MTS Systems D808 PRO User manual

User manual
808nm Diode Laser Hair Removal Machine
D808 PRO

CONTENTS
1. Introduction
2. Security
3. System Installation
4. Machine operation
5. Treatment considerations
6. Maintenance
7. Technical description
8. Environmental protection

Limited liability guarantee
The company guarantees free repairs for products lacking workmanship during the
warranty period. During the warranty period, the company or its authorized
personnel will be responsible for maintenance and replacement of any products
found to be defective after inspection.
The warranty does not cover the following：
(a) Accidents caused by improper use and improper handling that have not been
carried out in accordance with the operating instructions.
(b)The machine has been repaired or improved by non-authorized personnel.
36 months warranty.
The machine is guaranteed within 36 months from the date of shipment. Among
them, the circuit board, touch screen, and related accessories are covered by the
warranty, but consumable items such as cooling water filters, fuses, etc. are not
covered by the warranty.
If you use parts not manufactured by our company or repaired not by our company
employees, it is not covered by our company's warranty. In addition, if
inappropriate materials or improper repairs are used, the performance of the
machine may be affected, which may violate medical device management
regulations. Relevant problems during use, please contact our company in time.
Precautions
1. Read the manual carefully before operation to understand the safety
requirements and operation process

2. Read the chapters under the logo such as before operating the machine.
3. Harmful radiation may be produced if it is not used or adjusted according
to the instructions.
4. Guidance and manufacturer's declaration: electromagnetic radiation and
resistance to electromagnetic interference.
808 Diode Laser Hair Removal System User Manual
Ⅰ.Introduction
Equipment description
808 diode laser hair removal technology is the standard in the field of laser hair removal, the
wavelength is longer than ruby laser (wavelength 694nm) and emerald laser (755nm)，But
shorter than long pulse (wavelength 1064nm). It can penetrate deeper into the skin than short
wavelengths and safer，so it can better avoid pigmentation on the skin surface. The wavelength
of the semiconductor laser can penetrate into the hair follicles and does not damage the skin
surface like ruby and alexandrine. This allows semiconductor lasers to be used to treat darker
skin.
The 808 semiconductor laser hair removal machine uses the latest painless hair removal
technology, which can reach a frequency of 10HZ and is used to treat various skins without pain.
Advantages of 808 diode laser hair removal machine
A. Painless and comfortable: Continue to move the hand tool during treatment to make the
temperature rise slowly, the energy transmission is even and the patient feels comfortable.
B. Applied to various skin types: its average power is high, but its energy density is low and
frequency is high, so it can be safely applied to hair removal treatment of various skin types.
C. Short treatment time: only 15-20 minutes to treat the back and legs

D. Scope of application: Hair removal: armpits, limbs, back chest, bikini line, face, upper lip and
chin; Skin rejuvenation: Reducing pores, whitening skin
Technical Parameters
Laser type: Diode laser
power: 600w
Wavelength：808nm 1064nm 755nm
Spot Site（mm）:12mmx12mm
Frequency：1-10Hz
Pulse width：50-500ms
Energy（max）：128J
Cooling：1--4℃
Power supply：110VAC/220VAC,50/60Hz
Ⅱ.Security
Motor classification
Protection against electric shock: Type I, Type B
Protection level against liquid: ordinary equipment
Operating mode: intermittent and continuous
Not suitable for environments with flammable objects.
Operating requirements
Before operating the system, you must read this manual carefully to be
familiar with all the safety requirements and operating procedures
The operation must be carried out in accordance with the regulations:
1. Familiar with the operation process
2. Have correct control procedures and understand warning signs

3. Understand the accident report
4. Understand the biological response of laser injury
● When the machine is not in use, it must be powered off. Remove the key
after the operation is completed, and keep the key properly, and prohibit
non-operators from using the machine.
Energy absorption increases the temperature of the material, so do not
work in the environment with flammable objects
Keep the surface of the machine clean and clean the machine properly
before operation
● If cleaned or disinfected with alcohol, make sure to air dry before
operation
Optical security
This system is the first type of laser product and has a mark on the laser
radiation port of the hand tool.
When operating the equipment, the operator should wear protective
glasses, and the patient should also be under protection.
Do not look directly at the laser radiation port, even if wearing protective
glasses.
Excessive laser energy will cause thermal damage to the skin, so please
operate the device in accordance with the instructions.
Make sure that all trained personnel have a familiar understanding of
equipment control and how to shut down the equipment in time.
When not using the device, make sure that the hand tool is always on
the hook of the device. When using the device for treatment, direct the

