My Child Floe Infant Carrier User manual

Floe Infant Carrier
For the Floe Convertible Pushchair
IMPORTANT – KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
This product conforms to ECE R44.04 and is tested to BS EN 1888:2018-1
Group 0+ child car seat. Suitable for children from birth to 13kg (approx. 12 months)
IMPORTANT ! CONSERVER POUR RÉFÉRENCE ULTÉRIEUR.
Ce produit répond aux normes ECE R44.04 et est testé pour BS EN 1888:2018-1
siège-auto Groupe 0+. Convient aux enfants de la naissance à 13Kg (environ 12
mois)
V7
●Français pages 19-35
●English pages 2-18

page 2
Safety advice
WARNING: The correct tting of the vehicle seatbelt (following the guide markings)
is of vital importance for the safety of your child. See the labels on the seat itself.
WARNING: Keep these instructions with the child car seat for future reference.
WARNING: Never leave your child unattended.
WARNING: NEVER use the child car seat on a passenger seat that is tted with a
front airbag. THIS CAN BE VERY DANGEROUS.
• The product is only safe if it is used in strict accordance with these instructions.
• The product must be replaced if it is involved in an accident as it may have
unseen damage.
• Do not use this product second hand as you do not know its history.
• Ensure that all other passengers, luggage and loose objects are properly
secured.
• Do not lubricate any of the moving parts.
• It is recommended that the child car seat should not be used more than 5
years from the date of production as the product may deteriorate due to, for
example, ageing of the plastic.
• Never use the child car seat without the covers. Only covers approved by the
manufacturer may be used.
• The child car seat must be secured with the vehicle seatbelt when not in use.
• Ensure that the child car seat is not damaged by heavy objects or being
caught in the car door.
• Never make unauthorised alterations to the product.
• Child car seat parts may become hot in direct sunlight. Cover with sheet to
prevent this.
• Most accidents occur on short trips, so do not be tempted to avoid using the
child car seat simply because you are not travelling very far.
• Do not leave the child in the child car seat for long periods of time. Take
regular breaks on long journeys.
• Set a good example by always wearing a seatbelt yourself.
• Make sure that your child never plays with the buckle.
WARNING: Failure to follow each of the following instructions can result in your child
striking the vehicle’s interior during a sudden stop or crash.
WARNING: Take care that the straps holding the child car seat to the vehicle, are
as tight as possible. Make sure that the straps restraining the child are adjusted to
the child’s body and the straps are not twisted.
WARNING: The child restraint system MUST BE CHANGED after it has suffered from a
violent impact in an accident.
Do not use a rear facing child car seat on a front passenger seat
where an active passenger air bag is tted. The air bag inates
rapidly and can throw a rear-facing child car seat into the back of a
passenger seat with great force, which can injure or kill a child.
! Extreme Danger !

