MVP Kool-It KCD-36R Operating instructions

KCD-36 48 CURVEDCURVED GLASSGLASS DELYDELY CCASEASE
KCD-36R
KCD-48R
Visit us on the web at www.mvpgroupcorp.com

Specifications
Pdt
CURVED GLASS DELY CASE
P
ro
d
uc
t
CURVED GLASS DELY CASE
Model KCD-36R KCD-48R
Gross Capacity (cu.ft) 4.3 5.8
Exterior
Dimensions
(Including
C)
W 35.8 47.4
D 20.1
C
asters
)
[inch] H 29.3
Net Weight (lbs) 183 359
Type of refrigeration system Indirect cooling (Fan blowing)
Control Thermostat Control
Shelve 1EA (Glass)
Illumination 2EA LED Lamp
Number of Doors 2 Sliding Door
Rated Voltage AC115V /60Hz
Type of Power Cord
NEMA 5
-
15
Type
of
Power
Cord
NEMA
5
15
Amps 6.4A
Compressor (HP) 3/8 HP
Refrigerant R-134a
Range of Temperature 35~44°F
♦Specifications and Designs are subject to change without notice
2
Visit us on the web at www.mvpgroupcorp.com

Installation
1 INDOOR USE ONLY
1
.
INDOOR
USE
ONLY
1) This unit is intended for indoor use only.
2. FOR LOCATION
1) Be sure that the location is strong enough to support the total weights of the unit and the content.
2) Keep the unit away from sunlight and other heat generating equipment.
3) The minimum clearance between the back of the unit and the wall should be 7 inches at least.
3. LEVELING
1) The unit should be leveled to provide adequate drainage.
. ELECTRICAL CONNECTION
1) The unit should be plugged into a 115V/60Hz, grounded wall receptacle to
prevent electrical shock and fire hazards.
2) Do not plug other electrical units into same wall receptacle this unit is plugged into.
3) Do not use an extension cord.
4) Compressor warranties are void if the compressor burns out due to low voltage.
Maintenance & Cleaning
Maintenance & Cleaning
1. To maintain proper refrigeration performance, the condenser fins should be
checked monthly and clean with a soft brush or vacuum cleaner as needed.
2. Wait at least 6mimutes after unplugging the unit before plugging in.
3 The interior and exterior of the unit can be cleaned using plugging in water
3
.
The
interior
and
exterior
of
the
unit
can
be
cleaned
using
plugging
in
water
.
1) Do not use an abrasive cleaners to avoid scratches on the surfaces.
3
Visit us on the web at www.mvpgroupcorp.com

Operation
1. The tem
p
erature controller
(
thermostat
)
is located on the u
pp
er left of the back side of the
p() pp
cabinet interior.
2. The controller has been preset "NORMAL" position at the factory.
3. Set the control-knob toward "COOL" for higher temperature and "COLD"
for lower temperature.
4. The thermostat controls compressor's ON/OFF by sensing inside temperatures of cabinet.
5. The unit is equipped with an off-cycle defrost.
4
Visit us on the web at www.mvpgroupcorp.com

Troubleshooting
SAMPTOMS REMEDY
COMPRESSOR WILL
NOT START
•Check the power cord and make sure it is plugged in.
•Check the temperature controller. If is in the “OFF” position,
turn it clockwise to set a desired temperature.
POOR PERFORMANCE
•Move the unit away from direct sunlight.
• Move the unit away from heating devices.
•Install the unit in a well ventilated place, with at least 7 inches of
clearance on all sides.
• Clean the condenser if heav
y
dust is collected.
y
• Clear contents from blocking the air duct.
• Check the temperature controller for incorrect setting.
•Check the refrigerant level, it may need to be charged.
•Check the door and be sure it is completely closed.
NO INTERIOR LIGHT
•Turn off the light switch and turn it on again.
• Insert the bulb correctly into the socket.
• Replace the bulb.
•Install the unit on a leveled surface.
• Maintain 7 inches of clearance from the wall
UNIT NOISY
•Maintain
7
inches
of
clearance
from
the
wall
.
• Check for loose parts or mounting.
•Keep the tubing free from any contact to avoid rattle.
CONDENSAION ON
CABINT AND/OR FLOOR •Reduce humidity where the unit is installed.
5
Visit us on the web at www.mvpgroupcorp.com

MVP GROUP CORPORATION
5659 Royalmount Ave.
Montreal, QC, Canada
H4P 2P9
Telephone : [phone]
Toll Free Telephone : [phone]
Fax : [phone]
Toll Free Fax : [phone]
Email : [email protected]
Website :
www mvpgroupcorp com
6
Website :
www
.
mvpgroupcorp
.
com
12000 Biscayne Blvd. Ste 108
Miami, FL United States
33181
(786)-600-4687
(844)-218-8477
(786)-661-4100
