Murata LBEE58D1VF-TEMP User manual

Preliminary Specification Number : SP-8D1VF-H
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
W-LAN+Bluetooth Combo Module Data Sheet
Qualcomm Chipset QCA6390
for IEEE802.11a/b/g/n/ac/ax 2*2 MIMO + BT 5.1
Sample P/N : LBEE58D1VF-TEMP

Preliminary Specification Number : SP-8D1VF-H
1 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
The revision history of the product specification
Revised No.
Revised Date
Note
-
2019.3.5
Initial Release
A
2019.3.29
2.1 Block Diagram Updated
3. ABSOLUTE MAXIMUM RATINGS Updated
4. OPERATING CONDITION Updated
5.1 Dimensions Update and <PIN SHAPE>
5.2 Pin Layput updated
9. LAND PATTERN (TOP VIEW) Updated
Added 5.3. Module PIN Descriptions
Added 6. POWER OF SEQUENCE
B
2019.5.29
5.1 UBM sizu Updated
2. Weight Updated
C
2019.6.3
5. Added Marking information(Tentative)
10. Added Dimensions of Tape(Tentative)
D
2019.7.1
2.1 Changed block diagram (remove xtal inside module)
5.1 Changed pin shape
5.2 Changed pin shape and pin description (XTALO->XTALI)
5.3 Changed pin description (XTALO->XTALI)
9 Changed pin shape
E
2019.8.23
3. ABSOLUTE MAXIMUM RATINGS updated
4. OPERATING CONDITION updated
F
2019.9.10
7. REFERENCE CIRCUIT
Added the latest circuit
10.TAPE AND REEL PACKING
(1) Dimensions of Tape (Plastic tape
Change tape dimensions for MP
(4) Leader and Tail tape
Changed packaging unit to 2000pcs/reel for MP
G
2019.12.15
8. ELECTRONICAL CHARACTERISTICS
Updated the value
H
2019.12.26
5.3 Revised pin description for terminal P1 and P2.

Preliminary Specification Number : SP-8D1VF-H
2 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
TABLE OF CONTENTS
1. SCOPE..................................................................................................................................................... 3
2. KEY FEATURE ...................................................................................................................................... 3
2.1. Block Diagram .......................................................................................................................... 3
2.2. Ordering Information............................................................................................................... 3
2.3. RoHS Compliance..................................................................................................................... 3
3. ABSOLUTE MAXIMUM RATINGS...................................................................................................... 4
4. OPERATING CONDITION ................................................................................................................... 4
5. DIMENSIONS, MARKING AND TERMINAL CONFIGURATIONS ................................................. 5
5.1. Dimensions ............................................................................................................................... 5
5.2. Pin Layout................................................................................................................................. 7
5.3. Module PIN Descriptions....................................................................................................... 10
6. POWER OF SEQUENCE..................................................................................................................... 14
7. REFERENCE CIRCUIT....................................................................................................................... 15
8. ELECTORICAL CHARACTERISTICS (Chain 0/1) ........................................................................... 16
8.1. DC/RF Characteristics for IEEE802.11b - 2.4GHz.............................................................. 16
8.2. DC/RF Characteristics for IEEE802.11g - 2.4GHz .............................................................. 16
8.3. DC/RF Characteristics for IEEE802.11n - 2.4GHz.............................................................. 17
8.4. DC/RF Characteristics for IEEE802.11ax - 2.4GHz............................................................ 17
8.5. DC/RF Characteristics for IEEE802.11a - 5GHz ................................................................. 18
8.6. DC/RF Characteristics for IEEE802.11n(HT 20/40MHz) - 5GHz....................................... 18
8.7. DC/RF Characteristics for IEEE802. 11ac (VHT20/VHT40/VHT80) - 5GHz .................... 20
8.8. DC/RF Characteristics for IEEE802. 11ax (HE20/HE40/HE80) - 5GHz ........................... 21
8.9. DC/RF Characteristics for Bluetooth.................................................................................... 22
8.10. DC/RF Characteristics for Bluetooth（LE）.................................................................... 23
9. LAND PATTERN (TOP VIEW)............................................................................................................ 24
10. TAPE AND REEL PACKING........................................................................................................... 25
11. NOTICE............................................................................................................................................. 28
11.1. Storage Conditions: ............................................................................................................ 28
11.2. Handling Conditions: ......................................................................................................... 28
11.3. Standard PCB Design (Land Pattern and Dimensions):................................................. 28
11.4. Notice for Chip Placer: ....................................................................................................... 28
11.5. Soldering Conditions: ......................................................................................................... 29
11.6. Cleaning: ............................................................................................................................. 29
11.7. Operational Environment Conditions:.............................................................................. 29
11.8. Input Power Capacity:........................................................................................................ 30
12. PRECONDITION TO USE OUR PRODUCTS ............................................................................... 31
Please be aware that an important notice concerning availability, standard warranty and use in critical applications of
Murata products and disclaimers thereto appears at the end of this specification sheet.

