Mueller UltraStorm LB-570 User manual
USER MANUAL
Your satisfaction is guaranteed. If you are not completely satisfied
with our UltraStorm Cordless Leaf Blower the results it brings, we
insist that you let us know. We’ll help make the leaf blower work
for you, or we’ll refund your money.
UltraStorm
Cordless Leaf Blower
Model: LB-570
CONTENTS:
Technical Data
Intended Use
Important Safeguards
Important Safety Warnings & Instructions
General Safety Warnings & Instructions
Package Content List
Meet Your UltraStorm Cordless Leaf Blower
Using Your UltraStorm Cordless Leaf Blower
Before the First Use
Assembly Instructions
Operating Instructions
Cleaning and Care
Cleaning
Storage
Battery Maintenance
Charger Maintenance
Environmentally Safe Battery Disposal
1
pg 1
pg 1
pg 2
pg 2
pg 2
pg 5
pg 5
pg 6
pg 6
pg 6
pg 7
pg 9
pg 9
pg 9
pg 9
pg 10
pg 10
TECHNICAL DATA:
Motor voltage: 20V
Idle speed: 7000 rpm / 10500 rpm
Air velocity:
Setting 1: 90 mph / 145 km/h
Setting 2: 130 mph / 209 km/h
Rechargeable battery (Li-Ion):
Nominal voltage: 20V
Capacity: 2.0Ah
Charging time: 1h
Run-time:
Setting 1: max 30 min
Setting 2: max 15 min
Charger: 120V
Overall dimensions: 37.4 x 5.7 x 7in / 95 x 14.5 x 18cm
Weight: 3.3lbs / 1.5kg
INTENDED USE:
WARNING: This equipment is only intended for household use only. Any other
use not approved in this user manual may damage the equipment and cause
serious danger to the user or bystanders.
The operator or user is responsible for accidents or damage to other people
and their property caused by improper use or incorrect operation.
1
IMPORTANT SAFEGUARDS:
WARNING: TO REDUCE RISK OF INJURY:
Before use, be sure that anyone using this unit reads and understands all safety
instructions and other information contained in this manual.
Save these instructions and review frequently prior to use and for instructing others.
The appliance is not to be used by persons (including children) with reduced physi-
cal, sensory or mental capabilities, or lack of experience and knowledge unless they
have been given supervision or instruction.
Do not point the unit discharge at self or bystanders.
Keep long hair and loose clothing away from openings and moving parts.
WARNING: When using an electric tool, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and personal injury.
WARNING: Some dust created by this product contains chemicals known to the
State of California to cause cancer, birth defects, or other reproductive harm. Some
examples of these chemicals are:
compounds in fertilizers
compounds in insecticides, herbicides, and pesticides
arsenic and chromium from chemically treated lumber
To reduce your exposure to these chemicals, wear approved safety equipment such
as dust masks that are specifically designed to filter out microscopic particles.
IMPORTANT SAFETY WARNINGS & INSTRUCTIONS
GENERAL SAFETY WARNINGS & INSTRUCTIONS
WARNING: Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire, and/or
serious injury.
• To reduce the risk of electric shock, the battery charger has a polarized plug (one
blade is wider than the other) and will require the use of a polarized extension cord.
The plug will only fit into a polarized extension cord one way. If the plug does not fit
fully into the extension cord, reverse the plug. If the plug still does not fit, obtain a
correct polarized extension cord. A polarized extension cord will require the use of a
polarized wall outlet. This plug will only fit into the polarized wall outlet one way. If the
plug does not fit fully into the wall outlet, reverse the plug. If the plug still does not fit,
contact a qualified electrician to install the proper wall outlet. Do not change the equip-
ment plug, extension cord receptacle, or extension cord plug in any way.
2
• WEAR eye protection that is marked to comply with ANSI Z87.1 when operating this product.
• USE ONLY as described in this manual. Use only the manufacturer’s recommended
attachments.
• INSPECT THE AREA before using this leaf blower. Remove all debris and hard objects
such as rocks, glass, wire, etc., that can ricochet, be thrown, or otherwise cause injury
or damage during operation.
• KEEP CHILDREN, BYSTANDERS, AND ANIMALS AWAY from the work area a
minimum of 30 feet (10 meters) when starting or operating this appliance. Do not blow
debris in the directions of bystanders.
• DO NOT operate this unit when you are tired, ill, or under the influence of alcohol,
drugs, or medication.
• DO NOT operate in poor lighting.
• DO NOT allow to be used as a toy. Close attention is necessary when used by or near
children. Not recommended for use by children.
