MUBEA SYSTEME BULLDOG 65 User manual

BULLDOG 65 Hydraulic Steelworker
Name and Addres:
MUBEA SYSTEME
E XPORT D EPARTMENT
H OGESCHUURSTRAAT 2
B-8850 ARDOOIE
B ELGIUM
_______________________
MUBEA SYSTEME Gmbh
Viersenerstraße 3
D-47929 GREFRATH
Germany
Year of Manufacture: ..........................
Model Type: BULLDOG 65 HYDRAULIC STEELWORKER
Serial Number: ........................................
(Note: last 2 digits represent year of manufacture)
Weight of Machine: 2375 lb NETT

BULLDOG 65 Hydraulic Steelworker
MUBEA SYSTEME BULLDOG 65 HYDRAULIC STEELWORKER
This MUBEA SYSTEME Steelworker has been developed to give you, the
user, a reliable long service - low maintenance machine tool.
These machines are capable of performing five basic functions, with the
facility to add various additional tooling arrangements to complement
the fully universal aspects of the Steelworker.
These instructions give general guide lines for the use of the Steelworker,
commissioning, operating and maintenance, and should be carefully studied
by the installation engineer and operator before the machine is put into
operation.
Any assistance regarding the machines, should first be sought from the
supplier or agent:
MUBEA SYSTEME
PINNEY
MACHINERY & SUPPLY, INC.
_________________________________________________
7053 PRODUCTION COURT - FLORENCE, KY 41042
PHONE [phone] FAX [phone]
TOLL FREE 800-255-5698

BULLDOG 65 Hydraulic Steelworker
I
INDEX
1 SAFETY NOTES FOR MUBEA SYSTEME STEELWORKERS 1
2 BRIEF SPECIFICATIONS 2
2.1 M EASUREMENTS 2
2.2 C APACITIES 2
2.3 S TANDARD E QUIPMENT SUPPLIED WITH M ACHINE 2
3 BRIEF DESCRIPTION OF MACHINE 4
3.1 P UNCHING 4
3.2 S HEARING 4
3.3 A NGLE C UTTING 4
3.4 S ECTION C UTTING 4
3.5 N OTCHING 4
3.6 F URTHER I NFORMATION 5
3.7 S AFETY P OINTS 6
3.8 O VERLOADING 6
3.9 W ARNINGS AND D ANGERS 6
3.10 O PERATING M ODE S WITCH 7
4 PUNCHING WORK STATION 8
4.1 G ENERAL D ESCRIPTION 8
4.2 P UNCH T OOLING 9
4.3 P UNCH T OOLING - G ENERAL G UIDES 9
4.4 P UNCH AND D IE L UBRICATION 10
4.5 P UNCHING CAPACITY 11
4.6 B AR B ENDING F ACILITY AT P UNCHING S TATION 13
4.7 S TANDARD P UNCH T OOLING 14
4.8 T YPICAL A PPLICATIONS 16
4.9 F LANGE P UNCHING 16
5 SHEARING STATION 17
5.1 D ESCRIPTION 17
5.2 S HEAR T OOLING - G ENERAL G UIDES 17
5.3 S HEAR B LADES 18
6 ANGLE CUTTING 19
6.1 D ESCRIPTION 19
6.2 A NGLE T OOLING - G ENERAL G UIDES 20
6.3 G RINDING OF C HANNEL I NSERT B LADES 21
6.4 G RINDING OF J OIST I NSERT B LADE 22