Preliminary Specification Number : SP-8D1VF-H
3 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
1. SCOPE
This specification is applied to the IEEE802.11a/b/g/n/ac/ax W-LAN + BT5.1 combo module.
2. KEY FEATURE
- Qualcomm QCA6390 inside
- Compliant with IEEE802.11a/b/g/n/ac/ax
- Supports W-LAN 2*2 MU-MIMO
- DBS(Dual band simultaneous) with dual MAC, up to 1774.5Mbps data rate (2*2 + 2*2, 11ax DBS)
- Compliant with BT specification
- 5G Rx Splitters inside for ANT sharing w/LAA
- Surface mount type 8.75 x 7.0 mm (Typical), H = 1.1 mm (Max)
- Extreme size efficient dual side mount structure with conformal shield.
- Weight : 0.19g
- MSL : 3
2.1. Block Diagram
2.2. Ordering Information
Ordering Part Number
Description
LBEE58D1VF-TEMP
In case of sample order
LBEE58D1VF-TEMP-D
EVK
2.3. RoHS Compliance
This module is compliant with the RoHS directive.

Preliminary Specification Number : SP-8D1VF-H
4 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
3. ABSOLUTE MAXIMUM RATINGS
Parameter
min.
max.
Unit
Storage Temperature
-40
85
deg.C
Supply Voltage
RFA0P8_LDO_IN
-0.3
Vddx+0.2
V
RFA12_LDO_IN
-0.3
Vddx+0.2
V
RFA17_LDO_IN
-0.3
Vddx+0.2
V
PCIE0P92_LDO_IN
-0.3
Vddx+0.2
V
PCIE18_LDO_IN
-0.3
Vddx+0.2
V
CX_MX_BT_LDO_IN
-0.3
Vddx+0.2
V
AON_RFACMN_LDO_IN
-0.3
Vddx+0.2
V
VDD18_DIG_IO
-0.3
Vddx+0.2
V
VPH_PA_2G_CH0,
VPH_PA_2G_CH1,
VPH_PA_5G_CH0,
VPH_PA_5G_CH1
-0.3
5.25
V
* Vddx is the supply voltage associated with the input or output pin to whichthe test voltage is
applied.
* Stresses in excess of the absolute ratings may cause permanent damage. Functional operation
is not implied under these conditions. Exposure to absolute ratings for extended periods of time
may adversely affect reliability. No damage assuming only one parameter is set at limit at a time
with all other parameters are set within operating condition.
4. OPERATING CONDITION
Parameter
min.
typ.
max.
unit
Operating Temperature*1
-20
25
+75
deg.C
Supply Voltage
RFA0P8_LDO_IN
0.9
0.95
1.0
V
RFA12_LDO_IN
1.3
1.38
1.42
V
RFA17_LDO_IN
1.9
2.0
2.1
V
PCIE0P92_LDO_IN
1.28
1.35
1.45
V
PCIE18_LDO_IN
1.9
2.0
2.1
V
CX_MX_BT_LDO_IN
0.9
0.95
1.0
V
AON_RFACMN_LDO_IN
0.9
0.95
1.89
V
VDD18_DIG_IO
1.71
1.8
1.89
V
VPH_PA_2G_CH0,
VPH_PA_2G_CH1,
VPH_PA_5G_CH0,
VPH_PA_5G_CH1
3.0
3.85
4.6
V
* Functionality is guaranteed but specifications require derating at extreme temperatures.

