mychway HR-SL808W User manual

808nm diode laser
Model：HR-SL808W
User Manual

1
Notice
Dear Customer：
Thank you for your choice of the our instrument which designed and
manufactured carefully by our company, in order to better play the
effectiveness of the product, we sincerely recommend：
Before using the instrument, please read this manual and keep it for future
reference.。
Please follow the instructions in the manual for correct installation, use and
operation。
Forbid disassemble this unit and modify any parts。
Except authorized personnel of this company, it is forbidden for others to
open the cover and disassemble the host computer。
Non-professionals are strictly forbidden to carry out repairs or alterations。
In the event of any failure, please contact us。
This product does not belong to medical equipment, do not use
it for disease treatment！

2
Product view
AS30 810nm semiconductor laser hair removal device is a 810nm precision wavelength hair
removal device using the most advanced micro channel laser technology, is currently the
best hair removal device in the beauty market.
Product Advantages
1、Laser: The world's top vertical stack laser
(1) Long service life: the sustainable light 5 million shots;
(2) High peak power: single bar power up to 100W / bar, the market single bar laser power
generally 50W / bar-80W / bar。
2、Efficient and stable cooling system
Laser cooling system with constant temperature cooling, to ensure that the entire system 7 * 24
hours of continuous work. Air-cooled + water-cooled way commonly used on the market can
only work continuously for 2 hours.
3、Use of contact sapphire cooling system, efficient cooling conduction efficiency, make
comfortable treatment
4、Intelligent water temperature control system: Avoid water temperature is too high,
damage the handle.
5、The unique shape design and color match make the product more beautiful and
fashionable.

3
Functional principle
808nm semiconductor laser hair removal system, using its unique long-pulse laser
penetrating the epidermis to the hair follicle site, based on the principle of selective light
absorption, the laser energy is preferentially absorbed by the melanin in the hair, and then
lose the regeneration of hair, while the course of treatment
Application
Hair removal: armpit hair, beard, lip hair, hair line, bikini line, limb hair.
Skin rejuvenation: Reducing pores, whitening skin
Technical Parameters
aser type: semiconductor laser Laser wavelength：808nm
Working frequency: 1--10Hz adjustable Spot size：12×16mm
Laser power：300W Input power：1600W
Operating language：English Output mode: pulse output
Screen size: 8-inch true color touch screen Shell material: ABS plastic + metal
Cooling system: semiconductor refrigeration + water + air cooling constant temperature
cooling
Handle temperature：-10--5℃
Supply voltage: AC220V; AC110V (can be customized)

4
Attachment list
1. Handle 1
2. Handle bracket 1
3. Water funnel 1
4. Power line 1
5. Instructions 1
Installation operation
1、Open the box and check
（1） Carefully remove the instrument and accessories from the package and save the
package for future transport or storage. Check attachment by list of accessories.
（2）Check for any mechanical damage
2、Install the handle bracket and handle
（1）Install the handle bracket
（2）Connect the handle to the instrument; then place the handle on the holder。
Note: When the handle is connected, make sure that the blue buttons on the top and
bottom of the connector are completely ejected, otherwise the water flow will not be
easy to flow！
3、Instrument water
（1）Remove the fill funnel and connect to the fill hole on the back of the instrument；
（2）Injecting pure water or distilled water; until the overflow outlet water so far。

5
Note: Be sure to use pure water or distilled water, tap water or other water shall not be
used。
4、Power on operation
（1）Connect the power line and turn on the main switch of the instrument；
（2）Turn on the power switch, emergency switch。
Interface introduction
1、Start interface；as shown below
Mode interface; item mode is optional, select the corresponding operation mode to
enter the interface

6

7
Operation Steps
1、Shaved hair
Before the operation, a shaving process, leaving 1-2mm hair on skin, to facilitate the
absorption of light。
2、Apply cold gel
Apply a little cold gel with thickness of the coin on the operating part , should not be too
thick, otherwise will reduce the effect。
3、The operation process
（1）Fit the skin, to avoid light leakage, slowly slide the handle probe to operate
（2）Energy adjustment: from the system default energy to start operating, if the operator
feels too much heat, then reduce the energy; if there is a slight sense of thermal expansion,
the melanin is absorbed by the wavelength of 810nm, laser light energy into heat, hair

8
follicle destruction of melanin, there is the best results.
（3）Operation time： Legs :10-15 minutes, Arms: 5-10 minutes, Armpit: 5 minutes , lip
hair: 3 minutes (for reference only, the specific time should be based on changes in hair,
hair removal site size) , Observed Hair follicles red, raised, slightly curly hair, hair follicles
swell, is the clinical endpoint.
4、 Skin cooling
After operation, cooling for 3-5 minutes on treatment location, or natural cooling soothing.
5、Clean the skin
Remove gel, apply moisturizing product or body lotion
Operational precautions
1、Forbid look into the glare from the front of the laser handle。
2、Slow sliding handle operation, don’t stay in one place continuous shot light, so as not
to cause customer discomfort。
3、Treatment interval: interval 20-28 days
Attention after treatment
1、7 days after hair removal to avoid overheating hot water bath, suitable for warm water
can be.
2、Avoid eating spicy, alcohol and tobacco, stimulating food

9
3、To avoid exposure, good sunscreen, wipe sunscreen, Cream
4、After hair removal to avoid pulling hair by hand. Good treatment hair removal
Equipment maintenance precautions
1、it is recommended to replace pure water or distilled water every 1 month;
2、The instrument should be placed at a temperature of 5 - 40 ℃, humidity not exceeding
80%, clean and ventilated room, avoid direct sunlight。
3、During machine working, to ensure that the instrument vents are not blocked, the
instrument at least 5cm around the gap。
4、Do not move the instrument over a long distance. Before shipping, drain all the water in
the instrument, block all the water holes, and use the cushioning packaging provided by
the manufacturer before shipping.
Taboo People
1、Heart disease, high blood pressure patients
2、Pregnant women, epilepsy patients
3、Hypertension, diabetes
4、Light allergy customers
5、Long-term work in the glare of the crowd, the recent sunburn skin
6、Short-term skinnable customers
7、Customers who are taking antioxidants or hormonal drugs
