Murdock M-OBR4-GRD Series Installation and operating instructions

M-OBR4-GRD Series
RECESSED OUTDOOR BOTTLE FILLER WITH
BI-LEVEL DRINKING FOUNTAIN
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER:
1.800.591.9360
Technical Assistance Fax: [phone]
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
OUTDOOR BOTTLE FILLERS
NOTES TO INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical and other applicable codes.
LIMITED WARRANTY - UNITED STATES & CANADA
Murdock warrants that its products are free from defects in material or workmanship under normal use and
service for a period of one year from date of install or for 18 months after the date of shipment from the factory,
whichever comes first. The sealed refrigeration system is warranted for five years. Murdock’s liability under this
warranty shall be discharged solely by replacement or repair of defective material, provided Murdock is notified in
writing within one year from date of shipment, F.O.B. Industry, California.
This warranty does not cover installation or labor charges and does not apply to materials, which have been
damaged by other causes such as mishandling, improper care or abnormal use. The repair or replacement of the
defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Murdock under this
warranty. Murdock shall not be liable under any circumstances for incidental, consequential or direct charges
caused by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all
other warranties expressed or implied. Product maintenance instructions are issued with each unit and disregard
or non-compliance with these instructions will constitute an abnormal use condition and void the warranty.
Stainless steel must be protected on job site during construction and must be properly maintained after the water
has been introduced into the water cooler or drinking fountain, or Murdock’s limited warranty is void.
LIMITED EXPORT WARRANTY - One year on parts only.
COMPLIES WITH
Member of
MURDOCK
15125 Proctor Ave.
City of Industry, CA
91746 U.S.A.
Phone [phone]
626-336-4561
Fax [phone]
www.murdockmfg.com
Murdock assumes no responsibility for use of void or
suspended data. © Copyright Murdock, City of
Industry, CA Member of Morris Group International.
Please visit www.murdockmfg.com for most
current specifications.
7020-960-001 Date: 12/01/17
Federal
Public Law
111-380
(No Lead)
Test rating conditions are
compliant with ARI 1010.

IMPORTANT
This fixture is intended to dispense water that has been lowered in temperature, but otherwise remains
unchanged by the materials in the drinking fountain.
NOTICE
A dielectric coupling must be used to connect the drinking fountain to the water supply . A nonmetallic coupler is
furnished with this water cooler to meet this requirement.
DIMENSIONAL DRAWING
Prior to roughing in, consult with local, state, and federal codes for proper mounting height.
M-OBR4-GRD Recessed Outdoor Bottle Filler with Bi-Level Drinking Fountain
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel approach installation,
decrease height of installation by 3 inches. Provide clear floor space as required. Adjust vertical dimensions as required to
comply with federal, state, and local codes.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
M-OBR4-GRD
Page 2 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
General Notes:
1. All dimensions are in inches [mm]
*2. Dimensions shown are for recommended adult height.
Adjust vertical dimensions as necessary to comply with
federal, state & local codes
3. Stop valve not provided
OUTDOOR BOTTLE FILLERS
8"
[203]
13
8"
[35]
6"
[152]
*333
8"
[848]
8"
[203]
361
2"
[927]
325
8"
[829]
*295
8"
[752]
*375
8"
[956]
18"
[457]
203
4"
[527]
125
8"
[320]
131
4"
[337]
8"
[203]
13"
[330]
19" [483]
43
4"
[121]
SHOWN WITH
2x4 STUD WALL
243
4"
[629]
4"
[102]

