MULTIQUIP GLOBUG Series Guide

OPERATION AND PARTS MANUAL
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
GLOBUG SERIES
MODEL GB114BS/BP
LIGHTING SYSTEM
Revision #3 (01/06/09)
Go to Discount-Equipment.com to order your parts

Discount-Equipment.com is your online resource for quality parts & equipment.
Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101
Need parts?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and
choose one of the options to help get the right parts and equipment you are looking
for. Please have the machine model and serial number available in order to help us
get you the correct parts. If you don’t find the part on the website or on one of the
online manuals, please fill out the request form and one of our experienced staff
members will get back to you with a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,
Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack,
Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic,
Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti,
Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin,
Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,
Stanley, Tamco, Toku, Hatz, Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air,
APT, Wylie, Ingersoll Rand / Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith
Surface Prep,Small Line, Wanco, Yanmar

PAGE 2 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
TABLE OF CONTENTS
MQ GLOBUG LIGHTING
SYSTEM
Table of Contents..................................................... 2
Parts Ordering Procedures...................................... 3
Safety Information ................................................ 4-7
Specifications .......................................................... 8
Dimensions (GB114BS) .......................................... 9
Dimensions (GB114BP) ........................................ 10
Floodlight Footcandle Plot .................................... 11
General Information............................................... 12
Components ..................................................... 14-15
Setup ................................................................ 16-17
Operation............................................................... 18
Operation/Shutdown.............................................. 19
Storage.................................................................. 20
Maintenance..................................................... 21-25
Troubleshooting (Lamp)......................................... 26
Wiring Diagram...................................................... 27
Voltage Measurements..................................... 28-29
Explanation of Code in Remarks Column ............. 30
Suggested Spare Parts ......................................... 31
COMPONENT DRAWINGS
Nameplate and Decals ..................................... 32-33
Ballast Assembly S/N G30001 & Below ........... 34-35
Ballast Assembly S/N G30002 & Above ........... 36-37
Fan Blower/Lamp Base Assembly.................... 38-39
Balloon/Lamp Guard Assembly ........................ 40-41
Offset Pole Assembly ....................................... 42-43
Terms and Conditions of Sale — Parts.................. 44
NOTICE
Specifications and part numbers are subject to change
without notice.
Go to Discount-Equipment.com to order your parts

PAGE 4 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION or NOTICE.
SAFETY SYMBOLS
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
GENERAL SAFETY
CAUTION
NEVERoperate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.
NEVERoperate this equipment when not
feeling well due to fatigue, illness or when
under medication.
NEVERoperate this equipment under the influence of
drugs or alcohol.
NOTICE
This equipment should only be operated by trained and
qualified personnel 18 years of age and older.
Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
NEVERuse accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
ALWAYSknow the location of the nearest
fire extinguisher.
ALWAYSknow the location of the nearest
first aid kit.
ALWAYSknow the location of the nearest phone or keep
a phone on the job site. Also, know the phone numbers
of the nearest ambulance, doctor and fire department.
This information will be invaluable in the case of an
emergency.
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 5
SAFETY INFORMATION
LIGHTING SYSTEM SAFETY
DANGER
NEVERuse lighting system in rain, snow or
areas of high humidity that could generate
electrical storms.
WARNING
NEVERdisconnect any emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm or even death. Disconnection of any of
these devices will void all warranties.
CAUTION
NEVERattempt service on a running machine.
NOTICE
To prevent the lighting system from overturning,NEVER
use in winds that exceed 22 mph (10 m/s).
The lighting system should only be used in temperatures
between 23° to 104°F (-5° to 40° C). Failure to comply
with these operating parameters could cause the lamp
to malfunction and shorten the ballast life.
ALWAYSkeep the lighting system in proper running
condition.
Fix damage to lighting system and replace any broken
parts immediately.
ALWAYSstore equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.
LAMP SAFETY
WARNING
NEVERattempt to replace lamp with the power on.
Always unplug the power cord from the generator or
power source when changing the lamp.
ALWAYSallow a sufficient amount of time for the lamp to cool
before changing.The possibility exists of severe burns.
CAUTION
NEVERuse force when installing the lamp. Excessive force
could cause the lamp to break, causing bodily harm.
NOTICE
NEVERleave any grease or oil residue on lamp surface
when replacing or removing lamp. This can create hot
spots, reducing the service life of the lamp.
ALWAYSmake sure lamp surface is clean and dry.
ALWAYSreplace with MQ recommended type lamp. See
parts section of this manual.
If applicable,ALWAYS make sure the lamp guard is
installed correctly. NEVER deform the lamp guard.
NEVERunplug the lamp’s AC power cable during
operation.
ALWAYShave a trained technician to install and
remove lamp or replace any damaged fixture wiring.
BALLOON SAFETY
WARNING
To prevent serious burns,NEVER touch
or unzip the balloon envelope when the
lamp is on.
CAUTION
ALWAYSkeep the balloon away from sharp objects and
excessive amounts of heat.
NOTICE
To prevent balloon deformation,NEVER use lighting
system in strong winds.
DO NOTplace the balloon inside its protective cover
until the lamp has had a sufficient amount of time to cool
down. This will prevent the balloon’s nylon cover from
being burned (touching the lamp surface).
ALWAYSplace the balloon inside its protective cover
after each use. This will prolong the life of the balloon
material, keeping it protected from harsh environmental
elements.
Replace balloon immediately if damaged. A damaged
balloon will not inflate properly, and may become more
damaged by touching the hot lamp surface.
DO NOTuse excessive force when zipping and unzipping
the balloon. Be gentle with the zipper mechanism. If the
zipper is broken, the balloon will become unusable.
Go to Discount-Equipment.com to order your parts

