturer’s web site and/or help from the Customer Support Department or an authorized
service dealer.
ENGINE INFORMATION
The engine manufacturer is responsible for all engine-related issues with regards to performance, power-rating, specifications,
warranty and service. Please refer to the engine manufacturer’s Owner’s/Operator’s Manual packed separately with your unit for
more information.
CALLING CUSTOMER SUPPORT
Please do NOT return the unit to the retailer from which it was purchased, without first contacting Customer Support.
If you have difficulty assembling this product or have any questions regarding the controls, operation or maintenance
of this unit, please call a Customer Support Representative.
For US Customers: 1- (330) 220-4MTD (4683) or 1- (800)-800-7310
For Canadian Customers: 1-800-668-1238
Please have your unit’s model number and serial number ready when you call. See previous section to locate this information.
You will be asked to enter the serial number in order to process your call.
HOW TO OBTAIN SERVICE
Warranty service is available, WITH PROOF OF PURCHASE, through your local authorized service dealer. To
locate the dealer in your area;
In the U.S.A.: Check your Yellow Pages, or contact MTD LLC at P.O. Box 361131, Cleveland, Ohio 44136-0019, or
call 1-800-800-7310 or 1-330-220-4683 or log on to our Web site at www.mtdproducts.com.
In Canada: Contact MTD Products Limited, Kitchener, ON N2G 4J1, or call 1-800-668-1238 or log on to our Web
site at www.mtdcanada.com.
Content Page
Customer Support 2
Important Safe Operation Practices 3
Slope Gauge 5
Setting Up 6
Operating Your Lawn Mower 9
Maintenance 11
Troubleshooting 14
Warranty 15
Parts List 16
Content Page
USA-www.mtdproducts.com 1-800-800-7310
CAN-www.mtdcanada.com 1-800-668-1238
MTD LLC
CLEVELAND, OH 44136
MTD PRODUCTS LIMITED
KITCHENER, ON N2G 4J1
Model Number
Numéro de modèle
XXXXXXXXXXX XXXXXXXXXXX
Serial Number
Numéro de sérier
Copy the model number here:
Copy the serial number here:

3
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES
WARNING: This symbol points out important safety instructions which, if not followed, could
endanger the personal safety and/or property of yourself and others. Read and follow all instructions in
this manual before attempting to operate this machine. Failure to comply with these instructions may
result in personal injury. When you see this symbol - heed its warning.
WARNING: Engine Exhaust, some of its constituents, and certain vehicle components contain or
emit chemicals known to State of California to cause cancer and birth defects or other reproductive
harm.
DANGER:This machine was built to be operated according to the rules for safe operation in this
manual. As with any type of power equipment, carelessness or error on the part of the operator can
result in serious injury. This machine is capable of amputating hands and feet and throwing objects.
Failure to observe the following safety instructions could result in serious injury or death.
General Operation
1. Read this operator’s manual carefully in its entirety before
attempting to assemble this machine. Read, understand, and
follow all instructions on the machine and in the manual(s)
before operation. Be completely familiar with the controls and
the proper use of this machine before operating it. Keep this
manual in a safe place for future and regular reference and for
ordering replacement parts.
2. This machine is a precision piece of power equipment, not a
plaything. Therefore, exercise extreme caution at all times. Your
unit has been designed to perform one job: to mow grass. Do not
use it for any other purpose.
3. Never allow children under 14 years old to operate this machine.
Children 14 years old and over should read and understand the
instructions in this manual and should be trained and supervised
by a parent. Only responsible individuals who are familiar with
these rules of safe operation should be allowed to use this
machine.
4. Thoroughly inspect the area where the equipment is to be used.
Remove all stones, sticks, wire, bones, toys and other foreign
objects which could be tripped over or picked up and thrown by
the blade. Thrown objects can cause serious personal injury.
Plan your mowing pattern to avoid discharge of material toward
roads, sidewalks, bystanders and the like. Also, avoid
discharging material against a wall or obstruction which may
cause discharged material to ricochet back toward the operator.
5. To help avoid blade contact or a thrown object injury, stay in the
operator zone behind the handles and keep children,
bystanders, helpers and pets at least 75 feet from the mower
while it is in operation. Stop machine if anyone enters the area.
6. Always wear safety glasses or safety goggles during operation
and while performing an adjustment or repair to protect your
eyes. Thrown objects which ricochet can cause serious injury to
the eyes.
7. Wear sturdy, rough-soled work shoes and close-fitting slacks
and shirts. Shirts and pants that cover the arms and legs and
steel-toed shoes are recommended. Never operate this machine
in bare feet, sandals, slippery or light weight (e.g. canvas) shoes.
8. Do not put hands or feet near rotating parts or under the cutting
deck. Contact with the blade can amputate hands and feet.
9. A missing or damaged discharge cover can cause blade contact
or thrown object injuries.
10. Many injuries occur as a result of the mower being pulled over
the foot during a fall caused by slipping or tripping. Do not hold
on to the mower if you are falling; release the handle
immediately.
11. Never pull the mower back toward you while you are walking. If
you must back the mower away from a wall or obstruction first
look down and behind to avoid tripping and then follow these
steps:
a. Step back from the mower to fully extend your arms.
b. Be sure you are well balanced with sure footing.
c. Pull the mower back slowly, no more than half way
toward you.
d. Repeat these steps as needed.
12. Do not operate the mower while under the influence of alcohol
or drugs.
13. Do not engage the self-propelled mechanism on units so
equipped while starting engine.
14. The blade control handle is a safety device. Never attempt to
bypass its operation. Doing so makes the safety device
inoperative and may result in personal injury through contact
with the rotating blade. The blade control handle must operate
easily in both directions and automatically return to the
disengaged position when released.
15. Never operate the mower in wet grass. Always be sure of your
footing. A slip and fall can cause serious personal injury. If you
feel you are losing your footing, release the blade control handle
immediately and the blade will stop rotating within three
seconds.
16. Mow only in daylight or in good artificial light. Walk, never run.
Stop the blade when crossing gravel drives, walks or roads.
17. If the equipment should start to vibrate abnormally, stop the
engine and check immediately for the cause. Vibration is
generally a warning of trouble.
18. Shut the engine off and wait until the blade comes to a complete
stop before removing the grass catcher or unclogging the chute.
The cutting blade continues to rotate for a few seconds after the
engine is shut off. Never place any part of the body in the blade
area until you are sure the blade has stopped rotating.
19. Never operate mower without proper trail shield, discharge
cover, grass catcher, blade control handle or other safety
protective devices in place and working. Never operate mower
with damaged safety devices. Failure to do so, can result in
personal injury.
20. Muffler and engine become hot and can cause a burn. Do not
touch.
21. Only use parts and accessories made for this machine by the
manufacturer. Failure to do so can result in personal injury.
22. If situations occur which are not covered in this manual, use care
and good judgment. Call customer assistance for the name of
your nearest servicing dealer.

