MX Thermostatic Care QI Guide

Thermostatic Control
Instantaneous Electric Shower
Installation and User Instructions
IMPORTANT!
This Step-by-Step guide should be given to the customer
after installation and demonstration.
Thermostatic Care
QI
Thermostatic Plus
QI

2
CONTENTS QI FEATURES
QI Features 2
Pack Contents 3
Installation
1. Shower Unit Familiarisation 4
2. Installation Check List 4
3. Important Safety Information 5
4. General Installation Layout Guide 7
5. Important Installation Information 8
6. Fixing the Shower to the Wall 9
7. Product Positioning Guide 10
8. Plumbing Connections 11
9. Electrical Connections 13
10. Changing the Operational
Programmes 16
11. Fitting the Front Cover 18
12. Riser Rail Fitting Instructions 19
13. Commissioning the Shower 20
User Guide
14. Operating the Shower 22
15. How Your Shower Works 24
16. Routine Maintenance 25
17. Troubleshooting and FAQs 26
18. Troubleshooting Checklist for
the Installer 28
19. Product Warranty 29
20. Service Policy 31
QI
QUICK INSTALLATION
a guide for installers
The MX range of QI Thermostatic
Care and Plus shower models have
been specially designed for Quick
Installation. Both water and electrics
can enter the shower unit from 8
different positions. The unit is wired
internally to accept mains cable from
both the left and right hand sides of
the back plate.
Removable corner sections allow
for easy plumbing connections.
The screw mounting hole positions
are visible when the front cover is
removed. The top two xing holes are
vertical key hole slots and the bottom
xing hole is a horizontal slot to allow
for alignment. The inlet water lter is
positioned so that it can be removed
quickly without taking the front cover
off for routine maintenance.
The MX QI Thermostatic Care and
Plus electric showers are designed
for domestic, light commercial
and healthcare applications and
are approved to the BEAB Care
performance standard.
These instructions contain all the
necessary fitting and operating
instructions for your electric shower.
Care taken during the installation
will provide a long, trouble free life
from your shower.

3
PACK CONTENTS
Please make sure
ALL components
are included before
starting the installation.
1. Shower Unit
2. Shower Handset
3. Riser Rail Tube
4. Riser Rail Brackets x2
5. Riser Rail Height
Adjuster
6. Flexible Shower Hose
7. Soap Dish
8. Hose Retaining Ring
9. Additional Wall
Handset Bracket
(Care model only)
10. Screw Packs
11. Installation and User
Instructions plus
Guarantee Card
Thermostatic Care
QI
Temperature
Flow Control
START/STOP
T
e
m
p
e
r
a
t
u
r
e
FLOW
Shower accessories
shown may vary
with product type.
• 1.ShowerUnit
• 2.ShowerHandset
• 6.Flexible
 ShowerHose
• 9.AdditionalWall
HandsetBracket
(Caremodelonly)
• 4.RiserRailBracket
• 4.RiserRailBracket
• 3.RiserRailTube
• 5.RiserRail
HeightAdjuster
• 7.SoapDish
• 8.HoseRetaining
Ring
• 10.ScrewPacks
• 11.FittingInstructions
 &GuaranteeCard
Instantaneous Electric Shower
Installation Instructions
IMPORTANT!
This Step-by-Step guide should be given to the customer
after installation and demonstration.
Thermostatic Care
QI

4
2. INSTALLATION CHECK LIST
1. Check that the water supply will satisfy requirements
2. Check that water and cable entry points of the unit meet
requirements
3. Check that the electric supply will satisfy requirements
4. Select a suitable position for the shower
5. Plumbing installation
6. Electrical installation
7. Fit to the wall and connect the shower supplies
8. ONLY Commission the shower in the way described
9. Fitting the front cover and aligning the controls
10. Familiarise yourself with the user operating instructions
Tick off as you complete
1. SHOWER UNIT FAMILIARISATION
Thermostatic Care
QI
Temperature
Flow Control
START/STOP
T
e
m
p
e
r
a
t
u
r
e
FLOW
Temperature buttons
Warmer (+) push button
Cooler (-) push button
“Secret Until Illuminated”
seven segment display
Flow Control button
Start/Stop button
NOTE: The “Secret Until Illuminated” seven segment display indicates the shower
outlet water temperature and shows through the front cover when the shower is
operating. In addition the display is programmed to show error codes should a
fault occur.
The temperature limit LED indicates, when lit, that the unit has a maximum
pre-programmed shower outlet temperature.
Temperature
Limit
Indicator LED