page 3
Vehicle seat travelling advice
In order to maximise the protection that the child car seat can give your child,
please adjust the harness so that it ts snugly and make sure that the child car seat
is tted correctly.
Research shows that correct installation is the most important factor in child car
seat safety.
Please take the time to read the instruction manual carefully.
Our product offers maximum protection when it is used in accordance with the
instructions.
If you have any questions concerning the use of the product please do not
hesitate to contact us.
• This child car seat is designed for use for children whose weight is 13kg or less
and whose heights are 66cm (26 inches) or less.
• This child car seat must only be used in a rear facing position, and must NEVER
be used forward facing. For maximum protection, the centre rear seat position
(if it is tted with an adult 3-point seatbelt) is recommended as the safest
position in most vehicles for installing an child car seat. (Only use the vehicle’s
rear centre seat if the vehicle seat is tted with a 3-point adult belt).
• Do not use your child car seat on a vehicle seat with lap belts only.
• Your child car seat should not be purchased or sold as a second hand item.
• Remove child out of the car as rst priority in an accident.
• While travelling it is recommended that any luggage or other objects liable to
cause injuries in the event of a collision shall be properly secured.
• Your child car seat should be securely belted to the vehicle, even when
unoccupied because in a crash an unsecured child car seat may injure other
passengers.
• Please take a rest every two hours if you are travelling with a baby in the child
car seat.
• Please check the child car seat condition if you are going to travel a long
distance with a child.
• Please put all excess luggage into the boot of your car if you are going to
travel with a baby, because loose items may hurt a baby when travelling on
unstable roads or because they move suddenly when braking.
• Please always check the child car seat before you place a baby into it.
• Please get in touch with the dealer if anything breaks on the child car seat.
Only the manufacturer or an authorised agent may do repairs. DO NOT try
and x the child car seat by yourself. It might be damaged or cause more
damage.
• Always check the buckle hole before you buckle up as it may contain crumbs
or obstructions that prevent a secure lock.
• Keep your child car seat out of reach of children when not in use.
• Please keep the plastic packaging bag out of the reach of children when
unpacking the child car seat.
• NEVER place the child car seat on a seat where an air bag is active.
• Do not modify the child car seat.

page 4
Safety advice for Floe Chassis & car seat
WARNING: To avoid injury ensure that your child is kept away when unfolding and
folding this product.
WARNING: Do not let your child play with this product.
WARNING: Never leave your child unattended.
WARNING: Ensure that all the locking devices are engaged before use.
WARNING: Always use the restraint system. Always use the crotch strap in
combination with the waist belt.
WARNING: Parcels, accessories and other items (e.g. hand bags, shopping
bags, etc) that are placed on the handles, back of the backrest or sides of the
pushchair will affect the stability of the pushchair.
WARNING: Always use the most reclined position for new born babies.
WARNING: Do not lift and carry the pushchair with a child in it.
WARNING: Do not use pushchair on steep slopes, stairs, escalators, beaches, mud,
etc.
WARNING: Check that the pushchair body or seat unit attachment devices are
correctly engaged before use.
WARNING: Do not allow your child to climb unassisted into or out of the pushchair.
Notices
1. The child car seat must only be used in vehicles which are tted with a
three point seatbelt system that has been approved by regulation ECE-16
or similar.
2. A correct t is likely if the vehicle manufacturer has declared in the
vehicle hand book that the vehicle is capable of accepting a ‘Universal
’child restraint for this group.
3. The child car seat is a ‘Universal’ child restraint; it conforms to regulation
ECE-R44/04 for general use in vehicles. It will t most, but not all vehicle
seats.
4. This child car seat has been declared ‘Universal’ under more stringent
conditions than those applied to earlier designs, which do not carry the
‘Universal’ mark.
5. Child car seats can mark vehicle seat upholstery. The manufacturer
cannot be held responsible for damage or marking to vehicle seats.
6. Never use rearward facing child car seat on a passenger seat with an
active airbag.
7. If in doubt, consult manufacturer or the retailer.
Vehicle seatbelt
The product must only be used with a 3-point vehicle seatbelt that has been
approved to ECE R16 or equivalent. NEVER use a 2-point seatbelt. Your child car
seat can be tted in most cars. However, some vehicles are designed in such
away that proper installation may not be possible. In this case, try another vehicle
seat.