4
Slope Operation
Slopes are a major factor related to slip and fall accidents which can
result in severe injury. Operation on slopes requires extra caution. If
you feel uneasy on a slope, do not mow it. For your safety, use the
slope gauge included as part of this manual to measure slopes before
operating this unit on a sloped or hilly area. If the slope is greater than
15 degrees, do not mow it.
Do:
1. Mow across the face of slopes; never up and down. Exercise
extreme caution when changing direction on slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps which can
cause you to slip or trip. Tall grass can hide obstacles.
3. Always be sure of your footing. A slip and fall can cause serious
personal injury. If you feel you are losing your balance, release
the blade control handle immediately, and the blade will stop
rotating within 3 seconds.
Do Not:
1. Do not mow near drop-offs, ditches or embankments, you could
lose your footing or balance.
2. Do not mow slopes greater than 15 degrees as shown on the
slope gauge.
3. Do not mow on wet grass. Unstable footing could cause slipping.
Children
Tragic accidents can occur if the operator is not alert to the presence
of children. Children are often attracted to the mower and the mowing
activity. They do not understand the dangers. Never assume that
children will remain where you last saw them.
1. Keep children out of the mowing area and under the watchful
care of a responsible adult other than the operator.
2. Be alert and turn mower off if a child enters the area.
3. Before and while moving backwards, look behind and down for
small children.
4. Use extreme care when approaching blind corners, doorways,
shrubs, trees, or other objects that may obscure your vision of a
child who may run into the mower.
5. Keep children away from hot or running engines. They can suffer
burns from a hot muffler.
6. Never allow children under 14 years old to operate a power
mower. Children 14 years old and over should read and
understand the operation instructions and safety rules in this
manual and should be trained and supervised by a parent.
Service
Safe Handling Of Gasoline:
1. To avoid personal injury or property damage use extreme care in
handling gasoline. Gasoline is extremely flammable and the
vapors are explosive. Serious personal injury can occur when
gasoline is spilled on yourself or your clothes which can ignite.
2. Wash your skin and change clothes immediately.
3. Use only an approved gasoline container.
4. Never fill containers inside a vehicle or on a truck or trailer bed
with a plastic liner. Always place containers on the ground away
from your vehicle before filling.
5. Remove gas-powered equipment from the truck or trailer and
refuel it on the ground. If this is not possible, then refuel such
equipment on a trailer with a portable container, rather than from
a gasoline dispenser nozzle.
6. Keep the nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete. Do not
use a nozzle lock-open device.
7. Extinguish all cigarettes, cigars, pipes and other sources of
ignition.
8. Never fuel machine indoors because flammable vapors will
accumulate in the area.
9. Never remove gas cap or add fuel while the engine is hot or
running. Allow engine to cool at least two minutes before
refueling.
10. Never over fill fuel tank. Fill tank to no more than ½ inch below
bottom of filler neck to provide for fuel expansion.
11. Replace gasoline cap and tighten securely.
12. If gasoline is spilled, wipe it off the engine and equipment. Move
unit to another area. Wait 5 minutes before starting the engine.
13. Never store the machine or fuel container near an open flame,
spark or pilot light as on a water heater, space heater, furnace
,clothes dryer or other gas appliances.
14. To reduce fire hazard, keep mower free of grass, leaves, or other
debris build-up. Clean up oil or fuel spillage and remove any fuel
soaked debris.
15. Allow a mower to cool at least 5 minutes before storing.
General Service:
1. Never run an engine indoors or in a poorly ventilated area.
Engine exhaust contains carbon monoxide, an odorless and
deadly gas.
2. Before cleaning, repairing, or inspecting, make certain the blade
and all moving parts have stopped. Disconnect the spark plug
wire and ground against the engine to prevent unintended
starting.
3. Check the blade and engine mounting bolts at frequent intervals
for proper tightness. Also, visually inspect blade for damage
(e.g., bent, cracked, worn) Replace blade with the original
equipment manufacture’s (O.E.M.) blade only, listed in this
manual. “Use of parts which do not meet the original equipment
specifications may lead to improper performance and
compromise safety!”
4. Mower blades are sharp and can cut. Wrap the blade or wear
gloves, and use extra caution when servicing them.
5. Keep all nuts, bolts, and screws tight to be sure the equipment is
in safe working condition.
6. Never tamper with safety devices. Check their proper operation
regularly.
7. After striking a foreign object, stop the engine, disconnect the
spark plug wire and ground against the engine. Thoroughly
inspect the mower for any damage. Repair the damage before
starting and operating the mower.
8. Never attempt to make a wheel or cutting height adjustment
while the engine is running.
9. Grass catcher components, discharge cover, and trail shield are
subject to wear and damage which could expose moving parts or
allow objects to be thrown. For safety protection, frequently
check components and replace immediately with original
equipment manufacturer’s (O.E.M.) parts only, listed in this
manual. “Use of parts which do not meet the original equipment
specifications may lead to improper performance and
compromise safety!”
10. Do not change the engine governor setting or overspeed the
engine. The governor controls the maximum safe operating
speed of the engine.
11. Maintain or replace safety labels, as necessary.
12. Observe proper disposal laws and regulations. Improper
disposal of fluids and materials can harm the environment.
Your Responsibility
• Restrict the use of this power machine to persons who read,
understand and follow the warnings and instructions in this
manual and on the machine.