laser exit of the hand tool directly at the treatment site.
Electrical and mechanical safety
Please turn off the equipment and disconnect the power when
performing maintenance.
It is best not to move frequently.
This equipment is connected to the ground through the ground wire in
the power cord. This grounding device is very necessary in safe
operation.
High voltage will be generated inside the device. Even if the power is off, there is
still electricity on some parts. Therefore, please cover all housings. Except the
manufacturer and its authorized maintenance personnel, no one should
disassemble the casing, otherwise it may cause electric shock.
Equipment buttons
The key of this device can be turned on, and it can only be removed
when the key switch is turned off.
No matter the machine is in any state, only press the red emergency
stop switch, the machine will immediately shut down.
The interlock switch must be connected to the machine, otherwise the
system cannot work normally.
Treatment safety
To ensure the safety of patients, well-trained personnel prioritize a comprehensive

understanding of the patient’s medical history before treatment. And sign a
treatment agreement with the patient, telling them the possible results and dangers
during the treatment process.
Fire Safety
The absorption of light energy will increase the temperature of the
absorbing substance. Do not use the device in an environment with
flammable substances.
Keep the surface of the device clean, and use a suitable detergent to
clean it before operation.
If alcohol is used for cleaning and disinfection, be sure to operate the
device when it is completely dry
Ⅲ. Equipment installation
Packing List
Equipment: 1 set
Protective glasses: 1 pcs
Goggles: 1 pcs
Power line: 1 pcs
Handle: 1 pcs
Funnel: 1 pcs (Watering tools)
Installation and operation preparation

A、Emergency Switch E、Water injection hole
B、Key Switch F、Power Switch
C、Handle G、Power line interface
D、Handle hanger H、Overflow hole
I、Drain hole

Follow the steps below to complete the installation：
Unpack the device
Check the equipment and all accessories for damage
First install the handle hanger, then install the handle, and then add water
Turn off the nut of Water injection hole, insert the water funnel into the
Water injection hole and add distilled water or pure water (it is
recommended to add frozen water in summer), if it is added to the
overflow, there is water overflow, indicating that the water tank is full
Unscrew the overflow nut before adding water, pull out the funnel after
filling, and do not cover the filling nut. Keep the air flow of the water tank
smooth
Plug the power cord into the corresponding power socket
Check all the steps to ensure correct connection, and then turn on
Environmental and input power requirements
Input voltage: 220V/50Hz, 110V/60Hz
Corrosive substances can damage electrical components, so use the
device in a non-corrosive environment
Metal dust can damage electrical components, and particulate dust
absorbs light and heat. Therefore, particulate dust should be reduced to
a minimum
In order to achieve the best equipment use effect, the room temperature should be

maintained between 20°C -25°C (68°F-77°F), the corresponding humidity is not
less than 80%
Do not store equipment with water below 2°C (35°F)
Device movement
Turn off the device before moving, pull out the key and power cord
If the moving distance is far, please drain all the water in the equipment
Hang your hand in the hook position
Because the device is vertical, please ensure that the device is in a
balanced state when moving. When moving a long distance, it is
recommended to use a cart to move the device
When moving, never tilt the device
When moving the device, do not push or pull hard, you should try to lift
the device
Ⅳ、Machine operation
Turn on/Turn off
Machine switch
1. Before starting up, check the connection between the system power cord and
the device and the connection of the main power supply
2. Hand radiation laser, everyone in the treatment room must wear protective
glasses
3. Hand radiation laser, everyone in the treatment room must wear protective glasses
4. Even wearing protective glasses is not allowed to look directly at the light exit
5. Except for the treatment area, the treatment head is not allowed to point directly at any other

part
Connect the power line
Turn on the power switch
Turn on the emergency stop switch
Use the key to turn on the instrument
Operation interface
Selection
Skin selection interface: six kinds of skin selection

Extension button：
hair color selection：

working interface
Cooling level : Cooling regulation （1-4）

Click the Cooling level button to display: select the cooling intensity level
1-4
Current: Energy output regulation（10-50）
Frequence: Frequency adjustment (number of light emission per
second)（1Hz-10Hz）
1Hz: Pulse width range is（10ms-500ms）
2Hz: Pulse width range is（10ms-250ms）
3Hz: Pulse width range is（10-160ms）
4Hz: Pulse width range is（10-120ms）
5Hz: Pulse width range is（10-100ms）
6Hz: Pulse width range is（10-80ms）
7Hz: Pulse width range is（10-70ms）
8Hz: Pulse width range is（10-60ms）
9Hz、10Hz: Pulse width range is（10-50ms）
Pulse duration: Pulse width adjustment
Count display：
Current counter: Current usage count
Total counter: Accumulated count of all operations
Water flow and temperature display：