BULLDOG 65 Hydraulic Steelworker
II
7 SECTION CUTTING 23
7.1 D ESCRIPTION 23
7.2 S ECTION T OOLING - G ENERAL G UIDES 24
8 NOTCHING STATION 25
8.1 D ESCRIPTION 25
8.2 N OTCHING T OOLING - G ENERAL G UIDES 25
8.3 R ECTANGULAR N OTCH T OOLING A RRANGEMENT 26
9 FURTHER INFORMATION 27
9.1 C APACITIES 27
9.2 S PECIFICATION 28
9.3 A DDITIONAL T OOLING 28
9.4 S TROKE A DJUSTMENT 29
9.5 H YDRAULIC S YSTEM 30
9.6 C LEANING 30
9.7 R EGULAR M AINTENANCE 30
9.8 H YDRAULIC F LUID 31
9.9 O ILING L UBRICANT 31
9.10 M ACHINE A RM A DJUSTMENT 32
9.11 P ARTS L IST 33
10 CIRCUITS 36
10.1 H YDRAULIC C IRCUIT 36
10.2 E LECTRICAL C IRCUIT 38
11 SPECIAL TOOLING 39
11.1 90° V EE N OTCH TOOLING ARRANGEMENT 39
11.2 W EB P UNCHING ARRANGEMENT FOR ‘I’ & ‘U’ S ECTIONS 39
11.3 L ARGE H OLE P UNCHING 40
11.4 B AR B ENDING U NIT 41
12 MANUAL APPENDIX 42
12.1 M ITRING ANGLE 45 DEGREES ON BULLDOG MACHINES 42

BULLDOG 65 Hydraulic Steelworker
1
1
11
1SAFETY NOTES FOR MUB
SAFETY NOTES FOR MUBSAFETY NOTES FOR MUB
SAFETY NOTES FOR MUBEA SYSTEME STEELWORK
EA SYSTEME STEELWORKEA SYSTEME STEELWORK
EA SYSTEME STEELWORKERS
ERSERS
ERS
In this manual particular references are made regarding aspects of safety and the notes below
are intended as a summary to highlight the main areas for your attention.
The machine should be positioned so that the operator has sufficient room to work having
regard for the long lengths of material which may be punched or cropped. Electrical supply
should be by overhead cable to avoid possible damage.
It should be considered if additional equipment will be required to safely handle long or heavy
items being processed.
Any person who will use the machine should be given adequate instruction on the operation
and safety aspects of the machine. Extra copies of this manual are available from the
manufacturer.
In addition it should be established which persons shall be responsible for the changing and
setting of tools and blades and these persons given a more detailed instruction.
Mubea Systeme machines are supplied complete with various guards and barriers as standard
equipment which provide a generally accepted level of guarding when the machine is used for
the purpose for which it was designed.
1. The main areas of deviation from design criteria would probably be:
2. The use of materials other than mild steel (65.000lbs.)
3. The incorrect use of material hold-downs
4. The punching, cropping or notching of small items
(as this would encourage the operator place fingers or hands into danger area).
If at any time additional tooling or equipment is fitted to the machine the question of adequate
guarding must be reviewed and the advice of the manufacturer sought if necessary.
All maintenance should be carried out by suitably qualified personnel and particular attention
must be paid to the correct setting and alignment of punches and dies, blades and other tools.