PAGE 6 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
SAFETY INFORMATION
GENERATOR SAFETY
If using a generator to power lighting system,
refer to applicable generator manual safety
information section.
ELECTRICAL SAFETY
DANGER
Lighting system is equipped with a ground pin on the
power plug. For your protection, ALWAYS complete the
grounding path. NEVER insert the AC power plug into a
2-prong receptacle to operate lighting system.
When applying power to the lighting system, ALWAYS
connect the AC power plug to a 3-prong receptacle that
is grounded. The possibility exists of electrical shock,
electrocution and even death if the lighting system is
not grounded.
NEVERoperate lighting system or
handle any electrical equipment while
standing in water, while barefoot,
while hands are wet or in the rain. A
dangerous electrical shock could
occur, causing severe bodily harm
or even death.
ALWAYSmake sure the area above
the lighting system is open and clear
of overhead power lines and other
obstructions. Contact with overhead
power lines or other obstructions
could result in equipment damage,
electrical shock, electrocution and
even death.
Power Cord/Cable Safety
DANGER
NEVERlet power cords or cables lay in water.
NEVERuse damaged or worn cables or cords. Inspect
for cuts in the insulation
NEVERgrab or touch a live power
cord or cable with wet hands. The
possibility exists of electrical shock,
electrocution or death.
Make sure power cables are securely connected.
Incorrect connections may cause electrical shock and
damage to the lighting system.
NOTICE
ALWAYSmake certain that proper power or extension
cord has been selected for the job. See Cable Selection
Chart in this manual.
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 7
SAFETY INFORMATION
LOADING AND UNLOADING
If lighting system is equipped with a transport lifting hook,
refer to the following safety information.
CAUTION
Before lifting, make sure that lighting system parts are
not damaged and screws are not loosened or lost.
ALWAYSmake sure crane or lifting device has been
properly secured to lifting hook of the equipment.
NEVERlift the equipment while lighting system is
running.
Make sure the mast is completely lowered before lifting
the lighting system.
Use adequate lifting cable (wire or rope) of sufficient
strength.
Use one point suspension hook and lift straight upwards.
Never allow any person or animal to stand underneath the
equipment while lifting.
DO NOTlift machine to unnecessary heights.
TRANSPORTING SAFETY
NOTICE
When transporting the lighting system, if applicable,
always place in stow position and place mast in its
carrying case.
ALWAYSremove balloon/lamp assembly from the mast
when transporting lighting system. This will prevent
damage to the bulb due to vibration.
NEVERleave the balloon/lamp exposed during transport.
Exposure to excess wind or rain could damage the
balloon’s nylon cover.
ALWAYSplace balloon inside its protective cover during
transport. Be sure the cover is secured tightly around the
balloon/lamp assembly.
Go to Discount-Equipment.com to order your parts