IMPORTANT:
1. Water Supply Service Stop Valve, and Water Connections to be supplied by others in accordance with local
codes.
2. Waste is 1-1/4” Outer Diameter. Drinking Fountain water inlet is 1/4” outer diameter Push-In Fitting. Bottle
Filler water inlet is 1/4” Outer Diameter Push-In Fitting. Water line by others.
3. Completely flush supply lines of all foreign debris before connecting to fixture.
4. Do NOT solder tubes inserted into the chiller, bottle filler or the fountain strainer as damage to the o-rings on
the push-in fittings may result.
5. All burrs must be removed from outside of cut tubes before inserting into strainer or other components.
6. WARNING: Warranty is voided if installation is not made following current Murdock Mfg. installation
instructions and if components are assembled to the fixture that are not approved by Murdock Mfg.
7. Fixture operates within water pressure range of 25 PSIG (174 kPa) to 105 PSIG (724 kPa).
8. Per UPC 609.10-All building water supply systems in which quick acting valves are installed shall be
provided with devices to absorb the hammer caused by high pressure resulting from the quick closing of the
valve. These pressure-absorbing devices shall be approved mechanical devices. Water pressure-absorbing
devices shall be installed as close as possible to the quick closing valve
PRIOR TO INSTALLATION:
1. Read all installation instructions carefully, before proceeding.
2. Carefully remove all fixture components from packaging, preventing scratching or damage. Inspect fixture and
all parts from damages and all parts that are bolted on.
3. Provide mounting surface, adequate to support the fixture and loads on the fixture.
4. Provide rough-ins as shown on the roughing-in and dimensional drawing, including water supply, drain pipe
and gravel drain well. (See rough-in details)
5. Completely flush water supply lines of all foreign debris, before connecting to the fixture.
DRINKING FOUNTAIN START UP:
1. Before connecting power supply, but after thoroughly flushing the supply line and connecting it to the cooler,
turn on building water supply and check all connections for leaks.
2. Air within the drinking fountain system or the structure supply piping will cause an irregular bubbler outlet
stream until purged out by incoming water. Covering the bubbler with a clean cup (or similar object) is
recommended when first activating drinking fountain to prevent excessive splashing.
3. Depress front push pad until steady water stream is achieved.
4. If water flow requires adjustment, insert a slotted narrow blade screwdriver in the hole centered on the
underside of the fixture in the knee clearance area up to the flow regulator. Turning clockwise will increase
flow and turning counterclockwise will decrease flow.
5. Recheck all water connections with water flowing through system.
BOTTLE FILLER START UP:
1. Pushbutton Operated: Air within the bottle filler system or the structure supply piping will cause an irregular
spout outlet stream until purged out by incoming water. Press and hold pushbutton until steady water stream
is achieved
2. Sensor Operated: Hold container to be filled just below the sensor in the center of the filler spout and then
move the container upward and water flow will start automatically. When the container is almost filled, lower
the container below the sensor until the water stops flowing. (See label on the bottle filler.)
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
M-OBR4-GRD
Page 3 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Mounting Installation
NOTES: Dimensions shown for Adult ADA compliant installation. For Child ADA compliant parallel approach installation,
decrease height of installation by 3 inches. Provide clear floor space as required. Adjust vertical dimensions as required to
comply with federal, state, and local codes.
Note:
Electrical Service
Required for Plug-In
Transformer; Transformer
does not sit inside Botle
Filler Box.
M-OBR4-GRD
Page 4 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
1-1/4" O.D. Drinking Fountain Waste
1-1/4" O.D. Bottle Filler/Drinking Fountain Waste
1
2
1Provide wall opening as indicated in rough-in detail provided. Block-out for bottle filler box and provide structural support for
mounting plate ø1/4” anchoring holes provided.
281
2"
36"
16"
Stud Frame
Wall Spacing
321
8"
41
2"
121
2"
16"
Ø1"
19" 81
2"
1
2"
31
2" 16"
2"
5
8"
4"
1
4"
3
3
41
2"
2
57
8"
1
21"
143
8"
1/4" O.D. Drinking Fountain Supply Inlet
3
1/4" Anchoring Hardware, by others
5/16" Threaded Studs
5
6
2x6 Stud Wall, for reference only
7
5
6
7
7
Mounting Holes
4
4
GFCI Electrical Service Protected Circuit
8
for -SO Sensor Operated units, by others
26 7
8"
A.F.F.
113
16"
8
4

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Mounting Installation (Continued)
M-OBR4-GRD
Page 5 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
Mounting Plate
2x6 Stud Frame
Finish Wall, Ref. only
1
2
3
2Separate Fixture Panel, Bottle Filler Box, Mounting Plate and #10-32 x 1/4"
Screws from packaging careful to avoid damage to fixtures and fixture
sub-assemblies.
5
Anchoring Hardware,
4
4
1
2
3
Finished
Floor
36"
267
8"
1
281
2"
3Supporting Mounting Plate against wall, align Bottle Filler opening and
Mounting Plate Ø1/4" Anchoring holes with structural support before fixing to
wall with installer provided Anchoring Hardware.
provided by others
2
3
4
Bottle Filler Panel
Mounting Plate
Waste Outlet, Ref. only
1
2
3
Bottle Filler Box
4
(Plumbing may vary)
(4) #10-32 x 1/4" Phillps
5
Head Screws