Flow: Water flow detection
Temperature：Temperature detection
Working and pause selection button
.
READY: Ready to work
STANDBY：Pause to work
Appears when the READY button is pressed
Appears when the STANDBY button is pressed
When pressing the READY button, press the handle switch to start
shot
Alarm display：
Display the following content in the prompt box：
Temperature: Turn red and flashing (alarm when the water
temperature is higher than 30 degrees)
Flow :Turn Red and flashing (alarm when the water flow is
below 2)
5. Setting Interface
Press System setting：Enter the setting interface
Ⅴ、Treatment considerations

Contraindications：
The following symptoms cannot be treated with laser：
Malignant or diseased pigment;
Light sensitive skin;
Pregnant
Use of non-coagulating drugs;
Scar constitution;
Bacterial infectious diseases;
Defects in the immune system;
scleroderma;
diabetes;
Other diseases that cannot be used for laser treatment
Preparation before treatment：
1.Establish customer information files
2.Exclude patients with the above contraindications；
3.Determine why the patient seeks treatment and its expectations, and
tell the patient the course of treatment, treatment results, possible
side effects and discomfort;
4.Inform patients of safety matters that should be noted;
note:
When treating the eye socket area, use an eyelid plate to protect the
eyeballs. Use 0.5% tetracaine for topical anesthesia and lubricate the
eyelid plate to avoid corneal infection. Physicians and assistants should

wear protective glasses。
Do not wear reflective accessories such as watches, necklaces, bracelets,
etc.
There should be warning signs in the treatment room and no entry
Treatment parameters
Choosing the right treatment parameters is very necessary for
successful treatment. The optimal pulse width allows effective
thermotherapy with minimal skin damage.
Note：
Generally, treatment is performed from a lower setting parameter,
and energy is gradually increased to avoid side effects.
When treating light photoaging skin, the parameter selection and
scar treatment are similar, you can refer to the Patrick classification
of skin type.
I - Burns, no sun exposure (pale skin)
II – Easy to burn, minimum sun exposure (white skin)
III -Moderate burns, even sun exposure (light brown skin)
IV – Minimal burns, good sun exposure (medium brown skin)
V - Not easy to burn, easy to sun (dark brown skin)
VI –No burns (black)
In addition, the lighter the skin color, the more energy should be
used.
Matters after treatment:

After treatment, it is recommended to apply cold compress to the
treatment area but not ice.
It is best not to expose the skin to sunlight for two weeks after
treatment.
The skin may become red or erythema after treatment, but these
symptoms will disappear within six months.
After treatment, blisters or skin ulcers appear, which can be treated
with antibiotics or burn ointment.
Two weeks after treatment, it is recommended to use two to four
weeks of hydroquinone (2-5%) and hydrocortisone ointment (1%).
For patients with skin type III or IV, pigmentation may appear within
two to four weeks after treatment, but it can disappear within three
months.
Ⅵ、Daily maintenance
Machine cleaning
Warning:
1.The circulating cooling water of this equipment must be distilled water, and
the circulating water must be replaced within one to three months
2.The machine should be cleaned at least once a week. Turn off the machine and wipe
the surface of the machine. Take care to avoid liquids flowing into the machine。
3.Before and after each treatment, disinfect the tools used by the patient
and the operator, such as hand tools and protective glasses.

4.When disinfecting the machine, you can use 70% medical alcohol or
related disinfection methods.
5.Clean the light emitting port on the front of the handle after each
operation
Ⅶ、Technical Description
Label
Laser treatment instrument
Electric shock protection：Class I, Type B
Resistance to humidity: ordinary equipment
Avoid contact with combustible substances
Operation mode: continuous
First class laser products
Ⅷ、Environmental protection
We have taken environmental requirements into consideration
during system design, and all non-toxic and safe raw materials are
used in production. After the system is scrapped, classify the system
correctly according to local laws and regulations, and then treat it as
waste.
808nm diode laser machine
Clinical basics
Ⅰ、The principle of treatment