PAGE 8 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
SPECIFICATIONS
SpecificationsTable 1.
GloBug Lighting System
Model GB114BS/GB114BP
Input Voltage 120 VAC
Ballast Magnetic Ballast 60 Hz
Frequency 60 Hz Single-Phase
Max. Current 9.5 Amps
Lamp
Lamp Type 1000 Watt Metal Halide
Lumens 112,000
Light Coverage (360°) 150 ft. (45.72 meters)
Surface Temperature (Longitudinal) 476.6°F (247°C) Max.
Surface Temperature (Transversal) 417.2°F (214°C) Max.
Fan Motor
Balloon Fan Motor 115 VAC, 60 Hz
Max. Current .360 Amps
Pressure 31.26 PSI (215.6 kPA)
Balloon
Diameter 47.16 in. (1,200 mm)
Material Heat Resistant Nylon
Heat Resisting Temperature 320 ~ 356°F (160 ~ 180°C)
Melting Temperature 500°F (260°C)
Internal Temperature of Balloon 126°F (52°C) Average
Water Resistance 1,500 mm H20
Weight
GB114BS 83 lb. (38 kg)
GB114BP 61 lb. (28 kg)
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 9
DIMENSIONS (GB114BS)
Dimensions (GB114BS)Figure 1.
DimensionsTable 2.
Reference Letter Dimension in. (mm.) Reference Letter Dimension
in. (mm.)
A88.0 -108.0 in.
(2,230 - 2,730 mm.) D35.00 in.
(900 mm.)
B 59 in. (1,500 mm.) E 35.00 in.
(900 mm.)
C 47.16 in. (1,200 mm.)
Go to Discount-Equipment.com to order your parts

PAGE 10 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
DIMENSIONS (GB114BP)
B
A
Dimensions (GB114BP)Figure 2.
DimensionsTable 3.
Reference
Letter Dimension in. (mm.)
A 28.00 in. (712 mm.)
B 47.16 in. (1,200 mm.)
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 11
FOOTCANDLE PLOT
360° Coverage
Floodlight Footcandle Plot (BAL-115 Drum Shaped)Figure 3.
Scale: Grid = 50 ft. (15.25 meters)
Values listed as footcandles
.5 1
2
5
10
Go to Discount-Equipment.com to order your parts

PAGE 12 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
GENERAL INFORMATION
The Multiquip GloBug GB114BS, and GB114BP are
general purpose portable glare-free lighting systems.
Typical applications for these types of lighting systems
include construction sites, emergency road crews and
backyard parties.
BALLOON ENVELOPES
The GloBug lighting system can be configured with a
variety of balloon envelopes (canopy). Please contact
Discount-equipment for the balloon of your choice.
The GloBug GB114BS and GB114BP shipped from the
factory with the drum type balloon.
LIGHTING
Multiquip's GloBug lighting system is comprised of one
"Metal Halide" 1000-watt lamp.This lamp has an output of
112,000 lumens.Typical lighting coverage is in excess 150
ft. (46 meters) in a 360 degree pattern.
POWER
These GloBug lighting systems are powered by a
portable ballast that can be hand carried.The input power
requirements for operating the lighting system is 120 VAC,
60 Hz @ 9.5 amps
GB114BS
The GB114BS lighting system (offset pole) is designed to
be attached to a external piece of a equipment such as a
paver (Figure 4).This system is equally easy to assemble.
Simply attach the supplied support clamps to an external
pole or support and you are ready.
GB114BS Offset Pole (Paver)Figure 4.
GB114BP
When only a complete lamp assembly is required please
order Model GB114BP. This model number includes the
lamp, protective guard, balloon protective covering and all
other components that make up the lamp assemby.
TRANSPORT
The GB114 lighting systems can be transported quite easily.
The GB114BP consists of a balloon/lamp, power cable
and a ballast, and it has a combined weight of 61 lbs (28
kg). The GB114BS consists a balloon/lamp, power cable,
ballast and offset pole, and it has a combined weight of
83 lbs (38 kg).
For ease of service or transport, the lamp assembly is
equipped with a quick-disconnect connector that allows
the lamp fixture to be removed quickly. This feature is
extremely useful during transport of the lighting system. It
is always best to remove the lamp and pack it safely so it
will not be damaged.
Go to Discount-Equipment.com to order your parts