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Bottle Filler Installation
M-OBR4-GRD
Page 6 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
Finished Wall1
1Position Bottle Filler Box in the center of the Mounting Plate
opening and secure with #10-32 x 1/4" Phillips Head Screws.
Note: Cutoff 2-1/2" of material from the tailpiece. See Detail A.
2Position Bottle Filler Panel and center to Mounting Plate and
secure with #10-32 x 1/2" Stainless Steel Flat Head Center
Reject Hex Screw.
3With Bottle Filler Panel installed, to open Bottle Filler, remove
#10-32 x 3/4" Flat Head Center Reject Screws and swing open
Bottle Filler.
Mounting Plate2
Bottle Filler Box3
10-32 x 1/4" Screws
4
1
2
3
2
43
1
23
4
3
Finished Wall
1
Mounting Plate
2
Bottle Filler Panel
3
10-32 x 1/2" Screws
4
Bottle Filler Panel
1
Bottle Filler
2
#10-32 x 3/4" Screws
3
1
2
32
1
2
1-1/4" OD Tailpiece
5
5
Detail A
21
2"Cutoff Material

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Drinking Fountain Installation
M-OBR4-GRD
Page 7 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
Finished Wall
1
1Install the drinking fountain threaded studs through the Bottle
Filler Panel and into the Mounting Plate so that a minimum of
1-1/4" of thread projects beyond Bottle Filler Panel .
3Align threaded studs with drinking fountain mounting
openings and slide fixtures to panel and secure with nuts
and washers.
2Remove the Drinking Fountain bottom Access Panel by
removing the Access Panel Vandal Resistant Screws. Be sure
to safeguard drain Access Panel screws.
Bottle Filler Panel
2
5/16"-18 Threaded Studs
3
1
3
2
Drinking Fountain
1
Bottom Access Panel
2
#10-32 x 3/8" Screws3
Finished Wall
1
5/16"-18 Threaded Studs
2
Drinking Fountain Housing
3
1
3
2
2
3
5/16"-18 Hex Nut4
5/16"-18 Zinc Plated Washer5
1
33
2
5
4

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Supply Connections
M-OBR4-GRD
Page 8 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
13/8" OD Water Supply Line
Shut-Off Valve
Fixture Supply Inlet
1
2
3
3/8" OD Shut-Off Valve (Ref. Only)
3/8" OD Water Supply Tubing (Ref. Only)
1
2
2Multiple Water Supply connections are required from the Building
Water Supply Line to connect to (2) 1/4" NCT x 1/4" OD Push-In
Y-Strainers and 1/4" NPT Male Fitting for the Bottle Filler Supply
Line (See Steps 3 and 4). DO NOT SOLDER. Soldering will
damage strainer O-Ring preventing a watertight seal. Layout
shown for reference only.
To Building Water
Supply Line
3/8" OD Push-in Tee (Ref. Only)
3
61/4" NCT x 1/4" OD Push-In Y-Strainer
71/4" OD x 1/4" NPT Male Fitting
91/4" OD Water Supply Tubing to Bottle Filler
3/8" OD Push-in Elbow (Ref. Only)
4
3/8" OD Push-in x 1/4" Female NPT (Ref. Only)
5
4
3
3
2
2
2
2
6
8
9
7
5
6
8
1
To Building Water
Supply Line
2
1
3
It is recommended that a supply stop be installed before making up
connections to the fixture 3/8” OD supply inlet.
81/4" OD Water Supply Tubing to
Drinking Fountain

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Supply Connections (Continued)
M-OBR4-GRD
Page 9 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
3Connect two of the Multiple Water Supply Connections to the 1/4" NCT x 1/4" OD
Push-In Y-Strainer located within the Drinking Fountains. To increase or decrease
flow, use slotted screwdriver. Re-install Access Panel with screws.
4Connect the last Multiple Water Supply Connection to the 1/4" OD Tube x 1/4"
NPT Male Fitting. (Note: An adapter is required to connect the Main Water
Supply Line to the 1/4" Male NPT Fitting). Connect the blue 1/4" OD Tube to
Bottle Filler Spout.
1/4" NCT x 1/4" OD
Drinking Fountain
1
2
Drinking Fountain Bubbler3
Pushbutton4
Bottom Access Panel5
Access Panel Scews6
Ø3
16" Hole
Slotted
Screwdriver
Decrease
Flow
Increase
Flow
34
2
1
6
5
4
Water Supply Tubing
3/8" OD x 1/4" Female NPT Adapter
1
2
1/4" OD x 1/4" NPT Male Fitting
3
Bottle Filler Spout
4
1/4" OD Blue Tube
5
3
1
4
5
2
(For Reference Only)
Push-In Y-Strainer

