Mustek Mp100 User manual

MPEG-4

DVD Recorder

Portable DVD Player

R100LTA

Features:

Built-in TV tuner

MPEG4 files playback

Smooth, crystal-clear progressive-scan

DVD playback

Kodak picture CD compatible & JPEG readable

DVD+R,DVD+RW record from VHS, DVD,

TV, Satellite, MP3, CD or Photo CD

R100LM

Features:

Slim and compact design

Built-in TV tuner

DivX/MPEG4 files playback, AVI

and Xvid compatible

i-link connection

Smooth, crystal-clear progressive-scan

DVD playback

Kodak picture CD compatible & JPEG readable

DVD+R,DVD+RW record from VHS,

DVD, TV, Satellite, MP3, CD or Photo CD

R100LTB

Features:

Built-in TV tuner

DivX/MPEG4 files playback

DV input

Smooth, crystal-clear

progressive-scan DVD playback

Kodak picture CD compatible &

JPEG readable

DVD+R,DVD+RW record from VHS,

DVD, TV, Satellite, MP3, CD or Photo CD

R100LTC

Features:

Built-in TV tuner

DivX/MPEG4 files playback

Smooth, crystal-clear progressive-scan DVD playback

Kodak picture CD compatible & JPEG readable

DVD+R,DVD+RW record from VHS, DVD, TV,

Satellite, MP3, CD or Photo CD

R500V1

Features:

Built-in TV tuner

Time shift and HDD editing function

DV input

VCR+plus function makes schedule recording

Kodak picture CD compatible &

JPEG readable

DVD+R,DVD+RW record from VHS,

DVD, TV, Satellite, MP3, CD or Photo CD

PVR-H140

Features:

3.6"TFT LCD(4:3)

40GB HDD

LCD resolution: 320RGBx240

AV recording (MPEG4 compatible)

TV playback through AV out

MMC/SD card reader

USB2.0 connection

PVR-H160

Features:

3.6"TFT LCD(4:3)

60GB HDD

LCD resolution: 320RGBx240

AV recording(MPEG4 compatible)

TV playback through AV out

MMC/SD card reader

USB2.0 connection

PVR-H440

Features:

7.0"TFT LCD(4:3)

40GB HDD

LCD resolution: 480RGBx234

AV recording(MPEG4/DivX compatible)

TV playback through AV out

MMC/SD card reader

USB2.0 connection

MP70B

Features:

7" wide active-matrix TFT LCD

Two Built-in Stereo Speakers

DivX/MPEG4 files playback

Kodak Picture CD & JPEG readable

Anti Shock Protection function

MMC/SD card reader

USB host

MP90

Features:

9" wide active-matrix TFT LCD

Two Built-in Stereo Speakers

DivX/MPEG4 files playback

Kodak Picture CD & JPEG readable

Anti Shock Protection function

MMC/SD card reader(option)

USB host(option)

MP100

Features:

10" wide active-matrix TFT LCD

Two Built-in Stereo Speakers

DivX/MPEG4 files playback

Kodak Picture CD & JPEG readable

Anti Shock Protection function

MMC/SD card reader(option)

USB host(option)

MP80B

Features:

8" wide active-matrix TFT LCD

Two Built-in Stereo Speakers

DivX/MPEG4 files playback

Kodak Picture CD & JPEG readable

Anti Shock Protection function

MMC/SD card reader

USB host

MP72

Features:

7" wide active-matrix TFT LCD

Two Built-in Stereo Speakers

MPEG4 files playback

AV input

Kodak Picture CD & JPEG readable

Anti Shock Protection function

MP82

Features:

8" wide active-matrix TFT LCD

Two Built-in Stereo Speakers

MPEG4 files playback

AV input

Kodak Picture CD & JPEG readable

Anti Shock Protection function

PT100D

Features:

7" wide active-matrix TFT LCD

Digital TV receiver in a slim box

(no DVD player function)

AV-in and AV-out connector

Audio/video cable for TV connection

Built-in stereo speakers

Program Auto-scan for easy operation

Mustek Pacific Inc.

6F, No.17, Sec3, Jen Ai Road,

Taipei, Taiwan,R.O.C.

http: //www.mustek.com.tw

R200LTB

Features:

Built-in TV tuner

MPEG4 files playback

DV input

Dual-Format disc support for recording

Smooth, crystal-clear progressive-scan DVD playback

Kodak picture CD compatible & JPEG readable

DVD+R,DVD+RW record from VHS, DVD, TV, Satellite,

MP3, CD or Photo CD

R200LTA

Features:

Built-in TV tuner

MPEG4 files playback

Dual-Format disc support for recording

Smooth, crystal-clear progressive-scan DVD playback

Kodak picture CD compatible & JPEG readable

DVD+R,DVD+RW record from VHS, DVD, TV, Satellite,

MP3, CD or Photo CD

Portable DVD PlayerPortable DVD Player

Portable DVD Player

DVD RecorderDVD Recorder

DVD Recorder

MPEG-4MPEG-4

MPEG-4

Model Name PVR-H140 PVR-H160 PVR-H440

Function

Digital Video Player Yes Yes Yes

Digital Video Recorder Yes Yes Yes

Digital Voice Recorder Yes Yes Yes

Digital Photo Player Yes Yes Yes

Music Player Yes Yes Yes

USB Pocket Drive Yes Yes Yes

SD/MMC Card Reader Yes Yes Yes

Game Player Yes Yes Yes

DPS Yes Yes No

USB OTG No No No

Hardware Spec.