5
SECTION 2: SLOPE GAUGE
Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower
on such slopes.
15°
SIGHT AND HOLD THIS LEVEL WITH A VERTICAL TREE
A POWER POLE
A CORNER OF A BUILDING
OR A FENCE POST
FOLDONDOTTEDLINE,REPRESENTINGA15°SLOPE
DANGER
Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower could
overturn and cause serious injury. If operating a walk-behind mower on such a slope, it is extremely difficult to maintain your footing and you could slip, resulting in serious injury.
Operate RIDING mowers up and down slopes, never across the face of slopes. Operate WALK-BEHIND mowers across the face of slopes, never up and down slopes.

6
SECTION 3: SET-UP
NOTE: This operator’s manual covers various models of mowers. Follow instructions pertaining to your unit only.
It is suggested that this manual be read in its entirety before attempting to assemble or operate. Keep this manual in
a safe place for future reference and for ordering replacement parts.
This unit is shipped WITHOUT GASOLINE or OIL. After assembly, service engine with gasoline and oil as
instructed in the separate engine manual packed with your unit.
NOTE: Reference to right, left, front or back of the lawn mower is from the operating position only, unless otherwise
stated.
Tools Required for Assembly
(2) 1/2" Wrenches (1) 9/16" Wrench
(1) 7/16" Wrench (1) 3/4" Wrench
NOTE: Locknuts cannot be threaded onto a bolt by hand, a wrench is required for assembly. This type of nut is used
where vibrations occur.
Remove the lawn mower and all parts from the carton. Make certain all parts and literature have been removed from
the carton before the carton is discarded.
Refer to “Contents of Hardware Pack”, Figure 1, for hardware identification.
Contents of Hardware Pack
Figure 1
AATTACHING THE LOWER HANDLE
Rope Guide
(710-1205)
Hex Locknut
1/4-20
(712-0324)
FSECURING THE CABLE
E
INSTALLATION OF WHEELS
Cupped Washer .375 ID x
.87 OD x .063 (736-0105)
Axle Bolts
(738-0533)
Cupped Washer .39 ID
x 1.13 OD (736-0331)
Hex Nut
3/8-16
(712-3017)
B
Carriage Bolt
(710-0262)
ATTACHING THE UPPER HANDLE
Hex Flange
Locknut
5/16-18
(712-3004A)
Hex Bolt
5/16-18x .75
(710-3008)
D
ATTACHING THE CHUTE DEFLECTOR
Carriage Bolt
1/4-20 x 1.0
(710-0932) Flat Washer
(736-0173)
Hex Locknut
1/4-20
(712-0324)
CATTACHING THE STARTER ROPE
Shoulder Scr.
.438x .160: 5/16-18
(738-04033)
Cable Tie
(726-0240)
Hex Nut
5/16-18
(712-3010)
Lockwasher
5/16” ID
(736-0119)