PAGE 14 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
COMPONENTS
Major ComponentsFigure 5.
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 15
COMPONENTS
Figure 5 shows the location of the components for the
GloBug lighting system. The function of each component
is described below:
Lamp Guard1. — This guard (cage) protects the lamp
from being hit by objects.
Lamp2. — 1000 watt metal-halide type lamp. Replace
only with MQ recommended type lamp. Always allow
a sufficient amount of time for the lamp to cool down
before changing.
Fan Motor (Blower)3. — This electric motor is
responsible for inflating the balloon. It will supply a
pressure of 31.26 psi /215.6 kPA. Please note that the
balloon will begin to inflate as soon as power is applied
to the lighting system.
Balloon Cover/Carrying Case4. — When zipped, this
protective cover acts like a carrying case.The complete
lamp assembly is enclosed within the cover-carrying
case. Allow a sufficient amount of time for the lamp
to cool down before covering balloon. The possibility
exists of the balloon getting burned.
Lamp Assembly Connector5. — Quick-disconnect
cable. Provides AC power to lamp assembly.
T-Handle Bolt Lock6. — Always tighten this lock to hold
the lamp/balloon securely in place.
Balloon7. — This balloon is made of heat-resistant
nylon, with a diameter of 47 inches (1200 mm).
Offset Pole8. — Supports lamp assembly when attached
to the main mast. Included with the offset pole is a
17/19 mm wrench.
Lamp Power Cable (Output)9. — Connect this cable
between the ballast receptacle and the lamp assembly
connector.
Pole Clamps10. — Attach these clamps (2) to the
main pole and external support pole. Always tighten
both clamps securely to prevent slippage of the light
assembly.
Main Pole11. — Used in conjunction with the offset pole
to support the lamp assembly.
Ballast12. — Power source for lamp. Input power
requirements are 120 VAC, 60 Hz @9.5 amps.
Ballast AC Power Cable (Input)13. — Connect this cable
to a 120 VAC, 60 Hz power source.
Go to Discount-Equipment.com to order your parts

PAGE 16 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
SETUP
POLE SETUP
Refer to Figure 6 for the following procedure.
Remove the offset pole (B) from the shipping1.
container.
Attached to the offset pole is a 17/19 mm open-end2.
wrench (C). Remove the wingnut (D) securing the
wrench to the offset pole and remove wrench.
Reinsert wingnut and washer back into offset pole so3.
they will not get lost or misplaced.
Remove the two pole clamp assemblies (A) from the4.
shipping container. Attach one pole clamp assembly
(E) to the main pole (F) about 3 inches (76.2 mm) down
from the main pole extension clamp. Using supplied
19 mm wrench, tighten locknut on the pole clamp
assembly securely.
Attach the other pole clamp assembly (G) to the main5.
pole (F) about 7.0 in. (140 mm.) down from the previous
attached pole clamp assembly (E). Using the 19 mm
wrench, tighten locknut on the pole clamp assembly
securely.
To attach main pole (F) to equipment support pole (I),6.
swing open adjustable tension plate (H) on clamp so
that it can accomodate the diameter of the equipment
support pole. Insert equipment support pole (I) through
the two equipment support pole clamp assemblies as
shown in Figure 6.
Once the equipment support pole (I) has been seated7.
properly, move adjustment bolt and locknut (J) into
locking position. Use the supplied 17 mm wrench, to
tighten locknuts (J) on both clamps securely.
Place offset pole (B) with adapter clamp (K) on top of8.
adjustable extension pole (L). Make sure that offset
pole has been seated correctly.
NOTICE
The pole clamp assembly used in this setup procedure
is a dual type clamp. One side of the clamp is for the
attachment of the main pole of the lighting system.The
other side of the clamp is used for the attachment of
a support pole that is usually connected to a piece of
equipment such as a paver.
Using 17 mm wrench, tighten both bolts (M) on the9.
offset adapter clamp (K) securely.
Place lamp assembly (N) onto offset pole (B).Tighten10.
T-handle bolt (O) securely.
Offset Pole AssemblyFigure 6.
T-HANDLE
LAMP
ASSEMBLY
OFFSET
POLE
ADJUSTABLE
EXTENSION
POLE
EQUIPMENT
SUPPORT
POLE
MAIN POLE
CLAMP
ADJUSTABLE
CHANNEL
ADJUSTMENT
BOLT AND
LOCKNUT
MAIN
POLE 7.0 IN.
(140 M
M
3.0 IN.
(76.2 M
M
EXTENSION
CLAMP
BOLT
REMOVE
WRENCH
C
WINGNUT
E
G
POLE
CLAMP
ASSY.
LOCKNUT
EQUIPMENT
SUPPORT
POLE CLAMP
M
OFFSET
ADAPTER
CLAMP
O
BALLOON
POWER
CABLE
P
B
D
L
F
POLE
CLAMP
ASSEMBLY
TENSION
PLATE
I
K
N
Q
A
POLE
CLAMP
ASSY.
J
H
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 17
SETUP
REMOVING THE PROTECTIVE COVERING
Expose the balloon by pulling down on the velcro tab1.
and unzip the protective cover as shown in Figure 7.
Folding Protective CoverFigure 7.
VELCRO
TAB
PROTECTIVE
COVER
BALOON
UNZIP
PROTECTIVE
COVER
STEP 1
BALLOON
FULLY
EXPOSED
FOLD PROTECTIVE
COVER INTO ITSELF
STEP 2
CONNECTING POWER CABLE
Connect 16.4 ft. (5 meters) lamp power cable (Figure 8)1.
to the balloon power cable.
Connecting Lamp Power CableFigure 8.
Attach both S-type hooks (Figure 9) on the lamp power2.
cable into the cable support holes on the offset pole.
Attachment of S-HooksFigure 9.
BALLOON
POWER
CABLE LAMP
ASSEMBLY
LAMP
POWER
CABLE
BALLAST
OFFSET
POLE
S-TYPE
HOOK
LAMP
POWER
CABLE
Go to Discount-Equipment.com to order your parts