Preliminary Specification Number : SP-8D1VF-H
5 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
5. DIMENSIONS, MARKING AND TERMINAL CONFIGURATIONS
5.1. Dimensions
<TOP VIEW>
<SIDE VIEW>

Preliminary Specification Number : SP-8D1VF-H
6 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
(Marking information)
Lot No
2D code
1pin mark
Murata Logo
Module Type

Preliminary Specification Number : SP-8D1VF-H
7 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
5.2. Pin Layout
<TOP VIEW>
Address
X
Y
Net Name
A1
0.325
0.35
GND
A2
0.325
0.8
PCIE_TXN
A3
0.325
1.25
GND
A4
0.325
1.7
PCIE_RXP
A5
0.325
2.15
GND
A6
0.325
2.6
PCIE_REFCLKN
A7
0.325
3.05
GND
A8
0.325
3.5
WLAN_SW_CTRL
A9
0.325
3.95
CLK_OUT_REF
A10
0.325
4.4
PCIE0P92_LDO_IN
A11
0.325
4.85
GND
A12
0.325
5.3
RFA0P8_LDO_IN
A13
0.325
5.75
CX_MX_BT_LDO_IN
A14
0.325
6.2
VDD18_DIG_IO
A15
0.325
6.65
GND
B1
0.775
0.35
GND
B2
0.775
0.8
PCIE_TXP
B3
0.775
1.25
GND
B4
0.775
1.7
PCIE_RXN
B5
0.775
2.15
GND
B6
0.775
2.6
PCIE_REFCLKP
B7
0.775
3.05
GND
B8
0.775
3.5
PCIE_CLKREQ#
B9
0.775
3.95
WL_LED/PCIE_BAR_SIZE0
B10
0.775
4.4
GND
B11
0.775
4.85
PCIE18_LDO_IN
B12
0.775
5.3
GND
B13
0.775
5.75
CX_MX_BT_LDO_IN