5
3. PLEASE READ THIS IMPORTANT SAFETY INFORMATION
Products manufactured by the MX Group are safe and without risk provided they
are installed, used and maintained in good working order in accordance with our
instructions and recommendations.
FOR THE USER:
WARNING: DO NOT operate shower if frozen, or suspected of
being frozen. It must thaw out before using.
DO NOT operate the unit if the showerhead or spray hose becomes
damaged.
DO NOT restrict ow out of shower b y placing showerhead in direct
contact with your body or ther solid object.
WARNING: the outlet of the shower acts as a vent and must not
be connected to anything other than the exible shower hose and
handset supplied or approved by the manufacturer.
DO NOT operate the shower if water ceases to ow during use or
if water has entered inside the unit because of an incorrectly tted
cover.
DO NOT place items such as soap, shampoo or other such bottles
on top of the unit as liquid could leak through the joint between the
cover and back plate and damage the sealing rubber.
The shower spray head and shower inlet lter MUST be cleaned
regularly to remove scale and debris. The frequency of the cleaning
will vary according to the local water quality. If the water outlet
temperature becomes hot and you are unable to obtain cooler
water, immediately check the shower handset and inlet lter for
blockage. See section 16 for cleaning instructions.
IMPORTANT: This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should
be supervised to ensure they do not play with the appliance.
!

!
!

!
!

!
!

!
!

!
!

!
!

!
!

!

6
FOR THE INSTALLER:
DEFAULT PLUMBING SETTING: The shower unit is supplied for right
hand mains water connection. To plumb the unit from the left of the
shower back plate you must remove the blanking cap by sliding off the
metal retaining clip and ret to the right hand side of the unit ensuring the
metal retaining clip is retted and pushed rmly into the groove. Whilst
leak testing the installation please ensure that there is NO water leaks
from this area. See Section 8: Plumbing Connections.
IMPORTANT: To comply with water regulations, building regulations or
any specic local water company regulations and in accordance with BS
EN 806 a double check valve should be tted where it is possible that the
shower head may come into contact with used water, for example in the
bath or a shower tray.
IMPORTANT: Check that there are no hidden cables or pipes before
drilling holes for the wall plugs. Chose a at piece of wall to avoid the
possibility of distorting the back plate and making the front cover a poor
t. Exercise great care when using power tools near water. The use of a
residual current device (RDC) is recommended.
IMPORTANT: Before connecting the water supply to the shower unit
the water supply pipe should be ushed out to remove all debris. After
ushing the pipe work make the connection to shower inlet and ensure
the shower is positioned squarely on the wall and all xing screws are
tightened.
IT IS VERY IMPORTANT to ensure that the terminal block screws are
FULLY tightened and that no cable insulation is trapped under the
screws. The earth continuity conductor of the electrical installation must
be effectively bonded to earth on the fuse board.
IMPORTANT: Ensure that the ow control knob is turned to FULL ow
and the commissioning instructions are followed before switching the unit
on. This will make sure that the unit is full of water when rst activated.
IMPORTANT: The shower unit MUST be full of water before the heat
settings are used.

