Nac EMR-9 User manual

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 1
N
NA AC C E Ey ye e M Ma ar rk k R Re ec co or rd de er r E EM MR R- -9 9 Q Qu ui ic ck k S St ta ar rt t G Gu ui id de e
M
Ma ay y 2 20 00 09 9
N
NA AC C I Im ma ag ge e T Te ec ch hn no ol lo og gy y I In nc c. .

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
2(00175)D
C
Co on nt te en nt ts s
1
1. . S Sy ys st te em m C Co on nf fi ig gu ur ra at ti io on ns s
1
1. .1 1 S St ta an nd da ar rd d c co on nf fi ig gu ur ra at ti io
on n
1
1. .2 2 H He ea ad d u un ni it t v va ar ri ia at ti io on ns s
1
1. .3 3 O Op pt ti io on na al l i it te em ms s
2
2. . B Ba as si ic c O Op pe er ra at ti io on ns s
2
2. .1 1 C Co on nn ne ec ct ti io on n
2
2. .2 2 C Co on nt tr ro ol ll le er
r k ke ey y f fu un nc ct ti io on ns s
2
2. .3 3 H He ea ad d u un ni it t a ad dj ju us st tm me en nt ts s
2
2. .4 4 E Ey ye e
p po os si it ti io on n a ad dj ju us st tm me en nt ts s
2
2. .5 5 P Pu up pi il l d de et te ec ct ti io on n a ad dj ju us st tm me
en nt ts s
2
2. .6 6 C Ca al li ib br ra at ti io on n
2
2. .7 7 M Me ea as su ur re em me en nt t a an nd d r re ec co or rd di in ng
g ( (d da at ta a s st to or ra ag ge e) )
2
2. .8 8 P Pl la ay yb ba ac ck k
2
2. .9 9 P Pa ar ra am me et te er rs s s se et tt
ti in ng gs s/ /c ch ha an ng ge es s
3. Specifications

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 3
1
1. . S Sy ys st te em m C Co on nf fi ig gu ur ra at ti io on ns s
1.1. Standard Configuration
Head Unit
Cap-Type / Glasses-Type (see 1.2)
Controller
AC Adapter
View Lens 44deg.
SD Card 1GB AV Cable
Carrying Case for Main Unit
Manual

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
4(00175)D
1.2. Head Unit Variations
Cap-Type, Dual-Eye Detection
Glasses-Type,
Dual Eye Detection
1 x Head Unit
1 x Right Eye Detector
1 x Left Eye Detector
1 x Head Unit
1 x Right Eye Detector
1 x Left Eye Detector
Cap-Type, Right-Eye Detection
Glasses-Type,
Right-Eye Detection
1 x Head Unit
1 x Right Eye Detector 1 x Head Unit 1 x Right Eye Detector
Cap-Type, Left-Eye Detection
Glasses-Type,
Left-Eye Detection
1 x Head Unit
1 x Left Eye Detector 1 x Head Unit 1 x Left Eye Detector
View Lenses
View Lens 44deg.
(Standard)
View Lens 62deg.
(Option)
View Lens 92deg.
(Option)
View Lens 121deg.
(Option)

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 5
1.3. Optional Items
LCD Viewfinder
Battery & Charger
View Lens
44deg., 62deg., 92deg, 121deg Pointer
Serial Cable
Cue Switch Event/Reset Cable Head Unit
Extension Cable, 3m
EMR-dStation
Remote Control Software
EMR-dFactory
Eye Movement Analysis
Software
Carrying Case for
Accessories

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
6(00175)D
2
2. . B Ba as si ic c O Op pe er ra at ti io on ns s
2
2. .1 1 C Co on nn ne ec ct ti io on n
1) Turn off the power.
2) Connect the Head Unit and the Controller.
3) Connect a video monitor to an AV out of the Controller by the AV cable.
4) Insert a SD card (specified one) to a SD slot of the Controller.
5) Connect the AC adapter to the Controller. You can use a battery pack instead of theACAdapter.
6) Turn on the power. It takes about 25sec for boot up. Then a message of ”The system parameter was
loaded from SD card.” will appear about 60sec after power on. Push the key while a cursor is at
OK.
Note: Power must be OFF when connecting devices.
2) Connect the
Head Unit
3) Connect a
video monitor
4) Insert a SD card
5) Connect the AC
adapter