BULLDOG 65 Hydraulic Steelworker
2
2
22
2BRIEF SPECIFICATIONS
BRIEF SPECIFICATIONSBRIEF SPECIFICATIONS
BRIEF SPECIFICATIONS
The machine has been developed to perform five basic functions:
Punching, Flat Bar Shearing, Notching, Angle and Section Cutting.
2.1
2.12.1
2.1 M
MM
M EASUREMENTS
EASUREMENTSEASUREMENTS
EASUREMENTS (Full details, see page 26-27.)
Length x Width x Height 59 1/2 ’’ x 23 1/4 ’’ x 62’’ (+ 4“ lifting eye)
Die Height from floor 37’’
Shear Support from floor 37’’
Angle Support from floor 44 3/4 ’’
Notch Height from floor 37’’
2.2
2.22.2
2.2 C
CC
C APACITIES
APACITIESAPACITIES
APACITIES (Full details, see page 26-27.)
Punching 1 1/4 ’ x 15/32 ’’ or 1 1/16 x 5/8 ’’
Shearing 8 x 3/4 ’’ or 12 x 5/8 ’’
Angle Cutting 4 3/4 ’’ x 1/2 ’’, 5 1/8 ’’ x 1/2 ’’ with modified blade
Section Cutting 1 9/16 ’’ Round, 1 3/8 ’’ Square
Notching 3/8 ’’ Thickness
(All capacities are based on materials of 65.000 lbs. Tensile Strength.)
Punch Pressure 65 Tons
2.3
2.32.3
2.3 S
SS
S TANDARD
TANDARD TANDARD
TANDARD E
EE
E QUIPMENT SUPPLIED WI
QUIPMENT SUPPLIED WIQUIPMENT SUPPLIED WI
QUIPMENT SUPPLIED WITH
TH TH
TH M
MM
M ACHINE
ACHINEACHINE
ACHINE
Punch Bolster BULLDOG 65-319
Shear Blade (1 set mounted) 3409 & 3309
Angle Blades (1 set mounted) 3549 & 3550 (Arm), 3548 & 3547 (Body)
Section Blades (1 pair mounted) 3427 & 3428
Notch Punch & Dies (1 set mounted) Punch H1 ∅9/16’’ and die H1 ∅19/32’’
Notch Bolster 3315

BULLDOG 65 Hydraulic Steelworker
3
•
•Tool Kit co prisi
Tool Kit co prisiTool Kit co prisi
Tool Kit co prising
ngng
ng:
•Allen Key 4, 5, 6, 8, 10, 12, 14, 17mm
•19 and 24mm Open-Ended Spanner

BULLDOG 65 Hydraulic Steelworker
4
3
33
3BRIEF DESCRIPTION OF
BRIEF DESCRIPTION OFBRIEF DESCRIPTION OF
BRIEF DESCRIPTION OF MACHINE
MACHINE MACHINE
MACHINE
3.1
3.13.1
3.1 P
PP
P UNCHING
UNCHINGUNCHING
UNCHING (For details see pages 8-15)
The punching unit is fitted with a quick-change device for punches and dies. Changes are
made quickly and without a problem, and require no additional devices.
3.2
3.23.2
3.2 S
SS
S HEARING
HEARINGHEARING
HEARING (For details see page 16-17)
The shearing unit is fitted with a simple robust hold-down which is adjustable to any thickness
of material within the cutting capacity of the machine. A shear feed table with adjustable
guides is fitted to allow the accurate feeding of materials. The guide can be adjusted to allow
mitre cutting up to 45 degrees for flat bars or to trim the flanges of angle sections previously
cut at the angle cutting station.
3.3
3.33.3
3.3 A
AA
A NGLE
NGLENGLE
NGLE C
CC
C UTTING
UTTINGUTTING
UTTING (For details see page 18-21)
This station provides large capacity angle cutting at 90 degrees and lighter angle cutting at 45
degrees. Angles between 45 and 90 degrees can be achieved by first cutting at 90 degrees and
then flange trimming to the required angle in the shearing station.
The hold-down supports the material thus ensuring a true cut.
3.4
3.43.4
3.4 S
SS
S ECTION
ECTION ECTION
ECTION C
CC
C UTTING
UTTINGUTTING
UTTING (For details see pages 22-23)
The machines are fitted as standard with blades for cutting round and square bars. With extra
equipment, the machines are able to cut, in this aperture, Channels, Joists and Tee Sections.
The blades are retained by simple clamps, allowing easy changes without the need for
elaborate setting.
3.5
3.53.5
3.5 N
NN
N OTCHING
OTCHINGOTCHING
OTCHING (For details see page 24-25)
The notching station is fitted as standard with a rectangular unit and notch table with
adjustable back stops allowing repetitive positioning. Extra equipment is available for narrow
widths or vee notching of angles up to 90 degrees vee; units are also available for bar end
shaping applications.