LCD Size 3.6" TFT LCD ( 4 : 3 ) 3.6" TFT LCD ( 4 : 3 ) 7.0" TFT LCD

LCD Resolution 320RGBx240 320RGBx240 480RGBx234

H.D.D Capacity 2.5"/40GB 2.5"/60GB 2.5"/40GB

Internal Power Rechargeable Li-ion Battery Rechargeable Li-ion Battery Rechargeable Li polymer Battery

Card Slot SD/MMC SD/MMC SD/MMC

Microphone Built-in Built-in Built-in

Speaker Built-in Built-in Built-in

Television System NTSC/PAL NTSC/PAL NTSC/PAL

File Formats

Video Formats .asf , wmv, .avi, .mpeg, mpg,dat .asf , wmv, .avi, .mpeg, mpg,,dat .asf , wmv, .avi, .mpeg, mpg,,dat

Audio Formats MP3 MP3 MP3

Photo Formats .BMP, TIF, GIF, PNG,JPEG .BMP, TIF, GIF, PNG,JPEG .BMP, TIF, GIF, PNG,JPEG

Image Formats BMP, JPG BMP,JPG JPG

Play Time

Video Play Time 2.5 hrs 2.5 hrs 4 hrs

Audio Play Time 3.5 hrs 3.5 hrs 10 hrs

Dimension

Dimension(LxWxH)mm 111.1x30x80.2 111.1x30x80.2 200x27x123

Weight 290g 310g TBD

Model Name R100LM R100LTA R100LTB

Description Slim Type DVD Recorder W/DivX  Slim Type DVD Recorder W/MPEG4  Slim Type DVD Recorder W/DivX

 Playback Playback Playback

HDD N/A N/A N/A

Playable Disc Types

DVD DVD+RW/DVD+R/DVD-RW/DVD-R DVD+RW/DVD+R/DVD-RW/DVD-R DVD+RW/DVD+R/DVD-RW/DVD-R

CD  CD/CD-R/CD-RW CD/CD-R/CD-RW CD/CD-R/CD-RW

Video Format DVD/VCD/DivX(MPEG4 files) DVD/VCD/MPEG4 Compatible DVD/VCD/DivX(MPEG4 files)

Operation Features

Recording Sources S-Video/TV/DV/AV(RCA) Input S-Video/TV/AV(RCA) Input S-Video/TV/DV/AV(RCA) Input

One Touch Recording Yes Yes Yes

Progressive Scan Yes Yes Yes

Input

S-Video 1 1 1

Composite Video 1 1 1

Composite Audio 1 1 1

SCART(only for PAL Tuner) 1 1 1

DV-in(IEEE1394/i-Link) 1 N/A 1

RF Antenna Coaxial 75 OHMx1 Coaxial 75 OHMx1 Coaxial 75 OHMx1

Output 

S-Video 1 1 1

Composite Video 1 1 1

Composite Audio(5.1 CH/2CH) 1 1 1

SCART(only for PAL Tuner) 1 1 1

Digital Audio Output Coaxialx1  Coaxialx1 Coaxialx1

YPbPr/P-Scanning Either Either Either

TV Turner NTSC or SECAM/PAL NTSC or PAL NTSC or SECAM/PAL

RF TV/Modulator Coaxial 75 OHMx1 Coaxial 75 OHMx1 Coaxial 75 OHMx1

VCR+Plus(VCR+,Video+ Optional Optional Optional

Plus,Showview,G-Code)"

Dimension

Dimension(WxHxD)mm 420x53x260  420x53x260 420x53x260

Weight 3.1kg 3.1kg 3.1kg

Model Name R100LTC R200LTA R200LTB R500V1

Description Slim Type DVD Recorder W/DivX "Slim Type DVD Recorder W/MPEG4 "Slim Type DVD Recorder W/MPEG4 HDD DVD Recorder W/DVD+R/RW

 Playback Playback,Daul-Media Recordable" Playback,Daul-Media Recordable"

HDD N/A N/A N/A 80GB

Playable Disc Types 

DVD DVD+RW/DVD+R/DVD-RW/DVD-R DVD+RW/DVD+R/DVD-RW/DVD-R DVD+RW/DVD+R/DVD-RW/DVD-R DVD+RW/DVD+R/DVD-RW/DVD-R

CD  CD/CD-R/CD-RW CD/CD-R/CD-RW CD/CD-R/CD-RW CD/CD-R/CD-RW

Video Format DVD/VCD/DivX(MPEG4 files) DVD/VCD/MPEG4 Compatible DVD/VCD/DivX/MPEG4 Compatible DVD/VCD