PAGE 18 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
OPERATION
RAISING THE EXTENSION POLE
Before raising the extension pole, make sure the1.
T-handle bolt lock (Figure 6-O) is securely tightened.
This will prevent the balloon/lamp assembly from falling
off. In addition make sure that the lamp power cable
is connected to the mating end of the power source
cable.
Raise extension pole (Figure 6-L) to desired height.2.
Watch out for any overhead obstructions.
Using 19 mm wrench, tighten extension clamp bolt3.
(Figure 6-Q) securely. Keep wrench in a safe place
where it will not get lost.
DANGER
ALWAYS make sure the area
above the lighting system is
open and clear of overhead
power lines and other
obstructions. Contact with
overhead power lines or other
obstructions could result in
equipment damage, Serious
Injury or Death!
DANGER
When raising the extension pole, ALWAYS
be on the lookout for overhead obstructions
such as high voltage power lines. The
possibility exists of electrocution, even
death! if the lighting system comes in
contact with high voltage power lines.
APPLYING POWER
Make sure the power ON/OFF switch (Figure 10)1.
located near the bottom of the ballast is in the OFF
position.
Power OFF/ON Switch (Off Positon)Figure 10.
If using a power source (Figure 11) other than a2.
portable generator, plug the AC power cord from the
ballast into a 120 VAC, 60 Hz receptacle that is
protected by a at least a 15 amp circuit breaker.
Applying 120 VAC PowerFigure 11.
BALLAST
OFF
ON/OFF
SWITCH
EXTERNAL
SINGLE-PHASE
(120 VAC)
POWER SOURCE
RECEPTACLE
BALLAST
CONNECT
TO BALLOON
POWER
CABLE
AC POWER
CORD
NOTICE
If using a portable generator, start the generator as
referenced in the "Start-up Section" of the supplied
generator manual.
Once the generator has started, plug the AC power cord
from the ballast (Figure 11) into a GFCI receptacle on
the generator.
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 19
OPERATION/SHUTDOWN
Place the ON/OFF switch (Figure 12) on the ballast in3.
the ON position.
Ballast On/Off Switch (On Position)Figure 12.
4. Notice that the balloon envelope will begin to deploy
as soon as power is applied.
5. The lamp should now be on. If the lamp is not on,
check all connections and repeat steps 1 thru 4. If the
lamp still does not come on, contact Discount-
equipment.
6. The lighting system is now ready for use.
NOTICE
ALWAYS Make sure ballast is securely mounted to
a surface where it will not move, slip or fall. This will
prevent severe damage to the ballast.
BALLAST
ON
ON/OFF
SWITCH
SHUTDOWN
Place the ON/OFF switch on the ballast to the OFF1.
position. The balloon should begin to deflate and the
lamp turns off.
If using a portable generator, shut-down the generator2.
as referenced in the "Shutdown Section" of the supplied
generator manual. ALWAYS place the main circuit
breaker in the OFF position before turning off the
generator.
If using a power source other than an AC generator,3.
disconnect the ballast AC power cable from the power
source.
Go to Discount-Equipment.com to order your parts