BULLDOG 65 Hydraulic Steelworker
5
3.6
3.63.6
3.6 F
FF
F URTHER
URTHER URTHER
URTHER I
II
I NFORMATION
NFORMATIONNFORMATION
NFORMATION
3.6.1 System Pressure
To check any operational loadings, a pressure gauge can be fitted at the manifold position.
The max. system pressure has been set at the works to 234 bar (3500 P. S. I.) which is below
the max. continuous working pressure of the pump, thereby giving increased reliability.
3.6.2 Cleaning
On arrival, all anti-corrosion lacquer should be removed from the machined bright parts with
petroleum solvent. When the machine is operational, all visible working parts should be
regularly cleaned of foreign matter, thus preventing excessive wear and possible failure.
3.6.3 Lifting
The machine is supplied with a lifting eye, mounted on top of the machine. All lifting and
manoeuvring should be carried out using this eye along with a suitably rated chain or sling.
The eye can be removed if desired after final siting of the machine but hole should be blanked
off.
DO NOT USE SLINGS UNDER MACHINE!
3.6.4 Installing
Locate the machine on a solid foundation allowing sufficient area all round for easy working
and maintenance. The machine may be used free standing, but bolting to the foundation is
recommended. With the machine mounted directly on the floor - this gives a comfortable
working height.
3.6.5 Electrical Supply
Input wires should arrive at the machine via suitably protected underground supply directly
into the electrics box in the base of the machine. As an alternative by overhead supply to the
top of the machine and routed inside the top guard and hydraulic pipe trunking to the electrics
box. A 30 amp isolating switch, fuse and appropriate cable should be used for mains supply
connection. The circuit provides protection against sustained over-load and phase failure.
Should the machine cut out during an operation or whilst running, the cause of the problem
should be investigated to prevent re-occurrence.
IMPORTANT
Motor rotation MUST be as arrow on motor fan end cover!
This machine will not operate if the motor is running in the wrong direction. It must be
stressed however that the motor must not be allowed to run in the wrong direction for
more than a few seconds, as this will cause seizure of the pump. To check motor
direction start and stop motor with foot on footswitch if machine does not operate
reverse two of the incoming 3 phase connections.

BULLDOG 65 Hydraulic Steelworker
6
3.7
3.73.7
3.7 S
SS
S AFETY
AFETY AFETY
AFETY P
PP
P OINTS
OINTSOINTS
OINTS
•All adjustments, setting, change of tooling and maintenance must be carried out by a
suitable qualified engineer in accordance with the manufacturers instructions.
•Remove off-cuts, slugs and any other waste from around the machine before leaving the
work station.
•The operator should check all tooling is in good condition before operating machine.
•All stations should be checked for obstructions.
•Heavy work should be supported by a sound work steady.
•The machine should never be left running while unattended.
•When leaving, the machine MUST be switched off.
3.8
3.83.8
3.8 O
OO
O VERLOADING
VERLOADINGVERLOADING
VERLOADING
In the event of an accidental overload to the hydraulic circuit, the oil will be diverted direct
back to the tank via a relief valve, until the overload condition is removed.
IT MUST BE STRESSED HOWEVER IT IS NOT ADVISABLE TO EXCEED THE
CAPACITY OF THE MACHINE USING RELIEF VALVE AS A SAFETY VALVE.
3.9
3.93.9
3.9 W
WW
W ARNINGS AND
ARNINGS AND ARNINGS AND
ARNINGS AND D
DD
D ANGERS
ANGERSANGERS
ANGERS
Any point of the machine painted RED should be treated as a danger area. Operators should
be instructed not to extend any finger or limbs into or beyond the vicinity of the warning
labels. Any guards or hold downs removed for maintenance or adjustments MUST be replaced
before the machine is put back in service.

