MTM HTX620 User manual

Hedge Trimmer - HTX620
User Manual
RETAIN THIS MANUAL FOR FUTURE REFERENCE
PLEASE READ THIS MANUAL CAREFULLY BEFORE USE

Hedge Trimmer - HTX620
i
Table of Contents
Safety Precautions..................................................................................................................................... 1
Fuel Safety ................................................................................................................................................... 2
Two-Stroke Oil....................................................................................................................................................2
Mixture................................................................................................................................................................2
Operation........................................................................................................................................................ 3
Quick Start Guide...............................................................................................................................................3
Trimming Techniques.........................................................................................................................................4
Maintenance ................................................................................................................................................. 4
Daily Maintenance..............................................................................................................................................4
Weekly Maintenance..........................................................................................................................................5
Monthly Maintenance......................................................................................................................................... 5
Specifications ............................................................................................................................................... 5
Preface
Thanks for buying the Hedge Trimmer, another high-quality machine from our company.
To get the most out of your purchase, please read the manual before using the hedge trimmer.
We ask you to please read this manual carefully beforehand in order to familiarise yourself with this product and
after reading, please store this instructional manual for future reference. Failure to follow the proper protocols
listed in the manual may cause personal injury to the operator or damage to equipment.

Hedge Trimmer - HTX620
1
Safety Precautions
Proper safety precautions must be observed.
Like all power equipment this unit must be handled carefully.
Do not expose yourself or others to danger.
Do not permit others to use this trimmer unless they have read this manual and are trained in its
operation
Never allow children to use the machine.
Avoid operating while people, especially children are nearby.
Dress properly! Do not wear loose clothing or jewellery which can be caught in moving parts. Use of sturdy
gloves, on-skid footwear, and safety glasses is recommended.
Stop the engine or disconnect from mains before.
Cleaning or when clearing a blockage.
Checking, maintenance or working on the machine.
While operating the machine always be sure of a safe and secure operating position especially when using
steps or a ladder.
Do not operate the trimmer with a damaged or excessively worn cutting device.
To reduce fire hazards keep the engine and silencer free of debris leaves, or excessive lubricant.
Do not use any attachments with this power head other than the ones recommended by our company.
Serious injury to the operator or bystanders can result as well as cause damage to the machine.
Always use proper handles and shoulder strap when cutting.
Never start or run the engage inside a closed room or building. Fumes from the exhaust contain dangerous
carbon monoxide.
Never attempt to make engine adjustments while the unit is running and strapped to the operator. Always
make engine adjustments with the unit resting on a flat, clear surface.
Do not use the unit if it is damaged or poorly adjusted. Never remove the machine’s guard. Serious injury to
the operator or bystanders could result as well as damage to the machine.
Never leave the trimmer running and unattended.
Do not use this unit for any job other than those for which it is intended as described in this manual.
Clean the machine completely, especially, the fuel tank, its surroundings, and the air cleaner.
The engine should be turned off when the trimmer is moved between areas and when transporting or storing
the machine always fit the cutting device guard.
In start-up or during operation of the engine, never touch hot parts such as the muffler, the high voltage wire
or the spark plug.
After the engine has stopped, the muffler will still be hot. Never place the machine in any places where there
are flammable materials (dry grass, etc.), combustible gases or combustible liquids.
Do not operate the trimmer in the rain.
Before proceeding to adjust or repair the machine, be sure to stop the engine and detach the spark
plug.

Hedge Trimmer - HTX620
2
Keep the machine away from fire or sparks.
Always wear ear protection. Loud noises for an extended period of time may damage your hearing.
Total face and head protection must be worn to prevent injury from plummeting branches.
Wear no-slip heavy duty work gloves to improve your grip on the brush cutter handle. Gloves also reduce the
transmission of machine vibration to your hands.
Always ensure all handles and guards are fitted when using the machine.
Always be aware of your surroundings and stay alert for possible hazards that you may not hear due to the
noise of the machine.
Fuel Safety
Use unleaded or quality leaded petrol.
The lowest recommended octane rating is 90. If you run the engine on petrol with a lower octane rating than 90
so-called knocking can occur. The knocking means that there is a markedly increased engine temperature which
can cause a serious engine breakdown.
Two-Stroke Oil
Use high quality two-stroke oil intended for air cooled engines.
Mixing ratio: 1:25 (1 part oil to 25 parts of petrol; 40ml of oil to 1 litre of petrol).
Never use two-stroke oil intended for water cooled outboard motor oil.
Never use oil intended for four-stroke engines.
Mixture
Always mix petrol and oil in a clean container intended for petrol.
Always start by filling half the quantity of petrol required.
Mix (shake) the fuel mixture. Fill the remaining quantity of petrol.
Mix (shake) the fuel mixture carefully before filling in the machine’s fuel tank.
Do not mix fuel for more than approximately 2 months use.
If the trimmer is not used for a long period of time, the fuel tank should be emptied and cleaned.
Clean around the fuel cap. Contamination in the tank can disrupt operations.
Ensure that the fuel is well mixed by shaking the container before filling the tank.
Keep the handles free from oil and fuel.
Do not smoke while mixing fuel or filling tank.
Do not mix fuel in an enclosed room or near open flames. Always assure adequate ventilation.
Always mix and store the fuel in a properly marked container that is approved by local codes and ordinances
for such usage.
Never remove the fuel tank cap while the engine is running.
When refuelling, be sure to stop the engine and confirm that it is cooled down. Never refuel when the engine
is running or hot. When gasoline spills, be sure to wipe it up to completely dispose of those materials before
starting the engine.