Preliminary Specification Number : SP-8D1VF-H
8 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
B14
0.775
6.2
GND
B15
0.775
6.65
RFA12_LDO_IN
C1
1.225
0.35
PCIE_WAKE#
C2
1.225
0.8
GND
C14
1.225
6.2
AON_RFACMN_LDO_IN
C15
1.225
6.65
GND
D1
1.675
0.35
LF_CLK_IN
D2
1.675
0.8
PCIE_RST#
D14
1.675
6.2
GND
D15
1.675
6.65
RFA17_LDO_IN
E1
2.125
0.35
BT_I2S0_SDO/EDL_MODE
E2
2.125
0.8
BT_I2S0_SCK/BT_SLIMBUS_CLK
E14
2.125
6.2
CLK_REQ_IN
E15
2.125
6.65
GND
F1
2.575
0.35
BT_I2S0_SDI/BT_SLIMBUS_DATA
F2
2.575
0.8
BT_I2S0_WS
F14
2.575
6.2
GND
F15
2.575
6.65
WLAN_EN
G1
3.025
0.35
BT_SENS_RXD
G2
3.025
0.8
BT_SENS_TXD/CPU_INIT_RESET
G14
3.025
6.2
GND
G15
3.025
6.65
BT_EN
H1
3.475
0.35
XTAL_GND
H2
3.475
0.8
XTAL_GND
H14
3.475
6.2
GND
H15
3.475
6.65
LAA_AS_EN
J1
3.925
0.35
XTALI
J2
3.925
0.8
XTAL_GND
J14
3.925
6.2
WL_PA_MUTE
J15
3.925
6.65
WL_TXEN
K1
4.375
0.35
XTAL_GND
K2
4.375
0.8
XTAL_GND
K14
4.375
6.2
LAA_TXEN
K15
4.375
6.65
LAA_RX
L1
4.825
0.35
BT_UART_CTS
L2
4.825
0.8
BT_UART_RXD
L14
4.825
6.2
GND
L15
4.825
6.65
GND
M1
5.275
0.35
BT_UART_TXD
M2
5.275
0.8
BT_UART_RTS
M14
5.275
6.2
GPS_COEX/PBL_BOOTSPEED_0
M15
5.275
6.65
CLK_REQ_OUT/PBL_FAST_BOOT
N1
5.725
0.35
COEX_TXD/BOOT_FROM_ROM
N2
5.725
0.8
COEX_RXD
N14
5.725
6.2
WL_UART_RXD
N15
5.725
6.65
WL_UART_RTS/PBL_AUTH_EN
P1
6.175
0.35
HST_SLM_CH0_CTL0/CLK_REQ_0
P2
6.175
0.8
HST_SLM_CH0_CTL1/CLK_REQ_1
P14
6.175
6.2
GND
P15
6.175
6.65
WL_UART_TXD/WDOG_DISABLE
Q1
6.625
0.35
HST_SLM_CH1_CTL0/PBL_BOOTSPEED_1

Preliminary Specification Number : SP-8D1VF-H
9 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
Q2
6.625
0.8
HST_SLM_CH1_CTL1/XO_TCXO_SEL
Q14
6.625
6.2
GND
Q15
6.625
6.65
GND
R1
7.075
0.35
GND
R2
7.075
0.8
GND
R14
7.075
6.2
GND
R15
7.075
6.65
GND
S1
7.525
0.35
5G_CH0_LTE-U_RX_AS
S2
7.525
0.8
GND
S14
7.525
6.2
GND
S15
7.525
6.65
2G_CH1
T1
7.975
0.35
GND
T2
7.975
0.8
GND
T3
7.975
1.25
VPH_PA_5G_CH0
T4
7.975
1.7
GND
T5
7.975
2.15
GND
T6
7.975
2.6
GND
T7
7.975
3.05
GND
T8
7.975
3.5
GND
T9
7.975
3.95
GND
T10
7.975
4.4
GND
T11
7.975
4.85
GND
T12
7.975
5.3
VPH_PA_5G_CH1
T13
7.975
5.75
GND
T14
7.975
6.2
GND
T15
7.975
6.65
GND
V1
8.425
0.35
GND
V2
8.425
0.8
GND
V3
8.425
1.25
VPH_PA_2G_CH0
V4
8.425
1.7
GND
V5
8.425
2.15
2G_CH0
V6
8.425
2.6
GND
V7
8.425
3.05
GND
V8
8.425
3.5
5G_CH0
V9
8.425
3.95
GND
V10
8.425
4.4
5G_CH1_LTE-U_RX_AS
V11
8.425
4.85
GND
V12
8.425
5.3
VPH_PA_2G_CH1
V13
8.425
5.75
GND
V14
8.425
6.2
5G_CH1
V15
8.425
6.65
GND

