Nagman MTC Series User manual

UNIVERSAL DRY BLOCK
HIGH TEMPERATURE CALIBRATOR
MTC 1200

NAG/IM/MTC1200/01/22 2
BRIEF PROFILE
An ISO 9001-2015 certified Instrumentation company
(since 1972) serving Industries in India & Worldwide thro’ the
Manufacture & Supply of World-Class Calibration
Instruments & Systems like Temperature, Pressure & Signal
Calibrators, Black Body Calibration Sources, Pneumatic &
Hydraulic Hand Pumps, Dead Weight & Comparison Testers,
Calibration Test Benches, etc.

NAG/IM/MTC1200/01/22 3
Dear User,
Thank you for selecting Nagman’s Universal
Dry Block High Temperature Calibrator and
becoming a proud owner of this Calibration
Instrument.
We have strived hard to ensure the accuracy
of the contents of this manual. We would
appreciate any suggestions/feedback to
correct any errors noticed and to improve
the quality of contents of this Manual
Specifications are subject to change owing to
continuous development and we reserve
rights to effect Changes / Modifications to
this Manual.
Read the Instructions before starting to use
the Product.
Wishing you for a long association with us.
For any service related issues, please contact
VERSION CONTROL
Version No. Updated on Updated by
V 1.1 01.09.2022 Nagman

NAG/IM/MTC1200/01/22 4
CONTENTS
S.No. Description Page No.
1. Introduction …………………………………………………………..5
2. Specification…………………………………………………………….6
3. Standard Delivery & Optional Accessories ……………9
4. Parts Identification with Picture ……………………………10
5. Connection Diagram ………………………………………….…17
6. Safety Instructions ………………………………………………….18
7. Operating Instruction ………………………………………….….24
8. Troubleshooting / Maintenance……………………………..28

NAG/IM/MTC1200/01/22 5
1. INTRODUCTION
Nagman’s Universal Dry Block High Temperature
Calibrator is used for calibrating RTD’s,
Thermocouples, Temperature Switches, Temperature
Indicators etc.
The front panel continuously shows the current
Thermowell block temperature. Desired temperature
is set by using keypad which gives the corresponding
set value in the display.
Proper use of the instrument will provide accurate
calibration of temperature sensors.
Heater Block
The “Block” is made up of Inconel and provides a
relatively constant and accurate temperature
environment.
A thermo well is provided that may be used for
sensors of that size or may be sleeved down with
various sized multi-hole probe sleeves.
Heaters embedded in the block assembly provide
uniform heat to the sensor. A high temperature
platinum RTD is embedded at the base of the block
assembly to sense and control the temperature of
the block.
The entire assembly is suspended in an air cooled
chamber thermally isolated from the chassis and
electronics.

NAG/IM/MTC1200/01/22 6
2. SPECIFICATION
Range 300°C to 1200°C
Resolution 1°C
Accuracy ±2°C
Stability ±0.5°C
Stabilisation Time 15 Minutes
Temperature Readout °C / °F Selectable
Well Diameter 26 mm
Immersion Depth 105 mm
Dry Block Material Inconel
Heating Time
(Ambient to max.)
60 Minutes approx.
Cooling Time (to min.) 45 Minutes approx. (with Forced Air Cooling)
Switch Test facility Provided
Thermowell Dia 8 mm
Housing / Mounting Bench-top
Power Supply 230V AC, 50 Hz
Instrument
Dimensions
(L x D x H)
160 x 365 x 450 mm
Instrument Weight
(approx.)
15 Kg.
Measurement
Capability
Thermocouples ISA Types J, K, R, S, N, B, T
RTD Pt100 IEC Std.
mA 0 to 25 mA
mV 0 to 100 / 1000 mV
Volt 0 to 10 V
Resistance 0 to 500Ω / 3.5 KΩ