page 5
Welcome
Thank you for purchasing the Floe 0+ Car Seat.
Please read the instructions and warnings carefully before use to ensure safe
and satisfactory operation of this product.
Your child’s safety is your responsibility. If you have a query with this product or
require replacement parts, please contact your nearest MyChild retailer.
Safety advice for Floe Chassis & car seat (continued)
WARNING: Ensure that children are clear of moving parts before making
adjustments.
WARNING: Never leave raincovers, hoods and aprons on indoors or in hot
weather as your child might overheat.
WARNING: Do not use replacement parts or accessories other than those
approved by the manufacturer as others may render the product unsafe.
WARNING: Do not load the basket with a weight in excess of 2kg.
WARNING: Always apply the brakes when the pushchair is stationary, and when
placing and removing children.
WARNING: Taking children up or down stairs, escalators, steps, steep slopes
and muddy/rough terrain could be dangerous and should not be attempted.
Remove your child from the pushchair for easy carrying to negotiate such
hazards, or simply avoid them.
WARNING: Never assume a driver can see you or your child.
WARNING: If your pushchair is to be used by someone who is unfamiliar with it,
e.g. grandparents, then show them how it works before letting them use it.
WARNING: This pushchair is not suitable for running or skating.
WARNING: Hold onto your pushchair when close to moving vehicles and trains as
the draught from the vehicles may move the pushchair even with the brakes on.
WARNING: This product is designed to carry only one child at a time.
This product complies with BS EN 1888:2018-1

page 6
1Carry handle
2Shoulder pads
3Harness buckle
4Harness adjuster button
(under seat cover)
5Harness adjuster strap
6Insert cushion
7Shoulder strap slots
8Crotch pad
9Hood
10 Handle adjuster buttons (on left and right of shell)
11 Diagonal seatbelt guide (on rear of shell)
12 Lap belt guides
13 Shell
14 Pushchair adaptors
Parts checklist
48
7
6
1
2
3
5
9
10
11
13
14
12

page 7
Front passenger seat (no active
airbag)
Yes
Front passenger seat (active
airbag)
NO
2-point seatbelt NO
3-point seatbelt Yes
Back left & right seats Yes
Back centre seat (3-point seatbelt) Yes
Back centre seat (2-point seatbelt) NO
Side facing seats NO
Rear facing seats NO
A B
Positioning the child car seat
The child car seat can only be used with an
automatic 3-point safety belt (A) and NOT
with a 2-point lap belt (B).
The child car seat can be secured on
forward-facing back seats of the vehicle by
using the existing seat belts. However, on
some seats, if the installation is not properly
secured, we suggest you try another seat in
your vehicle.
Although not recommended, the child car
seat can be used on a passenger side front
seat, so long as there is no active airbag in
place.
WARNING: Never use on a seat with an active
airbag.
WARNING: Never use on rearward or side
facing vehicle seats
The child car seat must not touch the front
passenger seat.

page 8
The carry handle has 4 positions.
(1) Feeding/non-rocking position.
(2) Rocking position.
(3) Carrying position: Make sure handle is
locked before lifting.
(4) Fitting position.
Press both buttons (A) and rotate the
handle to the desired position.
WARNING: NEVER place the child car seat
on a soft surface e.g. cushion, mattress,
pillow etc, due to risk of suffocation if child
car seat tips over. Never leave a child
unattended.
Adjusting the carry handle
Adjusting the shoulder harness height
The harness should exit the child car seat
at the same height as the child’s shoulder
and should not exit higher or lower than
the child’s shoulder.
WARNING: You should not attempt to
adjust the harness height with a child
seated in the child car seat.
1
2
3
4
A

page 9
Adjusting the shoulder harness height (continued)
Press the belt adjuster button and pull
on the shoulder harness straps to create
slack.
Press the red release button (A), unbuckle
the harness, move the shoulder straps
apart and remove the shoulder pads.
click
Unhook the shoulder straps at the rear of the seat shell by sliding the straps through the slits
in yoke (B). Remove the straps, pulling them out from the front of the seat.
Pass the shoulder straps back through at one of the four desired heights (C) and
reconnect them to the yoke (B).
B
A
C

page 10
Buckle up the harness. Connect the two
shoulder strap connectors (D) and insert
into the buckle (E). Ensure harness buckle
is rmly clicked into place.
Pull the harness adjuster strap tight and
check straps are not twisted.
The crotch strap can be repositioned for a
more comfortable t as your child grows.
To reposition the crotch strap: pass the
strap retainer up through one of the 3
slots in the base of the child car seat and
thread it back down through the desired
slot.
E
click
D D
Adjusting the shoulder harness height (continued)
Adjusting the crotch strap