7
Spark Plug Wire
1. Disconnect spark plug wire from the spark plug, and
ground it against the engine.
2. If engine is equipped with a rubber boot, attach rubber
boot to a bolt on the engine to ground. See Figure 2.
Attaching Lower Handle
(Hardware A)
1. Raise the rear of the deck and place it on a block
securely.
2. Place the lower handle over the deck aligning the
lower two holes in the handle with the corresponding
holes on the deck. See Figure 2.
3. Attach the lower handle to the deck with shoulder
screws in the upper hole and hex screws in the lower
hole as shown in Figure 3, secure both with hex flange
locknuts. Using two 1/2” wrenches, tighten securely.
Attaching Upper Handle
(Hardware B)
1. Place the upper handle in position over the lower
handle. The blade control must be on the upper side
of the handle.
2. Secure the upper handle to the lower handle using the
carriage bolts, lockwashers and hex nuts, see Figure
4. Make sure that the carriage bolt heads go on the
outside of the handle.
Attaching Blade Control Handle
NOTE: If the blade control handle got displaced either
during shipping or during assembly of other two handles,
reassemble it now. If the blade control handle is firmly
secured in place, you may proceed to the next assembly.
1. To reattach the blade control handle to the upper
handle, first identify the proper holes in the upper
handle. This can be done by placing the blade control
handle flat against the upper handle. The ends of the
blade control handle will approximate the hole
positions.
2. Insert the curved end of the blade control handle into
the right hole. See Figure 5.
3. Squeeze the handle in, and insert the straight end of
the blade control handle into the left hole of the upper
handle.
4. Squeeze the blade control handle against the upper
handle to check for proper assembly.
NOTE: The hole in the blade control handle must be on
the left side and the control handle must touch the upper
handle when squeezed.
Spark
Plug
Bolt
Spark Plug
Spark Plug
Wire
Wire
Figure 2
Lower Handle
Shoulder Screw
Hex Screw
Figure 3
Figure 4
Lockwasher
Hex Nut
Carriage Bolt
Blade Control
Handle
Insert curved end
Figure 5
IMPORTANT
The blade control handle is a safety
device. Never attempt to bypass its
operations.
of control handle
here.

8
Attaching Brake Cable
1. Make certain the blade control handle is on the top of the
upper handle.
2. The brake cable is attached to the engine, and has a “Z”
fitting on the loose end. Route the brake cable over the
lower handle. Snap the plastic fitting into the hole on the
inside of the upper handle as shown in Figure 6.
3. Hook the “Z” end of the brake cable into the hole in the
blade control handle from the outside to the inside as
shown in Figure 6, inset.
4. Brake cable must be assembled as shown for proper
blade brake operaiton.
Securing Brake Cable
(Hardware F)
Attaching Wheels
(Hardware E)
NOTE: The holes provide three cutting heights for your
mower. Use the same hole location for all four wheels when
assembling. For example, if you desire the lowest cutting
position, assemble each wheel at the highest hole on the deck.
1. Block the mower securely.
2. Place axle bolt through the wheel with the hub side of the
wheel facing the deck. See Figure 8 .
3. Place the small cupped washer on the axle bolt with the
cupped side towards the deck. See Figure 8.
4. Secure the wheel to the deck with one larger cupped
washer on the inside of the deck (cupped side against the
deck) and the hex nut.
5. Tighten axle bolt until cupped washers flatten. Assembled
the other wheels in the same manner.
6. Remove blocks and put the mower on ground.
WARNING: The cable must be routed
properly to avoid contact with all sharp
edges and hot surfaces. Such contacts
damage the cable and render the controls
inoperative.
WARNING: Secure the cable to the
lower left handle near the base of the unit
with a cable tie from the hardware pack.
Trim off extra length of the cable tie. See
Figure 7.
Brake Cable
“Z” Fitting
Blade
Control
Handle
Snap
Fitting
Figure 6
“Z” Fitting
Figure 7
Lower
Cable Tie
Handle
Crowned Cupped
Side Side
Axle
Bolt
Larger
Cupped
Washer
Smaller
Cupped
Washer
Hex Nut
Figure 8