NAG/IM/MTC1200/01/22 7
MEASUREMENT : RANGE, RESOLUTION & ACCURACY
Type Range Resolution Accuracy
mV (Low) 0 to 100 0.01 ±0.05% F.S.
mV (High) 0 to 1000 0.1 ±0.05% F.S.
Volts 0 to 10 0.001 ±0.05% F.S.
mA 0 to 25 0.001 ±0.05% F.S.
Ohms 0 to 500 0.01 ±0.05% F.S.
KOhms 0 to 3.5 0.0001 ±0.05% F.S.
RTD Pt100 -100 to 800 0.1 ±0.05% F.S.
Type Range Resolution Accuracy
TC Type J -100 to 1200 0.1 ±0.1% F.S.
TC Type K -60 to 1260 0.1 ±0.1% F.S.
TC Type R 150 to 1700 0.1 ±0.1% F.S.
TC Type S 170 to 1700 0.1 ±0.1% F.S.
TC Type N 0 to 1300 0.1 ±0.1% F.S.
TC Type B 920 to 1820 0.1 ±0.1% F.S.
TC Type T 0 to 400 0.1 ±0.1% F.S.

NAG/IM/MTC1200/01/22 8
ENVIRONMENTAL CONDITIONS
This instrument should not be operated in an excessively
dusty & dirty environment and explosive zones.
The instrument operates safely under the following
conditions :
Operating temperature : 23 ±2˚C
Storage Temperature : -20˚C to 40˚C.
Ambient relative humidity : 15 – 50%
Mains voltage within ±10% of nominal
Minimum vibrations in the calibration environment.

NAG/IM/MTC1200/01/22 9
3. STANDARD DELIVERY & OPTIONAL ACCESSORIES
Standard Delivery
Basic Instrument
Test Leads
Mains Cable
Insertion Tubes (to suit 1/4“ & 1/2“ probes)
Tool for Insertion Tubes
Spare Fuses
Computer Interface
“MTCCal” Calibration Software
Traceable Calibration Certificate
Instruction Manual
Carrying Case
Optional Accessories
Additional Thermowells / Insertion Tubes (to choose
from) :
Single hole standard sizes to suit 1/8”, 1/4”, 3/8”,
1/2”, 3/4” & 3, 4, 5, 6, 7, 8, 10, 12, 13, 15, 17, 19 & 21
mm probes
Multihole (Typical) : (1x6 + 1x8) or (3x6) or (1x10 +
1x4) mm
Power Supply 110V AC, 60 Hz
Calibration Certificates are issued in Accordance with
our Scope as granted by NABL per ISO/IEC
17025:2017 Standards

NAG/IM/MTC1200/01/22 10
4. PARTS IDENTIFICATION
Heater
Block
Keypad &
Display
Front Panel
PC Interface
Connector

NAG/IM/MTC1200/01/22 11
Input for
Switch Test
PC Interface
Connector
Input for
RTD, TC, mA
& Voltage Test
Power Inlet
Socket

NAG/IM/MTC1200/01/22 12
Input for Switch Test :
Switch Test Connection details are shown below :
Select menu option in keypad, press upward key, the
display shows in
1. Switch test
2. Edit date/time.
Enter Numeric key 1.
Computer Interface :
To interface with Computer USB
Switch Test
READ 50
OPEN :
CLOSE : 50

NAG/IM/MTC1200/01/22 13
Input for RTD, TC, mA and Voltage Test
RTD : The RTD Input Connection details are shown below :
2 Wire Use terminals BC for 2 wire with A, B and C, D to be short
3 Wire Use terminals A, B, C for 3 wire with C, D to be short
4 Wire Directly insert to A, B, C, D.
Thermocouple : For all TC, B for Positive (+) and C for
Negative (-)
mA

NAG/IM/MTC1200/01/22 14
Passive Loop for 2 Wire :
Transmitter with Internal Power Supply (A for
Positive (+) and B for Negative (-))
Active Loop :
Transmitter with External Power Supply (B for
Positive (+) and C for Negative (-))
Voltage
B for Positive (+) and C for Negative (-)
* Note that this connection is for potential free contact.
Power Inlet Socket :
Input Supply 230V AC/50 Hz Standard;
110V AC/60 Hz Optional

NAG/IM/MTC1200/01/22 15
Keypad & Display :
Keypad
S.No.
Description
1
NUMERIC KEYS used to
enter
values
2
LCD
(128 x 64) Graphic display
3
SELECT KEY used to select the parameter i.e.
mvL, mvH, Volts, mA, Ohms, kOhms, T/C,
and RTD
4 & 8
Upwards /
D
ownward KEYS
5
STR KEY (Store key) used to store the input
values(Max 10 values)
6
°C/°F KEY used to select the units
7
RCL KEY (Recall key)
used to recall the stored
input values using increment and
decrement.
9
PGM
KEY
used to manually add
-
Thermocouple Cj external temperature
10
ENTER KEY used to accept selected options
or entered values.
11
CE KEY (escape key) used to cancel a
selection/edit or return to previous menu.

