LX2-HPA Headphone Amplifier
Instruction Manual
Introduction
Thank you for purchasing the LX2-HPA. We
sincerely hope that it will bring you many years
of outstanding listening pleasure.
Installation Precautions
Your new LX2-HPA is designed and built to
provide trouble-free performance, but as with all
electronic devices, it is necessary to observe a
few precautions:
Do not use the LX2-HPA near water. The unit
must not be exposed to dripping or splashing
and no objects lled with liquids, such as vases,
must be placed on the unit.
Keep the LX2-HPA away from heat such as
radiators. No naked flame sources, such as
lighted candles, should be placed on the unit.
Power Supply Note:
Only use approved Musical Fidelity DC power
supply. The use of other adaptors or supplies
could seriously damage the LX2-HPA.
This Hi-fi product has been tested to ensure
that its operation is not adversely affected by
normal background levels of Radio Frequency
Interference (R.F.I.), and that it does not itself
generate excessive amounts of interference.
However, if a problem persists, please contact
your Musical Fidelity agent.
Never open the case of the LX2-HPA yourself, as
this will invalidate the guarantee.
Place all connecting cables where they are not
likely to be walked on or trapped by items placed
on them.
The LX2-HPA will operate in accordance with its
specications within the following environmental
range:
• Temperature 5 to 45 degrees Celsius
• Humidity 10 to 90% non condensing
There are no user adjustments inside. Please
refer all service work to an authorised Musical
Fidelity agent.
HPA

Connections
All connections must be made before the mains
adaptor is plugged in and before any amplier
connected is switched on. Always switch off
the equipment attached to the LX2-HPA before
connecting/disconnecting power, changing
leads or inputs. This is to prevent loud noises
being put out through the headphones.
Inputs
Using good quality RCA leads (not supplied),
connect the left and right outputs from a CD
player or other audio source to the LX2-HPA
INPUT sockets.
Outputs
Two headphone sockets are available to allow
a greater range of headphones to be used
without need of adaptors. the 3.5mm Jack is
standard for 3.5mm terminated phones. The
1/4 inch (6.3mm) jack is standard for 1/4 inch
terminated headphones.
Connect the LX2-HPA left and right OUTPUTS to
the desired LINE LEVEL (e.g. AUX) inputs of the
amplier system.
Power
Plug the DC connector lead from the power
supply unit into the LX2-HPA power inlet socket,
and plug the adaptor into a convenient wall
mains outlet. Switch on the unit, and the status
LED next to the power switch will light to confirm
the unit is ready for use.
Use
You can adjust the gain by +6dB or -6dB
according to listening preference and headphone
impedance.
This product has been designed so that it may
be left on indefinitely, but please note that the
mains adapter may become warm to the touch
- this is normal.
Turn the volume on the amplifier to normal
listening levels, sit back and enjoy the music.
HPA
HPA

Basic problem solving with an amplier is similar to trouble shooting other electrical or electronic
equipment. Always check the most obvious possible causes rst, such as the following examples:
No power Power supply not switched on.
Power plug is not fully inserted into
rear power socket.
Check power supply s plugged in and
switched on.
Plug in securely.
No sound Wrong connections between input
source and the LX2-HPA.
Wrong connections between
the LX2-HPA and the following
component.
Check audio input lead
connections.
Check audio output connections.
Hum Audio connector plug not fully
pushed in.
Inset plug securely and check
leads.
If none of the above actions effect a cure, please contact your dealer, or an authorised Musical
Fidelity service agent.
Specications Total harmonic distortion
Signal / noise ratio
0.01%
>80dB
General Power requirement 12 - 24V 100mA regulated
Connections RCA Input
RCA Output
Headphone output (6.3mm)
Headphone output (3.5mm)
Power Input
1pr RCA sockets
1pr RCA sockets
1 Stereo jack socket 6.3mm
1 Stereo jack socket 3.5mm
DC Jack (1.3mm inner pin,
outer Θ 3.5mm)
Dimensions Length
Width
Height
197mm
172mm
46.50mm
Including terminals
Including feet
Weight Unit alone
Unit with packing
1.05Kg
1.50Kg
Accessories
(supplied)
Power Supply 12V 500mA