• DO NOT use with damaged cord or plug. If the appliance is not working as it should, has
been dropped, damaged, or dropped into water, contact MuellerGarden customer support.
• DO NOT put any objects into openings. Do not use with any opening blocked; keep
free of dust, lint, hair, and everything that may reduce airflow.
• KEEP hair, loose clothing, fingers, and all parts of the body away from openings and
moving parts.
• DO NOT place inlet or outlet of blower near eyes or ears when operating.
• DON’T OVERREACH. Keep proper footing and balance at all times.
• DO NOT blow anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• DO NOT operate blower in a gaseous or explosive atmosphere. Motors in these tools
may spark, and the sparks might ignite fumes.
• DO NOT use to blow flammable or combustible liquids such as gasoline or use in
areas where they may be present.
• USE EXTRA CARE when cleaning on stairs.
• NEVER immerse the motor part of the blower, battery, or charger in liquid.
• DO NOT unplug the charger by pulling on the cord. To unplug, grasp the plug, not the cord.
• DO NOT handle charger, including charger plug and charger terminals with wet hands.
• DO NOT charge the unit outdoors.
• MAINTAIN TOOL WITH CARE. Keep fan area clean for best and safest performance.
Follow instructions for proper maintenance.
• DO NOT attempt to clear clogs from the tool without first removing the battery.
• DO NOT attempt to repair the blower. To assure product safety and reliability, repairs,
maintenance, and adjustments should be performed by authorized service personnel.
• STORE IDLE TOOLS. When not in use, the unit should be stored in a dry, high, or
locked-up place - out of reach of children.
3
FOR BATTERY-OPERATED APPLIANCE:
• To prevent unintentional starting, ensure the switch is in the off-position before
connecting the battery to the motor unit. Carrying the appliance with your finger on the
switch or that has the switch on may cause accidents.
• Disconnect the battery from the motor unit before disassembling the blower tube, or
storing the appliance. Such preventive safety measures reduce the risk of starting the
appliance accidentally.
• Recharge only with the charger specified by the manufacturer. Using an unsuitable
charger creates a fire risk.
• When the battery is not in use, keep it away from other metal objects like paper clips,
coins, keys, nails, screws, or other small metal objects that may connect one terminal
to another.
• The charge of the battery will diminish, even when not used. We, therefore, recom-
mend regular charging, e.g. every four to six months.
• Shorting the battery terminals together may cause burns or a fire.
• Under extreme conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
• Do not use a battery or appliance that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of
injury.
• Do not expose the battery or appliance to fire or excessive temperature. Exposure to
fire or temperature above 140°F / 60°C may cause an explosion.
• Have servicing performed by a qualified repair person using only identical replace-
ment parts. This will ensure that the safety of the product is maintained.
CHILD SAFETY
Tragic accidents can occur if the operator is not aware of the presence of children.
• Keep children out of the working area and under the watchful care of a responsible
adult.
• Do not allow children under the age of 14 to operate this blower. Children who are 14
years of age and older must read and understand the operating instructions and safety
rules in this manual and must be trained and supervised by adult.
• Stay alert and turn the blower off if a child or any other person enters the working
area.
• Use extreme care when approaching blind corners, doorways, shrubs, trees, or other
objects that may obscure your view of a child who may run into the path of the blower.
4
• WEAR eye protection that is marked to comply with ANSI Z87.1 when operating this product.
• USE ONLY as described in this manual. Use only the manufacturer’s recommended
attachments.
• INSPECT THE AREA before using this leaf blower. Remove all debris and hard objects
such as rocks, glass, wire, etc., that can ricochet, be thrown, or otherwise cause injury
or damage during operation.
• KEEP CHILDREN, BYSTANDERS, AND ANIMALS AWAY from the work area a
minimum of 30 feet (10 meters) when starting or operating this appliance. Do not blow
debris in the directions of bystanders.
• DO NOT operate this unit when you are tired, ill, or under the influence of alcohol,
drugs, or medication.
• DO NOT operate in poor lighting.
• DO NOT allow to be used as a toy. Close attention is necessary when used by or near
children. Not recommended for use by children.
• DO NOT use with damaged cord or plug. If the appliance is not working as it should, has
been dropped, damaged, or dropped into water, contact MuellerGarden customer support.
• DO NOT put any objects into openings. Do not use with any opening blocked; keep
free of dust, lint, hair, and everything that may reduce airflow.
• KEEP hair, loose clothing, fingers, and all parts of the body away from openings and
moving parts.
• DO NOT place inlet or outlet of blower near eyes or ears when operating.
• DON’T OVERREACH. Keep proper footing and balance at all times.