9
Attaching Chute Deflector
(Hardware D)
CAUTION: Do not run your lawn mower without chute
deflector or an approved grass catcher in place. The
deflector will deflect a projectile thrown by the blade into
the lawn.
The chute deflector provided is a safety device. Do not operate
the mower unless the chute deflector has been properly
installed.
1. Place the chute deflector in position on the deck, aligning
holes. See Figure 9.
2. Insert the carriage bolts from the underside of the deck up
through the chute deflector. Secure each bolt with a flat washer and locknut.
NOTE: Make certain all nuts and bolts are tightened securely.
Attaching Starter Rope
(Hardware C)
1. The starter rope is attached to the engine. Additional rope
may be wound around the starter handle. If so, unwind the
rope from the handle.
2. With the spark plug wire disconnected and grounded,
depress the blade control handle and pull the rope out of
the engine.
3. Place the rope guide around the starter handle, so the
opening in the rope guide is toward the front of the mower.
Insert the rope guide into the right side of the handle, and
secure with hex locknut. See Figure 10.
NOTE: If the starter rope becomes disconnected from rope guide on handle, disconnect and ground the spark
plug wire. Depress the blade control handle and pull the starter rope out from engine slowly. Slip the starter rope
into the rope guide bolt on handle.
SECTION 4: OPERATING YOUR LAWN MOWER
Controls
Blade Control Handle
The blade control handle is located on the upper
handle of the mower. See Figure 11. The blade
control handle must be depressed in order to
operate the unit. Release the blade control handle
to stop the engine and blade.
Recoil Starter
The recoil starter is attached to the handle. Stand
behind the unit and pull the recoil starter rope to
start the unit.
WARNING: This blade control
mechanism is a safety device. Never
attempt to bypass its operation.
Chute
Deflector
Lock Nut
Flat Washer
Carriage Bolt
Figure 9
Rope
Guide Nut
Starter
Rope
Hex
Lock
Figure 10
Blade Control Handle
Upper Handle
Recoil Starter Handle
Starter Rope
Chute Deflector
Spark Plug
Figure 11

10
Before Starting
Service the engine with gasoline and oil as instructed in the separate engine manual packed in your mower. Read
instructions carefully.
WARNING: Never fill fuel tank indoors, with engine running or until the engine has been allowed to cool
for at least two minutes after running.
• Attach spark plug wire to spark plug. If unit is equipped with a rubber boot over the end of the spark plug wire,
make certain the metal loop on the end of the spark plug wire (inside the rubber boot) is fastened securely over
the metal tip on the spark plug. See Figure 2.
WARNING: The operation of any lawn mower can result in foreign objects being thrown into the eyes,
which can damage your eyes severely. Always wear safety glasses while operating the mower, or while
performing any adjustments or repairs on it.
To Start Engine and Engage Blade
• If your unit is equipped with a primer, prime
engine as instructed in the separate engine
manual packed with your unit.
• Standing behind the unit, depress the blade
control handle and hold it against the upper
handle as shown in Figure 12.
• Grasp the recoil starter handle as shown and
pull slowly until resistance is felt, then pull
rapidly to start engine and avoid kickback.
Return it slowly to the rope guide bolt.
NOTE: The blade control handle must be
depressed in order to operate the unit. Release
the blade control handle to stop the engine and
blade.
WARNING: THIS CONTROL MECHANISM IS A SAFETY DEVICE. NEVER ATTEMPT TO BYPASS
ITS OPERATION.
Stopping Engine
1. Release blade control handle to stop the engine and the blade.
2. Disconnect spark plug wire from spark plug and ground against the engine.
Using Your Lawn Mower
IMPORTANT: Be sure the lawn is clear of stones, sticks, wire, or other objects which could damage the lawn mower
or the engine. Such objects could be accidently thrown by the mower in any direction and cause serious personal
injury to the operator and others.
WARNING: If you strike a foreign object, stop the engine. Remove wire from the spark plug, thoroughly
inspect the mower for any damage, and repair the damage before restarting and operating the mower.
Extensive vibration of the mower during operation is an indication of damage. The unit should be promptly
inspected and repaired.
Figure 12
Starter
Handle
Blade Control
Handle

11
Cutting Height Adjustment
Adjustment may be made by removing and moving axle bolts to desired position. Cutting heights will be raised as
axle bolts are moved to a lower hole and lowered as axle bolts are moved to a higher hole in the deck All axle bolts
must be assembled so that the cupped side of the washers are against the deck.
SECTION 5: MAINTENANCE
General Recommendations
• Always observe safety rules when performing any maintenance.
• The warranty on this lawn mower does not cover items that have been subjected to operator abuse or
negligence. To receive full value from the warranty, operator must maintain the lawn mower as instructed here.
• Changing of engine-governed speed will void engine warranty.
• All adjustments should be checked at least once each season.
• Periodically check all fasteners and make sure these are tight.
Lubrication
(See Figure 13)
Blade Control Handle
• Lubricate the pivot points on the blade control
handle at least once a season with light oil.
The blade control must operate freely in both
directions. See Figure 13.
Chute Deflector
• The torsion spring and pivot point should be
lubricated periodically with light oil to prevent
any rust or binding. Deflector must work
freely.
Wheels
• If the wheels are removed for any reason,
lubricate the surface of the axle bolt and inner
surface of the wheel with light oil.
Engine
Refer to the separate engine manual for engine
maintenance instructions.
WARNING: Always stop engine, disconnect spark plug, and ground against engine before cleaning,
lubricating or doing any kind of maintenance on your machine.
Operating Tips
• For best results, do not cut wet grass.
• New grass, thick grass, or wet grass may require a narrower cut.
• For a healthier lawn, never cut off more than one-third of the total length of the grass.
• Your lawn should be cut in the fall as long as there is growth.
• Adjust ground speed according to the condition of the lawn.
Figure 13
Lubricate these
points
Lubricate these
points before
re-assembly