7
4. GENERAL INSTALLATION LAYOUT GUIDE
Plan your installation carefully. Check on
the nearest and most accessible rising
main water supply, this may be beneath
the bath or in the loft, where it feeds the
water storage tank. Use only the cold
rising water main.
Avoid connecting the shower unit if
possible where it will be affected by water
drawn off by another appliance. For
example from the mains feed to the toilet
as this may cause a drop in pressure to a
level that is too low for the shower unit to
work correctly.
A WRAS (water regulations advice
scheme) listed isolating valve must be
tted between the rising main and the
unit to comply with water regulations and
to allow for routine maintenance and
servicing.
BATH
COLD WATER
MAINS SUPPLY
SEPARATE PERMANENTLY
CONNECTED SUPPLY
FROM CONSUMER UNIT
ISOLATING
STOP TAP
DOUBLE POLE
HEATER SWITCH
WALL MOUNTED
IN ACCORDANCE
WITH LOCAL
AUTHORITY
REGULATIONS
SHOWER
UNIT
BATHROOM
FLOOR
CEILING JOISTS
IMPORTANT
This appliance is not intended for use by persons (Including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
!

!
!

!

8
5. IMPORTANT INSTALLATION INFORMATION
nShower installation must be carried
out by a suitably qualied person and be
in accordance with BS 7671 (IEE wiring
regulations) building regulations, water
regulations and or any specic local water
company regulations in force and should
be in accordance with BS EN 806.
nThis shower unit is designed to be
connected to a 15mm cold water mains
supply.
nTo make sure the heating elements are
activated the shower must be connected
to mains water supply with a minimum
running pressure of 100kPa (15lb/sq in) –
1 Bar at a minimum ow rate of 8 litres per
minute. The maximum static pressure is
1000kPa (150lb/sq in) 10 Bar.
NOTE: For 9.5kW units the minimum
running pressure must be
obtained at 9 L/min.
For 10.5kW units the minimum
running pressure must be
obtained at 11 L/min.
n The shower unit must not be tted
where it may be exposed to frost, for
example in an outdoor area. The shower
must not be used if suspected of being
frozen. Frost damage is not covered by
the guarantee.
nPlumbers jointing compound must NOT
be used.
In instances of difcult joints use P.T.F.E.
Tape.
The use of jointing compound will
invalidate the product guarantee.
nDO NOT solder ttings near the
shower unit as heat can travel along pipe
work and damage components.
nDO complete all plumbing connections
before making the electrical connections.

9
6. FIXING THE SHOWER TO THE WALL
Position your shower on the wall so that it
will NOT be in the direct water spray from
the shower handset when xed.
You may wish to consider mounting the
unit so that the shower handset could be
used over a sink for washing hair.
The shower unit should be positioned so
that the shower head cannot be immersed
in the bath or shower tray when hanging
down. A shower hose retainer is supplied
with the accessories (see pages 3
and 10).
The unit can be mounted at a lower level
if required for less abled users and for use
with a shower seat.
The shower unit can be mounted at
a lower level if required for less abled
users and for use with a shower seat.
The installation should comply with the
relevant British Standard covering the
design of buildings to meet the needs of
disabled people. It is important that if this
option is chosen the shower unit must not
be mounted directly in the water spray
from the handset.
Remove the four front cover xing screws
and lift the cover off complete with the
warmer (+) and cooler (-) push buttons and
ow control knob in place.
Note: there is a connector and lead
attached to the control PCB mounted on
the shower back plate. This will require
connecting to inside of the front cover
before completing the installation.
Having decided on the water and cable
entry points and chosen a at piece of
wall hold the shower vertically against the
wall and mark the top two xing holes.
Carefully drill the two holes as marked
using a sharp 5.5mm masonry drill after
rst making certain there are no pipes or
wires behind the proposed holes.
Insert the wall plugs and screws provided
leaving the screw head proud by
approximately 5mm. The shower can now
be hung on these screws.
Make sure that the shower is positioned
vertically now mark and drill the lower
slotted xing hole. Then x the shower to
the wall. Do not fully tighten the screws at
this stage.
The shower back plate has moulded
knock out sections which are clearly
indicated to allow the chosen service entry
option to be removed prior to nal x.