BULLDOG 65 Hydraulic Steelworker
7
3.10
3.103.10
3.10 O
OO
O PERATING
PERATING PERATING
PERATING M
MM
M ODE
ODE ODE
ODE S
SS
S WITCH
WITCHWITCH
WITCH
The Operating Mode Switch has two positions - NORMAL and INCH. With
the switch set to INCH all work stations are in the slow speed Inching Mode.
3.10.1 Inching Positon
In Inching position the arm will travel down slowly when footswitch is fully depressed. The
arm will remain in any position when foot is removed. Turn switch to NORMAL to return
arm to top of stroke. All tool setting and adjusting and setting of stroke limit switches should
be done in the Inching position.
3.10.2 Normal Operating
With Selector Switch to NORMAL the arm will travel down at operating speed when
footswitch is fully depressed and will return to top of stroke when foot is completely removed.
The footswitch does however have three “positions” giving the very useful facility that after
bringing the arm down by full depression of switch, the arm may be held in any position of the
stroke by raising the foot to the mid-position. Remove foot and arm will return to top position.
3.10.3 Punch and Die Alignment
Should be checked before using, and MUST be checked after punch and die changes have
been made.
To check alignment switch mode of operation INCH, then inch the punch
down by fully depressing the footswitch. Care must be taken as the punch
approaches the die, if misalignment is apparent remove foot from switch.
To align punch and die release bolster fixing screws, operate the foot switch with care,
aligning the bolster containing the die to the punch, the punch will stay in the down position.
Centralise the die clearance around the punch, clamp the bolster in position, tighten die
retaining screw, check die maintains in the central position after clamping. Return punch to
top position by switching back to run position.
NORMAL INCH
NORMAL INCH

BULLDOG 65 Hydraulic Steelworker
8
4
44
4PUNCHING WORK STATIO
PUNCHING WORK STATIOPUNCHING WORK STATIO
PUNCHING WORK STATION
NN
N
4.1
4.14.1
4.1 G
GG
G ENERAL
ENERAL ENERAL
ENERAL D
DD
D ESCRI
ESCRIESCRI
ESCRIPTION
PTIONPTION
PTION
The punch station is a particular well equipped station. It offers many features normally
associated with much larger machines.
The large punch bed area is designed to give a very wide range of punching applications,
including overhang work in small channel sections. The punch table is particularly useful
when the side and back stops are set for small repetetive work. This coupled with a finely
adjusted stroke length gives a very productive machine. The table is assembled in two parts of
which the front is removable for flange punching.
The punch is retained by means of a quick-change device. Changes are quikly and without
problem and require no additional devices. The die is retained in the bolster by a set screw,
ensure the screw locates correctly on the machined flat on the die when shaped punches and
dies are being aligned.
The punch stripper plate must be correctly adjusted allowing sufficient clearance for placing
and removal of material, but must NOT restrict the punch stroke, ensure the bottom stroke
limit switch is correctly adjusted. Punch holes with sufficient material around the hole so that
contact will be made on both sides of the stripper plate. Stripping forces can be severe and
unbalanced stripping forces, due to contact on one side stripper, may cause punch breakages.
When using stripper fingers for oversize holes or irregular shapes position and adjust fingers
equally so as to avoid unbalanced stripping loads.
Additional tooling in this versatile work station can provide bar bending, corner notching,
tube notching and general die-set work.
WHEN ORDERING REPLACEMENT PUNCHES AND DIES, ALWAYS
QUOTE - MODEL, TYPE AND SERIAL NUMBER OF MACHINE.