NAG/IM/MTC1200/01/22 16
Display
The Display is divided into four separate segments.
1st line indicates the set Temperature
2nd line indicates the Read Temperature
3rd line indicates the Input value
(eg.: mVL, mVH, Volts. etc.)
4th line indicates switch status and parameters.

NAG/IM/MTC1200/01/22 17
5. CONNECTION DIAGRAM
Temperature
Sensor (UUT)
Measuring Instrument
(for UUT)
MTC 1200 - Universal Dry Block
High Temperature Calibrator

NAG/IM/MTC1200/01/22 18
6. SAFETY INSTRUCTIONS
Symbols Used
S.
No. Symbol Description
1.
Read the user manual before operating
the instrument.
2.
Warning- conditions that may pose
hazards to the user.
3. Caution-conditions that may damage the
instrument.
4.
Special Information
5.
Hot surface- areas which are at high
temperature
6.
Electric shock- condition that may pose
shock to the user.

NAG/IM/MTC1200/01/22 19
Warning- conditions that may pose hazards to the user.
Inspect the instrument for damage before
each use. Do not use the instrument if it
appears damaged or operates abnormally
Do not place the instrument under a cabinet
or other structure. Leave enough clearance
to allow for safe and easy insertion and
removal of probes
Do not slam the probe sheath into the
thermo well. It may cause a shock to the
sensor and affect the calibration.
Do not operate this instrument in an
excessively wet, oily, dusty or dirty
environment and explosive zones.
Do not leave the inserts in the instrument for
prolonged periods. It may cause damage due
to high operating temperature of the
instrument.
Do not operate near flammable materials.
Calibration Equipment should only be used
by Trained Personnel.
This instrument and the thermometer probes
are sensitive instrument that can be
damaged. Always handle those devices with
care.

NAG/IM/MTC1200/01/22 20
Caution-conditions that may damage the instrument.
Do not use this instrument for any
application other than the calibration work.
Any other use of the instrument may cause
unknown hazards to the user. Also
Completely unattended operation is not
recommended
Do not use the instrument if the Cooling fan
located at the bottom of the Instrument is
out of order
Always operate this instrument at room
temperature at 23 ± 2˚C. Allow sufficient air
circulation for the instrument by leaving at
least 6 inches (15cm) of clearance around the
instrument
Do not turn off the instrument at
temperatures higher than 100˚C. This would
create a hazardous situation. Select a set-
point less than 100˚C (preferably close to the
ambient temperature) and allow the
Instrument to cool before it turning OFF.
Component life time can be shortened by
continuous high temperature operation. Use
of this instrument at HIGH TEMPERATURES
for extended periods of time requires
caution.
Not to be used in explosive zones.
This manual suits for next models
1
Table of contents
Other Nagman Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands

Digga
Digga TORQUE LOGIC Installation, operating and troubleshooting instructions

Badger Meter
Badger Meter Hedland T303 user manual

Rohde & Schwarz
Rohde & Schwarz VOR/ILS Analyzer EVS200 user manual

BURK Technology
BURK Technology Plus-X VSWR instruction manual

SENTRON
SENTRON TITAN Operation manual

Agreto
Agreto HFM II manual

HBM
HBM K148 operating manual

General
General DCFM8906 user manual

Dwyer Instruments
Dwyer Instruments TP2-10 Specifications-installation and operating instructions

GuardTrax
GuardTrax GT2 quick start guide

Teilch
Teilch TCH PRO 203 quick start guide

Keysight Technologies
Keysight Technologies N9030A Installation note