Preliminary Specification Number : SP-8D1VF-H
10 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
5.3. Module PIN Descriptions
No.
Pin name
Type
System
Connection to
Description
IC pin name
A1
GND
GND
-
A2
PCIE_TXN
I/O
PCIE20_TXM
Transmiter Negative of
PCIE
A3
GND
GND
-
A4
PCIE_RXP
I/O
PCIE20_RXP
Reciver Positive of PCIE
A5
GND
GND
-
A6
PCIE_REFCLKN
I
PCIE20_REFC
LK_EPCLK_N
PCIe differential clock
input (negative). 100ohm
differential.
A7
GND
GND
-
A8
WLAN_SW_CTRL
I/O
GPIO
GPIO_46
A9
CLK_OUT_REF
I/O
GPIO
GPIO_55
A10
PCIE0P92_LDO_IN
I
VDD13_PMU_
PCIE_I
1.3 V input for 0.92 V
output LDO
A11
GND
GND
-
A12
RFA0P8_LDO_IN
I
VDD09_PMU_
RFA_I
0.9 V input for 0.8 V
output LDO
A13
CX_MX_BT_LDO_IN
I
VDD095_PMU
0.95 V input for BT LDO
A14
VDD18_DIG_IO
P
VDD for Digital I/O circuit
A15
GND
GND
-
B1
GND
GND
-
B2
PCIE_TXP
I/O
PCIE20_TXP
Transmitter Positive of
PCIE
B3
GND
GND
-
B4
PCIE_RXN
I/O
PCIE20_RXN
Receiver Negative of PCIE
B5
GND
GND
-
B6
PCIE_REFCLKP
I
WL PCIe
PCIE20_REFC
LK_EPCLK_P
PCIe differential clock
input (positive). 100ohm
differential.
B7
GND
GND
-
B8
PCIE_CLKREQ#
I/O
GPIO
GPIO_59
B9
WL_LED/PCIE_BAR_
SIZE0
I/O
GPIO
GPIO_54
B10
GND
GND
-
B11
PCIE18_LDO_IN
P
VDD19_PMU_
PCIE_I
VDD PMU for LDO input
in PCIE
B12
GND
GND
-
B13
CX_MX_BT_LDO_IN
P
VDD095_PMU
0.95 V input for BT LDO
B14
GND
GND
-
B15
RFA12_LDO_IN
P
VDD13_PMU_
RFA_I
1.3 V input for 1.2 V
output LDO
C1
PCIE_WAKE#
I/O
GPIO
GPIO_58

Preliminary Specification Number : SP-8D1VF-H
11 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
C2
GND
GND
-
C14
AON_RFACMN_LDO
_IN
P
VDD_PMU_A
ON_I
C15
GND
GND
-
D1
LF_CLK_IN
I/O
GPIO
GPIO_14
D2
PCIE_RST#
I/O
GPIO
GPIO_57
D14
GND
GND
-
D15
RFA17_LDO_IN
P
VDD19_PMU_
RFA_I
1.9 V input for 1.7 V
output LDO
E1
BT_I2S0_SDO/EDL_
MODE
I/O
GPIO
GPIO_6
E2
BT_I2S0_SCK/BT_SL
IMBUS_CLK
I/O
GPIO
GPIO_7
E14
CLK_REQ_IN
I
CLK_REQ_IN
clock request signal
E15
GND
GND
-
F1
BT_I2S0_SDI/BT_SLI
MBUS_DATA
I/O
GPIO
GPIO_4
F2
BT_I2S0_WS
I/O
GPIO
GPIO_5
F14
GND
GND
-
F15
WLAN_EN
I
WLAN_EN
Enable WLAN
G1
BT_SENS_RXD
I/O
GPIO
GPIO_9
G2
BT_SENS_TXD/CPU_
INIT_RESET
I/O
GPIO
GPIO_8
G14
GND
GND
-
G15
BT_EN
I
BT_EN
Enable BT
H1
XTAL_GND
GND
-
H2
XTAL_GND
GND
-
H14
GND
GND
-
H15
LAA_AS_EN
I
LAA_AS_EN
Enable LTE-U Antenna
Sharing
J1
XTALI
I
XTALI
J2
XTAL_GND
GND
-
J14
WL_PA_MUTE
I/O
GPIO
GPIO_43
J15
WL_TXEN
I/O
GPIO
GPIO_41
K1
XTAL_GND
GND
-
K2
XTAL_GND
GND
-
K14
LAA_TXEN
I/O
GPIO
GPIO_40
K15
LAA_RX
I/O
GPIO
GPIO_42
L1
BT_UART_CTS
I/O
GPIO
GPIO_2
L2
BT_UART_RXD
I/O
GPIO
GPIO_0
L14
GND
GND
-
L15
GND
GND
-
M1
BT_UART_TXD
I/O
GPIO
GPIO_1
M2
BT_UART_RTS
I/O
GPIO
GPIO_3