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Waste Plumbing Installation
M-OBR4-GRD
Page 10 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
1-1/4" Tee Assembly with 1
1Remove the 1-1/4" Tee Assemblies with compressions and the 1-1/4" OD x 4" Long
Brass Tubing from packaging.
2From the interior of the building, install Tee Assembly with Compression to
Drinking Fountain and Bottle Filler. Cut to fit Drinking Fountain tailpiece.
1-1/4" OD x 4" Long2
21
4"
1
1
2
Slip Joint Compression Nuts
1-1/4" OD Bottle Filler Tailpiece
1
2
4
3
2
2
5
1
1
4
1-1/4" Tee Assembly with
Slip Joints Compression Nuts
1-1/4" OD Drinking Fountain
3
1-1/4" OD Waste Outlet Tailpiece
4
Bottle Filler
5
Brass Tubing
Tailpiece

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Waste Plumbing Installation (Continued)
M-OBR4-GRD
Page 11 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
3
4Install P-Traps to Waste outlets. P-Traps are provided by others.
P-Trap, by others
1
2 1-1/4" OD Waste Outlet Tailpiece
Bottle Filler
3
From the interior of the building of the fixture wall, install Tee Assembly with
Compression to Drinking Fountain with Two tailpieces. Cut to fit Drinking
Fountain tailpiece.
21
4"
1-1/4" OD Vent Outlet Tailpiece
1
2 1-1/4" Tee Assembly with Slip
Joint Compression Nuts
1-1/4" OD Drinking Fountain3
1-1/4" OD Waste Outlet Tailpiece4
2
4
1
2
4
1
3
11
2
1
3
2
Tailpiece

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
1. Open Bottle Filler Access Door by unfastening #10-32
screws from Bottle Filler Access Door .
2. Locate Shut-Off Valve Knob and give it a 1/4 turn
clockwise to shut-off water supply.
3. With the Filter Assembly secured on the unit, hold the
Cap firmly, turn the Replaceable Cartridge Filter
counterclockwise to remove.
3. Remove and replace the cartridge turning clockwise to
secure.
4. Turn Shut-Off Valve Knob a 1/4 turn counterclockwise
to open water supply.
5. Test for leaks and proper operation before closing
Bottle Filler Access Door and re-fastening #10-32
Screws.
Water Filter Cartridge Replacement Instructions:
M-OBR4-GRD
Page 12 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
#10-32 Screws
Bottle Filler
Access Door
Water Inlet
Valve Open
Water Inlet
Valve Closed
Replacement
Cartridge
OUTDOOR BOTTLE FILLERS