BULLDOG 65 Hydraulic Steelworker
9
4.2
4.24.2
4.2 P
PP
P UNCH
UNCH UNCH
UNCH T
TT
T OOLING
OOLINGOOLING
OOLING
The Punch and Die should be checked for alignment, prior to punching any material.
4.2.1 Tooling Changes
Punch: With quick-change device. No need of additional devices.
Die: To change die, slacken set screw in side of bolster, remove die and replace with new
die, retighten set screw.
After replacing punches and dies, it is important that they are correctly aligned. See page 6 for
alignment procedure under the heading ‘Safety Points’. Extra care must be taken when fitting
square or shaped punches that they are correctly aligned before operating machine.
4.3
4.34.3
4.3 P
PP
P UNCH
UNCH UNCH
UNCH T
TT
T OOLING
OOLING OOLING
OOLING -
--
- G
GG
G ENERAL
ENERAL ENERAL
ENERAL G
GG
G UIDE
UIDEUIDE
UIDES
SS
S
1. The punch stripper plate must be adjusted correctly with sufficient clearance to allow
positioning and removal of the material being punched.
2. Punch holes with sufficient material around the hole so contact is made on both sides of the
stripper plate. Stripping forces can be severe. Unbalanced stripping forces may cause punch
breakage.
3. Liberal oiling of the punch will considerably lengthen the life of the punch and die and also
help reduce the stripping forces.
4. The quality of the hole (or blank) is an immediate indication of the condition of the punch
and die.
5. Do not punch material thicker than the punch diameter, this overloads the punch and can
result in breakage.
6. Punch full and complete holes, do not punch partial holes unless tooling is specifically
designed to do so.
7. When punching small items (i.e. small pieces of plate, bar etc) these items MUST be places
and extracted with suitable handling aids, extra guarding may be required too ensure
operator safety.
8. Stay within the rated capacity of the machine.

BULLDOG 65 Hydraulic Steelworker
10
4.4
4.44.4
4.4 P
PP
P UNCH AND
UNCH AND UNCH AND
UNCH AND D
DD
D IE
IE IE
IE L
LL
L UBRICATION
UBRICATIONUBRICATION
UBRICATION
It is recommended that one of the following oils is applied by brush to the punch and die or
both sides of the material being punched.
SHELL - GARIA 927
B. P. - SERVORA 68
CASTROL - ILOBROACH 219
DUCKHAMS - ADFORNOL EP7
Die clearance: It is normal practice to aim for a clearance of 10% material thickness.
Whether clearance is added to the size of the die or deducted from the size of the punch,
depends on the nature of the work. When holes of a given size are required the punch is made
to size and the die is made larger. Conversely, when blanks of a given size are required the die
is made to size and the punch smaller.
Special clearance dies for thin sheet and plate punching, or size dies and special clearance
punches can be supplied to order.

BULLDOG 65 Hydraulic Steelworker
11
4.5
4.54.5
4.5 P
PP
P UNCHING CAPACITY
UNCHING CAPACITYUNCHING CAPACITY
UNCHING CAPACITY
The graph shows the punch capacity curves for the BULLDOG 65 and BULLDOG 50
machines. As an example it can be seen to punch material 15mm ( 5/8 ’’) thick, the maximum
diameter is 22mm ( 7/8 ’’) on the BULLDOG 50 and the maximum diameter on the BULLDOG
65 is 28mm (1 1/16 ). As an alternative it is possible to calculate a capacity by using the machine
constant. By dividing the machine constant by the material thickness will give the maximum
diameter through that thickness.
(1’’ = 25,4mm)
0
2
4
6
8
10
12
14
16
0 22 30 50 70 90
Max. Hole Diameter [mm]
Material Thickness [mm]
45XA
60XA
The machine constants are:
BULLDOG 50 330
BULLDOG 65 420
If you want to calculate the max. Material thickness / max. hole sizes use one of the following
formulars:
Constants / Material Thickness = max. Diameter
or:
Constants / Diameter = Max. Material Thickness
Note:

BULLDOG 65 Hydraulic Steelworker
12
All capacities are based on materials to be punched having a tensile strength of 45 kg/mm²
(65.000lbs). Always keep within the rated capacity of the machine and never attempt to punch
a hole smaller in diameter than the thickness of material being punched.