12
Cleaning Mower
• The underside of the mower deck should be cleaned after each use to prevent a buildup of grass clippings,
leaves, dirt or other matter. Follow the steps below for this job.
NOTE: We do not recommend the use of pressure washers or garden hose to clean your unit. These may cause
damage to electric components, spindles, pulleys, bearings, or the engine. The use of water will result in shortened
life and reduce serviceability.
1. Disconnect spark plug wire. Drain gasoline from the lawn mower, or place a piece of plastic under the gas cap.
2. Tip the mower so that it rests on the housing. Keep the side with the air cleaner facing up. Hold the mower firmly.
3. Scrape and clean the underside of the deck with a suitable tool. Do not spray with water.
4. Put the mower back on its wheels on the ground. If you had put plastic under the gas cap earlier, make sure to
remove it now.
Blade Care and Replacementt
Periodically inspect the blade adapter for cracks, especially if you strike a foreign object. Replace when necessary.
Follow the steps below for blade service:
• Disconnect spark plug wire from spark plug.
• Tip mower as specified in separate engine manual. If it does not specify turn mower on its side making sure that
the air filter and the carburetor are up.
• Remove the bolt and the blade bell support which
hold the blade and the blade adapter to the engine
crankshaft. See Figure 14.
• Remove blade and adapter from the crankshaft.
• The blade may be resharpened by removing it and
either grinding or filing the cutting edge keeping as
close to the original bevel as possible. Do not
attempt to sharpen the blade while it is still on the
mower.
•It is extremely important that each cutting edge
receives an equal amount of grinding to prevent
an unbalanced blade.
NOTE: Improper blade balance will result in excessive
vibration causing eventual damage to the engine and
mower. Be sure to carefully balance blade after
sharpening. Possible damage resulting from blade
unbalance condition is not the responsibility of the manufacturer.
NOTE: Always remove blade from the adapter for testing balance.
• The blade can be tested for balance by balancing it on a round shaft screwdriver. Remove metal from the heavy
side until it balances evenly.
• Before reassembling the blade and the blade adapter to the unit, lubricate the engine crankshaft and the inner
surface of the blade adapter with light oil.
• Install the blade adapter on the crankshaft with the “star” away from the engine. See Figure 14. Place the blade
with the side marked bottom (or with part number) facing away from the adapter. Align the blade bell support
over the blade with the tabs in the holes of the blade and insert the hex bolt.
WARNING: Never tip the mower more than 90 degrees in any directions and do not leave the mower
tipped for any length of time. Oil can drain into the upper part of the engine causing a starting problem.
WARNING: When removing the cutting blade for sharpening or replacement, protect your hands with a
pair of heavy gloves or use a heavy rag to hold the blade.
Figure 14
Blade Bell
Hex. Bolt
Crankshaft
Blade
Blade
Adapter
Support

13
• Tighten the hex bolt to the torque listed below:
Blade Mounting Torque
Center Bolt 450 in. lb. min., 600 in.lb. max.
To insure safe operation of your unit, ALL nuts and bolts must be checked periodically for correct tightness.
NOTE: Cutting grass in sandy soil condition causes abrasive wear to the blade.
Off-Season Storage
The following steps should be taken to prepare your lawn mower for storage.
1. Clean and lubricate mower thoroughly as described in the lubrication instructions.
IMPORTANT: We do not recommend the use of a pressure washer or garden hose to clean your unit.
2. Refer to engine manual for correct engine storage instructions.
3. Coat mower’s cutting blade with chassis grease to prevent rusting.
4. Store mower in a dry, clean area. Do not store next to corrosive materials, such as fertilizer.
NOTE: When storing any type of power equipment in a poorly ventilated or metal storage shed, care should be
taken to rust-proof the equipment. Using a light oil or silicone, coat the equipment, especially cables and all moving
parts of your lawn mower before storage.
NOTE: Be careful not to bend or kink cables.
NOTE: If the starter rope becomes disconnected from rope guide on handle, disconnect and ground the spark plug
wire. Depress the blade control handle and pull the starter rope out from engine slowly. Slip the starter rope into the
rope guide bolt on handle.

