Instruction Manual
“SY” Series
Circuit Breaker Switches
Models: SY2010 • SY2018 • SY2025 • SY2035 •
SY2050 • SY2070 • SY2080 • SY2100 • SY2150
“SY”
Series
Circuit Breaker
Switches

© Munters Corporation, August 2017
2QM1353r5
“SY” Series Circuit Breaker Switches
Instructions for Use and Maintenance
Thank You:
Thank you for purchasing a “SY” Circuit Breaker Switch. Munters equipment is designed to be the highest
performing, highest quality equipment you can buy. With the proper installation and maintenance it will provide
many years of service.
Please Note:
To achieve maximum performance and insure long life from your Munters product it is essential that it be installed
and maintained properly. Please read all instructions carefully before beginning installation.
Warranty:
For Warranty claims information see the “Warranty Claims and Return Policy” form QM1021 available from the
Munters Corporation office at 1-800-227-2376 or by e-mail at [email protected].
Conditions and Limitations:
• Products and Systems involved in a warranty claim under the “Warranty Claims and Return Policy” shall have
been properly installed, maintained and operated under competent supervision, according to the instructions
provided by Munters Corporation.
• Malfunction or failure resulting from misuse, abuse, negligence, alteration, accident or lack of proper installation
or maintenance shall not be considered a defect under the Warranty.

3 Munters Corporation, August 2017 QM1353r5
Index
Chapters Page
1. Unpacking the Equipment 4
1.1 Equipment 4
1.2 Dimensions 4
2. Installation Instructions 5
2.1 Installation 5
3. Troubleshooting 10
4. Circuit Breaker Switch Selection Chart 15

© Munters Corporation, August 2017
4QM1353r5
1.1 Equipment
Unpacking the Equipment 1.
Before beginning installation, check the overall condition of the equipment. Remove packing materials, and examine all
components for signs of shipping damage. Any shipping damage is the customer’s responsibility and should be reported
immediately to your freight carrier.
The Circuit Breaker Switch provides overload protection and a disconnect for single phase fan motors and other electri-
cal equipment. Maximum voltage is 250VAC. An on/off indicating light and front seal are included. The Circuit Breaker
Switch cannot be held “ON” against an overload.
See ‘Selection Chart’ in Chapter 4 for matching Circuit Breaker Switch model to load.
Note:
Three phase motors require motor starters with three phase overload
protection. Contact your local electrician or electrical supply store.
1.2 Dimensions
SIDE VIEW
FRONT VIEW
3¹⁄₈”3⁷⁄₁₆”
5¹⁄₂”

5© Munters Corporation, August 2017 QM1353r5
2.1 Installation
Step 1
Determine a location for the Circuit Breaker Switch where the equipment to be controlled is no
more than 25 feet away and is visible from the area of the switch. Open the enclosure and
mount rear portion to a secure surface using (4) #6 x 1” screws through the holes in the back
of box (not provided). See Figure 1.
Step 2
Drill entrance hole(s) in bottom of the enclosure for wiring. Use watertight connectors or PVC
conduit to seal all wiring entrances. Watertight connectors may be ordered from Munters as
follows:
Installation Instructions 2.
Figure 1
CAT. NO.
Used
with Wire
Round
Cable
Mounting
Hole Dia.
WC3208M ---- ⁄” - ¹⁄₄” ¹⁄₂”
WC3217M 14/2 UF ⁄” - ¹⁄₂” ⁄”

© Munters Corporation, August 2017
6QM1353r5
Installation InstructionsChapter 2
Step 3
All wiring should be installed in accordance with National, State and Local electrical
codes. Disconnect electrical power at the main service panel. Make electrical
connections as shown below.
Step 4
Position all wires in the enclosure to make room for the switch. Tighten any watertight
connectors and then screw down the cover. Make sure the cover sits tight against the
bottom. The Circuit Breaker Switch is now ready for use.
                   