Operation Features   

Recording Sources S-Video/TV/AV(RCA) Input S-Video/TV/AV(RCA) Input S-Video/TV/DV/AV(RCA) Input S-Video/TV/DV/AV(RCA) Input

One Touch Recording Yes Yes Yes Yes

Progressive Scan Yes Yes Yes Yes

Input 

S-Video 1 1 1 2

Composite Video 1 1 1 2

Composite Audio 1 1 1 2

SCART(only for PAL Tuner) 1 1 1 1

DV-in(IEEE1394/i-Link) N/A N/A 1 1

RF Antenna Coaxial 75 OHMx1 Coaxial 75 OHMx1 Coaxial 75 OHMx1 Coaxial 75 OHMx1

Output

S-Video 1 1 1 1

Composite Video 1 1 1 1

Composite Audio(5.1 CH/2CH) 1 1 1 1

SCART(only for PAL Tuner) 1 1 1 1

Digital Audio Output Coaxialx1  Coaxialx1 Coaxialx1 Coaxialx1,optionalx1

YPbPr/P-Scanning Either Either Either Either

TV Turner NTSC or PAL NTSC or SECAM/PAL NTSC or SECAM/PAL NTSC or PAL

RF TV/Modulator 0 0 0 Coaxial 75 OHMx1

"VCR+Plus(VCR+,Video+ Optional Optional Optional Optional

Plus,Showview,G-Code)"

Dimension 

Dimension(WxHxD)mm 420x53x260  350x50x250 350x50x250 430x76x290

Weight 3.1kg <5kg <5kg 4.8kg

Model Name  MP80B  MP72 MP82  MP90  MP100  PT100D

Description 8" Portable DVD Player 7" Portable DVD Player 8" Portable DVD Player 9" Portable DVD Player 10"" Portable DVD Player 7" Digital TV Receiver

Video Compatibility DVD Playback,Kodak Picture CD & DVD Playback,Kodak Picture CD & DVD Playback,Kodak Picture CD DVD Playback,Kodak Picture CD DVD Playback,Kodak Picture CD & No DVD Player Function

 JPEG,MPEG4 (DivX)  JPEG,MPEG4  & JPEG,MPEG4  & JPEG,MPEG4 (DivX) JPEG,MPEG4 (DivX)

Audio Compabibility CD,CD-R,CD-RW,MP3 CD,CD-R,CD-RW,MP3 CD,CD-R,CD-RW,MP3  CD,CD-R,CD-RW,MP3 CD,CD-R,CD-RW,MP3 No

Audio Characteristic 2-Channel Analog 2-Channel Analog 2-Channel Analog 2-Channel Analog 2-Channel Analog 2-Channel Analog

  5.1-Channel Digital Output 5.1-Channel Digital Output 5.1-Channel Digital Output 5.1-Channel Digital Output  5.1-Channel Digital Output TBD

Dolby Digital Decoding Yes Yes Yes Yes Yes TBD

Screen  8"Wide Screen Active-Matrix  7" Wide Screen Active-Matrix  8" Wide Screen Active-Matrix 9" Wide Screen Active-Matrix 10" Wide Screen Active-Matrix 7" Wide Screen Active-Matrix

 TFT LCD" TFT LCD TFT LCD" TFT LCD"  TFT LCD

Speaker Two Built-in Stereo Speakers Two Built-in Stereo Speakers Two Built-in Stereo Speakers Two Built-in Stereo Speakers Two Built-in Stereo Speakers Two Built-in Stereo Speakers

Anti Shock Protection Yes Yes Yes Yes Yes Yes

DivX Playback Yes Optional Optional Yes Yes N/A

Analog TV Tuner N/A N/A N/A N/A N/A N/A

IR Earphone N/A N/A N/A N/A N/A N/A

Terminals

Audio/Video Oupput 1 1 1 1 1 1

Audio/Video Input N/A 1 1 1 1 1

S-Video/P-Scan Output  1(No S-Video) 1(No S-Video) 1(No S-Video) 1(Option) 1(Option) N/A

SD/MMC Card Slot  1 N/A N/A 1(Option) 1(Option)  N/A

USB Host 1 N/A N/A 1(Option) 1(Option) N/A

Digital Audido Output(Coaxial) 1 1  1 1(Option)  1(Option)  N/A

Earphone Jack 1 1 1 2  2 1

Power Consumption  Approx. 15W (12V,1.25A) Approx. 15W (12V,1.25A)  Approx. 15W (12V,1.25A)  Approx. 15W (12V,1.25A) Approx. 15W (12V,1.25A) Approx. 15W (12V,1.25A)

Dimension

Dimension(LxWxH)mm 210x155x41 210x155x41 210x155x41 282x195x45.6 282x195x45.6 210x140x24

Weight 832g 800g 832g 1230g 1230g TBD

Model Name  MP70B

Description 7" Portable DVD Player

Video Compatibility DVD Playback,Kodak Picture CD

 & JPEG,MPEG4 (DivX)

Audio Compabibility CD,CD-R,CD-RW,MP3

Audio Characteristic 2-Channel Analog

  5.1-Channel Digital Output

Dolby Digital Decoding Yes

Screen  7" Wide Screen Active-Matrix
