mychway WL-919M2 User manual

I
Unoisetion+Quadrupole RF Vacuum
+Bipolar+Quadrupole+Sextupole 3D RF Slimming Spa

II
Part Two Function&Parameters&Package Including
Unoisetion Cavitation 2.0 40K Function
• Instant Inch-Loss
• Non-Invasive Fat Removal | Cellulite Reduction
• Body Sculpting | Slimming Treatments
3D RF (radio frequency) Function
• Reduce fine lines and wrinkles
• Lift, tone and brighten the face
• Tighten the skin on the underarms and legs
• Reduce cellulite
• Contour and tighten post-pregnancy tummy
• Treatment on face, neck, hands, knees etc
Parameters
Power supply Input:100V-240V
Power :190W
●40K cavitation head:
Frequency:40KHz Power:15W
●Sextupolar 3D RF for Body
Freqeuncy:1MHz
Power:50W
●Quadrupole RF with Vacuum
Freqeuncy:1MHz
Power:50W

III
Vacuum: <-80kPa
Pressure: >250kPa
Air flow: >10L/minute
Noise level: <70dB (30cm away)
●Quadrupole 3D RF for face
Freqeuncy:1MHz
Power:30W
●3D Bipolar RF
Freqeuncy:1MHz
Power:10W
Package Including
1 x Host
1 x Uoisetion 40K Cavitation Head
1 x Sextupolar 3D RF Head
1 x Bipolar 3D RF Head
1 x Quadrupolar 3D RF Head
1 x Quadrupole RF with Vacuum Head
1 x Holder
1 x Power Supply Cord ( Both 110v and 220v voltage (frequency: 50/60Hz) version
are available. Also we stock the USA, UK, AU, EU plug to suit for the country all
over the world.)
Part Three Operation

IV
3.1 Before operation
1.1 Please connect all parts well
1.2 Please connect power cord with power supply
1.3 Run on the machine
1.4 Then will be enter this screen below
3.2 40K Unoisetion
2.1 Press button then login 40k unoisetion function display,please see
the following:

V
2.2 Please click to set working time.
2.3 Please click to increase or decrease the ENERGY
2.4 Please click to chose working model.
2.5 Please click to start or pause function.
3.3 Quadrupole RF Vacuum
3.3.1 Press button then login Quadrupole RF Vacuum operation display
3.3.2 Please click to set working time.
3. 3.3 Please click to increase or decrease the ENERGY
3.3.4 Please click to chose working model.
3.3.5 Please click and to adjust the suction and release.
3.3.6 Please click to start or pause function.

VI
3.4 Sextupole 3D RF
3.4.1 Press button then login Sextupole RF operation display.
3.4.2 Please click to set working time.
3.4.3 Please click to increase or decrease the ENERGY
3.4.4 Please click to chose working model.
3.4.5 Please click to start or pause function.
3.5 Quadrupole RF
3.5.1 Press button then login Quadrupole Radio Frequency operation display

VII
3.5.2 Please click to set working time.
3.5.3 Please click to increase or decrease the ENERGY
3.5.4 Please click to chose working model.
3.5.5 Please click to start or pause function.
3.6 Bipolar Eye Radio Frequency
3.6.1 Press button then login Eye Radio Frequency operation display.

VIII
3.6.2 Please click to set working time.
3.6.3 Please click to increase or decrease the ENERGY
3.6.4 Please click to chose working model.
3.6.5 Please click to start or pause function.
Part Four

IX
Treatment time and times
1）Abdomen, thigh,buttock, arms slimming
Please clean the skin and then put the ultrasound gel on the treatment area, then turn on the
machine, set the time and energy. Please set the energy from low to high to get the best
comfortable temperature, then follow this steps:
1, Please use the Sextupole head 5 mins
2，Please use the unoisetion 40k cavitation head 15-30min
3，Please use the Quadrupole RF Vacuum head 10-15min
Work time: 2-3 times/ week
2）Face, eyes around,neck skin lifting:
Please clean the skin and then put the rf gel on the treatment area, then turn on the machine , set
the time and energy, pls set the energy from low to high to get the best comfortable temperature,
then follow this steps:
1,use face radio frequency head for face for 25-30 min
2,use eye radio frequency head for eye around for 25-30min
Work time: 2-3 times/ week
BUTTOCKS
ILLUSTRATIN of OPERATION
FACE
Treated time: 30 minutes

X
1. Massage the mandible center in circles to produce deep heat.
2. Massage lower jaw in lines.
3. Massage the triangle zone of both sides of the face in circles.
4. Massage from jaw to angulus oris to ear in lines.
THIGH
Treated time: 30 minutes
1. From down to upper, pushing to the groin to dredge the lymph.
2. From down to upper, circling push by anticlockwise can help decomposing

XI
fatness.
3. Also can push by come-and-go to decompose fatness.
4. Pull from the knee and muscle texture to upper, can improve the curve.
Treated time: 20 to 30 minutes
1. Along the lymph direction, pulling to the waist.
2. From upper to down, by anticlockwise gesture, pull come-and-go.
3. Along the muscle of arm, pull up to lift and tight the muscle.
BACK
Treated time: 20 to 30 minutes

XII
1. First by come-and-go, pushing the bladder nerve 2 to 3 times.
2. Circling by anticlockwise to stimulate the underarm lymph node.
3. On the back, by anticlockwise circling, can help to decompose the
fatness.
4. Using lymph drainage gesture, pull the toxin to the lymph node, can help
improving the back curve.

XIII

XIV