PAGE 20 — GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09)
LOWERING THE EXTENSION POLE
Using the supplied 19 mm wrench, loosen extension1.
clamp bolt (Figure 6-Q).
Carefully pull down on the adjustable extension pole2.
(Figure 6-L) and lower lamp assembly.
Remove wingnut (Figure 6-D) from offset pole (Figure3.
6B) and insert wrench into wrench holder. Reinsert
wingnut and tighten.
REMOVING LAMP ASSEMBLY
Disconnect balloon power cable (Figure 13) from the1.
lamp power cable. Place lamp power cable in a safe
place where it will not get damage or lost..
Disconnecting Power CablesFigure 13.
NOTICE
Allow a sufficient amount of time (15-20 minutes) for the
lamp to cool down .The possibility exists of the balloon
getting burned (touching the lamp).
BALLOON
POWER
CABLE
LAMP
POWER
CABLE
LAMP
ASSEMBL
Y
STORAGE
Remove both S-type hooks (Figure 9) on the lamp2.
power cable from the cable support holes on the offset
pole.
Unzip the zipper on the protective cover (Figure 14),3.
and pull down cover over balloon/lamp assembly.
Unzipping the Protective CoverFigure 14.
Fully zip protective cover and fold velcro tab in place.4.
Zipping the Protective CoverFigure 15.
Loosen T-handle bolt (Figure 6-O) by turning5.
counterclockwise and remove lamp assembly (Figure
6-N) from offset pole.
Store lamp assembly enclosed within its protective6.
cover (Figure 16) in a safe location where it will not be
damaged.
Storing Lamp AssemblyFigure 16.
PROTECTIVE
COVER
ZIPPER
VELCRO
TAB
PROTECTIVE
COVER
COVER/LAMP
CARRYING
CASE
Go to Discount-Equipment.com to order your parts

GB114BS/BP GLOBUG LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #3 (01/06/09) — PAGE 21
MAINTENANCE
REMOVING THE LAMP ASSEMBLY
Allow lamp (Figure 17) 15-20 minutes to cool before1.
changing.
Hot Lamp Surface
Figure 17.
If lamp assembly is attached to offset pole, loosen2.
T-handle knob (Figure 18) that secures the lamp to the
offset pole.
T-Handle Knob
Figure 18.
Lift lamp assebly from offset pole, and place on a3.
suitable work bench that is free of dirt, and sharp
objects that could damage the balloon.
CAUTION
Before performing any maintenance
procedures, be sure to READ the lamp,
balloon, and general safety guidelines
in this manual. Failure to read and
understand these safety guidelines could
cause severe equipment damage and
bodily harm.
T-HANDLE
KNOB
LAMP
ASSEMBLY
REMOVING THE BALLOON
Expose the balloon (Figure 19) by pulling down on the1.
velcro tabs and unzip the protective cover as shown in
Figure 7. Next, fold the protective cover into itself and
zip
Exposing the Balloon
Figure 19.
Unzip the zipper (Figure 19) at the bottom of the balloon2.
and roll the balloon envelope upwards to expose the
lamp (Figure 20). Remove the lamp guard to gain
access to the lamp. DO NOT use excessive force when
unzipping the balloon.
Removing the Lamp GuardFigure 20.
CAUTION
DO NOT use excessive force when zipping
or unzipping the balloon. The possibility
exists of the zipper tearing, which would
make the balloon unusable.
BALLOON
PROTECTIVE
COVER
(FOLDED)
ZIPPER
(BOTTOM) ZIPPER
(TOP)
DO NOT USE
EXCESSIVE FORCE
WHEN ZIPPING OR
UN ZIPPING THE
BALLOON
TO REMOVE
LIFT UPWARDS
FROM PIPE FRAME
LAMP GUARD
PIPE FRAME
BALLOON
LAMP GUARD
Go to Discount-Equipment.com to order your parts