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 7
2
2. .2 2 C Co on nt tr ro ol ll le er r K Ke ey y F Fu un nc ct ti io on ns s
Note:
 During the recording, the recording is stopped if you push either [CAL] or [RESULT] or
[OFFSET] or [MENU] or [FILE] key.
Do not push multi keys at the same time which causes operation failure.
Battery Indicator LED
It indicates the battery amount
when pushing the Check Key. If
the battery will be running out in
5min, it indicates in red
Battery/SD Card Check Key
Push this key check the amount of
the battery and SD Card
REC LED
It turns on during
the recordin
g
.
CAL Key
It enters / exits the calibration
mode.
RESULT Key
It shows the result of calibration and
exits the result mode.
MENU Key
It enters/exits the menu mode.
UP Ke
y
LEFT Key
RESET Key
It resets the counter.
DOWN Key
SET Key
RIGHT Key
FILE Key
It enters / exits the file mode.
OFFSET Key
It enters / exits
the offset mode.
FUNCTION Key
It turns Auto Binary Image
mode
STOP Key
It stops the recording /
playback.
REC Key
It starts the recording.
SD Card Indicator LED
It indicates the SD card amount
when pushing the Check Key. If the
memory will be occupied in 5min, it
indicates in red

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
8(00175)D
2
2. .3 3 H He ea ad d U Un ni it t A Ad dj ju us st tm me en nt ts s
1. Preparations
Set the parameters regarding configuration according to system configuration. Following
shows the path of essential parameters. Push the key to enter/exit Menu mode. Go to and/or
change the parameters using UP /DOWN /LEFT /RIGHT keys. The key will not be
used for parameter settings.
1) System Type
Menu > System > System Type > CAP / GLASSES
2) Sampling Rate (in case of 120/240Hz version)
Menu > System > Sampling > NTSC 60 (60Hz) / NTSC 120 (120Hz) /NTSC 240 (240Hz)

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 9
3) View Lens
Menu > System > Lens > 44/ 62 / 92 / 121
4) Eye to be detected
Menu > User > Eye > L / R / RL
2. Head Unit Adjustments in case of the Cap-Type
1) Push the key to enter Menu
mode. In Menu mode, a LED of eye
detector is off, and a subject can
wear the Head Unit safely.
Or just close eyes when wearing the
Head Unit for eye protection
(Recommended!).

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
10 (00175)D
2) Wear the Head Unit as shown in the following pictures.
3) Push the key to get back
the view image.
4) Adjust the view camera position so that an
object in the view image becomes center while a
subject watches the object slightly below (about
10degree).
A

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 11
3. Head Unit Adjustments in case of the Glasses-Type
1) Push the key to enter Menu
mode. In Menu mode, a LED of eye
detector is off, and a subject can
ware the Head Unit safely.
Or just close eyes when wearing the
Head Unit for eye protection
(Recommended!).
2) Wear the Head Unit as shown in the following pictures.

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
12 (00175)D
3) Push the key to get back the
view image.
4) Adjust a view camera position so that an object
in the view image becomes center while a subject
watches the object slightly below (about
10degree).
A

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 13
2
2. .4 4 E Ey ye e P Po os si it ti io on n A Ad dj ju us st tm me en nt ts s
1) Display an eye image on the
monitor. You can change the monitor
image by pushing the LEFT or
RIGHT keys.
Ex. View image > Right Eye > Left
Eye > Quad image > View
2) Verify if an eye is displayed within
a frame and in focus.
For horizontal adjsutment
3) If the eye is out of frame or out of focus, adjust
the eye detector as shown in pictures left.
For vertical adjsutment
For focus adjsutment

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
14 (00175)D
2
2. .5 5 P Pu up pi il l D De et te ec ct ti io on n A Ad dj ju us st tm me en nt ts s
1. Auto Binary Image Adjustment for Pupil Detection
It allows you to adjust the binary image level of Pupil and Purukinje automatically. If you
set “AUTO”, the binary image adjustment automatically starts when you enter the calibration
mode.
1) In order to set auto binary image adjustment, enter Menu and go to:
Menu > User > Pupil THR:
・AUTO ：Binary image adjustment automatically starts when you enter the
calibration mode, then goes back to the calibration mode upon
completion of the auto binary image adjustment.
・MANUAL (default)：Binary image adjustment is performed manually.
2) When the auto binary image adjustment is completed, a message of “finish” is displayed. If the
auto binary image adjustment is failed, a message of “failure” is displayed. In the later case,
adjust the binary image level of Pupil and Purukinje manually as per 2.5.2.
Note: When you push the FUNCTION key in eye mark mode, the binary image adjustment
automatically start regardless of above Pupil THR setting.