10
Thermostatic Care
QI
Temperature
Flow Control
START/STOP
T
e
m
p
e
r
a
t
u
r
e
FLOW
7. PRODUCT POSITIONING GUIDE
Showerunitcanbemounted
eithersideofriserrail
Heightof
showerhead
andshower
tosuituser’s
requirements
Mainscoldwatersupply
(eithertop,bottom,left,
rightorrearentry
25mmminimum
Outlineofbathor
showertray
Spilloverlevel
Spilloverlevel
Soapdish
Hoseretainingring
Additionalwall
mountedhandset
holder

11
8. PLUMBING CONNECTIONS
The 8arrows depict
water and electrical
entry points
Location holes for
mounting are easily
marked off from
inside unit
Bottom xing
position
Left hand
water
entry
sealing
cap
and clip
NOTE!
PLUMBING THE
SHOWER UNIT
MUST PRECEDE
WIRING!
QI
QUICK
INSTALLATION
As you can see from
the diagram right
the shower unit can
be both plumbed
and wired from 8
different positions;
nTop right
nTop left
nBottom right
nBottom left
nRight side
nLeft side
nRear right
nRear left
Removable cover plates for left or right
and bottom inlets, accessible once
cover plate is removed. These simply slide
into place and secure with xing screw
before replacement of cover.
Water inlet, this can be
switched with the cap and
xing clip opposite to change
water input direction.
See next page for
instruction.

12
IMPORTANT
To comply with water regulations, building regulations or any specic local water
company regulations and should be in accordance with BS EN 806. A double check
valve must be tted with all exible shower accessories where it is possible that the
showerhead may come into contact with used water i.e. In the bath or shower tray.
!

!
!

!
DEFAULT PLUMBING SETTING
The shower unit is supplied for right
hand installation. To plumb the unit on
the left you must:
1. Remove the bottom left hand side
cover plate.
2. Carefully pull the metal retaining clip
out of the blanking end cap with a pair
of pliers.
3. Slide off the blanking cap.
4. Ret the blanking cap on to the inlet
pipe on the right hand side of the unit.
5. Re-insert the metal xing clip
ensuring it is pushed primly into place.
IMPORTANT: When leak testing the
installation you must ensure there are
no leaks from this area.
PLUMBING CONNECTIONS (CONT.)
The shower back plate incorporates into
the lower right and left hand side of the
back plate removable trim sections to
allow easy access when deciding on and
connecting to the water mains supply.
Remove the bottom right hand side cover
plate giving access to the inlet spigot.
IMPORTANT: Before connecting the
mains water supply to the shower, ush
out the pipe work to remove all swarf
and system debris. This is achieved by
connecting a hose to the pipe work and
turning on the mains water supply at the
isolating stop tap long enough to clear the
debris to waste.
Turn off the mains water supply at the
isolating stop tap.
Having decided on the direction of the
water inlet supply: Top (falling) Bottom
(rising) or Rear Inlet, it is necessary
to remove the appropriate knock out
(thinned out plastic) cross section from the
back plate before commencing with the
installation.
The connection to the unit is made using
a 15 mm copper, stainless or plastic pipe
with a 15 mm compression elbow or 15
mm push t elbow.
IMPORTANT: Do not use excessive force
when making the connection to the unit.

13
IMPORTANT
Before turning on the water supply to the shower unit the water supply pipe should
be ushed out to remove debris. After ushing the pipework ensure that the shower
unit is positioned squarely on the wall and tighten the screws. Tighten all plumbing
connections and check the pipework for leaks.
!

!
!

