Multimo 750-SIMPLE BUNK User manual

Assembly Instructions
750- SIMPLE BUNK
100min.
180min.
Technical Service
End User
+-
VIDEO
link

Page 1 Page 2
AMR 03 (300 N)
4 / piece
MRD 01
1 / piece 2 / piece
KLF -F (fabric cover) KOR -F
2 / piece
DD - 01 ( R10 )
14 / piece
SG - 01
8 / piece
TAP - 01
64 / piece
KVL 01
28 / piece
MNG - 01
64/ piece
Accessories List
MNX 02
24/ piece
MNX - 03
20 / piece
PL - 04 (5x12x0,7) mm
16 / piece
SC-79
2 / piece
AL - 01 (4MM)
1 / piece
AL - 02 (5MM)
1 / piece
TFC - 01(8x70) mm
14 / piece
KOR -B
2 / piece
BKA - 01
2 / piece
B
C
A
D
B
D
C
A
A
A
E-R
E-L
F
F
J
G-R
G-L
H
K
H
G-R
G-L
KCE - 01
8 / piece
YSB - 01 ( 3,9x16 ) mm
16 / piece
SYS-01
2 / piece
VTB - 02 (4,2x16) mm
72 / piece
2 / piece
SC-98
KBY- 02
4 / piece28 / piece
SC-110
IM - 02 (6x20) mm
8 / piece
CTM - 01 ( 6x10 ) mm
8 / piece
SKT 01
8 / piece 6 / piece
CTM - 04 ( 8x25 ) mm
LTA - 01
28 / piece
SC-78
4 / piece
Track Title
(inch) (mm)
Piece T hickness Length Width Piece T hick Height Most
A40,71 36,14 13,58 418 918 345
B20,71 84,17 12,09 2 18 2138 307
C20,71 84,17 12,09 2 18 2138 307
D20,71 84,17 12,09 2 18 2138 307
E-R / E-L 265,94 2 1675
F275,98 2 1930

Page 1 Page 2
AMR 03 (300 N)
4 / piece
MRD 01
1 / piece 2 / piece
KLF -F (fabric cover) KOR -F
2 / piece
DD - 01 ( R10 )
14 / piece
SG - 01
8 / piece
TAP - 01
64 / piece
KVL 01
28 / piece
MNG - 01
64/ piece
Accessories List
MNX 02
24/ piece
MNX - 03
20 / piece
PL - 04 (5x12x0,7) mm
16 / piece
SC-79
2 / piece
AL - 01 (4MM)
1 / piece
AL - 02 (5MM)
1 / piece
TFC - 01(8x70) mm
14 / piece
KOR -B
2 / piece
BKA - 01
2 / piece
B
C
A
D
B
D
C
A
A
A
E-R
E-L
F
F
J
G-R
G-L
H
K
H
G-R
G-L
KCE - 01
8 / piece
YSB - 01 ( 3,9x16 ) mm
16 / piece
SYS-01
2 / piece
VTB - 02 (4,2x16) mm
72 / piece
2 / piece
SC-98
KBY- 02
4 / piece28 / piece
SC-110
IM - 02 (6x20) mm
8 / piece
CTM - 01 ( 6x10 ) mm
8 / piece
SKT 01
8 / piece 6 / piece
CTM - 04 ( 8x25 ) mm
LTA - 01
28 / piece
SC-78
4 / piece
Track Title
(inch) (mm)
Piece T hickness Length Width Piece T hick Height Most
A40,71 36,14 13,58 418 918 345
B20,71 84,17 12,09 2 18 2138 307
C20,71 84,17 12,09 2 18 2138 307
D20,71 84,17 12,09 2 18 2138 307
E-R / E-L 265,94 2 1675
F275,98 2 1930

Page 3 Page 4
STEP 1
E-R
E-L
F
F
SYS - 01
BKA - 01
F
KBY - 02
E
VIDEO
link
VIDEO
link
SC - 98
STEP 3
STEP 2
Ø 10 mm / 0,254 nch
DD - 01
TFC - 01
2010 mm
1730 mm
Use mounting frame as a drilling template.
Attach frame to the wall at one point only.(STEP-2)
Ensure frame is perfectly level.(STEP-2)
Mark drilling points through predrilled holes in the frame.(STEP-3)
Remove frame from the wall and drill pilot holes in the wall.(STEP-4)
Attach frame to the wall using supplied hardware.(STEP-5-6)
ATTENTION!!!
Must be secured to the wall made of brick, concrete or similarly strong material.
Mounting to wooden or metal studs is also acceptable.
Do not mount directly to sheetrock or paper-mache type walls not supported by studs.

Page 3 Page 4
STEP 1
E-R
E-L
F
F
SYS - 01
BKA - 01
F
KBY - 02
E
VIDEO
link
VIDEO
link
SC - 98
STEP 3
STEP 2
Ø 10 mm / 0,254 nch
DD - 01
TFC - 01
2010 mm
1730 mm
Use mounting frame as a drilling template.
Attach frame to the wall at one point only.(STEP-2)
Ensure frame is perfectly level.(STEP-2)
Mark drilling points through predrilled holes in the frame.(STEP-3)
Remove frame from the wall and drill pilot holes in the wall.(STEP-4)
Attach frame to the wall using supplied hardware.(STEP-5-6)
ATTENTION!!!
Must be secured to the wall made of brick, concrete or similarly strong material.
Mounting to wooden or metal studs is also acceptable.
Do not mount directly to sheetrock or paper-mache type walls not supported by studs.