Note:
Information in parenthesis refers to 120VAC control.
Connecting 120VAC neutral through L2 as shown
will allow indicating light to operate.
   
L1 = Line 1
L2 = Line 2
O.L. = Overload
H = Hot
N = Neutral
G = Ground
Power from
Ventilation
Control
250VAC Max.
    
    

    
    

To Load
 
 
 
 
  
WARNING
!
High Voltage, disconnect
power before servicing.

7© Munters Corporation, August 2017 QM1353r5
Troubleshooting 3.
SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION
SY Circuit Breaker
light is on but fan
will not run
 
Defective wiring from breaker
to fan
 
Defective motor
Replace wiring
Service Motor
SY Circuit Breaker
light is off and fan
will not run
 
SY Breaker is turned off
 
Panel circuit breaker has
tripped
 
Thermostat or control is not
calling for fan to be on

Defective wiring to SY
Breaker
!
Defective SY Breaker
Turn on breaker
Reset breaker
Adjust temperature set point
Replace wiring
Replace Breaker
3.1 Troubleshooting
WARNING
!
High Voltage, disconnect
power before servicing.

© Munters Corporation, August 2017
8QM1353r5
Circuit Breaker Switch
Selection Chart 4.
Direct Drive Fan Motors - 60 Hz - Single Phase
Used with Fan Motor HP Motor RPM 120 VAC SY Series/Fuses 240 VAC SY Series/Fuses
9”-10” 1/6 3250 SY2025 / 2.5A ----
9”-10” 1/6 3250 ---- SY2018 / 1.8A
14” 1/8 1625 SY2018 / 1.8A SY2010 / 1.0A
16” 1/4 1625 SY2035 / 3.5A SY2018 / 1.8A
18” 1/3 1625 SY2050 / 5.0A SY2035 / 3.5A
24”-26” 1/3 1075 SY2050 / 5.0A SY2035 / 3.5A
36” 1/2 850 SY2080 / 8.0A SY2050 / 5.0A
36” 1/2 825 SY2080 / 8.0A SY2050 / 5.0A
36”-48” 1 850 ---- SY2070 / 7.0A
Belt Drive Fan Motors - 60 Hz - Single Phase
36” 1/2 1725 SY2070 / 7.0A SY2035 / 3.5A
36” 1/2-0.14 1725-1140 ---- SY2035 / 3.5A
36”-51” 1.0-0.29 1725-1140 ---- SY2070 / 7.0A
36”-54” 1 1725 SY2150 / 15.0A SY2080 / 8.0A
36”-60” 1-1/2 1725 ---- SY2100 / 10.0A
48”-60” 1.5-0.44 1725-1140 ---- SY2080 / 8.0A
48”-60” 2 1725 ---- SY2150 / 15.0A
Pumps - Single Phase Motors
Catalog No. Motor HP Motor RPM 120 VAC SY Series/Fuses 240 VAC SY Series/Fuses
EC1119 3/10 1725 SY2100 / 10.0A ----
EC1319* 1/3 1750 SY2070 / 7.0A ----
EC1122* 4/10 1750 SY2150 / 15.0A ----
EC1123* 4/10 1750 ---- SY2080 / 8.0A
EC1163 4/10 1725 SY2150 / 15.0A ----
EC1225 4/10 1600 SY2150 / 15.0A ----
EC1227 4/10 1600 ---- SY2080 / 8.0A
EC1120 1/2 1725 SY2150 / 15.0A ----
EC1320 1/2 1725 ---- SY2070 / 7.0A
EC1154 1/2 3450 SY2150 / 15.0A SY2080 / 8.0A
EC1155* 3/4 3450 SY2150 / 15.0A SY2100 / 10.0A
EC1156* 1 3450 ---- SY2150 / 15.0A
EC1228 1 3450 ---- SY2150 / 15.0A
EC1269* 1 3450 ---- SY2150 / 15.0A
*Currently Available Pumps