!
PLUMBING CONNECTIONS (CONT.)
Tighten the back plate xing screws so the
unit is rmly xed to the wall.
If rear entry pipe work is used we
recommend the use of a suitable sealant
to seal around the incoming pipe work to
prevent water entering the wall.
Turn on the mains water supply and check
for leaks. At this stage no water can ow
through the unit.
IMPORTANT: Remember to replace the
lower inlet covers before retting the front
cover.
9. ELECTRICAL CONNECTIONS
The electrical installation must be in
accordance with the current BS 7671
(I.E.E. wiring regulations) and part P of
the building and / or local regulations.
The shower unit is designed for a single
phase 50 Hz a.c. electrical supply.
ELECTRICAL SPECIFICATIONS
IMPORTANT: The heating elements on
the UK models are manufactured to 240V
specication and will give a lower kW
rating if the voltage supply is below 240V.
The shower unit must be permanently
connected to the electrical supply, direct
from the consumer unit via a double pole
linked switch with a minimum contact
gap of 3 mm. The switch must be readily
accessible and clearly identiable and
sited out of reach of a person using the
shower over a xed bath or shower tray,
unless the switch is pull cord operated.
The wiring must be connected to the
switch without the use of a plug or socket
outlet.
The supply cable size is determined by
the kW rating of the product (as detailed
on the rating plate xed to the back plate)
and the distance between the shower and
the consumer unit. The table below is for
guidance only but will help you choose
the correct cable for your installation.
If you are in any doubt consult an
electrician.
Nominal Power rating at 240V
8.5kW - (40A MCB rating)
9.5kW - (40A MCB rating)
10.5kW - (45A MCB rating)
Nominal Power rating at 230V
7.8kW - (40A MCB rating)
8.7kW - (40A MCB rating)
9.6kW - (45A MCB rating)

14
ELECTRICAL CONNECTIONS (CONT.)
The incoming cable should be hidden.
IMPORTANT: The shower unit is supplied
with 2 separate sets of connecting
terminal blocks mounted on the shower
back plate so that the shower can be
wired for left or right installations with
minimum effort. ONLY connect to one of
the terminal blocks.
The diagram below shows the route of the
cable into the shower unit for connection
to the terminal block. (illustrated on left
hand side)
IMPORTANT: Remove the appropriate
lower cover section to improve access for
mains cable tting.
Earth cable to terminal marked
Neutral cable to terminal marked N
Live cable to terminal marked L
The outer sheath of the supply cable must
be striped back to the minimum length as
illustrated and the earth conductor must
have an earthing sleeve tted.
IMPORTANT
Ensure that the terminal block screws are fully tightened and that no cable insulation
is trapped under screws. Ensure the cable clamp is used to secure the cable. The
earth continuity conductor of the electrical installation must be effectively connected
to all exposed metal parts of other appliances and services in the room in which the
shower unit is installed to conrm
N
E
Terminal
block
L
KW
RATING
NOMINAL
AT 240V
MINIMUM
RATING OF
ISOLATING
SWITCH
FUSE
RATING
MAX CABLE
RUN
6mm 10mm
7.5 31.25amps 40amps 40amps 29m 48m
8.0 33.33amps 40amps 40amps 27m 44m
8.5 35.41amps 40amps 40amps 23m 38m
9.5 39.58amps 40amps 40amps 21m 32m
10.5 43.75amps 45amps 45amps 18m 30m
!

!
!

!

15
ELECTRICAL CONNECTIONS (CONT.)
Connect the cable to the terminal block.
Ensure that ALL the retaining screws
are VERY tight and that NO cable
insulation is trapped under the screws.
Loose connections can result in cable
overheating.
IMPORTANT: Failure to ensure that the
retaining screws are VERY tight could
result in a failure of the terminal block.
IMPORTANT: DO NOT switch on the
electricity supply until the shower cover
has been tted.
The diagram below shows a schematic
wiring diagram.
IMPORTANT: The use of connections
within the unit or other points in the
shower circuit to supply power to other
equipment such as an extractor fan or
pump etc will invalidate the guarantee.
L
N
E
1
3 4
5
6
79

8
2
1. Heater body
2. Solenoid valve
3. Thermal cut-out
4. Power PCB
5. Triac PCB
6. Flow sensor
7. Inlet/outlet temperature sensors
8. Display PCB
9. Start/Stop button PCB
10. Stepper motor