Preliminary Specification Number : SP-8D1VF-H
12 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
M14
GPS_COEX/PBL_BO
OTSPEED_0
I/O
GPIO
GPIO_47
M15
CLK_REQ_OUT/PBL
_FAST_BOOT
I/O
GPIO
GPIO_56
N1
COEX_TXD/BOOT_F
ROM_ROM
I/O
GPIO
GPIO_11
N2
COEX_RXD
I/O
GPIO
GPIO_10
N14
WL_UART_RXD
I/O
GPIO
GPIO_49
N15
WL_UART_RTS/PBL_
AUTH_EN
I/O
GPIO
GPIO_52
P1
HST_SLM_CH0_CTL
0/CLK_REQ_0
I/O
GPIO
GPIO_36
P2
HST_SLM_CH0_CTL
1/CLK_REQ_1
I/O
GPIO
GPIO_37
P14
GND
GND
-
P15
WL_UART_TXD/WD
OG_DISABLE
I/O
GPIO
GPIO_50
Q1
HST_SLM_CH1_CTL
0/PBL_BOOTSPEED_
1
I/O
GPIO
GPIO_38
Q2
HST_SLM_CH1_CTL
1/XO_TCXO_SEL
I/O
GPIO
GPIO_39
Q14
GND
GND
-
Q15
GND
GND
-
R1
GND
GND
-
R2
GND
GND
-
R14
GND
GND
-
R15
GND
GND
-
S1
5G_CH0_LTE-U_RX_
AS
RF
RF
Antenna sharing 5G_CH0
and LTE-U
S2
GND
GND
-
S14
GND
GND
-
S15
2G_CH1
RF
RF
ANT
T1
GND
GND
-
T2
GND
GND
-
T3
VPH_PA_5G_CH0
P
Power from Battery for
5G_CH0_PA
T4
GND
GND
-
T5
GND
GND
-
T6
GND
GND
-
T7
GND
GND
-
T8
GND
GND
-
T9
GND
GND
-
T10
GND
GND
-
T11
GND
GND
-
T12
VPH_PA_5G_CH1
P
Power from Battery for
5G_CH1_PA

Preliminary Specification Number : SP-8D1VF-H
13 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
T13
GND
GND
-
T14
GND
GND
-
T15
GND
GND
-
V1
GND
GND
-
V2
GND
GND
-
V3
VPH_PA_2G_CH0
P
Power from Battery for
2G_CH0_PA
V4
GND
GND
-
V5
2G_CH0
RF
RF
ANT
V6
GND
GND
-
V7
GND
GND
-
V8
5G_CH0
RF
RF
ANT
V9
GND
GND
-
V10
5G_CH1_LTE-U_RX_
AS
RF
RF
Antenna sharing 5G_CH1
and LTE-U
V11
GND
GND
-
V12
VPH_PA_2G_CH1
P
Power from Battery for
2G_CH1_PA
V13
GND
GND
-
V14
5G_CH1
RF
RF
ANT
V15
GND
GND
-

Preliminary Specification Number : SP-8D1VF-H
14 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
6. POWER OF SEQUENCE

Preliminary Specification Number : SP-8D1VF-H
15 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
7. REFERENCE CIRCUIT