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 15
2. Manual Binary Image Adjustment for Pupil Detection
1) Enter Menu and go to:
Menu > Video > S-Impose > Pupil &
Purkinje.
Turn ON the Purkinje by pushing the
UP or DOWN keys.
Note: The key will not be used
for parameter settings.
2) Display an eye image to be adjusted on the
monitor. You can change the monitor image by
pushing the LEFT or RIGHT keys.
3) Push the key to show a
binary image.
Adjust the binary image level by
pushing the UP or DOWN
keys so that Pupil and Purkinje
images are displayed clearly
meantime reduce level of binary
image of other parts, such as
eyelashes, an eyelid and skin, as
much as possible.
P
up
il
Purkin
j
e

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
16 (00175)D
【NG】Too weak 【NG】Too weak 【NG】Weak
【OK】Fine though bit weak
and a pupil diameter may be
measured bit smaller than
actual
【OK】Fine 【OK】Acceptable though bit
strong
【OK】Acceptable though bit
strong
【NG】Strong
【NG】Too strong
4) Adjust the binary image level by pushing the UP or DOWN keys so that cross
lines appear on Pupil image. Make the subject see upper right, upper left, lower right
and lower left and verify the Pupil and Purkinje images are detected properly.
Upper Right Upper Left Lower Right Lower Left

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 17
5) Push key to go back to
the normal image from the
binary image.
6) Display the view image on the
monitor. You can change the
monitor image by pushing the
LEFT or RIGHT keys.
Ex. View image > Right Eye >
Left Eye > Quad image >
View image
Note:
 To show the cross lines, go to Menu > System > Algorism.
¾When you select “STD” or “PUPIL”, the cross lines of both Pupil and Purukinje
appear on display.
¾When you select PURUKINJE”, only the cross lines of Purukinje appear on
display.
2
2. .6 6 C Ca al li ib br ra at ti io on n
1. Calibration
1) Push the CAL key to go
calibration mode. Nine CAL marks
appear on display (in standard
calibration mode).
CAL mark

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
18 (00175)D
2) Point out a position where the CAL mark
appears on the view image using a laser pointer
or a something stick, such as a pen.
Tips:
9It is easier to calibrate on a wall or a fixed
plane.
9If a laser point may not be visible on the
display, use the stick to point out the CAL
mark.
3) When the subject see the pointed
CAL mark (calibration target point),
push the CUE key (or the Cue
switch). Then the calibration target
point moves to next CAL mark.
4) Repeat seeing the pointed CAL mark and
pushing the CUE key until end of calibration
(9 calibration points).
Upon completion of the calibration, an eye mark
appears on the view image.
Remarks:
If the subject fails to see the CAL mark, push the
FUNCTION key to go back the previous
CAL mark.
If the CAL mark doesn’t move even push the
CUE key, the Pupil and Purkinje images
may not be detected properly. Please cancel the
calibration mode (push the CAL key again)
and readjust binary image level as per 2.5).

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
(00175)D 19
2. Calibration Result Check
In case of the 9-point calibration, you can check if the calibration is OK or NG, as
follows. If the lines are on all of 9 CAL marks, the calibration went well. On the other hand, if
the lines are not on or are away from one/some of 9 CAL marks, the calibration was NG.
OK ＮＧ
1) Push the Result Key. The 9 CAL marks and lines appear to
show the result of calibration.
2) You can switch the calibration result of the left eye and the right eye
by pushing the LEFT or RIGHT keys.
3) Push the Result Key again to go back the view image (eye
mark mode).

EMR-9 Quick Start Guide
__________________________________________________________________________________________________________________________
20 (00175)D
2
2. .7 7 M Me ea as su ur re em me en nt t a an nd d R Re ec co or rd di in ng g ( (D Da at ta a S St to or ra ag ge e) )
1. Eye Mark Mode
Immediately after the calibration, the eye mark (the gazing point of the subject) appears on
the view image. This state is called as Eye Mark mode (but the data recording is not made in this
mode). In the Eye Mark mode, you can display eye marks (a left, a right and/or a compensated
eye mark(s)), trajectory of eye mark, real time fixation points.
2. Recording
Then (in the Eye Mark Mode), push the REC Key to start the recording. The data is
recorded on the SD card.
Note:
You can record the eye marks which are superimposed on the view image. However, there
is a time rag up to 3/29.97sec between the eye marks and the view image.
You cannot record the trajectory of the eye marks and the fixation points superimposed on
the view image to the SD card. But you can display those on view image using optional
EMR-dFactory software.
1) Scene Number Setting
You can change the scene
number by the UP or DOWN
keys.
2) Recording
Push the REC key to start the recording. The data is recorded
on the SD card.
During the recording, an access lamp of SD indicator LED flashes.
During the recording, the trajectory or fixation points are not
displayed.
Remarks: During the recording, the recording is stopped if you push
either [CAL] or [RESULT] or [OFFSET] or [MENU] or [FILE] key.