• DO NOT blow anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• DO NOT operate blower in a gaseous or explosive atmosphere. Motors in these tools
may spark, and the sparks might ignite fumes.
• DO NOT use to blow flammable or combustible liquids such as gasoline or use in
areas where they may be present.
• USE EXTRA CARE when cleaning on stairs.
• NEVER immerse the motor part of the blower, battery, or charger in liquid.
• DO NOT unplug the charger by pulling on the cord. To unplug, grasp the plug, not the cord.
• DO NOT handle charger, including charger plug and charger terminals with wet hands.
• DO NOT charge the unit outdoors.
• MAINTAIN TOOL WITH CARE. Keep fan area clean for best and safest performance.
Follow instructions for proper maintenance.
• DO NOT attempt to clear clogs from the tool without first removing the battery.
• DO NOT attempt to repair the blower. To assure product safety and reliability, repairs,
maintenance, and adjustments should be performed by authorized service personnel.
• STORE IDLE TOOLS. When not in use, the unit should be stored in a dry, high, or
locked-up place - out of reach of children.
PACKAGE CONTENT LIST:
1. Motor Unit
2. Lower Blower Tube
3. Upper Blower Tube
4. Rechargeable Battery
5. Charger
6. User Manual
MEET YOUR ULTRASTORM CORDLESS LEAF BLOWER:
5
Lower Blower Tube
Upper Blower Tube
2nd Gear1st Gear
Off Switch
Position
Handle
Battery Release
Button
Rechargeable
Battery
Charger
Charge Indicator
Lights
Motor Unit
Lock/Release Button
On/Off Switch
The battery is pre-charged before shipping. However, before using the blower for the
first time, place the battery in the battery charger and charge it until the GREEN charge
indicator light turns ON.
ATTENTION! The rechargeable battery will become hot with heavy use. Allow the
rechargeable battery to cool to room temperature before recharging.
DO NOT charge the battery for more than 5 hours at a time.
Make sure to read all safety precautions and follow the instructions in this section.
USING YOUR ULTRASTORM CORDLESS LEAF BLOWER:
BEFORE THE FIRST USE:
Before assembling the product, make sure all parts are present. Compare parts with
package contents list. If any part is missing or damaged, do not attempt to assemble
the product.
ASSEMBLY INSTRUCTIONS:
WARNING: To prevent accidental starting that could cause serious personal injury,
always remove the battery from the Motor Unit when assembling parts.
ASSEMBLING THE BLOWER TUBE:
Slide the Lower Tube over the end of
Upper Tube, aligning the triangular tab
and node until locked into place.
Align the widest end of the Upper
Blower Tube with the front opening on
the Motor Unit and lock into place.
CONNECTING AND REMOVING THE BATTERY:
IMPORTANT!
To remove the battery
Grasp the blower firmly. Press
and hold down the release button
on the battery.
Pull the battery out of the Motor Unit.
1
2
1
2
6
1
2
OPERATING INSTRUCTIONS:
Connecting the battery
Align the rails of the battery with the rails on the bottom of the Motor Unit, and slide the
battery forward until it locks into place.
WARNING: Follow these instructions in order to avoid injury and to reduce the risk
of electric shock or fire:
Replace the battery or the charger immediately if the battery case or charger cord is
damaged.
Verify that the switch is in the OFF position before inserting or removing the battery.
Verify that the battery is removed and the switch is in the OFF position before
inspecting, adjusting, or performing maintenance on any part of the blower.
WARNING: Read and thoroughly understand all instructions and safety informa-
tion before operating this blower. Failure to do so may cause serious injury or death.
Do not allow anyone to operate this blower who has not read this manual. A blower
can be dangerous if assembled or used improperly. Do not operate this blower if you
have doubts or questions concerning safe operation. Call our customer service
department at (888)-632-9981 to address these concerns.
Starting/stopping the blower:
Connect the battery to the Motor Unit. (Refer to Connecting the battery section of
this manual).
Push the On/Off Switch forward to start the blower. The blower will engage at 1st Gear.
To engage the 2nd Gear, push the On/Off Switch forward once again.
To stop the blower, pull the On/Off switch all the way backward.
ATTENTION! Only use the equipment with the blower tube attached!
Use the blower to:
- Blow debris or grass clippings off of driveways, sidewalks, patios, parks, parking
lots, etc.
- Remove debris from corners, around joints, and between bricks.
- Gather grass clippings, straw, or leaves into piles.
- Conserve water by using a power blower instead of hoses for many lawn and
garden applications, including areas such as gutters, screens, patios, grills, porches,
and gardens.