page 11
Fitting the harness
Press the belt adjuster button and pull
on the shoulder harness straps to create
slack.
Press the red release button (A), unbuckle
the harness and move the shoulder straps
apart.
Place the child in the child car seat and ensure there are no spaces under the child.
Note: a new born baby may need extra support around the head and body. Ensure
you use the supplied insert cushion if you are going to use it for a newborn or small baby
less than 7 months old (9kg or less). Also ensure that the shoulder harness is at the lowest
height setting.
click
A

page 12
Buckle up the harness. Connect the two
shoulder strap connectors (B) and insert
into the buckle (C). Ensure harness buckle
is rmly clicked into place.
Place the shoulder harness over the
shoulders.
Note: Do not place your child in a
sleeping bag, blanket or other bulky
wrapping before putting the child in the
child car seat. The shoulder straps will not
t snugly and the child will not be safe.
Pull the harness adjuster strap to secure
the harness around the child.
Fitting the harness (continued)
C
click
B B

page 13
The harness should allow 1 nger-
width (1cm) of space at the top of the
shoulders. This is the ideal tightness.
Note: Check that the buckle is secured by
tugging the shoulder and waist straps.
1cm
Fitting the harness (continued)
Choose a seat suitable for tting the child
car seat to. See page 6, ‘Positioning the
child car seat’.
Place the child car seat rearward-facing
on the vehicle seat.
Ensure the handle is in the tting position
as shown.
Fitting the child seat in a vehicle
Place the vehicle lap belt across the child car seat and slide the lap belt into the slots (A)
on both sides of the child car seat.
Buckle up the vehicle seat belt (B).
B
click
A
A

page 14
Take the diagonal belt around the back
of the child car seat and slot it into the
rear seat belt guide (C), ensuring that
the diagonal section passes behind the
pushchair adaptor (D).
Once the seat belts are in their correct
mounting points make sure the seat belt
buckle is secure and there are no twists in
the belt and that all slack is removed from
the lap and diagonal sections.
Fitting the child seat in a vehicle (continued)
Note: If the vehicle seatbelt buckle is
above or touching the top edge of the
shell then this car seat is not suitable for
the vehicle and may cause the vehicle
seatbelt to come undone in an accident.
D
C

page 15
To remove the hood: press the small tabs
(A) on each side of the child car seat and
slide the plastic stay out from the socket.
To re-attach the hood push the plastic
stays into the sockets on each side of the
carrier, ensuring they click into place.
Press the belt adjuster button and pull
on the shoulder harness straps to create
slack.
A
Removing and attaching the hood
Removing the seat cover
Press the red release button (A), unbuckle
the harness and move the shoulder straps
apart.
click
A

page 16
Removing the seat cover (continued)
The seat cover is held in place with plastic
clips at points 1, 2 & 3 on each side of the
child car seat.
Slide the plastic clips down and out of the
keyhole slots (C).
Loosen the seat cover all around the
edges of the shell. Carefully pass all straps
and buckles through the slots in the cover
and remove the cover.
To replace: reverse the above steps.
B
Unhook the shoulder straps at the rear of
the seat shell by sliding the straps through
the slits in yoke (B). Remove the straps,
pulling them out from the front of the seat.
123
C

page 17
Attaching the seat to the chassis
Removing the seat from the chassis
Note: The car seat can only be tted
parent facing (as shown).
Hold the car seat so that it is facing the
stroller handle. Position the car seat joints
(A) above the mounting points (B) and
push the seat downwards until it clicks
into place.
Attention: Lift the car seat to ensure it is
rmly attached to the stroller chassis.
Standing in front of the chassis, lift up the release catches (A) on each side of the car seat
and lift it from the chassis.
click
click B
A
A