Page 5 Page 6
STEP 4
Ø 10 mm / 0,254 nch
DD - 01 x 13
STEP 5
TFC - 01 X 3
A-
STEP 6
TFC - 01 X 8
A-
A-
SC - 98
VIDEO
link
VIDEO
link

Page 5 Page 6
STEP 4
Ø 10 mm / 0,254 nch
DD - 01 x 13
STEP 5
TFC - 01 X 3
A-
STEP 6
TFC - 01 X 8
A-
A-
SC - 98
VIDEO
link
VIDEO
link

Page 7 Page 8
STEP 7
KVL 01
MNG - 01
MNG - 01 x 6
KVL - 01 x 3 A
MNG - 01 x 5
MNG - 01 x 10
MNG - 01 x 5 B
C
D
MNX - 03 x 10
KVL - 01 x 4
KVL - 01 x 4
MNX - 03
210°
STEP 8
STEP 9
B
C
D
KVL 01
MNG - 01
210°
210°
210°
210°
VIDEO
link
VIDEO
link

Page 7 Page 8
STEP 7
KVL 01
MNG - 01
MNG - 01 x 6
KVL - 01 x 3 A
MNG - 01 x 5
MNG - 01 x 10
MNG - 01 x 5 B
C
D
MNX - 03 x 10
KVL - 01 x 4
KVL - 01 x 4
MNX - 03
210°
STEP 8
STEP 9
B
C
D
KVL 01
MNG - 01
210°
210°
210°
210°
VIDEO
link
VIDEO
link

Page 9 Page 10
STEP 10 STEP 11
J
G-R
G-L
H
- K
LTA - 01 x 14
H
J - K
G-R
G-L
B
C
D
Install plastic corners and
metal joints without gaps
SKT - 01
CTM - 01
69 mm 69 mm
J - K
1-
-3
SC-110 x 10
VTB - 02 x 20
SC-110 x 4
VTB - 02 x 8
VIDEO
link
VIDEO
link
AL - 01
J - K
H
G-R
2-
Assemble the brackets over the
places shown over H,J,K proles
Assemble the brackets over the
places shown over G-L,G-R proles

Page 9 Page 10
STEP 10 STEP 11
J
G-R
G-L
H
- K
LTA - 01 x 14
H
J - K
G-R
G-L
B
C
D
Install plastic corners and
metal joints without gaps
SKT - 01
CTM - 01
69 mm 69 mm
J - K
1-
-3
SC-110 x 10
VTB - 02 x 20
SC-110 x 4
VTB - 02 x 8
VIDEO
link
VIDEO
link
AL - 01
J - K
H
G-R
2-
Assemble the brackets over the
places shown over H,J,K proles
Assemble the brackets over the
places shown over G-L,G-R proles

Page 11 Page 12
STEP 12
STEP 13
LTA - 01 x 14
B
C
D
STEP 14
MNX - 02
AMR - 03
STEP 15
AMR - 03 SG - 01
J - K
J
CTM - 04 X 2
MNX - 02 x 12
J
Unscrew the Screws
J - K
VIDEO
link
VIDEO
link

Page 11 Page 12
STEP 12
STEP 13
LTA - 01 x 14
B
C
D
STEP 14
MNX - 02
AMR - 03
STEP 15
AMR - 03 SG - 01
J - K
J
CTM - 04 X 2
MNX - 02 x 12
J
Unscrew the Screws
J - K
VIDEO
link
VIDEO
link

Page 13 Page 14
STEP 18
STEP 16
STEP 17
SG - 01
AMR - 03
AMR - 03
J
J
PL - 04
YSB - 01
IM - 02 x 2
SC - 78
AL - 02
SC - 78
VIDEO
link
SC - 78
VIDEO
link

Page 13 Page 14
STEP 18
STEP 16
STEP 17
SG - 01
AMR - 03
AMR - 03
J
J
PL - 04
YSB - 01
IM - 02 x 2
SC - 78
AL - 02
SC - 78
VIDEO
link
SC - 78
VIDEO
link

Page 15 Page 16
STEP 19
CUITION !
Please make sure
that leg ledder supports
the center of the top
bed and use all tme
when the bed s opened
STEP 20
MNG - 01 x 12
STEP 21
210°
VIDEO
link
VIDEO
link
VTB - 02 x 4
SC - 78
MRD - 01
MRD - 01
A
A

Page 15 Page 16
STEP 19
CUITION !
Please make sure
that leg ledder supports
the center of the top
bed and use all tme
when the bed s opened
STEP 20
MNG - 01 x 12
STEP 21
210°
VIDEO
link
VIDEO
link
VTB - 02 x 4
SC - 78
MRD - 01
MRD - 01
A
A

Page 17 Page 18
STEP 22
KLF -FRONT
(fabric cover)
KOR - FRONT
KCE - 01 X 4
PL - 04
YSB - 01
TAP - 01
STEP 23
MNX - 02
AMR - 03
STEP 24
AMR - 03 SG - 01
MNX - 02 x 12
K
K
VIDEO
link
VIDEO
link

Page 17 Page 18
STEP 22
KLF -FRONT
(fabric cover)
KOR - FRONT
KCE - 01 X 4
PL - 04
YSB - 01
TAP - 01
STEP 23
MNX - 02
AMR - 03
STEP 24
AMR - 03 SG - 01
MNX - 02 x 12
K
K
VIDEO
link
VIDEO
link

Page 19 Page 20
STEP 25 STEP 27
STEP 26
AL - 01
SC - 79
IM - 02 x 2
SC - 78
AL - 02
K
PL - 04
YSB - 01
CTM - 04
K
AL - 01
CTM - 04
VIDEO
link
VIDEO
link
SC - 78
SC - 78