14
SECTION 6:TROUBLE SHOOTING
NOTE: For repairs beyond the minor adjustments listed above, contact an authorized service dealer.
Problem Cause Remedy
Engine fails to start 1. Blade control handle disengaged.
2. Spark plug wire disconnected.
3. Fuel tank empty or stale fuel.
4. Blocked fuel line.
5. Faulty spark plug.
6. Engine flooded
1. Engage blade control handle.
2. Connect wire to spark plug.
3. Fill tank with clean, fresh gasoline.
4. Clean fuel line.
5. Clean, adjust gap, or replace.
6. Wait a few minutes to restart, but do not
prime.
Engine runs erratic 1. Spark plug wire loose.
2. Blocked fuel line or stale fuel.
3. Vent in gas plugged.
4. Water or dirt in fuel system.
5. Dirty air cleaner.
6. Carburetor out of adjustment.
1. Connect and tighten spark plug wire.
2. Clean fuel line; fill tank with clean, fresh
gasoline
3. Clear vent.
4. Drain fuel tank. Refill with fresh fuel.
5. Refer to engine manual.
6. Refer to engine manual.
Engine overheats 1. Engine oil level low.
2. Air flow restricted.
3. Carburetor not adjusted properly.
1. Fill crankcase with proper oil.
2. Remove blower housing and clean.
3. Refer to engine manual.
Occasional skip (hesitates)
at high speed
1. Spark plug gap too close. 1. Adjust gap to .030”. Refer to engine
manual.
Idles poorly 1. Spark plug fouled, faulty or gap too
wide.
2. Carburetor improperly adjusted.
3. Dirty air cleaner.
1. Reset gap to .030” or replace spark
plug. Refer to engine manual.
2. Refer to engine manual.
3. Refer to engine manual.
Excessive vibration 1. Cutting blade loose or unbalanced.
2. Bent cutting blade.
1. Tighten blade and adapter. Balance
blade.
2. Replace blade.
Uneven cut 1. Wheels not positioned correctly.
2. Dull blade.
1. Place all four wheels in same height
position.
2. Sharpen or replace blade.

15
SECTION 7: MANUFACTURER’S LIMITED WARRANTY FOR:
The limited warranty set forth below is given by MTD LLC with respect to new merchandise purchased and used in the United States and/or its
territories and possessions, and by MTD Products Limited with respect to new merchandise purchased and used in Canada and/or its territories
and possessions (either entity respectively, “MTD”).
MTD warrants this product (excluding its normal wear parts as described below) against defects in material and workmanship for a period of two
(2) years commencing on the date of original purchase and will, at its option, repair or replace, free of charge, any part found to be defective in
materials or workmanship. This limited warranty shall only apply if this product has been operated and maintained in accordance with the
Operator’s Manual furnished with the product, and has not been subject to misuse, abuse, commercial use, neglect, accident, improper
maintenance, alteration, vandalism, theft, fire, water, or damage because of other peril or natural disaster. Damage resulting from the installation
or use of any part, accessory or attachment not approved by MTD for use with the product(s) covered by this manual will void your warranty as to
any resulting damage.
Normal wear parts are warranted to be free from defects in material and workmanship for a period of thirty (30) days from the date of purchase.
Normal wear parts include, but are not limited to items such as: batteries, belts, blades, blade adapters, grass bags, rider deck wheels, seats,
snow thrower skid shoes, friction wheels, shave plates, auger spiral rubber and tires.
HOW TO OBTAIN SERVICE: Warranty service is available, WITH PROOF OF PURCHASE, through your local authorized service dealer. To locate
the dealer in your area;
In the U.S.A.:
Check your Yellow Pages, or contact MTD LLC at P.O. Box 361131, Cleveland, Ohio 44136-0019, or call 1-800-800-7310 or 1-330-220-4683 or
log on to our Web site at www.mtdproducts.com.
In Canada:
Contact MTD Products Limited, Kitchener, ON N2G 4J1, or call 1-800-668-1238 or log on to our Web site at www.mtdcanada.com.
This limited warranty does not provide coverage in the following cases:
a. The engine or component parts thereof. These items may carry a separate manufacturer’s warranty. Refer to applicable
manufacturer’s warranty for terms and conditions.
b. Log splitter pumps, valves, and cylinders have a separate one-year warranty.
c. Routine maintenance items such as lubricants, filters, blade sharpening, tune-ups, brake adjustments, clutch adjustments, deck
adjustments, and normal deterioration of the exterior finish due to use or exposure.
d. Service completed by someone other than an authorized service dealer.
e. MTD does not extend any warranty for products sold or exported outside of the United States and/or Canada, and their respective
possessions and territories, except those sold through MTD’s authorized channels of export distribution.
f. Replacement parts that are not genuine MTD parts.
g. Transportation charges and service calls.
h. If Products are used commercially. (MTD may separately offer Limited Commercial Warranties on certain select products. Ask your
dealer or retailer for details or contact MTD Service for more information.)
No implied warranty, including any implied warranty of merchantability of fitness for a particular purpose, applies after the applicable
period of express written warranty above as to the parts as identified. No other express warranty, whether written or oral, except as
mentioned above, given by any person or entity, including a dealer or retailer, with respect to any product, shall bind MTD. During the
period of the warranty, the exclusive remedy is repair or replacement of the product as set forth above.
The provisions as set forth in this warranty provide the sole and exclusive remedy arising from the sale. MTD shall not be liable for
incidental or consequential loss or damage including, without limitation, expenses incurred for substitute or replacement lawn care
services or for rental expenses to temporarily replace a warranted product.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied
warranty lasts, so the above exclusions or limitations may not apply to you.
In no event shall recovery of any kind be greater than the amount of the purchase price of the product sold. Alteration of safety features of the
product shall void this warranty. You assume the risk and liability for loss, damage, or injury to you and your property and/or to others and their
property arising out of the misuse or inability to use the product.
This limited warranty shall not extend to anyone other than the original purchaser or to the person for whom it was purchased as a gift.
HOW LOCAL LAWS RELATE TO THIS WARRANTY: This limited warranty gives you specific legal rights, and you may also have other rights that
vary in different jurisdictions.
IMPORTANT: Owner must present Original Proof of Purchase to obtain warranty coverage.
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019; Phone: [phone]
MTD Products Ltd., P. O. BOX 1386, KITCHENER, ON N2G 4J1; Phone: [phone]