Preliminary Specification Number : SP-8D1VF-H
16 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
8. ELECTORICAL CHARACTERISTICS (Chain 0/1)
8.1. DC/RF Characteristics for IEEE802.11b - 2.4GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
11Mbps mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11b-2.4GHz
Mode
CCK
Channel frequency (spacing)
2412 to 2472 MHz (5MHz)
Current Consumption
Min.
Typ.
Max.
unit
(a) Tx mode
-
-
350
mA
(b) Rx mode
-
-
90
mA
Transmitter
Min.
Typ.
Max.
Unit
Power Levels(Power setting : 21dBm)
18.5
21
23.5
dBm
Spectrum Mask
(a) 1st side lobes
-
-
-30
dBr
(b) 2nd side lobes
-
-
-50
dBr
Power-on/off ramp
-
-
2.0
Usec
Modulation Accuracy
-
-
35
%
Spurious Emissions (BW=100kHz)
(a) 30-1000MHz
-
-
-36
dBm
(b) 1000-12500MHz
-
-
-30
dBm
(c) 1800-1900MHz
-
-
-47
dBm
(d) 5150-5300MHz
-
-
-47
dBm
Receiver *FER< 8%
Min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-76
dBm
8.2. DC/RF Characteristics for IEEE802.11g - 2.4GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
54Mbps mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11g-2.4GHz
Mode
OFDM
Channel frequency (spacing)
2412 to 2472 MHz (5MHz)
Current Consumption
Min.
Typ.
Max.
Unit
(a) Tx mode
-
340
mA
(b) Rx mode
-
90
mA
Transmitter
Min.
Typ.
Max.
Unit
Power Levels (Power setting : 18dBm)
15.5
18
20.5
dBm
Spectrum Mask
(a) at fc +/- 11MHz
-
-
-20
dBr
(b) at fc +/- 20MHz
-
-
-28
dBr
(c) at fc > +/-30MHz
-
-
-40
dBr
Constellation Error
-
-
-25
dB
Spurious Emissions (BW=100kHz)
(a) 30-1000MHz
-
-
-36
dBm
(b) 1000-12500MHz
-
-
-30
dBm
(c) 1800-1900MHz
-
-
-47
dBm
(d) 5150-5300MHz
-
-
-47
dBm
Receiver *PER< 10%
Min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-65
dBm

Preliminary Specification Number : SP-8D1VF-H
17 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
8.3. DC/RF Characteristics for IEEE802.11n - 2.4GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
65Mbps (MCS7) mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11n-2.4GHz
Mode
OFDM
Channel frequency (spacing)
2412 to 2472 MHz (5MHz)
Current Consumption
Min.
Typ.
Max.
Unit
(a) Tx mode
-
300
mA
(b) Rx mode
-
90
mA
Transmitter
Min.
Typ.
Max.
Unit
Power Levels (Power setting :16dBm)
13.5
16
18.5
dBm
Spectrum Mask
(a) at fc +/- 11MHz
-
-
-20
dBr
(b) at fc +/- 20MHz
-
-
-28
dBr
(c) at fc > +/-30MHz
-
-
-45
dBr
Constellation Error
*measured at full packet channel estimation
-
-
-27
dB
Spurious Emissions (BW=100kHz)
(a) 30-1000MHz
-
-
-36
dBm
(b) 1000-12500MHz
-
-
-30
dBm
(c) 1800-1900MHz
-
-
-47
dBm
(d) 5150-5300MHz
-
-
-47
dBm
Receiver *PER< 10%, LDPC enabled
Min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-64
dBm
8.4. DC/RF Characteristics for IEEE802.11ax - 2.4GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
MCS9 mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11ax-2.4GHz
Mode
OFDM
Channel frequency (spacing)
2412 to 2472 MHz (5MHz)
Current Consumption
Min.
Typ.
Max.
Unit
(b) Tx mode
-
350
mA
(b) Rx mode
-
90
mA
Transmitter
Min.
Typ.
Max.
Unit
Power Levels (Power setting : 16dBm)
13.5
16
18.5
dBm
Spectrum Mask
(a) at fc +/- 11MHz
-
-
-20
dBr
(b) at fc +/- 20MHz
-
-
-28
dBr
(c) at fc > +/-30MHz
-
-
-45
dBr
Constellation Error
*measured at full packet channel estimation
-
-
-32
dB
Spurious Emissions (BW=100kHz)
(a) 30-1000MHz
-
-
-36
dBm
(b) 1000-12500MHz
-
-
-30
dBm
(c) 1800-1900MHz
-
-
-47
dBm
(d) 5150-5300MHz
-
-
-47
dBm
Receiver *PER< 10%, LDPC enabled
Min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-57
dBm