Hedge Trimmer - HTX620
3
Operation
Always operate the trimmer using both bands.
Quick Start Guide
When starting the engine for the very first time, please refer to the full manual for further details if the quick start
guide below does not work.
Please use 25:1 oil mixture ratio.
Ensure that enough petrol/ (2
stroke) oil mix is in the tank.
Press primer bulb 2 –3 times (fuel
should flow through the clear tube).
Ensure that the ON/OFF switch is
turned ‘ON’.
Turn the choke to ‘COLD’.
Pull the starter cord 3 –4 times
(engine should start).
Turn the choke to ‘RUN’.
If the engine stalls, pull the starter
cord 3 –4 times again.
When finished, push the ON/OFF
switch to ‘OFF’.

Hedge Trimmer - HTX620
4
Trimming Techniques
To trim your hedge in a straight line, try using string. Stretch a piece of string along the hedge at the
appropriate height. Trim the hedge just above this guide line of string.
Do not try to trim hedges which are above your normal reach. You must hold the trimmer with both hands at
all times while operating.
Trim the side of a hedge so that it will be slightly narrower at the top. More of the hedge will be exposed
when shaped this way and its growth will be more uniform.
When trimming new growth, use a wide, sweeping action so that the stems are fed directly into the cutter
blade. Older growth will have thicker stems and will be trimmed easiest by using a sawing movement.
Do not try to cut stems that are larger than 3/8 inch which will be too thick and too large to feed into the
cutter blade. Use a non-powered hand saw or pruning saw to cut the larger stems.
Maintenance
Below are some general maintenance instructions. If you need further information, please contact the
manufacturer.
Daily Maintenance
Clean the outside of the trimmer.
Check that the stop switch functions.
Clean the air filter. Replace if necessary.
Check guards for damage and ensure that they are not cracked. Replace the guards if they gave been
exposed to impact or are cracked.
Check that the trimmer blade is undamaged and not cracked. Replace the trimmer blade if necessary.
Check that all nuts and screws are tightened.

Hedge Trimmer - HTX620
5
Weekly Maintenance
Check the starter, the starter cord and the return spring.
Make sure that the vibration damping elements are not damaged.
Clean the outside of the spark plug. Remove and check the electrode gap. Adjust the gap to 0.5 mm or
change the spark plug.
Clean the cooling fins on the flywheel.
Clean or replace the spark arrest screen on the silencer.
Clean the carburettor area.
Clean the cooling fins on the cylinder and check that the air intake in the starter unit is not blocked.
Clean the air filter.
Monthly Maintenance
Clean the fuel tank using petrol.
Clean the carburettor and the area surrounding it.
Check the fuel filter and the fuel pipe, replace if necessary.
Check all cables and connections.
Change the spark plug.
If there is any abnormality of the machine, stop operation immediately and check the machine carefully.
If necessary, have the machine serviced by Edisons. Never continue to operate a machine which may be
malfunctioning.
Make periodic inspections to assure safe and efficient operation.
Specifications
Engine Type
Petrol EURO 2 - Two Stroke Commercial
Maximum Power
1Hp
Displacement
26cc
Maximum Engine Speed
9,000 RPM
Transmission
Centrifugal clutch
Fuel Tank Capacity
500mL
Fuel Mix
25:1 (25 parts fuel to 1 part two stroke oil)
Fuel Type
Regular Unleaded 95 +RON
Blade Length
24" / 600mm
Maximum Cutting Capacity
20mm
Blades Material
Ultra-Hardened Knife Steel
Weight
5 kg.
Dual Weighted Crank / Double Ringed Piston

Some experts believe the incorrect or prolonged use of almost any
product could causeserious injury or death. For information that
may reduce your risk of serious injury or death consult thepoints
below and additionally, the information available at
www.datastreamserver.com/safety
- Consult all documentation, packaging and
product labelling be fore use. Note that some
products feature online documentation which
should be printed and kept with the product.
- Check product for loose / broken / damaged /
missing parts, wear or leaks (if applicable) be fore
each use. Never use a product with loose / broken
/ damaged / missing parts, wear or leaks (if
applicable).
- Products must be inspected and serviced (if
applicable) by a qualified specialist every 6
months assuming average residential use by a
person of average weight and strength, ab ove
average technical aptitud e, on a property
matching average metropolitan specification.
Intended use outside these guidelines could
indicate the product is not suitable for intended
use or may require more regular inspection or
servicing.
- Ensure all possible users of the p roduct have
completed an industry recognised training course
before being given access to the product.
- The product has been supplied by a general merchandise
retailer that may not be familiar with your specific applic ation or
your description of the application. Be sure to attain third party
approval for your application from a qualified specialist before use
regardless of prior assurances by the retailer or its representatives.
- This product is not intended for use where fail-safe operation is
required. As with any product (take an au tomobile, aircraft,
computer or ball point pen for example) there is always a small
chance of a technical issue that needs to be repaired or may
require replacement of the product or a part. If the possibility of
such failure and the associated time it takes to rectify could in any
situation inconvenience the user, business or employee or could
financially affect the user, business or employee then the product
is not suitable for your requirements. This p roduct is not for use
where incorrect operation or a failure of any kind, including but
not limited to a condition requiring product return, replacement,
service by a technician or replacement of parts could cause a
financial loss, loss of employee time or an in convenience
requiring compensation.
- If this item has been purchased in error considering the points
above simply contact the retailer directly for details of their
returns policies if required.