1
2
3
4
7
Charging the battery:
Charge the battery when the last LED in the charge indicator changes from green to
yellow/red.
Connect the battery to the charger and plug in. The charge indicator on the charger will
light up red when charging starts and whilst charging. Once charging is complete, the
charge indicator will change to green.
8
NOTE: Use rakes and brooms to loosen debris before blowing. In dusty conditions,
slightly dampen surfaces when water is available.
NOTE: To keep from scattering debris, blow around the outer edges of a debris pile.
Never blow directly into the center of a pile.
NOTE: Keeping a distance of 3-5 inches from the ground will provide optimal results
when using the blower.
ATTENTION: Watch out for children, pets, open windows, or freshly washed cars, and
blow debris safely away.
• You may remove the blower tube from the motor unit for storage.
To do so, press the locking button and slide the upper blower tube forward and off.
• Store the equipment in a dry location, protected from use and out of the range of
children.
• Remove the rechargeable battery from the equipment before storing for an extended
period of time (e.g. over winter).
• Store the battery only if it is at least partially charged. When storing for extended
periods, the charge should be at least 40-60%.
• When storing for extended periods, check the battery charge about every 4-6 months
and recharge if necessary.
• Store the rechargeable battery at 50˚F - 77˚F / 10˚C - 25˚C.
• Avoid storing in locations of extreme cold or heat to ensure the rechargeable battery
does not lose power.
• Remove the battery from the Motor Unit.
• Detach the Upper and Lower tubes.
• Clean debris out of the air vents using a brush or damp cloth. Keep the air vents free
of obstructions, sawdust, and wood chips. Do not spray, wash, or immerse the air
vents or Motor Unit in water.
• Wipe off the housing and the plastic components using a moist, soft cloth. Do not
use strong solvents or detergents on the plastic housing or plastic components.
Certain household cleaners may cause damage and may cause a shock hazard.
CLEANING AND CARE:
WARNING: In order to avoid personal injury and the risk of fire and electric shock,
remove the battery before adjusting, inspecting, or cleaning the blower.
CLEANING
STORAGE
BATTERY MAINTENANCE
•Store the battery fully charged.
•Once the charging light turns green, remove the battery from the charger and discon-
nect the charger from the outlet.
• Do not store the battery on the blower.
• After charging, the battery may be stored in the charger, as long as the charger is not
plugged in. NOTE: The battery should NOT charge for more than 5 hours at a time.
9
CHARGER MAINTENANCE
ENVIRONMENTALLY SAFE BATTERY DISPOSAL
• Keep the charger clean and clear of debris. Do not allow foreign material to get into
the recessed cavity or onto the contacts. Wipe the charger clean with a dry cloth. Do
not use solvents or water, and do not place the charger in wet conditions.
• Unplug the charger when there is no battery in it.
• Store the charger at normal room temperature. Do not store it in excessive heat. Do
not use the charger in direct sunlight. Recharge at room temperature between 45˚F
and 104˚F. If the battery is hot, allow it to cool down before recharging.
The battery used in this blower contains the following toxic and corrosive material:
LITHIUM-ION.
WARNING:
Toxic materials must be disposed of in a specified manner in order to prevent contami-
nation of the environment. Before disposing of damaged or worn out Lithium-Ion
batteries, contact your local waste disposal agency for information and specific
instructions. Take the batteries to a local recycling and/or disposal center that is certi-
fied for disposal.
If the battery cracks or breaks, whether it leaks or not, do not recharge it and do not use
it. Dispose of it and replace with a new battery. DO NOT ATTEMPT TO REPAIR IT!
Follow these instructions in order to avoid injury and the risk of fire, explosion, or
electric shock, and to avoid damage to the environment:
• Cover the battery's terminals with heavy-duty adhesive tape.
• DO NOT attempt to remove or destroy any of the components of the battery.
• DO NOT attempt to open the battery.
• If a leak develops, the electrolytes that are released are corrosive and toxic. Do not
get the solution in eyes or on the skin, and do not swallow.
• DO NOT place the battery in regular household trash.
• DO NOT incinerate the battery.
• DO NOT place the battery where it will become part of any waste landfill or municipal
solid waste stream.
• Dispose of the battery at a certified recycling or disposal center.
10
If you are not happy with the product for any reason, please
with your feedback or questions, and we will do our best to
make things right for you!
Your purchase comes with a 100%
satisfaction guarantee from Müeller
168 Mason Way Unit #4A,
City of Industry, CA 91746
Telephone: (888) 632-9981
E-mail: [email protected]
Web: www.muellerdirect.com
Müeller USA
Table of contents