Trouble Shooting:
IMPORTANT: BEFORE MAKING ANY OF THE REPAIRS LISTED, MAKE SURE THE
WATER CHILLER IS DISCONNECTED FROM THE ELECTRICAL SUPPLY AND THE
WATER SUPPLY VALVE IS SHUT OFF.
TROUBLE SHOOTING:
1. ADJUSTMENTS:
a. Cartridge – The water flow can be adjusted using a slotted narrow blade screwdriver and turning
clockwise to increase flow and counterclockwise to decrease flow.
b. Cold Water Thermostat – The water temperature can be adjusted using a slotted screwdriver and turning
clockwise to make colder and counterclockwise to make warmer.
c. Bubbler Stream - Bubbler can be rotated slightly to direct the stream backwards or forwards. Adjust the
stream to minimize splashing. Splashing may occur from bubbler stream if the unit is not level. Shim lower
mounting point, if necessary, to level chiller.
2. RESTRICTED OR NO WATER FLOW:
a. Ensure water supply service stop valve is fully open.
b. Verify minimum 20 psig supply line flow pressure.
c. Check for twists or kinks in outlet tubing.
d. Check the water inlet “Y” strainer. Sediment from the main supply can get trapped in the screen along
with installation materials such as pipe dope and flux. The screen should be cleaned and checked on a
regular basis and replace if needed.
e. The cartridge valve located in the water control assembly or bubbler can also become clogged with
foreign material. The cartridge valve can only be replaced and not repaired.
f. Check flow adjustment. See start up note #3.
g. Flow control in solenoid valve outlet elbow clogged remove & clean.
h. No power to transformer connections, loose or wires cut.
3. WATER DRIPS OR WILL NOT SHUT OFF:
a. Open fixture. Loosen nuts holding valve bracket assembly to bottom of fixture but, do not remove. Move
complete valve bracket assembly further back from the front push pad and tighten to lock in place.
b. Replace valve cartridge.
SENSOR TROUBLE SHOOTING:
4. IF LIGHT WITHIN SENSOR DOES NOT FLASH ONCE WHEN USER IS WITHIN RANGE:
a. Verify 120VAC input & 9VDC output transformer output 9VDC.
b. Replace defective transformer.
c. Transformer polarity crossed. Replace transformer, sensor may be damaged and also need replacement.
d. Sensor in “Security Mode” after 30 seconds of consistent detection. Remove source of detection and wait
30 seconds before checking.
e. Sensor is picking up a highly reflective surface. Eliminate cause of reflection and wait 30 seconds before
checking.
5. IF LIGHT WITHIN SENSOR LENS FLASHES ONCE WHEN THE USER IS WITHIN RANGE:
a. Repair bad connection from sensor to solenoid.
b. There is debris or scale in the solenoid assembly. Remove solenoid, pull out plunger and spring. Clean
with scale remover solution.
c. There is debris or scale in the center or two holes in convolution of the water diaphragm. Remove and
clean.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
M-OBR4-GRD
Page 13 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS

CLEANING & MAINTENANCE GUIDE:
1. Motors have lifetime lubrication and do not require scheduled maintenance.
2. Excess dirt or poor ventilation will cause the compressor overload protector to turn the compressor off and it
will cycle on and off with no cold water coming out of bubbler. Periodically clean with vacuum cleaner, air
hose or brush the condenser fins and cabinet ventilation louvers. In environments where dirt and dust is
more prevalent, clean more frequently.
3. Periodically remove fountain top and clean out in-line strainer.
4. Periodically remove access panel of cooler and clean out inline “Y’’ strainer
For Powder coated units: Units should be cleaned using a mild soap solution with a sponge or cotton cloth.
Wipe down surfaces then rinse with clean water.
For Stainless steel units:
1. To Remove water spots or rust spots, stainless steel cleaner/polish on a cloth is
recommended.
2. If there are stubborn spots or if you wish to treat a scratch, using synthetic abrasive general
purpose pads, such as Scotch-Brite™, are recommended.
3. Apply stainless steel cleaner/ polish to the synthetic abrasive pads and carefully rub the
panel with the grain.
4. DO NOT use harsh chemicals, abrasive or petroleum based cleaners. Use of these will
void the Murdock warranty. DO NOT use abrasives on powder coated units.
5. Stainless steel should be kept clean at all times. If a coating of stainless steel cleaner/
polish is maintained, stainless steel surfaces will retain their new, clean, polished
appearance indefinitely.
DRINKING FOUNTAIN CARTRIDGE REPLACEMENT/ STRAINER MAINTENANCE
Note: Use the universal maintenance tool to perform the following:
1. Strainer plug must be removed before cartridge replacement and strainer maintenance (no need to turn the
water off at the angle stop). Some residual water will drain during plug removal.
2. Clean strainer as needed using clean water.
3. Cartridge replacement - insert diamond end of the universal tool into pushbutton, rotate 90 degrees and pull
firmly to remove the button. Remove cartridge retaining nut . Remove and replace cartridge. When replacing
cartridge be sure to align the inlet and outlet ports on the cartridge with the ports in the valve body.
—NOTE: STRAINER SCREEN MUST BE IN PLACE FOR WATER TO FLOW.
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
ITEM # PART NUMBER DESCRIPTION
1 7000-050-001 Valve Cartridge Assembly
2 7000-060-000 Valve Cartridge
3 7000-053-199 Jam Nut
2
1
3
CARTRIDGE VALVE PARTS BREAKDOWN
M-OBR4-GRD
Page 14 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS

Drinking Fountain Parts Breakdown
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION
1 7000-050-001 Valve Cartridge 7 7000-021-001 "Y" Strainer
2 7000-068-001 Retaining Ring and Button Assembly 8 0112-002-000 Center Reject Allen Button Head Screw
3 7000-065-001 Recessed Pushbutton Valve Assembly 9 0296-025-199 Center Reject Hex Driver Bit
4 7000-012-001 Stainless Steel Bubbler 10 0401-128-000 #128 O-Ring
5 0152-010-000 Center Reject Allen Flat Head Screw 11 7000-017-001 Elbow, O-Ring x 1-1/4" Compression
6 7000-006-000 Flat Drain Adapter Gasket 12 7000-112-199 1-1/4" OD x 20-1/2" LG Drain Tube
11
10
12
5
3
1
2
4
6
8
9
7
M-OBR4-GRD
Page 15 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS

I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION
1 7007-081-001 WALL MOUNTED DRINKING FOUNTAIN 6 0116-004-000 #10-32 x 1/4" ROUND HEAD SCREW
2 JSMBF505-001 COVER PLATE ASSEMBLY 7 JSMBF494-001 WATER AND AIR SUPPLY COMPONENTS
3 0152-002-000 #10-32 x 1/2" FLAT HEAD SCREW 8 JSMBF504-001 WASTE OUTLET COMPONENTS
4 JSMBF475-001 BOTTLE FILLER DOOR ASSEMBLY 9 JSMBF501-001 MOUNTING PLATE ASSEMBLY
5 JSMBF462-002 BOTTLE FILLER HOUSING ASSEMBLY
1
1
4
5
9
2
3
8
7
6
M-OBR4-GRD Series Breakdown
M-OBR4-GRD
Page 16 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS

5 Bottle Filler Door Assembly Parts Breakdown
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
CONTEMPORARY WATER COOLERS
I N S TA L L AT I O N / M A I N T E N A N C E I N S T R U C T I O N S
Repairs must be made with Murdock Manufacturing parts only. Please order through your local
representative or distributor. The phone number to locate your local representative is 1.800.591.9360.
ITEM # PART NUMBER DESCRIPTION
1 JSMBF483-001 DRAIN TRAY ASSEMBLY
2 0112-011-000 #10-32 x 3/8" CENTER REJECT SCREWS
3 JSMBF483-002 DRAIN TRAY
4 0124-055-000 #8 x 3/4" PHILLIPS ROUND HEAD SCREW
5 7000-006-000 DRAIN ADAPTER GASKET
6 7003-180-000 DRAIN
7 JSMBF464-001 VALVE ASSEMBLY
8 7012-311-000 WF1 WATER FILTER
ITEM # PART NUMBER DESCRIPTION
1 7002-125-002 PUSHBUTTON ASSY.
2 0152-006-000
#10-32 x 3/4" HEX FLAT HEAD SCREW
3 JSMBF479-199 BOTTOM SCREEN
4 JSMBF480-199 ALCOVE SCREEN PLATE
5 0302-005-000 1/4-20 UNC STN. STL. HEX NUT
6 2566-050-002 BACK OUTLET PUSHBUTTON ASSY.
7 2566-022-000 ESCUTCHEON RETAINER
8 2566-001-000 AIR-TROL DIAPHRAGM
9 2566-056-199 DIAPHRAGM RETAINER, BACK OUTLET
10 1895-450-000 1/8" OD NYLON COMPRESSION NUT
11 7013-010-199 NANO SENSOR BRACKET
12 6527-108-000 #8 INTERNAL TOOTH LOCKWASHER
13 0302-003-000 #8-32 UNC STN. STL. HEX NUT
14 0331-023-000 #8 STN. STL. FLAT WASHER
15 7013-019-199 FOAM TAPE
16 7013-057-002 NANO SENSOR ASSY.
17 7013-009-001 NANO SENSOR SPACER ASSY.
18 0341-107-000 STN. STL. CLEVIS PIN
19 6560-016-000 COTTER PIN
6 Bottle Filler Housing Assembly Parts Breakdown
7
8
1
2
4
5
6
3
71098
17
16
15
14
13
12
11
Shown for
Ref. Only
1
3
4
5
2
Shown for
Ref. Only
6
18
19
M-OBR4-GRD
Page 17 of 17
New: 12/01/17
7020-960-001
MURDOCK MFG. • 15125 Proctor Avenue • City of Industry, CA 91746 USA
Phone [phone] or 626-333-2543 • Fax [phone] • www.murdockmfg.com Member of
OUTDOOR BOTTLE FILLERS