page 18
Care and maintenance
1) Store this child car seat in a safe place when not in use.
2) DO NOT place heavy objects on top of it.
3) Always store the child car seat in a dry environment.
4) DO NOT store the child car seat near a direct heat source such as a radiator.
Covers
1) The seat cover is easily removable and should be hand washed with a pH neutral soap
and cold water.
2) Do not press, iron, dry clean, tumble dry or wring the covers.
3) Do not use solvents, caustic or abrasive cleaning materials.
4) Dry at, away from direct heat and sunlight.
5) If the seat covers need to be replaced only use parts certied by the manufacturer.
They are the only ones that are guaranteed to have been safety tested and designed to t
this seat.
Plastic/Metal Parts
1) Wipe clean using a mild soap and warm water.
2) You must not remove, dismantle or alter any part of the seat shell.
3) You must not oil or lubricate any part of the seat shell.
Inspection
1) Check your child car seat regularly for wear and tear.
2) The child car seat may have a slight rattle when not in use, this is normal. If in any doubt,
contact the retailer immediately.
3) Check the adjustable parts of your child seat at intervals of about 6 months to ensure it is
still ts correctly for your growing child.
Whilst we make and test our products to the highest standards of durability there’s
always a small chance of a hiccup! Our promise is to repair, replace or refund a MyChild
product that has an identied manufacturing defect from the date of purchase for a full
3 years thereafter at no extra cost.
However, you must register within 28 days of the date of purchase to receive the full 3
years guarantee!
To receive your full guarantee you can register your product by:
visiting www.mychild.co.uk/warranty.html and complete the warranty form,
or by telephone on 0161 335 2508.
Your 3 year warranty

page 19
Conseil de sécurité
ATTENTION: L’installation correcte de la ceinture de sécurité du véhicule (en suivant
le guide) est d’une importance vitale pour la sécurité de votre enfant. Voir les
étiquettes sur le siège lui-même.
ATTENTION: Gardez ces instructions avec le siège-auto pour future référence.
ATTENTION: Ne jamais laisser votre enfant sans surveillance.
ATTENTION : NE JAMAIS utiliser le siège-auto sur un siège passager ou un airbag est
activé. CELA PEUT ETRE TRES DANGEREUX.
• Ce produit est able seulement s’il est utilisé en accordance avec ces
instructions.
• Le produit doit être remplacé s’il est impliqué dans un accident, il peut avoir
des dommages invisibles à l’œil nu.
• Ne pas utiliser ce produit en seconde main car vous ne connaissez pas son
passé.
• Assurez-vous que tous les passagers, sac et objets sont correctement attachés.
• Ne pas lubrier les parties amovibles.
• Il est recommandé de ne pas utiliser ce siège-auto plus de 5 ans après la date
de production, car le produit pourrait être endommagé à cause par exemple
du vieillissement du plastique.
• Ne jamais utiliser le siège-auto sans la housse. Seules les housses approuvées
par le fabricant peuvent être utilisée.
• Le siège-auto doit être attaché avec la ceinture de sécurité du véhicule même
lorsqu’il n’est pas utilisé.
• Assurez-vous que le siège-auto n’est pas abimé par des objets lourds ou n’est
pas coincé dans la portière du véhicule.
• Ne jamais faire des modications non-autorisées sur le produit.
• Certaines parties du siège-auto peuvent devenir très chaude au contact des
rayons du soleil. Couvrir avec un tissu pour l‘éviter.
• La plupart des accidents arrivent lors des trajets courts, donc ne soyez pas tenté
de ne pas utiliser le siège-auto simplement parce que vous n’allez pas loin.
• Ne pas laisser un enfant dans un siège-auto pendant longtemps. Faites des
pauses régulières lors des longs voyages.
• Montrer le bon exemple en portant toujours, vous-même votre ceinture de
sécurité.
• Assurez-vous que votre enfant ne joue jamais avec la boucle du harnais.
ATTENTION: tout manquement aux instructions pourrait mettre votre enfant en
danger, il pourrait se cogner violement à l’intérieur du véhicule lors d’un arrêt
soudain ou d’un accident.
ATTENTION: Assurez-vous que les sangles retenant le siège-auto au véhicule sont
resserrées au maximum. Assurez-vous que les sangles retenant l’enfant sont ajustées
au corps de l’enfant et que ces sangles ne sont pas enroulées.
ATTENTION: Le siège -auto DOIT ETRE CHANGE s’il a souffert d’un impact violent
dans un accident.
Ne pas utiliser dos à la route sur le siège passager avant, lorsqu’un
airbag est activé. Un airbag se gone très rapidement et peut
percuter un siège-auto dos à la route avec une grande violence, ce
qui peut blesser ou tuer un enfant.
Danger extrême!