BULLDOG 65 Hydraulic Steelworker
13
1. Example:
You are going to work with a material of 10mm ( 3/8 ’’) thickness on a BULLDOG 65 machine.
The max. hole size is then calculated by:
420 / 10 = 42 [mm] ⇒The max. hole size is 42mm (1 5/8 ’’).
2. Example:
Your punch / die diameter is 26mm (1’’).
The max. material thickness you can punch is calculated by:
420 / 26 = 15,4 [mm] ⇒The max. material thickness is 15mm ( 3/5 ’’).
This system will proably prove to be convenient because when the machine capacity constant
has been memorised, no tables or graphs are required to establish max. diameters through a
known thickness of meterial.
Please Note: DANGEROUS PRACTICE:
DO NOT ATTEMPT TO PUNCH MATERIAL
THICKER THAN THE PUNCH DIAMETER!
4.6
4.64.6
4.6 B
BB
B AR
AR AR
AR B
BB
B ENDING
ENDING ENDING
ENDING F
FF
F ACILITY AT
ACILITY AT ACILITY AT
ACILITY AT P
PP
P UNCHING
UNCHING UNCHING
UNCHING S
SS
S TATION
TATIONTATION
TATION
Press Brake type tooling is available for fitting at the Punching Station giving press brake
capacity of 4’’ x 1/2 ’’.
IMPORTANT NOTICE - HEALTH & SAFETY AT WORK ACT, SECTION 6
Bending tools must not be fitted to this machine until adequate safety measures have been
implemented. It is normally permitted to use the bending tools without additional fixed
guarding provided the following steps have been taken:
1. The clearance between the top tool and the work piece is kept to a minimum and must not
exceed 6mm at any time.
2. The bending tool is set by a skilled and competent person.
3. A lockable cover has been fitted to prevent unauthorised alteration of limit switch.
The key should be retained by the setter.
Bending Tools are supplied with suitable cover and lock as standard.

BULLDOG 65 Hydraulic Steelworker
14
4.7
4.74.7
4.7 S
SS
S TANDARD
TANDARD TANDARD
TANDARD P
PP
P UNCH
UNCH UNCH
UNCH T
TT
T OOLING
OOLINGOOLING
OOLING

BULLDOG 65 Hydraulic Steelworker
15
In the following table you can find a list of the standard punch tooling of modell BULLDOG
65. It includes which equipment is supplied with the machine.
Other punches and dies are available on request. (see p 42)
piece Art.No. Discription
1 0164405901 Punch holder, complete with quick change
1 0164405902 Punch holder
4 9099123540 Socket head screw
1 9079802100 Lock washer
1 0502105904 Quick change fixture
1 5053411638 Punch ∅9/16’’
1 3335 Stripper top plate
1 2407 Stripper pillar
2 3336 Stripper head
1 5066021642 Die ∅19/32’’
2 2556 Bolster clamp
1 3319 Bolster
With the Standard Quick-change device, you can punch from1/8’’ up to 1 1/4’’
Extension of the punching range up to 1 9/16’’ ∅is possible (see page 39)

BULLDOG 65 Hydraulic Steelworker
16
4.8
4.84.8
4.8 T
TT
T YPICAL
YPICAL YPICAL
YPICAL A
AA
A PPLICATIONS
PPLICATIONSPPLICATIONS
PPLICATIONS
( achieved with special tooling at punch station )
4.9
4.94.9
4.9 F
FF
F LANGE
LANGE LANGE
LANGE P
PP
P UNCHING
UNCHINGUNCHING
UNCHING
The standard bolster (3319) can accomodate flange punching in small sections. To achieve the
correct back-mark it will be necessary to use an eccentric die so as to off-set the bolster.
The front portion of the punch table must be removed and the bolster re-positioned for flange
punching.
NORMAL FLANGE
PUNCHING ECCENTRIC FLANGE PUNCHING