16
10. CHANGING THE OPERATIONAL SHOWER PROGRAMMES
The shower has four separate
operational programmes which can be
adjusted on installation via a series of DIP
switches located on the display PCB. This
is mounted on the back of the front cover
as shown above.
The programmes are:
1. Audible feedback to conrm user
command.
2. Maximum shower outlet
temperature lock to provide three
MAXIMUM shower outlet temperature
settings.
3. Automatic timed off operation:
four settings are available.
4. Shower start temperature can be
set to a FIXED 40ºC (display digit 8 on
the seven segment temperature display)
or MEMORY – with start up temperature
as per the last shower. A double bleep
conrms to the user when the outlet
temperature has been reached.
IMPORTANT: The Thermostatic Care
models are factory set in BEAB Care
mode with settings as follows:
• the audible feedback is ON (single bleep
on each push button command)
• maximum temperature lock set
to PROGRAMME 1. This limits the
maximum temperature selectable by the
user to 41ºC at digit 9 on the numerical
temperature indicator.
• automatic timed STOP feature set at the
maximum duration of 30 minutes.
• shower start temperature set at a FIXED
40ºC.
NOTE: DIP switch is ON when slider
switch in the upper position. DIP switch
is OFF when slider switch is in the
lower position.
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
SOUND
SWITCH
MAX
TEMP
RUNNING
TIME
TEMP
START
SOUND
SWITCH
MAX
TEMP
RUNNING
TIME
TEMP
START
DEFAULT SETTINGS –
THERMOSTATIC CARE
Sound: ON
Maximum temperature:
PROG 1 (30 – 41 ºC)
Running time: 30 MINS
Temperature Start:
FIXED (nominal 40ºC)
DEFAULT SETTINGS –
THERMOSTATIC PLUS
Sound: ON
Maximum temperature:
PROG 3 (30–47ºC)
Running time: 30 MINS
Temperature Start:
MEMORY (as last shower)

17
CHANGING THE OPERATIONAL SHOWER PROGRAMMES (CONT.)
AUDIO FEEDBACK
SOUND ON
slider switch 1 ON
SOUND OFF
slider switch 1 OFF
MAXIMUM TEMPERATURE
IMPORTANT: To retain BEAB Care
performance the factory set
Programme 1 MUST be used.
PROGRAMME 1
(30 – 41 ºC)
slider switch 2 OFF
slider switch 3 OFF
PROGRAMME 2
(30– 43 ºC)
slider switch 2 OFF
slider switch 3 ON
PROGRAMME 3
(30– 47 ºC)
slider switch 2 ON
slider switch 3 OFF
RUNNING TIME
30 MINS
slider switch 4 OFF
slider switch 5 OFF
20 MINS
slider switch 4 OFF
slider switch 5 ON
10 MINS
slider switch 4 ON
slider switch 5 OFF
5 MINS
slider switch 4 ON
slider switch 5 ON
TEMPERATURE START
FIXED
(start up at digit 8 –
nominal 40 ºC)
slider switch 6 ON
MEMORY
(start up temperature
as last shower)
slider switch 6 OFF.
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
ON DIP
ON DIP
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
ON DIP
1 2 3 4 5 6
IMPORTANT
If the programmes are adjusted following the unit commissioning switch off the
electricity at the isolating switch before removing the front cover taking care not
to damage the PCB ying lead and check correct operation of the shower
after re-tting the front cover.
!

!
!

!

18
11. FITTING THE FRONT COVER
IMPORTANT: it is necessary to align the
Multi pin connector and connect the ying
lead from the PCB to the rear of the front
cover.
Hold the front cover carefully and
attach the ying lead from the control
PCB (ensuring that the lock tags are
aligned with the slots on the display
PCB connector) to the rear of the front
cover as illustrated making sure that the
connector pins are fully engaged.
The cover can now be tted and secured
with the four xing screws provided.
Following the installation of the riser rail
(see section 12) attach the exible hose to
the shower outlet positioned centrally on
the back plate making sure that you use
the seal washer provided. The shower is
now ready for commissioning.
Thermostatic Care
QI
Temperature
Flow Control
START/STOP
T
e
m
p
e
r
a
t
u
r
e
FLOW