page 20
Ceinture de sécurité du véhicule
Le produit doit uniquement être utilisé avec une ceinture de sécurité 3 points qui
a été approuvé ECE R16 ou équivalent, NE JAMAIS utiliser une ceinture 2 points
ou ventrale. Votre siège-auto peut être installé dans la plupart des véhicules.
Cependant certains siège des véhicules ne permettront pas l’installation du siège,
dans ce cas, essayer un autre siège du véhicule.
Conseil d’installation dans un véhicule
Pour proter au maximum de la abilité et de la sécurité que ce siège-auto offre
à votre enfant, assurez-vous que le harnais est correctement attaché et serré ; et
que le siège est correctement installé. Les recherches montrent que l’installation
correcte du siège-auto est le facteur le plus important pour la sécurité de l’enfant.
Merci de prendre le temps de lire attentivement le manuel d’instruction. Notre
produit offre une protection maximum lorsqu’utilisé conformément aux instructions.
Si vous avez des questions concernant l’utilisation du produit, veuillez ne pas
hésiter à nous contacter.
• Ce siège-auto est conçu pour les enfants pesant 13Kg ou moins, et qui
mesurent 66cm ou moins.
• Ce siège-auto peut seulement être utilisé dos à la route, et ne doit JAMAIS
être utilisé face à la route. Pour un maximum de protection, le siège arrière du
milieu (s’il est équipé d’une ceinture de sécurité 3 points) est recommandé
comme étant la position la plus sure pour installer un siège-auto, dans la
plupart des véhicules. (Utiliser le siège arrière central UNIQUEMENT si celui-ci est
équipé d’une ceinture de sécurité 3 points).
• Ne pas utiliser votre siège- auto pour enfant dans un véhicule uniquement
équipé de ceintures ventrales.
• Votre siège-auto pour enfant ne devra jamais être acheté ou vendu comme
un article de seconde main.
• Sortir votre enfant de la voiture en cas d’accident doit être votre priorité.
• Lorsque vous voyagez, il est recommandé que tous les bagages et objets
pouvant causer des blessures lors d’un accident ou d’une collision, soient
correctement attachés.
• Le siège-auto de votre enfant devra être attaché au siège du véhicule même
lorsqu’il n’est pas occupé, car en cas d’accident, un siège-auto non attaché
peut blesser les autres passagers
• Faites une pause toutes les 2heures si vous voyagez avec un enfant dans le
siège-auto.
• Veuillez vérier l’état du siège-auto si vous voyagez pendant longtemps avec
un enfant.
• Veuillez mettre tous les bagages dans le coffre de votre véhicule si vous
voyagez avec un bébé, en effet des objets non attachés pourraient blesser
un bébé lors d’un freinage fort ou sur des routes en mauvais état.
• Veuillez toujours vérier le siège-auto avant de mettre un bébé dedans.
• Veuillez contacter le revendeur si quelque chose se casse sur le siège-auto.
Seul le fabricant ou un agent autorisé peuvent effectuer des réparations. NE
PAS essayer de réparer le siège-auto vous-même. Vous pourriez l’abimer et
même causer plus de dommages.