16
SECTION 8: PARTS LIST FOR SERIES 020/LISTE DE PIÈCES DETACHÉES SÉRIES 020
5
4
15
18
27
19
19
20
21
7
6
23
24
22
24
22 23
16
17
16
15
14
23
13
22
22
9
8
10
25
25
24
24
23
11
2
12
1
3
30
26
28
28
28
28
29
29

REF PART
NO. NO.
N° DE N° DE
RÉF PIÈCE DESCRIPTION DESCRIPTION
1710-0654A Hex Wash HD Tap Scr 3/8-16 x .88 Vis autotaraudée 3/8-16 x 0,88
2782-0048 20" Deck Tablier 20 po
3749-04037 Lower Handle Guidon inférieur
4749-1092A Upper Handle Guidon supérieur
5747-1161A Bail Étier
6731-0872B Rear Flap Abattant de protection arrière
717098 Hinge Clip Attache
8710-1044 Hex Bolt 3/8-24 x 1.5" Lg. (Gr 8) Vis à tête hex. 3/8-24 x 1,5 po de lg (Qual. 8)
9736-0524B Blade Bell Support Support de lame
10 748-0376C Blade Adapter Adaptateur de lame
11 742-0640 Blade, Centre Star, 20" Lame, centre étoile, 20 po.
12 731-0064 Fixed Side Chute Déflecteur
13 710-0932 Carriage Bolt 1/4-20 x 1.00" Lg. Boulon ordinaire 1/4-20 x 1,00
14 736-0173 Flat Washer .28 ID x .74 OD x .063 Rondelle plate 0,28 DI x 0,74 DE x 0,063
15 712-0324 Hex Ins. Locknut 1/4-20 Gr. 8 Nylon Écrou hex. 1/4-20 Qual. 8 nylon
16 710-3008 Hex Bolt 5/16-18 x .75" Lg. Gr. 5 Boulon hex. 5/16-18 x 0,75 po de lg. Qual. 5
17 712-3004A Hex Flange L-Nut 5/16-18 Gr. 5 Contre-écrou à embase 5/16-18 Qual. 5
18 710-1205 Rope Guide Bolt Boulon de guidage de cordon
19 710-0262 Carriage Bolt 5/16-18 x 1.50 Gr. 2 Boulon mécanique 5/16-18 x 1,50 Qual. 2
20 736-0119 L-Wash 5/16 ID Rondelle frein 5/16 DI
21 712-3010 Hex Nut 5/16-18 Gr. 5 Écrou hex 5/16-18 Qual. 5
22 734-1779 Front Wheel Ass’y 7 x 1.5 Diamond Ensemble de roue avant 7 x 1,5 Diamant
23 738-0533 Shoulder Screw .498" DIA. x 1.64 Vis épaulée 0,498 DIA x 1,64
24 736-0105 Cupped Washer .375 ID x Rondelle creuse 0,375 DI x 0,870 DE x 0,063
.870 OD x .063
25 712-3017 Flange Lock Nut 3/8-16 Gr. 8 Écrou hex 3/8-16 Qual. 8
26 726-0240 Cable Tie Attache câble
27 746-0946 Control Cable 48.25" Lg. (Tec) Câble de la commande 48,25 po de lg. (Tec)
27 746-0957 Control Cable 37.25" Lg. (B&S) Câble de la commande 37,25 po de lg. (B&S)
28 736-0331 Cupped Washer .39 ID x 1,12 OD Rondelle creuse 0,39 DI x 1,12 DE
29 738-04033 Shoulder Screw, 3/8-16 x .428 Vis épaulée 3/8-16 x 0,498 DIA
30 753-0588 Blade Adapter Kit Kit - Adaptateur de lame
11A-020
10.7.04
17

18
NOTES

18
NOTES

17
NOTES
