Haws 3150FR Guide

10/18 Model 3150FR Page 1 of 5
No. 2077073(20)
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected] website: www.hawsco.com
Model 3150FR
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential damages
claimed to arise under the contract of sale. The drinking fountain manufactured by
HAWS is warranted to function if installation and maintenance instructions provided
are adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

10/18 Model 3150FR Page 2 of 5
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12"
adjustable wrench, 10" pipe wrench, 5/64” hex key wrench, 9/16”, 1/2", 7/16” socket
wrench or open end wrench.
LOCATION OF UNIT: The Model 3150FR Drinking Fountain is a wheelchair
accessible drinking water facility. The height dimensions shown, meet current ADA
requirements. When installing this unit, local, state or federal codes should be
adhered to. If height other than shown is required, then dimensions must be adjusted
accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6
ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter
is recommended.
PLUMBING CONNECTIONS: Waste outlet is female 1-1/2” Slip PVC.
MAINTENANCE: Periodically clean the strainer. Refer to 6518.2FR Valve Operation
and Maintenance Sheet for additional information.
TROUBLESHOOTING 3150FR with 6518.2FR
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop
valve is wide open. (Customer
supplied). Turn counterclockwise.
b.
Verify minimum 30psi flowing
supply pressure.
c.
Adjust valve to increase flow. See
6518.2FR Valve Manual.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2018 Haws Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1 VALVE, DUAL, FREEZE RESISTANT
2
3 STRAINER ASSY
4 BUBBLER HEAD
5 PUSH BTN ASS'Y
PARTS BOTTOM PLATE
BREAKDOWN
A
VALVE BOX
(NOT SUPPLIED)
5881PBA
5703M
6466
PBM1047
6518.2FR
1
2
45
3
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
D. OLLOM
11/25/95
20
0002077073
3150FR
1:6
11
MJ 10/23/18
JP
3 of 5
PARTS BREAKDOWN
5362
2018
FV
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
1
DETAIL A
ROTATED 90° INTO VIEW
DETAIL OF ITEM 3
ENSURE TUBE IS DISCONNECTED FROM
"PUSH-IN" TYPE CONNECTOR ON PRESSURE
REGULATOR PRIOR TO REMOVAL. APPLY A DROP
OF LOCTITE 222MS ON NOZZLE THREADS PRIOR
TO REASSEMBLING BACK ONTO BUBBLER HEAD.
REATTACH TUBE TO "PUSH-IN" TYPE
CONNECTOR ENSURING IT IS FULLY BOTTOMED
OUT.
1
NOTE: 1

BRACKET
NOTES ON SHEET 2
DETAIL "A"
TOP VIEW
NOTES:
BOLT
3/8-16X1
HEX HEAD
6"
152mm
MAIN SEWER LINE LOCATED BELOW
MINIMUM TO A POROUS GRAVEL FILL OR
[1829mm]. WASTE TO BE 1-1/4" IPS
BURY DEPTHS OF 48" [1219mm] AND 72"
CONCRETE ANCHORS
WASHERS 3/8" LOCK & 3/8" FLAT
FROST LINE (NOT SUPPLIED).
152mm
6"
Ø
40"
1016mm
IN CONCRETE SLAB
203mm
VALVE BOX
MOUNTING DETAIL
8"
OUTLET)
1/2"-13 UNC
MTG BOLTS 4X
(SUPPLIED)
8"
203mm
4X
(TO SPOUT
1054mm
41-1/2"
MOUNTING HOLES FOR
1/2" ANCHOR BOLTS
TEMPLATE
PEDESTAL
832mm
(8")
WASTE (NOT SUPPLIED)
1-1/2" SLIP PVC
CONCRETE SLAB
(NOT SUPPLIED)
30" SQUARE
PLATES ACCESS
RECESSED
470mm
18-1/2"
CONFIGURATION
OF 2 FOR CHILD
DETAILS
SEE SHEET 2
OR ADULT
HEIGHT
L-BRACKET
SEE DETAIL "A"
32-3/4"
(SUPPLIED)
1(SUPPLIED)
ARM2
1
(SUPPLIED)
1
1
DISCONNECT COUPLING TO REPLACE BUBBLER HEAD
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CJL
09/29/92
20
0002077073.D
3150FR
1:13
12
MJ 10/23/18
JP
4 of 5
INSTALLATION
5362
2018
FV
(NOT SUPPLIED)
GROUND LEVEL

AVAILABLE ARM HEIGHTS
B32-3/4" / 832mm
CLEARANCE
KNEE
A
DIM
AADULT ADA
27" / 686mm
FINISHED GRADE
29-3/4" / 756mm
CHILD ADA
24" / 610mm
OUTLET
TO SPOUT
B
NOTES:
1 PROCEDURE FOR ASSEMBLING ARM TO PEDESTAL:
IMPORTANT: L-BRACKETS ARE PRE-ASSEMBLED AND MUST NOT BE
LOOSENED FOR ANY REASON.
STEP 1: ATTACH ENTIRE ARM ASSEMBLY TO MOUNTING PLATE ON PEDESTAL
USING 3/8"-16 X 1" BOLTS AND WASHERS (SUPPLIED) AND TIGHTEN SECURELY
IN PLACE.
STEP 2: (OPTIONAL) APPLY CAULKING AS NEEDED TO FILL ANY GAP PRESENT
BETWEEN ARM AND PEDESTAL.
2 SIDE ARM IS ADJUSTABLE TO ACCOMODATE EITHER CHILD OR ADULT
HEIGHTS (SEE "AVAILABLE ARM HEIGHTS" CHART).
3 BASED ON DESIRED HEIGHT (CHILD OR ADULT) OF ARM, ORIENT
BACKPLATE AS SHOWN IN FIGURE 1 AND USE APPROPRIATE SHADED
HOLES.
4 WASTE ASSEMBLY IS SUPPLIED DISASSEMBLED. THE SHORTER OF THE
TWO PIECES IS FOR THE ARM DRAIN, AND MUST BE INSTALLED SO THAT
ANY BEND IN THE FLEX TUBING WILL ALLOW WATER TO DRAIN
COMPLETELY. THE LONGER IS FOR THE PEDESTAL DRAIN AND IS SUPPLIED
AT THE LENGTH REQUIRED TO ASSEMBLE THE UNIT WITH THE ARM AT
CHILD HEIGHT. IN ORDER TO ASSEMBLE AT ADULT HEIGHT, 3" MUST BE
CUT FROM THE END OF THE FLEX TUBING PRIOR TO ASSEMBLY. TEE IS
TO BE GLUED TO THE FLEX TUBING WASTE ARMS USING PVC PIPE CEMENT.
FIGURE 1
BACKPLATE
3
CHILD
3
ADULT
4
8"
203mm
CHILD OR ADULT
HEIGHT CONFIGURATION
DETAILS
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CJL 09/29/92
20
0002077073.D
3150FR
1:13
22
MJ 10/23/18
JP
5 of 5
INSTALLATION
5362
2018
FV