19
12. RISER RAIL FITTING INSTRUCTIONS
1. Establish the height of the riser rail to
suit requirements, taking into account all
users.
2. Remove caps and covers from
brackets.
3. Mark the position of the lower bracket
then drill and plug the wall. If this is
a replacement installation locate the
bottom hole.
4. Fit rail through lower bracket and clamp.
Place the remaining bracket on top of
the rail making sure the slot in the rail is
located in the notch.
a. For a replacement riser x the top
bracket using the existing hole.
b. For a new installation ensure the hole
position is vertically aligned and mark
the wall. Unclamp the lower bracket and
remove the rail then drill and plug the
wall before xing the top bracket into
position.
5. Slide the height adjuster onto the
rail. Tighten to the rail by turning the
locking cap. Then t the soap dish –
dampening the rail will make it easier
to slide on. Finally t the hose retaining
ring onto the bottom of the rail below
the soap dish.
6. Replace the rail assembly through
the lower bracket. Fit the rail into top
bracket ensuring the slot locates into
the notch. Tighten the lower bracket
then ret the bracket caps.
NOTE: The adjustable height adjuster
grips the conical ends of the hose, not the
handle of the showerhead.
CAUTION
Check there are no hidden cables or pipes before drilling holes for wall plugs.
Exercise great care when using power tools near water.
The use of a residual current device (RCD) is recommended.
!

!
!

!
TIPS
A piece of insulating or masking
tape applied to the wall before
marking out the Fixing holes will
help stop the drill from wandering,
particularly on tiled surfaces. When
working near a basin or bath, insert
the plug in the waste tting so that
small parts cannot be lost.
Take care not to drop accessories or
tools into basin or bath.
!

!

20
13. COMMISSIONING THE SHOWER
IMPORTANT: This MX Thermostatic
shower unit incorporates a commissioning
procedure detailed below. It is important
that this procedure is followed.
1. Make sure that the electricity supply
has been isolated at the double pole
isolating switch.
2. Ensure that the water supply is fully on
at the mains stop cock and isolating
service valve (if tted)
3. Check that water is not leaking from the
bottom of the case.
4. Switch on the electrical supply at the
double pole switch or pull cord. The
power on neon indicator will light at the
switch.
5. On the shower unit press and hold the
warmer (+) and cooler (-) buttons for
a minimum of 3 seconds until COLD
water ows into the shower and through
to the shower handset, and then
release the buttons. When the water is
free owing and all the air has purged
through the system press the start /stop
button and this will stop the water ow.
7. Press the start /stop button, you will
hear a single bleep and the water will
ow freely within a few seconds. The
water ow will start at maximum ow
indicated by 3 LEDs around the ow
button.
NOTE: If the commissioning procedure is
not used the heaters will have a 6 second
delay before they are energised to allow
the water to ll the unit (this only happens
on the rst start up operation).
IMPORTANT: If the button does not
respond ensure that the ying lead from
the PCB has been connected to the back
of the front cover. Ensure front cover
is isolated at the mains supply before
removing.
9. The “Secret Until Illuminated” seven
segment display will activate and
show digit 8 for the Thermostatic Care
model which indicates the FIXED pre-
programmed start up temperature.
The Thermostatic Plus models are
supplied with MEMORY start up
temperature setting which will be as
per the last shower, however it may be
necessary to adjust to digit 8 at initial
start up. On all models the ow starts
at the maximum level clearly indicated
by the 3 illuminated LEDs.
10. The shower will start to heat the water.
A double bleep indicates when the
pre-programmed start up temperature
has been reached. Please note this
could take up to 30 seconds if the
shower is starting from cold. The unit
will automatically adjust the water ow
if required.
11. Check the operation of the
temperature control buttons by
pressing the cooler (-) button once.
The temperature digit will change to
show 7 conrmed by a single bleep (if
audio not de-selected on installation).
Keep pressing the cooler button
repeatedly until the digit reaches 1,
which when stable will give a nominal
outlet temperature of 30 ºC.
IMPORTANT
The shower unit must be full of water before heat settings are used.
!

!
!

!