Preliminary Specification Number : SP-8D1VF-H
18 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
8.5. DC/RF Characteristics for IEEE802.11a - 5GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
54Mbps mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11a-5GHz
Mode
OFDM
Channel frequency (spacing)
5180MHz to 5825MHz
Current Consumption
min.
Typ.
Max.
Unit
(a) Tx mode
-
360
mA
(b) Rx mode
-
100
mA
Transmitter
min.
Typ.
Max.
Unit
Power Levels (Power setting : 18dBm)
15.5
18
20.5
dBm
Spectrum Mask
(a) at fc +/- 11MHz
-
-
-20
dBr
(b) at fc +/- 20MHz
-
-
-28
dBr
(c) at fc > +/-30MHz
-
-
-40
dBr
Constellation Error
-
-
-25
dB
Spurious Emissions (BW=100kHz)
(a) 30MHz -1GHz
-
-
-36
dBm
(b) 1GHz –26GHz
-
-
-30
dBm
Receiver *PER< 10%
min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-65
dBm
8.6. DC/RF Characteristics for IEEE802.11n(HT20) - 5GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
MCS7 mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11n-5GHz
Mode
OFDM
Channel frequency
5180MHz to 5825MHz
Current Consumption
min.
Typ.
Max.
Unit
(a) Tx mode
-
310
mA
(b) Rx mode
-
100
mA
Transmitter
min.
Typ.
Max.
Unit
Power Levels(Power setting : 17dBm)
14.5
17
19.5
dBm
Spectrum Mask
(a) at fc +/- 11MHz
-
-
-20
dBr
(b) at fc +/- 20MHz
-
-
-28
dBr
(c) at fc > +/-30MHz
-
-
-40
dBr
Constellation Error
*measured at full packet channel estimation
-
-
-27
dB
Spurious Emissions (BW=100kHz)
(a) 30MHz -1GHz
-
-
-36
dBm
(b) 1GHz –26GHz
-
-
-30
dBm
Receiver *PER< 10%, LDPC enabled
min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-64
dBm

Preliminary Specification Number : SP-8D1VF-H
19 / 31
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
8.7. DC/RF Characteristics for IEEE802.11n(HT40MHz) - 5GHz
Normal Condition : 25deg.C, Supply voltage is typ value in ”4. operating condition”
MCS7 mode unless otherwise specified.
Items
Contents
Specification
IEEE802.11n-5GHz
Mode
OFDM
Channel frequency
5190MHz to 5795MHz
Current Consumption
min.
Typ.
Max.
Unit
(b) Tx mode
-
300
mA
(b) Rx mode
-
100
mA
Transmitter
min.
Typ.
Max.
Unit
Power Levels(Power setting : 16dBm)
13.5
16
18.5
dBm
Spectrum Mask
(a) at fc +/- 21MHz
-
-
-20
dBr
(b) at fc +/- 40MHz
-
-
-28
dBr
(c) at fc > +/-60MHz
-
-
-40
dBr
Constellation Error
*measured at full packet channel estimation
-
-
-27
dB
Spurious Emissions (BW=100kHz)
(a) 30MHz -1GHz
-
-
-36
dBm
(b) 1GHz –26GHz
-
-
-30
dBm
Receiver *PER< 10%, LDPC enabled
min.
Typ.
Max.
Unit
Minimum Input Level
-
-
-61
dBm
